Assembling the front and surround speakers

Assembled speakers: With stand:
Without stand:
With stand
Before assembling—
• Prepare a Philips screwdriver (not supplied).
• Take care not to drop any component part while assembling; otherwise, it may cause damage to the floor or injury.
• Each speaker cord has its name tag attached to one end. Attach the end without the name tag to the speaker terminal.
1
6
Speaker
Stand
5
Press
Red
Black
Black striped
1 6
Refer to Steps to
1 5
Refer to Steps to
or
Without stand
SP-XF30S
Speaker cord
White
Black
Screw
(M5 x 25 mm)
Insert Release
Copper
Speaker
cord
With stand
2
Base plate
(Rear side)
3
Stand
(or speaker
directly)
Base plate
4
– 3 –
or
Without stand
SP-XF30F
Route the cord
Speaker cord
Screw
(M5 x 25 mm)
Continue on the next page
