ProLinx 6201-WA-DFNT to DFNT Setup Manual

High speed wireless ethernet/ip gateway
Hide thumbs Also See for 6201-WA-DFNT to DFNT:
Table of Contents

Advertisement

Quick Links

Download this manual
6201-WA-DFNT to DFNT
ProLinx Wireless
High Speed Wireless EtherNet/IP Gateway
Setup Guide
August 12, 2008

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6201-WA-DFNT to DFNT and is the answer not in the manual?

Questions and answers

Related Manuals for ProLinx 6201-WA-DFNT to DFNT

Summary of Contents for ProLinx 6201-WA-DFNT to DFNT

  • Page 1 6201-WA-DFNT to DFNT ProLinx Wireless High Speed Wireless EtherNet/IP Gateway Setup Guide August 12, 2008...

  • Page 2: For Class I, Div

    Please Read This Notice Successful application of this module requires a reasonable working knowledge of the ProLinx Module, its connected devices, and the application in which the combination is to be used. For this reason, it is important that those responsible for implementation satisfy themselves that the combination will meet the needs of the application without exposing personnel or equipment to unsafe or inappropriate working conditions.

  • Page 3: Table Of Contents

    Contents 6201-WA-DFNT ♦ ProLinx Wireless High Speed Wireless EtherNet/IP Gateway Contents Please Read This Notice Important Installation Instructions ....................... 2 Your Feedback Please........................2 Introduction Before You Begin ...................... 5 Using the Sample ProSoft Configuration Builder Files ..........6 About Transmission Casts ..................7 Load the Required Software Install ProSoft Configuration Builder (PCB) ..............
  • Page 4 Contents 6201-WA-DFNT ♦ ProLinx Wireless High Speed Wireless EtherNet/IP Gateway Page 4 of 45 ProSoft Technology, Inc. August 12, 2008...

  • Page 5: Introduction

    Driver Manuals, on your ProSoft Solutions CD-ROM: DFNT Driver Manual PWP Driver Manual For general information on installing and configuring ProLinx modules, please refer to the ProLinx Reference Guide, also on your ProSoft Solutions CD-ROM. Before You Begin The insert included with your modules describes a sample SINGLE-REMOTE SITE SAMPLE application.

  • Page 6: Using The Sample Prosoft Configuration Builder Files

    Two PLCs are located far enough from each other that a wired connection would be impractical The application uses two ProLinx 6201-WA-DFNT modules to establish communication between the two PLCs The module's radio communication parameters are preset and configured to...

  • Page 7: About Transmission Casts

    Introduction 6201-WA-DFNT ♦ ProLinx Wireless High Speed Wireless EtherNet/IP Gateway About Transmission Casts The sample uses a UNICAST transmission type. UNICAST means that you set up Produce and Consume Commands that transfer or receive data between two individual modules. For example, a Produce command can specify that this data is only produced to one particular consuming module based on the consuming modules IP address.
  • Page 8 6201-WA-DFNT ♦ ProLinx Wireless Introduction High Speed Wireless EtherNet/IP Gateway Page 8 of 45 ProSoft Technology, Inc. August 12, 2008...

  • Page 9: Load The Required Software

    Copy the Sample Application File............10 There is one application (ProSoft Configuration Builder) and one file (PPF) that you must download from the ProLinx Solutions CD to your PC or Laptop whether you are using the sample configuration or are modifying the configuration to suit the needs of your application.

  • Page 10: Copy The Sample Application File

    Copy the Sample Application File From the ProLinx Solutions splash screen, click Product Documentation. Choose Samples → Wireless. Copy the PROLINX WIRELESS SAMPLE.PPF file to a location on your PC or Laptop. Page 10 of 45 ProSoft Technology, Inc. August 12, 2008...

  • Page 11: Configure The 6201-Wa-Dfnt 150 Module

    PROLINX WIRELESS SAMPLE.PPF. Start PCB. Select File → Open. Navigate to the location where you copied the PROLINX WIRELESS SAMPLE.PPF file and select this file. Expand the EtherNetIP to EtherNetIP folder. Expand the 6201-WA-DFNT_150 module selection.

  • Page 12: Complete The Prosoft Configuration Builder Sections

    Please refer to Default Module Configuration Assignments (page 35) for a list of pre-assigned ProSoft product IP addresses. The PWP Driver Manual located on the ProLinx Solutions CD contains a description of the remaining parameters. If you are making changes, be sure to save your changes before moving on to the next step.
  • Page 13 Configure the 6201-WA-DFNT 150 Module 6201-WA-DFNT ♦ ProLinx Wireless High Speed Wireless EtherNet/IP Gateway 3.1.2 Radio Configuration (Client_150) Expand the Wireless Configuration section and double-click on the icon. The default Signal LED 1 through 4 parameter values are fixed and cannot be modified.
  • Page 14 6201-WA-DFNT ♦ ProLinx Wireless Configure the 6201-WA-DFNT 150 Module High Speed Wireless EtherNet/IP Gateway Transmit Rate This parameter defines the data rate(s) for transmission of directed messages. Possible values are outlined in the following table. Value Definition Fixed 1 Mbit (1) Fixed 2 Mbit (2) Auto fallback high (11, 5.5, 2, 1)
  • Page 15 As you select each parameter, the help window on the screen displays information to help you make your selections. The PWP Driver Manual located on the ProLinx Solutions CD describes each parameter in detail.
  • Page 16 6201-WA-DFNT ♦ ProLinx Wireless Configure the 6201-WA-DFNT 150 Module High Speed Wireless EtherNet/IP Gateway Producer Command Narrative for the First Command: The first Produce command (on line 3) is as follows. Send data using Unicast Mode Send the data to IP Address 172.16.10.151.
  • Page 17 Configure the 6201-WA-DFNT 150 Module 6201-WA-DFNT ♦ ProLinx Wireless High Speed Wireless EtherNet/IP Gateway The corresponding Consume command on the DFNT Client 151 looks like this: This command states: Receive 600 words of data with each exchange ID = 1002 from IP: 172.16.10.150 and place them in 600 registers beginning at database register...
  • Page 18 Define each element of the command by selecting the element, then select or enter the desired values. Click OK when done. Note: In addition to the help on the dialog, the PWP Driver Manual located on the ProLinx Solutions CD provides descriptions of each parameter. Produce and Consume Commands Both the DFNT Client 150 and the DFNT Client 151 have corresponding Produce and Consume commands.
  • Page 19 This section does not contain any data for the sample application. The sample application uses UNICAST transmission and therefore there is no need to enter IPs of other devices in this section. The ProLinx PWP Driver Manual describes this section in detail.
  • Page 20 6201-WA-DFNT ♦ ProLinx Wireless Configure the 6201-WA-DFNT 150 Module High Speed Wireless EtherNet/IP Gateway 3.1.7 DFNT Client 0 Commands Double-click on the icon. Note: For command lines 1 and 2 to function properly with the ControlLogix processor, the menu item "Logic/Map PLC/SLC Messages ..." in the RSLogix 5000 application, must have the "File Number"...
  • Page 21 Double-click on the icon. This section does not require any editing for the sample application. Refer to the DFNT Driver Manual located on the ProLinx Solutions CD for information on setting up data mapping for your application. Double-click on the icon.

  • Page 22: Save And Download The Configuration File To The 6201-Wa-Dfnt Client 150

    6201-WA-DFNT ♦ ProLinx Wireless Configure the 6201-WA-DFNT 150 Module High Speed Wireless EtherNet/IP Gateway Save and Download the Configuration File to the 6201-WA-DFNT Client 150 Ensure that your PC or Laptop is still connected to the DEBUG port of the 6201-WA-DFNT Client 150 module.

  • Page 23: Configure The Dfnt Client 151 Module

    Configure the DFNT Client 151 Module 6201-WA-DFNT ♦ ProLinx Wireless High Speed Wireless EtherNet/IP Gateway Configure the DFNT Client 151 Module In This Chapter Complete the ProSoft Configuration Builder Sections ......23 Save and Download the Configuration File to the 6201-WA-DFNT Client 151 ......................
  • Page 24 Note: All modules must have the same Subnet Mask, Default Gateway, and Network Name (SSID) if they are all located on the same network. The PWP Driver Manual located on the ProLinx Solutions CD describes each parameter. If you are making changes, be sure to save your changes before moving on to the next step.
  • Page 25 Configure the DFNT Client 151 Module 6201-WA-DFNT ♦ ProLinx Wireless High Speed Wireless EtherNet/IP Gateway Transmit Rate This parameter defines the data rate(s) for transmission of directed messages. Possible values are outlined in the following table. Value Definition Fixed 1 Mbit (1) Fixed 2 Mbit (2) Auto fallback high (11, 5.5, 2, 1)
  • Page 26 As you select each parameter, the help window on the screen displays information to help you make your selections. The PWP Driver Manual located on the ProLinx Solutions CD describes each parameter in detail.
  • Page 27 Configure the DFNT Client 151 Module 6201-WA-DFNT ♦ ProLinx Wireless High Speed Wireless EtherNet/IP Gateway The first Produce command (on line 1) is as follows. Send data using Unicast Mode Send the data to IP Address 172.16.10.150. Send 600 registers beginning at DB Register 0.
  • Page 28 6201-WA-DFNT ♦ ProLinx Wireless Configure the DFNT Client 151 Module High Speed Wireless EtherNet/IP Gateway This command states: Receive 600 words of data with each exchange ID = 1002 from IP: 172.16.10.150 and place them in 600 registers beginning at database register 1200.
  • Page 29 This section does not contain any data for the sample application. The sample application uses UNICAST transmission and therefore there is no need to enter IPs of other devices in this section. The ProLinx PWP Driver Manual describes this section in detail.
  • Page 30 6201-WA-DFNT ♦ ProLinx Wireless Configure the DFNT Client 151 Module High Speed Wireless EtherNet/IP Gateway 4.1.7 DFNT Client 0 Commands Double-click on the icon. Note: For command lines 1 and 2 to function properly with the ControlLogix processor, the menu item "Logic/Map PLC/SLC Messages ..."...

  • Page 31: Save And Download The Configuration File To The 6201-Wa-Dfnt Client 151

    Configure the DFNT Client 151 Module 6201-WA-DFNT ♦ ProLinx Wireless High Speed Wireless EtherNet/IP Gateway Save and Download the Configuration File to the 6201-WA-DFNT Client 151 Connect your PC or Laptop to the DEBUG port of the 6201-WA-DFNT Client 151 module. Apply power to the module if you have not already done so.
  • Page 32 6201-WA-DFNT ♦ ProLinx Wireless Configure the DFNT Client 151 Module High Speed Wireless EtherNet/IP Gateway Select the appropriate COM port and click the Download button. The download is complete when the OK button becomes active. When the download is complete, click OK.

  • Page 33: Verify Data Exchange

    Verify Data Exchange 6201-WA-DFNT ♦ ProLinx Wireless High Speed Wireless EtherNet/IP Gateway Verify Data Exchange Run Diagnostics Using ProSoft Configuration Builder Move the connector from the Debug Port on the DFNT Client 151 module and plug it into the Debug Port of the DFNT Client 150 module. Ensure that power is applied to both modules.
  • Page 34 6201-WA-DFNT ♦ ProLinx Wireless Verify Data Exchange High Speed Wireless EtherNet/IP Gateway Press "?" to display the Diagnostic menu. Press "D" to display the Database menu. Press "3" to show database registers beginning at 3000. Press the "S" key to refresh the database values. The circled values in the example should change each time you press the "S"...

  • Page 35: Default Module Configuration Assignments

    Default Module Configuration Assignments 6201-WA-DFNT ♦ ProLinx Wireless High Speed Wireless EtherNet/IP Gateway Default Module Configuration Assignments In This Chapter IP Addresses ..................35 WATTCP Parameters................35 IP Addresses IP Address are assigned in ranges to each of the WA modules. This information is used in the Radio Ethernet Configuration section of the configuration file.
