Summary of Contents for Sure Electronics 2004 LCD SMARTIE ASSET
- Page 1 20x4 LCD Smartie Asset User’s Guide © 2004-2011 Sure Electronics Inc. DE-LP14111_Ver1.1...
-
Page 2: Table Of Contents
1.2.4 Select Sure-LCD V1.0 As Your Application ............5 1.2.5 How to Use Tips Function..................7 Chapter 2. Tips for Usage....................11 Chapter 3. Mechanical Drawing..................12 Chapter 4. Appendix ......................14 Chapter 5. Contact Us .....................17 © 2004-2011 Sure Electronics Inc. DE-LP14111_Ver1.1_Page i... - Page 3 20x4 LCD Smartie Asset NOTES: ： Product Version Ver 1.0 ： Document Version Ver 1.0 © 2004-2011 Sure Electronics Inc DE-LP14111_Ver1.1_Page ii...
-
Page 4: Chapter 1. Overview
Chapter 1. Overview 1.1 Overview Thanks for using this 2004 LCD Smartie Asset by Sure Electronics. It features an easy-to-install aluminum alloy housing which makes this product shapely and durable to be used in many applications. It’s also populated with a mirror screen which blocks your eyes from seeing the inside but ensuring perfect display effect when the item is powered. -
Page 5: Quick Start
Connect LCD Smartie and computer with mini USB cable like shown in figure 1-3. LCD will display the defaulted graphs like shown in figure 1-4. FIGURE 1-3 SCHEMATIC OF CONNECTION WITH MINI USB © 2004-2011 Sure Electronics Inc DE-LP14111_Ver1.1_Page 2... -
Page 6: Run Lcd Smartie
Settings, as shown in figure 1-7. Click “OK” or “Apply” at the lower right-hand corner to enable communication. After that, the display on LCD will be consistent with what is being simulated with LCD Smartie. © 2004-2011 Sure Electronics Inc. DE-LP14111_Ver1.1_Page 3... -
Page 7: De-Lp14111_Ver1.1_Page
“$UpTims” will appear in the place where cursor flashed, as shown in figure 1-8. Click “Apply” will make the LCD display the time of your PC system, as shown in figure 1-9. FIGURE 1-8 SELECT THE CONTENTS TO BE DISPLAYED © 2004-2011 Sure Electronics Inc DE-LP14111_Ver1.1_Page 4... -
Page 8: Select Sure-Lcd V1.0 As Your Application
Figure 1-11. Select “4*20” from “LCD Size” drop-down list like shown in Figure 1-12 and a 20×4 sized simulator pops up like shown in Figure 1-13. FIGURE 1-11 A CONFIGURATION PAGE © 2004-2011 Sure Electronics Inc. DE-LP14111_Ver1.1_Page 5... - Page 9 “Select” drop-down list under “Command Group” and then click “Send” like shown in Figure 1-16. You will read from the simulator screen 20040202000 like shown in Figure1-17 FIGURE 1-16 SELECT COMMAND “ABOUT ME” © 2004-2011 Sure Electronics Inc DE-LP14111_Ver1.1_Page 6...
-
Page 10: How To Use Tips Function
3. Close the configuration page. Right-click the simulator screen and select “Exist” as shown in Figure 1-20. Tips will be displayed on LCD screen soon afterwards. FIGURE1-20 TIPS WILL BE DISPLAYED ON LCD SCREEN © 2004-2011 Sure Electronics Inc. DE-LP14111_Ver1.1_Page 7... - Page 11 3 seconds. The last screen will last for about 10 seconds. When the content of tips doesn’t exceed 4 rows, the content displayed will be automatically switched between defaulted power-on content and the tips. © 2004-2011 Sure Electronics Inc DE-LP14111_Ver1.1_Page 8...
- Page 12 Overview FIGURE 1-21 A FLOW SIMULATING THE DISPLAY OF TIPS 5. Restart LCD Smartie or Sure-LCD, tips display will end. © 2004-2011 Sure Electronics Inc. DE-LP14111_Ver1.1_Page 9...
- Page 13 20x4 LCD Smartie Asset Note: Figure 1-1- Figure1-21 are provided for reference only © 2004-2011 Sure Electronics Inc DE-LP14111_Ver1.1_Page 10...
-
Page 14: Chapter 2. Tips For Usage
Tips will not be displayed once the power is off. If you send newly-created tips to MCU, previous tips will be replaced. You may refer to help of application for use of Sure-LCD. © 2004-2011 Sure Electronics Inc. DE-LP14111_Ver1.1_Page 11... -
Page 15: Chapter 3. Mechanical Drawing
20X4 LCD SMARTIE ASSET USER’S GUIDE Chapter 3. Mechanical Drawing FIGURE 4-1 MECHANICAL DRAWING OF THE HOUSING FIGURE 4-2 MECHANICAL DRAWING OF THE LEFT PANEL © 2004-2011 Sure Electronics Inc. DE-LP14111_Ver1.1_Page 12... - Page 16 20x4 LCD Smartie Asset FIGURE 4-3 MECHANICAL DRAWING OF THE RIGHT PANEL Note: The unit is mm. © 2004-2011 Sure Electronics Inc. DE-LP14111_Ver1.1_Page 13...
-
Page 17: Chapter 4. Appendix
0~7) CR 1~CR254 Request MCU to represents contrast 0xFE,0x63 send LCD contrast values at different reading levels BKLT 1~BKLT254 Request MCU to represents backlight 0xFE,0x62 send LCD backlight brightness at different reading level © 2004-2011 Sure Electronics Inc. DE-LP14111_Ver1.1_Page 14... - Page 18 “°” is degree. d 0xFE,0x77 send temperature is C or F, indicates centigrade and Fahrenheit. The returned value of temperature ranges from 0 to 60℃ (32 to 140℉). If the value is over the range, “Temp © 2004-2011 Sure Electronics Inc. DE-LP14111_Ver1.1_Page 15...
- Page 19 0xFE,0x66 can also be used to start tips Note: Please enter start command (command in the 12 row) first after power-on, or other commands will not response to the ports. © 2004-2011 Sure Electronics Inc DE-LP14111_Ver1.1_Page 16...
-
Page 20: Chapter 5. Contact Us
Chapter 5. Contact Us Sure Electronics Co., Ltd. East zone, 3F, Building 6 Jingang Technology Innovation Center No.108 Ganjiabian Rd (ZIP: 210000) Qixia District Nanjing P.R.China Tel: +86-25-68154800-860 Fax: +86-25-68154891-832 Website: www.sure-electronics.com Email: customerservice@sure-electronics.com © 2004-2011 Sure Electronics Inc. DE-LP14111_Ver1.1_Page 17...
