Front-loading
Product:
washing machine
Date:
11.1.2002
Reference:
N-Å Carlsson
ASKO Cylinda's range of washing machines was modified during the autumn of 2001. A brief
overview of the modifications which were carried out follows below.
Further information is given in the product data given below.
Replaces
New type
old type
WM33A
WM33
WM44A
WM44
WM50
NEW
WM55A
WM55
WM56
NEW
WM66A
WM66
Service manual
Overview of new/modified types of
washing machines introduced to the
market in 2001
Main differences
Programmer no longer fitted, replaced by rotary switch
and electronic control card. E2 no longer fitted,
new programs.
New panel graphic.
Programmer no longer fitted, replaced by rotary
switch and electronic control card.
E2 no longer fitted, new programs.
New panel graphic.
Electronic control with knob and 7-segment
LED display. 11 programs.
New control card. New menu logic.
New programs. Among other things, 1-24 hour delayed start.
New panel graphic. Shop program indicated on the display.
Electronic control with buttons and display.
8 programs. Shop program indicated on display.
See WM55A.
Type: WM33A WM44A
Group:
21
Page: 1(7)
Product info
A
A
B
C
D
C
Advertisement
Related Manuals for Asko WM33A
Summary of Contents for Asko WM33A
- Page 1 Reference: N-Å Carlsson Page: 1(7) ASKO Cylinda’s range of washing machines was modified during the autumn of 2001. A brief overview of the modifications which were carried out follows below. Further information is given in the product data given below.
- Page 2 • Wiring diagram, Art.no. 8064368 • Options This service information is intended as a supplement to the W600-series service manual. Example of WM33A Panel Example of WM44A Panel General Mechanically the machine is based on WM33/44 (W600/W620), except for the panel and control unit.
- Page 3 Handling 1. Sort the washing. 2. Turn on the main switch, , open the washer door, and load the textiles. 3. Putting in the detergent and conditioner. 4. Select program with the program selector knob. 5. Set the desired temperature with the temperature knob and press the appropriate option buttons. 6.
- Page 4 Available programs, 5 rinses Programme information Programme content Other Heavy wash C,30-95 1100 Normal wash C,30-95 1100 Light wash C,30-95 1100 Shorter main wash than for Normal wash. Synthetic wash C,30-95 Quick wash C,30-95 1100 Super quick wash C,30-95 1100 Wool wash (C) C,30-40 Hand wash (C)
-
Page 5: Consumption Values
Consumption values WM 33A/ 44A The following conditions apply for the consumption values indicated below: Temperature of incoming water: 15ºC. Element power: 2000 W. Options: None PROGRAM MATERIAL/WASHING LOAD WATER CONSUMP- POWER CONSUMP- PROGRAM TIME TION (approx. litre) TION (approx. kWh) (approx. minutes) TEMPERATURE(1) Heavy wash Cotton, linen, 60°C... - Page 6 Loops on control card for WM33A/WM44A Control unit Art.no. 8064361 Loops and their function. J1 J2 J3 J4 J5 Loops J1 J2 J3 3 Rinses 5 Rinses WM 33A 1000 rpm WM 33A 1100 rpm WM 33A 1200 rpm WM 44A 1200 rpm...
-
Page 7: Drain Pump
Components and measured values WASHING MACHINE MOTOR WM 33A/44A (FHP) DRAIN PUMP 50 Hz 80 637 32 (50 Hz) Art.no. Art.no. 80 616 96 Resistances: N.B. Ordered under art.no. 88 011 66. Pins 2-3 Stator 1,41W Resistance: 144 Ω Pins 1-3 Stator 0,57Ω... - Page 8 DOOR LOCK Art.no. 80 616 64 Art.no. 80 616 79 122 Ω ASKO Level sensor type 1166. Resistance: Voltage: Current: ca 2 A 0,5 V output from the sensor at pressure 0 and The door lock is mechanical and is controlled 0-level is reached during pumping out.
