ProStar M540V User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M540V and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ProStar M540V

Summary of Contents for ProStar M540V

  • Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Infor- mation contained herein is for reference only and does not constitute a commitment on the part of the man- ufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.

  • Page 4: Fcc Statement

    Preface FCC Statement (Federal Communications Commission) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 5: Important Safety Instructions

    Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 6: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be dam- aged.
  • Page 7 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.

  • Page 8: Power Safety

    Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a Power Safety steady, uninterrupted power supply. If you are unsure of your local power specifi- Warning cations, consult your service representative or local power company.

  • Page 9: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the com- puter. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way.

  • Page 10: Cleaning

    Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.

  • Page 11: Travel Considerations

    Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
  • Page 12 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshoot- ing, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
  • Page 13 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
  • Page 14 Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly.

  • Page 15: Table Of Contents

    Preface Contents Notice ................I Hot-Key Buttons & Keyboard ....... 1-10 FCC Statement ............II Function Keys ............1-11 Instructions for Care and Operation ..... IV System Map: Front & Rear Views ......1-12 Power Safety ............VI System Map: Left View ......... 1-13 Battery Precautions ..........VII System Map: Right View ........
  • Page 16 Preface Application Hot-Key ..........2-10 Recharging the Battery with the AC/DC Adapter 3-10 TouchPad and Buttons/Mouse .......2-11 Proper handling of the Battery Pack ....3-11 Configuring the TouchPad and Buttons ....2-11 Battery FAQ ............3-12 Audio Features ............2-12 Drivers & Utilities Adding a Printer .............2-13 USB Printer ............2-13 What to Install ............
  • Page 17 Preface Wireless LAN (WinXP) ........4-11 Intel On-Screen Branding Logo (Advanced Menu) 5-9 Bluetooth (WinXP) ..........4-11 APIC interrupt routing: (Advanced Menu) .... 5-10 PC Camera (WinXP) ...........4-11 PS/2 Mouse (Advanced Menu) ......5-10 Port Replicator (WinXP) ........4-11 Local Bus IDE adapter: (Advanced Menu) ... 5-10 OnChip USB /Audio /Modem /LAN Device: BIOS Utilities (Advanced Menu) ..........
  • Page 18 Preface Modules & Options Boot Password ............8-10 Audio & CD Device ..........8-11 Overview ..............7-1 Keyboard ..............8-12 Mini-PCI WLAN Module ........7-2 Operation ............... 8-13 MSI 6833 WLAN Driver Installation ....7-3 Modules ..............8-14 Bluetooth Module .............7-6 Bluetooth Driver Installation ........7-6 Interface (Ports &...
  • Page 19 Preface Serial Port ..............A-4 Keyboard & Pointing Device ........C-3 RJ-45 LAN Jack ............A-4 PCMCIA ..............C-3 USB 2.0/1.1 Ports ............A-5 Interface ..............C-4 Card Reader .............C-4 Video Driver Controls Communication ............C-4 Power Management ..........C-4 VIA Video Driver Installation ......... B-1 Power ...............C-5 Advanced Video Controls ........
  • Page 20 Preface XVIII...

  • Page 21: Quick Start Guide

    Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...

  • Page 22: Model Differences

    Quick Start Guide Model Differences This notebook series includes two different model types. The models differ slightly in design style including the LCD type, and the location of the card reader. See Figure 1 - 1 below and Table 1 - 1, on page 1 - 3 for an outline of the model differences.
  • Page 23 Quick Start Guide Feature Model A Model B 15.0” XGA (1024 * 768) TFT LCD Type 14.0” WXGA (1280 * 768) TFT 15.0” SXGA+ (1400 * 1050) TFT 4-in-1 Card Reader Location Left Side Front Hot-Key and Power Buttons Table 1 - 1 - Model Differences Overview 1 - 3...

  • Page 24: Advanced Users

    Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...

  • Page 25: Not Included

    Quick Start Guide Not Included Operating Systems (e.g. Windows XP) and applications (e.g. word processing, spreadsheet and database pro- grams) have their own manuals, so please consult the appropriate manuals. System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find this manual refers to the Microsoft Win- dows XP (Home &...

  • Page 26: System Startup

    Quick Start Guide System Startup Remove all packing materials. Place the computer on a stable surface. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. Attach the AC/DC adapter to the DC-In jack on the right of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter (Note: If you have included the Port Replicator in your purchase option see page 14).

  • Page 27: System Map: Model A - Top View With Lcd Panel Open

    Quick Start Guide System Map: Model A - Top View with LCD Panel Open Optional Built-In PC Camera Wireless Device LED Status Indicators Operation Aboard Hot-Key Buttons Aircraft Power Button Keyboard The use of any portable Built-In Microphone electronic transmission devices aboard aircraft is TouchPad and Buttons usually prohibited.

  • Page 28: System Map: Model B - Top View With Lcd Panel Open

    Quick Start Guide System Map: Model B - Top View with LCD Panel Open Optional Built-In PC Camera Wireless Device Speaker Operation Aboard LED Status Indicators Aircraft Hot-Key Buttons Power Button The use of any portable Keyboard electronic transmission TouchPad and Buttons devices aboard aircraft is usually prohibited.

  • Page 29: Led Indicators

    Quick Start Guide LED Indicators Table 1 - 3 - LED Power & Communication Indicators The two sets of LED indicators (LED Status Indica- Icon Color Description tors and LED Power & Communication Indicators) Green The Computer is On on the computer display helpful information about the Blinking The Computer is in Standby current status of the computer.

  • Page 30: Hot-Key Buttons & Keyboard

    Quick Start Guide Hot-Key Buttons & Keyboard The keyboard has an embedded numerical keypad for easy numeric data input, and features Function Keys to These buttons give instant access to the default Inter- allow you to change operational features instantly (see net browser and e-mail program, and to a user-defined Figure 1 - application, with one quick button press.
  • Page 31 Quick Start Guide Function Keys To use the function keys, press and hold the Fn key, then press the appropriate function key (F3 - F12 etc.). Function Function Function Key Fn + F9 Increase LCD Brightness Fn + F3 Mute Toggle Fn + F10 PC Camera Power Toggle Fn + F4...

  • Page 32: System Map: Front & Rear Views

    Quick Start Guide System Map: Front & Rear Views Figure 1 - 6 Model A Front & Rear Views LED Power & Communication Indicators Model B LCD Latch (Model A Only) 4-in-1 Card Reader (Model B Only) External Monitor Port RJ-11 Phone Jack Security Lock Slot Battery...

  • Page 33: System Map: Left View

    Quick Start Guide System Map: Left View Figure 1 - 7 Model A Left View RJ-45 LAN Jack Vent/Fan Intake 2 * USB 2.0 Ports S/PDIF-Out Jack Model B Line-In Jack PC Card Slot (see page 4-in-1 Card Reader (Model A Only) 4-in-1 Card Reader The card reader allows you to use the most popular digital storage card formats: MMC (MultiMedia Card) / SD (Secure Digital) / MS (Memory Stick) / MS Pro (Memory Stick Pro)

  • Page 34: System Map: Right View

    Quick Start Guide System Map: Right View Figure 1 - 8 - Right View Headphone-Out Jack Microphone-In Jack USB 2.0 Port Optical Device Drive Bay (for CD/ DVD Device - see page DC-In Jack Changing DVD Regional Codes Go to the Control Panel and double-click System > Hardware (tab), click Device Manager, then click the + next to DVD/CD-ROM drives.

  • Page 35: System Map: Bottom View

    Quick Start Guide System Map: Bottom View Figure 1 - 9 - Bottom View Model A Vent/Fan Intake Battery Memory (RAM)/WLAN Module/CPU Cover The CPU is not a user ser- Hard Disk Cover viceable part. Opening this Speakers (Model A Only) compartment, or access- ing the CPU in any way, may violate your warranty.

  • Page 36: Windows Xp Start Menu & Control Panel

    Quick Start Guide Windows XP Start Menu & Control Panel Most of the control panels, utilities and programs within Windows XP (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.

  • Page 37: Video Features

    Quick Start Guide Video Features You can switch display devices, and configure display options, from the Display Properties control panel in Windows as long as the video driver is installed. For further video information see “Advanced Controls” on page 3 - Click Start, point to Settings and click Control Panel (or click Control Panel).

  • Page 38: Display Devices & Options

    Quick Start Guide Display Devices & Options Besides the built-in LCD, you can also use an external VGA monitor (CRT)/external Flat Panel Display as your display device if connected to the external monitor port. The following display modes are available (see “Video Driver Controls”...

  • Page 39: Power Management Features

    Quick Start Guide Power Management Features The Power Options control panel icon in Windows (see page 16) allows you to configure power management features for your computer. You may conserve power through individual components such as the monitor or hard disk (by means of Power Schemes), or you may use either Standby or Hibernate mode to conserve power throughout the system (enable Hibernate support from the control panel as pictured in Figure 1 -...
  • Page 40 Quick Start Guide 1 - 20...

  • Page 41: Features & Components

    Features & Components Chapter 2: Features & Components Overview Read this chapter to learn more about the following main features and compo- nents of the computer: • Hard Disk Drive • Optical (CD/DVD) Device • 4-in-1 Card Reader • PC Card Slot •...

  • Page 42: Hard Disk Drive

    Features & Components Hard Disk Drive The hard disk drive is used to store your data in the computer. The hard disk Power Safety can be taken out to accommodate other 2.5" parallel (PATA) hard disk drives with a height of 9.5 mm. Before attempting to access any of the inter- The hard disk is accessible from the bottom of your computer as seen below.

  • Page 43: Optical (Cd/Dvd) Device

    Features & Components Optical (CD/DVD) Device There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The ac- Sound Volume tual device will depend on the module you purchased (see “Storage” on Adjustment page C - 3). The optical device is usually labeled “Drive D:” and may be used as a boot device if properly set in the BIOS (see “Boot Menu”...

  • Page 44: Handling Cds Or Dvds

    Features & Components Handling CDs or DVDs Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/ CD Emergency Eject DVDs can be accessed. If you need to manually Note the following: eject a CD (e.g.

  • Page 45: Dvd Regional Codes

    Features & Components DVD Regional Codes To change the DVD regional codes see “Changing DVD Regional Codes” on page 1 - DVD Regional Coding Table 2 - 1 Region Geographical Location DVD Regional Coding USA, Canada Western Europe, Japan, South Africa, Middle East &...

  • Page 46: 4-In-1 Card Reader

    Features & Components 4-in-1 Card Reader The card reader allows you to use some of the latest digital storage cards. Push Card Reader Cover the card into the slot and it will appear as a removable device, and can be ac- cessed in the same way as your hard disk (s).

  • Page 47: Pc Card Slot

    Features & Components PC Card Slot The computer is equipped with a PCMCIA 3.3V/5V slot for one type II PC- PC Card Slot Cover MCIA CardBus PC Card Slot. Make sure you install the PCMCIA/Card Read- er Card driver (see “PCMCIA/Card Reader (WinXP)”...

  • Page 48: Auto Mail Checker

    Features & Components Auto Mail Checker After you have installed the driver for the Auto Mail Checker program (see “AutoMail (WinXP)” on page 4 - 11) you may then configure it to give you notification when you receive new mail. You must be online to receive this notification (note that this program only supports the POP3 protocol), and your default mail program does not need to be open.
  • Page 49 Features & Components You may then configure the options for your mailserver, name, password, pro- gram and method(s) of notification. Note Check with your Inter- net Service Provider, network administrator or Mail Service provid- er for details on what to put on these pages.

  • Page 50: Application Hot-Key

    Features & Components Application Hot-Key The hot-key buttons give instant access to the default Internet browser and e- Application.exe mail program, and to a user-defined application, with one quick button press. To configure a program to open when the application hot-key is pressed You will need to locate the actual application...

  • Page 51: Touchpad And Buttons/Mouse

    Features & Components TouchPad and Buttons/Mouse The TouchPad is an alternative to the mouse; however, you can also add a Mouse Driver mouse to your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse. The central button may If you are using an ex- be configured to function as you require.

  • Page 52: Audio Features

    Features & Components Audio Features You can configure the audio options on your computer from the Sounds and Sound Volume Audio Devices Windows control panel (see Figure 1 - 7 on page 1 - 12). Adjustment Additional audio controls are available by double-clicking the Sound Effect How high the sound Manager icon in the taskbar/control panel.

  • Page 53: Adding A Printer

    Features & Components Adding a Printer The most commonly used peripheral is a printer. The following conventions Parallel Printer will help you to add a printer, however it is always best to refer to the printer manual for specific instructions and configuration options. After setting up the printer attach the paral- lel cable to the printer.
  • Page 54 Features & Components 2 - 14...

  • Page 55: Power Management

    Power Management Chapter 3: Power Management OS Note Overview Power management To conserve power, especially when using the battery, your computer uses the functions will vary ACPI power management system. Power management conserves power by slightly depending on controlling individual components of the computer (the monitor and hard disk your operating system.

  • Page 56: The Power Sources

    Power Management The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. Port Replicator AC/DC Adapter AC/DC Adapter You will be provided Use only the AC/DC adapter that comes with your computer. The wrong type with a 90W AC/DC of AC/DC adapter will damage the computer and its components.

  • Page 57: Turning On The Computer

    Power Management Turning on the Computer Now you are ready to begin using your computer. To turn it on simply press Shutdown the power button on the front panel. Note that you should always shut your com- When the computer is on, you can use the power button as a Standby/Hiber- puter down by choos- nate/Shutdown hot-key button when it is pressed for less than 4 seconds Turn...

  • Page 58: Power Schemes

    Power Management Power Schemes You can set your computer to conserve power through individual components Resuming by means of Power Schemes. You can also adjust the settings for each Operation scheme to set the monitor to turn off after a specified time, and the computer's The system can re- hard disk motor to turn off if the hard disk drive has not been accessed for a sume from Monitor or...
  • Page 59 Power Management Each Windows Power Scheme will also adjust the processor performance of your machine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose the Home/Office Desk scheme for maximum performance when the computer is powered from an AC power source.

  • Page 60: System Power Options

    Power Management System Power Options You can use the system power options to stop the computer’s operation and restart where you left off. This system features Standby and Hibernate sleep mode levels (Hibernate mode will need to be enabled by clicking the option in the Hibernate tab in the Power Options control panel - Figure 3 - 2 on page 3 -...

  • Page 61: Standby

    Power Management Standby Standby saves the least amount of power, but takes the shortest time to return to full operation. During Standby the hard disk is turned off, and the CPU is System Resume made to idle at its slowest speed. All open applications are retained in memo- The system can resume ry.

  • Page 62: Configuring The Power Button

    Power Management Configuring the Power Button The power button may be set to send the computer in to either Standby or Hi- bernate mode (Figure 3 - 3). In Standby mode, the LED will flash green. In Hibernate mode the LED will be off (battery) or orange (AC/DC adapter).

  • Page 63: Battery Information

    Power Management Battery Information Please follow these simple guidelines to get the best use out of your battery. Low Battery New Battery Warning Always completely discharge, then fully charge, a new battery (see “Battery When the battery is FAQ” on page 3 - 12 for instructions on how to do this).

  • Page 64: Recharging The Battery With The Ac/Dc Adapter

    Power Management Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. Conserving Battery Power We recommend that you do not remove the battery yourself. If you do need to remove the battery for any reason see “Removing the Battery”...

  • Page 65: Proper Handling Of The Battery Pack

    Power Management Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode • DO NOT connect the metal terminals (+, -) to each other Damaged Battery Warning Should you notice any physical defects (e.g.

  • Page 66: Battery Faq

    Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Caution Don’t turn off the computer by yourself even when you see a message that in- Danger of explosion if dicates the battery is critically low, just let the computer use up all of the bat- battery is incorrectly...

  • Page 67: Drivers & Utilities

    Drivers & Utilities Chapter 4: Drivers & Utilities What to Install This chapter deals with installing the drivers and utilities essential to the operation or improvement The Device Drivers & Utilities + User’s Manual of some of the computer’s subsystems. The system CD-ROM contains the drivers and utilities neces- takes advantage of some newer hardware compo- sary for the proper operation of the computer.
  • Page 68 Drivers & Utilities Navigate (Browse..) to D: You will notice that many of the instructions for driver installation require you to “Navigate (Browse) to D:”. We assume that you will install all drivers and utilities from the built-in CD device and it is assigned to “Drive D:”.

  • Page 69: Service Packs

    Drivers & Utilities Service Packs Check the warnings on the following pages regard- ing installation of the appropriate Service Pack for Windows XP Service Pack 2 your Windows OS. Make sure you have installed Make sure you install Windows XP Service Pack 2 the appropriate Service Pack before installing all (or a Windows XP version which includes Service the drivers.

  • Page 70: Authorized Driver Message

    Drivers & Utilities Authorized Driver Message Updating/Reinstalling Individual Drivers If you receive a message telling you that the driver you are installing is not authorized (Digital Signa- If you wish to update/reinstall individual drivers it ture Not Found), just click Yes or Continue Any- may be necessary to uninstall the original driver.To way to ignore the message and continue the do this go to the Control Panel in the Windows OS...

  • Page 71: Driver Installation

    Drivers & Utilities Driver Installation Check the driver installation order from Table 4 - 1 on page 4 - 6 (the drivers must be installed Insert the Device Drivers & Utilities + User’s Man- in this order) which is the same as that listed in ual CD-ROM and click Install WinXP Drivers the Drivers Installer menu below.
  • Page 72 Drivers & Utilities WinXP SP2 Driver Page # Install the appropriate Service Pack for WinXP Page 4 - 3 Chipset Page 4 - 8 Video Page 4 - 8 Audio Page 4 - 8 Page 4 - 8 Modem Page 4 - 9 TouchPad Page 4 - 9 PCMCIA/Card Reader...

  • Page 73: Driver Installation Procedure

    Drivers & Utilities Driver Installation Procedure Service Pack Installation This section covers driver and utility installation in- Make sure you install the appropriate service pack structions for Windows XP Home & Professional. for your operating system before installing any drivers (see “Windows XP Service Pack 2”...

  • Page 74: Chipset (Winxp)

    Drivers & Utilities Chipset (WinXP) Audio (WinXP) 1. Click 1.Install Chipset Driver > Yes from 1. Click 3.Install Audio Driver > Yes from the Drivers Installer menu. the Drivers Installer menu. Click Start (menu) > Run... and navigate Click Start (menu) > Run... and navigate (Browse..) to (Browse..) to D:\Drivers\Chipset\Setup.exe and click...

  • Page 75: Modem (Winxp)

    Drivers & Utilities Modem (WinXP) TouchPad (WinXP) 1. Click 5.Install Modem Driver > Yes from 1. Click 6.Install TouchPad Driver > Yes the Drivers Installer menu. from the Drivers Installer menu. Click Start (menu) > Run... and navigate Click Start (menu) > Run... and navigate (Browse...) to (Browse..) to D:\Drivers\Modem\Setup.exe and click...

  • Page 76: Pcmcia/Card Reader (Winxp)

    Drivers & Utilities PCMCIA/Card Reader (WinXP) Hot-Key (WinXP) 1. Click 7.Install PCMCIA Driver > Yes 1. Click 8.Install Hotkey Utility > Yes from from the Drivers Installer menu. the Drivers Installer menu. Click Start (menu) > Run... and navigate Click Start (menu) > Run... and navigate (Browse...) to (Browse..) to D:\Drivers\PCMCIA\Setup.exe and click...

  • Page 77: Automail (Winxp)

    Drivers & Utilities AutoMail (WinXP) Wireless LAN (WinXP) The AutoMail Driver must be installed manually as See the installation procedure in “MSI 6833 per the instructions below: WLAN Driver Installation” on page 7 - Bluetooth (WinXP) 1. Click Start (menu) > Run... and navigate (Browse..) to See install procedure in “Bluetooth Driver Instal-...
  • Page 78 Drivers & Utilities 4 - 12...

  • Page 79: Bios Utilities

    BIOS Utilities Chapter 5: BIOS Utilities BIOS Settings Overview Warning This chapter gives a brief introduction to the computer’s built-in software: Incorrect settings can cause your system to Diagnostics: The POST (Power-On Self Test) malfunction. To correct mistakes, return Setup and restore the Configuration: The Setup utility Setup Defaults with If your computer has never been set up, or you are making important changes...

  • Page 80: The Power-On Self Test (Post)

    BIOS Utilities The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds to con- POST Screen duct a POST, including a quick test of the on-board RAM (memory). 1.BIOS information As the POST proceeds, the computer will tell you if there is anything wrong. 2.CPU type If there is a problem that prevents the system from booting, it will display a 3.Memory status...

  • Page 81: Failing The Post

    BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non-fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.

  • Page 82: The Setup Program

    BIOS Utilities The Setup Program The Phoenix Setup program tells the system how to configure itself and man- age basic features and subsystems (e.g. port configuration). Entering Setup To enter Setup, turn on the computer and press F2 during the POST. The prompt (Press F2 to Enter Setup) seen in Figure 5 - 1 is usually present for a...

  • Page 83: Setup Screens

    BIOS Utilities Setup Screens The following pages contain additional advice on portions of the Setup. Setup Menus Along the top of the screen is a menu bar with five (5) menu headings. When Setup menus you select a heading, a new screen appears. Scroll through the features listed shown in this section on each screen to make changes to Setup.

  • Page 84: Main Menu

    BIOS Utilities Main Menu PhoenixBIOS Setup Utility Figure 5 - 2 Main Main Advanced Security Boot Exit Main Menu Item Specific Help System Time: [22:11:05] System Date: [05/30/2005] Legacy Diskette A: [Disabled] <Tab>, <Shift Tab>, or <Enter> selects field. IDE Channel 0 Master [30006MB] IDE Channel 0 Slave [CD-ROM]...

  • Page 85: Legacy Diskette A

    BIOS Utilities Legacy Diskette A: This control may be used to enable/disable, and to configure, any attached floppy disk drive. IDE Channel 0 Master/Slave (Main Menu) Pressing Enter opens the sub-menu to show the configuration of either a CD Device or HDD that on the computer’s IDE Channel 0. Use the “Auto” (Type:) setting to have the items configured automatically for you.

  • Page 86: Advanced Menu

    BIOS Utilities Advanced Menu Figure 5 - 3 PhoenixBIOS Setup Utility Advanced Menu Main Advanced Advanced Security Boot Exit Item Specific Help Setup Warning Setting itmes on this menu to incorrect values may cause your system to malfunction. When disabled, forces the Execute-Disable Execute-Disable Bit Capability: [Enabled]...

  • Page 87: Installed O/S: (Advanced Menu)

    BIOS Utilities Installed O/S: (Advanced Menu) This setting tells the computer what kind of operating system you’re using. Reset Configuration Data: (Advanced Menu) This item is set to “No” as default. You can change the setting to “Yes” if you have installed a new add-on which has reconfigured the system, resulting in such a serious system conflict that the operating system is unable to boot.

  • Page 88: Apic Interrupt Routing: (Advanced Menu)

    BIOS Utilities APIC interrupt routing: (Advanced Menu) Setting this menu item to “Enabled” will turn on the I/O APIC (Advanced Pe- ripheral Interrupt Controller). This is an is an Intel architecture for dealing with interrupt requests (IRQ’s) in multi-processor computer systems, and is fully supported under Windows XP.

  • Page 89: Security Menu

    BIOS Utilities Security Menu Figure 5 - 4 PhoenixBIOS Setup Utility Security Menu Main Advanced Security Security Boot Exit Item Specific Help Supervisor Password Is: Clear User Password Is: Clear Supervisor Password Set Supervisor Password [E E nter] controls access to the Set User Password [Enter] setup utility.

  • Page 90: Set User Password (Security Menu)

    BIOS Utilities Set User Password (Security Menu) You can set a password for user mode access to the Setup utility. This will not affect access to the computer OS, (only the Setup utility) unless you Password Warning choose to set a Password on Boot (see below). Many menu items in the Setup If you set a boot pass- utility cannot be modified in user mode.

  • Page 91: Boot Menu

    BIOS Utilities Boot Menu PhoenixBIOS Setup Utility Figure 5 - 5 Main Advanced Security Boot Exit Boot Menu Item Specific Help Boot priority order: USB FDC: IDE 0: TOSHIBA MK3025GAS-(PM) Keys used to view or IDE 1: configure devices: IDE 2: TSSTcorpCD/DVDW TS-L532A- Up and Down arrows select a device.
  • Page 92 BIOS Utilities When you specify a device as a boot device on the Boot Menu, it requires the availability of an operating system on that device. Most home computers come with an operating system already installed on “Drive C:”. If you wish to boot from a CD-ROM/DVD-ROM you will need to add it to the boot order.

  • Page 93: Exit Menu

    BIOS Utilities Exit Menu Figure 5 - 6 PhoenixBIOS Setup Utility Exit Menu Main Advanced Security Boot Exit Exit Item Specific Help Exit Saving Changes Exit Discarding Changes Exit System Setup and Load Setup Defaults save your changes to CMOS. Discard Changes Save Changes Help...
  • Page 94 BIOS Utilities 5 - 16...

  • Page 95: Upgrading The Computer

    Upgrading The Computer Chapter 6: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Follow the Warranty Warning steps outlined to make the desired upgrades. If you have any trouble or prob- lems you can contact your service representative for further help. Before you Please check with your begin you will need: service representative...

  • Page 96: When Not To Upgrade

    Upgrading The Computer When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replacing parts. Power Safety Warning You should not perform any of these upgrades if: Before you undertake any upgrade proce- • Your system is still under warranty or a service contract dures, make sure that you have turned off the •...

  • Page 97: Removing The Battery

    Upgrading The Computer Removing the Battery If you are confident in undertaking upgrade procedures yourself, for safety Warranty Warning reasons it is best to remove the battery. Please check with your Turn the computer off, and turn it over. service representative Slide the latch in the direction of the arrow, and hold it in place.
  • Page 98 Upgrading The Computer Lift the battery out in the direction of the arrow Figure 6 - 2 Battery Up Lift the battery out. Figure 6 - 3 Battery Out 6 - 4 Removing the Battery...

  • Page 99: Upgrading The Hard Disk Drive

    Upgrading The Computer Upgrading the Hard Disk Drive The hard disk drive can be taken out to accommodate other 2.5" parallel (PA- HDD System TA) hard disk drives with a height of 9.5mm (h) (see “Storage” on page C - Warning 3).
  • Page 100 Upgrading The Computer For Model A computers (see overleaf for Model B): Slide the hard disk and cover assembly in the direction of arrow Lift the hard disk and cover assembly up in the direction of arrow Remove the hard disk and cover assembly Remove the 4 screws to release the hard disk from the assembly cover, and reverse the process to install any new hard disk.
  • Page 101 Upgrading The Computer For Model B computers: Pull the tab to slide the hard disk and case assembly in the direction of arrow Lift the hard disk and case assembly out of the bay in the direction of arrow Remove screws to release the hard disk from the case , and...

  • Page 102: Upgrading The Optical (Cd/Dvd) Device

    Upgrading The Computer Upgrading the Optical (CD/DVD) Device Turn off the computer, and turn it over and remove the battery. Locate the memory bay cover and remove screws (Model A)/ (Model B). Remove the bay cover Use a screwdriver to carefully push out the optical device at point Reverse the process to install the new device.

  • Page 103: Upgrading The System Memory (Ram)

    Upgrading The Computer Upgrading the System Memory (RAM) The computer has one memory socket for 200 pin Small Outline Dual In-line (SO-DIMM) DDR type memory modules (see “Memory” on page C - 2 details of supported module types). The total memory size is automatically detected by the POST routine once you turn on your computer.
  • Page 104 Upgrading The Computer Remove the bay cover Figure 6 - 9 RAM Cover Removed Contact Warning Be careful not to touch Gently pull the two release latches on the sides of the memory socket in the the metal pins on the direction indicated by the arrows ( &...
  • Page 105 Upgrading The Computer The RAM module will pop-up, and you can remove it. Figure 6 - 11 RAM Removal Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory slot. The module’s pin alignment will allow it to only fit one way. Make sure the module is seated as far into the slot as it will go.

  • Page 106: Upgrading The Processor

    Upgrading The Computer Upgrading the Processor If you want to upgrade your computer by replacing the existing processor with Warranty a faster/new one you will need to contact your customer service representa- tive. We recommend that you do not do this yourself, since if it is done incor- The CPU is not a user serviceable part.

  • Page 107: Modules & Options

    Modules & Options Chapter 7: Modules & Options Wireless Device Overview Operation Aboard Aircraft This chapter contains the information on the optional modules which may come with your computer, depending on the configuration purchased. If you The use of any porta- are unsure please contact your service representative.

  • Page 108: Mini-Pci Wlan Module

    Modules & Options Mini-PCI WLAN Module If you have included an MSI 6833 (802.11g) Mini-PCI WLAN module in Wireless Device your purchase option, you will have the appropriate software CD provided for Operation Aboard your module. Aircraft The use of any portable Before installing the MSI 6833 (802.11g) Mini-PCI WLAN driver, make sure electronic transmission...

  • Page 109: Msi 6833 Wlan Driver Installation

    Modules & Options MSI 6833 WLAN Driver Installation 1. Make sure the WLAN module is powered ON. 2. Insert the Wireless LAN CD-ROM into the CD/DVD drive. 3. The program will run automatically. 4. Click Install Software (button) and click Next. 5.
  • Page 110 Modules & Options Changing the Control Setting in WinXP The operating system is the default setting for wireless LAN control in Win- dows XP. It is recommended that you switch to use the WlanUtility to control your WLAN connection. Right-click the WLAN icon in the taskbar and click Open Network Connections.
  • Page 111 Modules & Options Figure 7 - 1 Switching WLAN Controls Mini-PCI WLAN Module 7 - 5...

  • Page 112: Bluetooth Module

    Modules & Options Bluetooth Module If you have included an Bluetooth module in your purchase option, you will Wireless Device have the appropriate software CD provided for your module. Operation Aboard Aircraft Before installing the Bluetooth driver, make sure that the optional Bluetooth The use of any portable module is on (the LED will be orange).
  • Page 113 Modules & Options User Guide View the BlueSoleil User Guides from the Help Menu (or press the F1 key) in the IVT Corporation BlueSo- leil - Main Window control panel. Click BlueSoleil User Guides in the Con- tents tab, and click to select the appropriate User Guide from the panel on the right.

  • Page 114: Pc Camera Module

    Modules & Options PC Camera Module If you have included an PC Camera module in your purchase option, you will Taking Still have the appropriate software CD provided for your module. Pictures Before installing the PC Camera driver, make sure that the optional PC Cam- Double-click the My era is on.

  • Page 115: Sertek Pc Camera Driver Installation

    Modules & Options Sertek PC Camera Driver Installation 1. Press the Fn + F10 key combination to power on the PC Camera module (click Cancel if you see a “New Hardware Found” message) . 2. Insert the PC Camera CD-ROM into the CD/DVD drive. 3.

  • Page 116: Pc Camera Audio Setup

    Modules & Options PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Go to the Start menu and point to Settings (or just click Control Panel) and click Control Panel, then double-click the Sounds &...
  • Page 117 Modules & Options Figure 7 - 3 Audio Setup (Windows XP) PC Camera Module 7 - 11...

  • Page 118: Bisoncap

    Modules & Options BisonCap BisonCap is a video viewer useful for general purpose video viewing and test- ing, and can capture video files to .avi format. Pre-Allocating File Space Run the BisonCap program from the Start > Programs/All Programs > You may pre-allocate BisonCam menu (it is recommended that you set the capture file before the file size for the cap-...

  • Page 119: Eliminating Screen Flicker

    Modules & Options Eliminating Screen Flicker If you find that the video screen in the BisonCap program is flickering, you can try to adjust the setting in the Video Capture Filter options. Run the BisonCap program. Go to Options and scroll down to select “Video Capture Filter...”. Click either 50Hz or 60Hz under Frequency in Property Page (tab).

  • Page 120: Port Replicator Module

    Modules & Options Port Replicator Module If you have included the Port Replicator in your purchase option, the device Port Replicator will allow you to easily attach the notebook to standard, non-portable devices AC/DC Adapter e.g. a printer or monitor. Note the sidebar warning on the power supply. You will be provided with a 90W AC/DC You will be provided with a CD including drivers for the serial (COM) port,...

  • Page 121: Port Replicator Setup Instructions

    Modules & Options Port Replicator Setup Instructions: Turn the computer OFF. Attach the Port Replicator’s external monitor cable to the external monitor port on the rear of the computer. Attach the Port Replicator’s power cable to the DC-In jack on the right of the computer.

  • Page 122: Port Replicator Serial (Com) Port Driver

    Modules & Options Port Replicator Serial (COM) Port Driver 1. Insert the provided Port Replicator CD into the computer’s CD/DVD drive. 2. Click Start (menu) > Run... and navigate (Browse...) to D:\PL-2303 Driver Installer\PL-2303 Driver Installer.exe and click OK. 3. Click Next > Finish. Port Replicator Network (LAN) Driver 1.
  • Page 123 Modules & Options 6. Click "+" next to Other devices (if its sub-menu items are not shown). 7. Double-click AX88772 and click Driver (tab). 8. Click Update Driver (button). 9. When the Hardware Update Wizard appears select “No, not this time”...
  • Page 124 Modules & Options 7 - 18...

  • Page 125: Troubleshooting

    Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.

  • Page 126: Basic Hints And Tips

    Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer appears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.

  • Page 127: Backup And General Maintenance

    Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wallet.

  • Page 128: Viruses

    Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the definitions file updates are usually downloadable directly from the internet.

  • Page 129: Upgrading And Adding New Hardware/Software

    Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
  • Page 130 Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...

  • Page 131: Power

    Troubleshooting Power Problem Possible Cause - Solution You turned on the power Battery missing / incorrectly installed. Check the battery bay, make sure the battery is but it doesn’t work. present and seated properly (the design of the battery only allows it to go in one way). Make sure there’s nothing interfering with the battery contacts.
  • Page 132 Troubleshooting Problem Possible Cause - Solution The computer feels too Make sure the computer is properly ventilated and the Vent/Fan intakes are not blocked. If hot. this doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...

  • Page 133: Display

    Troubleshooting Display Problem Possible Cause - Solution Nothing appears The system is in a power saving mode. Toggle the sleep/resume key combination, Fn + F4 screen. (see “Sleep Button” on page 3 - The screen controls need to be adjusted. Toggle the screen control key combinations Fn + F8/F9.

  • Page 134: Boot Password

    Troubleshooting Boot Password Problem Possible Cause - Solution forget boot If you forget the password, you may have to discharge the battery of the CMOS. Contact password. your service representative for help. Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.

  • Page 135: Audio & Cd Device

    Troubleshooting Audio & CD Device Problem Possible Cause - Solution The sound cannot be The volume might be set too low. Check the volume control in the Volume Control Panel heard or the volume is in the Windows taskbar, or use the key combination Fn + F5 and F6 (see “Audio very low.

  • Page 136: Keyboard

    Troubleshooting Keyboard Problem Possible Cause - Solution Unwelcome numbers If the LED is lit, then Num Lock is turned ON. (see “LED Indicators” on page 1 - appear when typing. Other Keyboards If your keyboard is damaged or you just want to make a change, you can use any standard USB keyboard. The system will detect and enable it automatically.

  • Page 137: Operation

    Troubleshooting Operation Problem Possible Cause - Solution The system freezes or The system’s power saving features have timed-out. Use the AC/DC adapter, press the the screen goes dark. sleep (Fn + F4) key combination, or press the power button if no LEDs are lit. The system never goes Power Options features are not enabled.

  • Page 138: Modules

    Troubleshooting Modules Problem Possible Cause - Solution Wireless LAN/ The modules are off. Check the LED indicator to see if the WLAN/Bluetooth module is Bluetooth modules on or off (see “LED Indicators” on page 1 - 9). If the LED indicator is off, then press the cannot be detected.

  • Page 139: Interface (Ports & Jacks)

    Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the interface (ports & jacks) which allow your com- puter to communicate with external devices, connect to the internet etc. Interface (Ports &...

  • Page 140: Notebook Ports And Jacks

    Interface (Ports & Jacks) Notebook Ports and Jacks Item Description Built-In Microphone The built-in microphone allows you to record on your computer Card Reader Port The card reader allows you to use some of the latest digital storage cards. Push the card into the slot and it will appear as a removable device.

  • Page 141: Microphone-In Jack

    Interface (Ports & Jacks) Item Description Microphone-In Jack Plug an external microphone in to this jack to record on your computer. RJ-11 Phone Jack This port connects to the built-in modem. You may plug the telephone line directly into this RJ-11 telephone connection.

  • Page 142: Optional Port Replicator Ports And Jacks

    Interface (Ports & Jacks) Optional Port Replicator Ports and Jacks Item Description DC-In Jack Plug the supplied AC/DC adapter into this jack to power your computer. External Monitor (VGA) This port allows you to connect an external monitor, or Flat Panel Display, to get dual video Port or simultaneous display on the LCD and external monitor/FPD (see “Display Devices”...

  • Page 143: Usb 2.0/1.1 Ports

    Interface (Ports & Jacks) Item Description USB 2.0/1.1 Ports These USB 2.0 compatible ports (USB 2.0 is fully USB 1.1 compliant) are for low-speed peripherals such as keyboards, mice or scanners, and for high-speed peripherals such as external HDDs, digital video cameras or high-speed scanners etc. Devices can be plugged into the computer, and unplugged from the computer, without the need to turn the system off (if the power rating of your USB device is 500mA or above, make sure you use the power supply which comes with the device).
  • Page 144 Interface (Ports & Jacks) A - 6...

  • Page 145: Video Driver Controls

    Video Driver Controls Appendix B: Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on page 1 - VIA Video Driver Installation Make sure you install all the drivers in the order indicated in Table 4 - 1, on page 4 - 6.

  • Page 146: Advanced Video Controls

    Video Driver Controls Advanced Video Controls This section is about making adjustments for the LCD, and switching display Function Key devices. The basic settings for configuring the LCD are outlined in “Video Combination Features” on page 1 - You can use the Fn + F7 key combination to Video Driver Controls toggle through the dis-...

  • Page 147: S3Tray Plus Utility

    Video Driver Controls S3Tray Plus Utility When the video driver is installed the S3TrayPlus utility will appear in the taskbar. Click/Right-click the icon to bring up the menu below. From this menu you will also be able to make display adjustments, access the Display Properties control panel, check video memory information etc.

  • Page 148: S3 Display Control Panels

    Video Driver Controls S3 Display Control Panels The S3 Display control panels can be accessed from the S3Tray Plus utility in the taskbar, or from the Advanced tab in the Display Properties control panel. Figure B - 2 S3 Control Panels Help Menus Right-click on almost any item in the tabs to...

  • Page 149: Display Devices

    Video Driver Controls Display Devices Besides the built-in LCD, you can also use an external monitor (CRT)/flat S3Tray Plus Utility panel display as your display device. Connect it to the external monitor port at the rear of the computer. See the instructions below: You can also use the S3Tray Plus Utility in the taskbar to config-...

  • Page 150: Display Modes

    Video Driver Controls Display Modes Single Display Function Key Only one of your attached displays is used. Combination You can use the Fn + Multi-Monitor Mode F7 key combination to This display mode simply shows an exact copy of the Primary display desk- toggle through the dis- top on the Secondary display(s).
  • Page 151 Video Driver Controls To Enable Extended Desktop (Display Properties) Attach your external monitor to the external monitor port and turn it on. Click Start, point to Settings (or click Control Panel) and click Control Display Settings Panel (if you are in Category View choose Appearance and Themes). Extended Desktop Double-click Display (icon).
  • Page 152 Video Driver Controls B - 8...

  • Page 153: Specifications

    Specifications Appendix C: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly pro- cessor types/speeds and CD/DVD device types) may be changed or updated due to the manufacturer's release schedule.

  • Page 154: Processor

    Specifications Feature Specification µ Processor Intel Pentium® M Processor 0.09) 0.09 Micron Process Technology (478-pin) Micro-FC-PGA Package 2MB On-die L2 Cache & 533MHz FSB Models 730/ 740/ 750/ 760/ 770/ 780 1.6/ 1.73/ 1.86/ 2/ 2.13/ 2.26 GHz µ Intel Celeron® M Processor 0.09) 0.09 Micron Process Technology (478-pin) Micro-FCPGA Package 1MB On-die L2 Cache &...

  • Page 155: Video Adapter

    Specifications Feature Specification Video Adapter VIA PN800 Integration Shared Memory Architecture of up to 64MB of Dynamic Video Memory Allocation Supports Analog Monitor Pixel Resolution up to 1920 * 1400 Integrated 128 bit 3D Graphics Engine Accelerator Supports Dual View for 2 Displays Storage One Changeable 12.7mm(h) Optical Device (CD/DVD) Type Drive (see “Optional”...

  • Page 156: Interface

    Specifications Feature Specification Interface Three USB 2.0 Ports One S/PDIF Output Jack One External Monitor Port One RJ-11 Jack for Plug & Play Fax/Modem One Headphone-Out Jack One RJ-45 Jack for 10Mb/ 100Mb Fast One Microphone-In Jack Ethernet One Line-In Jack One DC-in Jack Card Reader Embedded 4-in-1 Card Reader (MS/ MS PRO/ SD/ MMC)

  • Page 157: Power

    Specifications Feature Specification Power Full Range AC/DC Adapter 20V, 3.25A (65 Watts), 100~240V, 47~63Hz Full Range AC/DC Adapter 20V, 4.5A (90 Watts), 100~240V, 47~63Hz (If Using the Optional Port Replicator) 6 Cell Smart Lithium-Ion Battery Pack, 4000mAH (44.4W) 6 Cell Smart Lithium-Ion Battery Pack, 4400mAH (48.8W) Environmental Temperature Relative Humidity...

  • Page 158: Optional

    Specifications Feature Specification Optional Optical Drive Module Options: (Factory Option) 56K Plug & Play Fax DVD-ROM Drive Module Modem V.90 / V.92 Compliant DVD/CD-RW Combo Drive Module DVD-Dual Drive Module Port Replicator (10/100Mb Base-T Ethernet Port, 4 * USB 2.0 Ports, Serial Port, Parallel 802.11g Wireless LAN Module with Mini-PCI Port, External Monitor Port, DC-In Jack) Interface...

Table of Contents
