E-Studio2330C/2820C/2830C/3520C/3530C/4520C, E-Studio2040C/2540C/3040C/3540C/4540C - Toshiba GD-1210 Service Manual

1.7.2 e-STUDIO2330C/2820C/2830C/3520C/3530C/4520C, e-
STUDIO2040C/2540C/3040C/3540C/4540C
Drawers
Paper feed pedestal
or
Large capacity feeder
GD-1210/1250/1270/1160/1260
SPECIFICATIONS AND OUTLINE OF SYSTEM
Reversing automatic document feeder
Fig. 1-13
Fig. 1-14
© 2006 - 2011 TOSHIBA TEC CORPORATION All rights reserved
1 - 20
11/04
Power switch
LINE2 connector
LINE connector
TEL connector
