Preparation; Installation - Capcom Naomi MARVEL VS. 2 Operator's Manual

WA.RNING:

PREPARATION

Disconnect and remove the old printed circuit board(s)
from the cabinet.
Remove or open the control panel, and disconnect and
remove the buttons and joystick(s) from the control panel.
Remove any covering from the control panel overlay, and
then remove the control panel overlay.
Determine where any new holes should go. Center punch
any needed new holes on the control panel.
Cut out the new holes using a l-3/16" hole saw.
If there is an additional Control Panel Cover, figure 1
(such as plastic or lexan) that will be utilized cut any
additional holes using the same template.
'Cover is not included in the kit.
Plug up unused holes with a wood dowel (l-1/8" diameter)
and sand any rough edges.

INSTALLATION

IARQUEE INSTALLATION
Remove the marquee plexi glass, marquee overlay, and
the cabinet graphics.
Install the new marquee and replace the plexi glass. Clear
plexi glass is included In "full" kit.
PANEL OVERLAY INSTALLATION (See
accommodate most control panel sizes. Center the
overlay on the control panel, leaving some excess
material at the edges.
1. Remove the protective backing from the overlay and
press it down on the control panel, keeping it property
aligned. Press it down firmly, smooth out any bubbles, ana
press it over the edges.
any excess from the overlay. Place the drill hole
template on top of the overlay, aligning it with the joystick
holes. Pierce through the overlay at each control panel
hole. Then, cut away overlay material covering the
joystick and button hoies.
off the overiay.
Remove the template and clean
align over the control panel holes, and press in place on'
the overlay (refer to the drill hole template for proper
placement). Using a knife, trim material from the center
hole of the joystick decal.
14. Install the control panel cover, figure.1.
Figure 1: Overlay Installation
CABINET DECAL INSTALLATION
15. Remove monitor glass and install monitor card
on both the top and bottom of the monitor card. (See
Figure 2). Also, apply the cabinet decals to both sides of
the cabinet
INSTRUCTION
Figure 2: Cabinet Decal Installation
(If required).
