ProAir CR43 Instruction Manual TABLE OF CONTENTS Receiving the Air Conditioner ................1 Handling and Testing the Air Conditioner ............1 Installation ......................2 System Controls....................2 Design Data, Model Drawing ................3 Cut out drawing ....................4 Components List ....................5 Wire Diagrams ....................6 Temperature Control..................8 Principles of Operation..................8...
Operate the air conditioner for five (5) to ten (10) minutes. No excessive noise or vibration should be evident during this run period. The condenser blower (ambient air), the evaporator blower (enclosure air), and the compressor should be running. Condenser air temperatures should be warmer than normal room temperatures within a few minutes. The compressor is provided with automatic reset thermal overload protection.
Page 4
ProAir CR43 6000-8500 BTU/Hr. (1758-2490 Watts) HxWxD: 43.31" (1100) x 15.75" (400) x 10.25" (260) Shipping BTU/Hr @ Amps @ BTU/Hr @ Amps @ Amb Temp Weight Model Voltage Phase Lbs/Kgs F/131 F 131 F/131 F 131 F/131 F/95 CR43-0615-XXX...
Page 5
CR43 Mounting Cutout Dimension CUT-OUT NOTES: 1. DASH LINES REPRESENT AIR CONDITIONER. 2. CUT-OUT DIMENSIONS FOR STANDARD PRODUCT ONLY. CR43 Mounting Gasket Kit DESIGN NOTES: 1. GASKET KIT INCLUDED. APPLY GASKET TO REAR OF AIR CONDITIONER BEFORE MOUNTING ON ENCLOSURE. 2.
CR43 Components List (Table A) CR43-0615-XXX CR43-0616-XXX CR43-0625-XXX CR43-0626-XXX 115 Volt 115 Volt 230 Volt 230 Volt Part Description 50/60 HZ 6000 BTU 60 HZ 6000 BTU 50 HZ 6000 BTU 60 HZ 6000 BTU Blower, Condenser 38-2019-04 38-2019-04 38-2020-04 38-2020-04 Blower, Evaporator 43-2013-01...
Page 7
Part Description Part No. Condenser Coil 43-2001-00 Filter, drier. Refrigerant 52-6028-00 Compressor See Table A Hot gas bypass valve 52-6027-00 Evaporator Coil See Table A Inlet air filter, reusable aluminum 10-1000-44 Evaporator blower See Table A Compressor thermal overload switch See Table A Capacitor, compressor See Table A...
Page 9
NOTE: For voltage, hertz, and options not shown in this manual, refer to the wiring diagram attached to the unit. CR43 Wire Diagram, Level II & III 10-1008-130 rev.14 317-257-6811 www.McLeanParts.net 317-257-1590 fax...
TEMPERATURE CONTROL The electromechanical thermostat is factory preset to 75 F/23 C. To change the temperature setting, remove the nylon plug from the back face of the unit. Use a standard screwdriver to adjust thermostat. For cooler temperatures turn clockwise, for warmer temperatures turn counterclockwise. PRINCIPLES OF OPERATION If electrical power to the air conditioner is interrupted and reapplied immediately, (within 3 to 5 seconds), the compressor may not restart due to the high back pressure of the compressor.
Do not run the air conditioner for extended periods of time with the filter removed. Particles of dust, lint, etc., can plug the fins of the condenser coil which will give the same reaction as a plugged filter. The condenser coil is not visible through the filter opening, so protect it with a filter. Continued operation under the above conditions can and will damage and shorten compressor life.
TROUBLE SHOOTING Basic Air Conditioning Trouble Shooting Check List Check manufacturer’s nameplate located on the unit for correct power supply. Turn the power to the unit on. The evaporator (Enclosure or “COLD” air) blower should come on. Is there airflow? YES, proceed to step # 3.
Page 13
Symptoms and Possible Causes: SYMPTOM POSSIBLE CAUSE Unit won’t cool * Blowers not running * Compressor not running * Compressor runs, but has bad valves * Loss of refrigerant Compressor tries to start but won’t run * Low line voltage at start. Should be +/-10% rated voltage * Compressor motor stuck * Bad relay * Bad overload switch...
Page 14
