Summary of Contents for ProStar N850HL

  • Page 1 N850HL...
  • Page 3 Preface Notebook Computer N850HL Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the N850HL se- ries notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 7: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...

  • Page 8: Power Safety

    Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.

  • Page 9: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

  • Page 10: System Startup

    Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD/DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup 1.
  • Page 11 Preface...
  • Page 12 Preface...

  • Page 13: Table Of Contents

    Preface Contents Introduction ..........1-1 Main Board ................... A-5 HDD ....................A-6 Overview ..................1-1 LCD ....................A-7 Specifications ..................1-2 Schematic Diagrams......... B-1 External Locator - Top View with LCD Panel Open ......1-4 External Locator - Front & Right Side Views .........1-5 System Block Diagram ..............B-2 External Locator - Left Side &...
  • Page 14 Preface PCH 6/8 ..................B-28 Unzip the downloaded files to a bootable CD/DVD or PCH 7/8 ..................B-29 USB Flash drive ................C-1 PCH 8/8 ..................B-30 Set the computer to boot from the external drive ......C-1 USB 3.0 ..................B-31 Use the flash tools to update the BIOS ...........C-2 M.2 SATA &...

  • Page 15: Introduction

    Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the N850HL series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about dri- vers (e.g.

  • Page 16: Specifications

    Introduction Specifications Processor Options Video Adapter Intel® Core™ i7 Processor Intel® Integrated GPU and NVIDIA® Discrete GPU i7-7700HQ (2.80GHz) Supports Microsoft Hybrid Graphics 6MB Smart Cache, 14nm, DDR4-2400MHz, TDP 45W  Intel® Core™ i5 Processor Intel Integrated GPU Latest Specification Information i5-7300HQ (2.50GHz) Intel HD Graphics 630 6MB Smart Cache, 14nm, DDR4-2400MHz, TDP 45W...
  • Page 17 Introduction Keyboard Card Reader Power Full-size “WinKey” keyboard (with numeric keypad) Embedded Multi-In-1 Card Reader Full Range AC/DC Adapter MMC (MultiMedia Card) / RS MMC AC Input: 100 - 240V, 50 - 60Hz (Factory Option) Full-size “WinKey” Illuminated White-LED SD (Secure Digital) / Mini SD / SDHC/ SDXC DC Output: 19V, 4.74A (90W) Keyboard (with numeric keypad) (Factory Option) Removable 6 Cell Smart Lithium-Ion Bat-...

  • Page 18: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. PC Camera 2. *PC Camera LED *When the PC camera is in use, the LED will be illuminated. 3. Built-In Array Microphone 4. LCD 5. Power Button 6.

  • Page 19: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right Side Views Figure 2 Front View 1. LED Indicator FRONT VIEW Figure 3 Right Side View 1. Headphone-Out RIGHT SIDE VIEW Jack 2. Microphone-In Jack 3. USB 2.0 Port 4. USB 3.0 (USB 3.1 Gen 1) Type A Port 5.

  • Page 20: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. DC-In Jack 2. RJ-45 LAN Jack 3. External Monitor Port LEFT SIDE VIEW 4. HDMI-Out Port 5. USB 3.0 (USB 3.1 Gen 1) Type C Port (Factory Option) USB 3.1 Gen 2 Type C Port...

  • Page 21: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Battery 2. Vent 3. Speakers  Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use. External Locator - Bottom View 1 - 7...

  • Page 22: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. KBC-ITE IT8587 1 - 8 Mainboard Overview - Top (Key Parts)

  • Page 23: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. GPU 2. CPU 3. Memory Slots DDR4 SO-DIMM 4. Mini-Card Connector (WLAN Module) 5. PCH 6. CMOS Battery 7. M.2-Card Connector (SSD Module) Mainboard Overview - Bottom (Key Parts) 1 - 9...

  • Page 24: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. DC-In Jack 2. RJ-45 LAN Jack 3. External Display Port 4. HDMI-Out Port 5. USB Port 3.0/3.1 (Type C) Connector 6. USB Port 3.0/3.1 (Type A) Connector 7. Multi-in-1 Card Reader 8.

  • Page 25: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. CCD Connector 2. Fan Connector 3. HDD Connector 4. Speaker Connector 5. LCD Connector Mainboard Overview - Bottom (Connectors) 1 - 11...
  • Page 26 Introduction 1 - 12...

  • Page 27: Disassembly

    Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the N850HL series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.

  • Page 28: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 29: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other components Warning could be damaged.

  • Page 30: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the 3G Module: 1. Remove the battery page 2 - 5 1.
  • Page 31 Disassembly Removing the Battery Figure 1 Battery Removal 1. Turn the computer off, and turn it over. 2. Slide the latch in the direction of the arrow (Figure 1a). a. Slide the latch in the 3. Slide the latch in the direction of the arrow. direction of the arrow.

  • Page 32: Removing The Keyboard

    Disassembly Removing the Keyboard Figure 2 Keyboard Removal 1. Turn off the computer, turn it over. 2. Remove screws from the bottom of the computer. a. Remove the screws from 3. Open it up with the LCD on a flat surface before pressing at point to release the keyboard module (use the spe- the bottom of the compu- cial eject stick...

  • Page 33: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive Figure 3 The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 7mm HDD Assembly (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in Removal Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 34 Disassembly 5. Remove screws from the HDD assembly (Figure 4d). Figure 4 6. Slightly lift and pull the hard disk assembly in the direction of arrow (Figure 4e HDD Assembly 7. Lift the hard disk assembly out of the bay (Figure 4f Removal (cont’d.) 8.

  • Page 35: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 5 RAM Module The computer has two memory sockets for 260 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting Removal DDR4 2400 MHz. The main memory can be expanded up to 16GB. The total memory size is automatically detected by the POST routine once you turn on your computer.

  • Page 36: Removing And Installing The M.2 Ssd Module

    Disassembly Removing and Installing the M.2 SSD Module Figure 6 M.2 SSD Module M.2 SSD Module Removal Procedure Removal 1. Turn off the computer, turn it over, remove the battery (page 2 - 2. The M.2 SSD module will be visible at point on the mainboard (Figure 6a).

  • Page 37: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 7 Wireless LAN 1. Turn off the computer, turn it over, remove the battery (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard (Figure 7a).

  • Page 38: Wireless Lan, Combo, 3G & Lte Module Cables

    Disassembly Wireless LAN, Combo, 3G & LTE Module Cables Note that the cables for connecting to the antennae on WLAN, WLAN & Bluetooth Combo, 3G and LTE modules are not labelled. The cables/covers (each cable will have either a black or transparent cable cover) are color coded for iden- tification as outlined in the table below.

  • Page 39: Removing The 3G Module

    Disassembly Removing the 3G Module Figure 8 3G Module Removal Procedure 3G Module Removal 1. Turn off the computer, remove the battery (page 2 - a. Locate the module. 2. Locate the module, it is visible at point Figure 8a b.

  • Page 40: Removing The Ccd

    Disassembly Removing the CCD Figure 9 CCD Removal 1. Turn off the computer, turn it over to remove the battery (page 2 - 2. Lay the computer down on a flat surface with the top case up forming a 90 degree angle. Carefully remove the a.
  • Page 41 Disassembly 5. Disconnect the cable (Figure 10c). Figure 10 6. Remove the CCD module (Figure 10d). CCD Removal 7. Reverse the process to install a new CCD module. (cont’d) c. Disconnect the cable. d. Remove the CCD mod- ule.  11.
  • Page 42 Disassembly 2 - 16...

  • Page 43: Part Lists

    Appendix A:Part Lists This appendix breaks down the N850HL series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 44: Part List Illustration Location

    Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A - 1 Part List Illustration Part Location page A - 3 Bottom page A - 4 page A - 5 Main Board page A - 6 page A - 7 A - 2...

  • Page 45: Top

    Figure A - 1 Top A - 3...

  • Page 46: Bottom

    Bottom Figure A - 2 Bottom A - 4 Bottom...

  • Page 47: Main Board

    Main Board Figure A - 3 Main Board Main Board A - 5...

  • Page 48: Hdd

    Figure A - 4 A - 6 HDD...

  • Page 49: Lcd

    Figure A - 5 LCD A - 7...
  • Page 50 A - 8...

  • Page 51: Schematic Diagrams

    Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the N850HL notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Table B - 1...

  • Page 52: System Block Diagram

    Schematic Diagrams System Block Diagram N850HL System Block Diagram (Kabylake) VDD3,VDD5 SHEET 41 nVIDIA GPU NVDIDA NVVDD Nvidia 2 VIA:3"~8" N17S-G1 RAM SIZE 2GB (256Mbx32x2))GDDR5 Kabylake-H PCIE*4 4 VIA:3"~9" SHEET 48 N850HL--N17S-G1 KBY-H 42 45W N870HL--N17S-G1 5V,3V,5VS,3VS 2 vias <10"...

  • Page 53: Processor 1/6

    Schematic Diagrams Processor 1/6 SKYLAKE_HALO U29C BGA1440 PEG_TX_0 C535 0.22u_10V_X5R_04 PEG_RX0 PEG_TX0 PEG_RXP[0] PEG_TXP[0] PEG_TX#_0 C534 0.22u_10V_X5R_04 PEG_RX#0 PEG_RXN[0] PEG_TXN[0] PEG_TX#0 PEG_TX_1 C532 0.22u_10V_X5R_04 6-36-00180-250(BOT) PEG_RX1 PEG_TX1 PEG_RXP[1] PEG_TXP[1] PEG_TX#_1 C533 0.22u_10V_X5R_04 PEG_RX#1 PEG_RXN[1] PEG_TXN[1] PEG_TX#1 CPU HOLD PEG_TX_2 C549 0.22u_10V_X5R_04 PEG_RX2 PEG_TX2...

  • Page 54: Processor 2/6

    Schematic Diagrams Processor 2/6 SKYLAKE_HALO SKYLAKE_HALO U29A U29B M_A_DQ[63:0] M_B_DQ[63:0] BGA1440 BGA1440 M_A_DQ0 M_B_DQ0 BT11 DDR0_DQ[0] DDR0_CKP[0] M_A_CLK_DDR0 DDR1_DQ[0]/DDR0_DQ[16] DDR1_CKP[0] M_B_CLK_DDR0 M_A_DQ1 M_B_DQ1 BR11 DDR0_DQ[1] DDR0_CKN[0] M_A_CLK_DDR#0 DDR1_DQ[1]/DDR0_DQ[17] DDR1_CKN[0] M_B_CLK_DDR#0 M_A_DQ2 M_B_DQ2 DDR0_DQ[2] DDR0_CKN[1] M_A_CLK_DDR#1 DDR1_DQ[2]/DDR0_DQ[18] DDR1_CKN[1] M_B_CLK_DDR#1 M_A_DQ3 M_B_DQ3 M_A_CLK_DDR1 M_B_CLK_DDR1 M_A_DQ4...

  • Page 55: Processor 3/6

    Schematic Diagrams Processor 3/6 NEAR CPU 1.0V_VCCST CFG[0]: Stall reset sequence after PLL lock until de-asserted: — 1 = (Default) Normal Operation; SKYLAKE_HALO U29E No stall. — 0 = Stall. BGA1440 BN25 CFG0 PCH_CPU_BCLK_R_DP CFG[1]: Reserved configuration lane. BCLKP CFG[0] BN27 100_04 56.2_1%_04...

  • Page 56: Processor 4/6

    Schematic Diagrams Processor 4/6 PLACE CAPS AT BOARD EDGE CPU_TOP_VCCCORE VCCEDRAM VCORE VCORE SKYLAKE_HALO VCORE U29G U29J SKYLAKE_HALO BGA1440 BGA1440 AA13 C203 AA31 BJ17 VCCOPC AA32 BJ19 VCCOPC C505 C219 C215 AA33 BJ20 PLACE CAP BACKSIDE VCCOPC AA34 BK17 VCCOPC AA35 BK19 VCCOPC...

  • Page 57: Processor 5/6

    Schematic Diagrams Processor 5/6 PLACE CAP BACKSIDE VCCVDDQ_CLK 1.0V_VCCST 1.0V_VCCST VCCSA VDDQ C249 C252 C226 SKYLAKE_HALO U29I 11.1A 2.8A BGA1440 VCCSA VDDQ SKYLAKE_HALO AE12 place to angle U29K VCCSA VDDQ VCCSA VDDQ BGA1440 VCCSA VDDQ TP_SKL_D1 TP_SKL_BM33 T104 BM33 VCCSA VDDQ RSVD_TP RSVD_TP...

  • Page 58: Processor 6/6

    Schematic Diagrams Processor 6/6 VCCGT VCCGT VCCGT SKYLAKE_HALO U29F SKYLAKE_HALO U29L U29M SKYLAKE_HALO VCCGTU BGA1440 BGA1440 BGA1440 SKYLAKE_HALO AK30 U29N SKYLAKE_HALO AK29 U29H AJ29 BGA1440 VCCGT BG34 AV29 AJ30 VCCGT BGA1440 VCCGT VCCGT BT32 AJ38 BG35 AV30 AJ31 AF29 VCCGT VCCGT VCCGT VCCGTX...
  • Page 59 Schematic Diagrams DDR4 CHA SO-DIMM Channel A SO-DIMM 0[RAM1] VTT_MEM RVS TYPE VDDQ J_DIMMA_2B H=5.2mm 2.5V J_DIMMA_2A M_A_DQ[63:0] VDD19 VDD18 M_A_DQ1 M_A_CLK_DDR0 CK0_T VDD17 M_A_DQ0 M_A_CLK_DDR#0 CK0_C M_A_DQ3 VDD16 VPP2 M_A_CLK_DDR1 CK1_T VDD15 VPP1 M_A_DQ2 M_A_CLK_DDR#1 CK1_C VDD14 M_A_DQ4 VDD13 M_A_DQ5 3.3VS M_A_CKE0...
  • Page 60 Schematic Diagrams DDR4 CHB SO-DIMM VTT_MEM J_DIMMB_1B Channel B SO-DIMM 0[RAM2] STD TYPE VDDQ 2.5V H=5.2mm VDD19 VDD18 VDD17 J_DIMMB_1A VDD16 VPP2 PLACE THE CAP WITHIN 200 MILS FROM THE SODIMM M_B_DQ[63:0] VDD15 VPP1 M_B_DQ5 M_B_CLK_DDR0 CK0_T VDD14 DDR4_DRAMRST# M_B_DQ1 8,23 DDR4_DRAMRST# M_B_CLK_DDR#0...
  • Page 61 Schematic Diagrams VGA PCI-E Interface U169A INS31399218 COMMON 1/14 PCI_EXPRESS PEX_VDD VDD_AON N16x 2.0 R389 0_04 DGPU_PEX_RST# PEX_DVDD AA22 C508 C509 C504 R390 0_04 AB23 PEX_RST PEX_DVDD GPU_PEX_RST# AC24 1u_6.3V_X6S_04 1u_6.3V_X6S_04 4.7u_6.3V_X6S_06 10u_4V_X6S_06 *10u_6.3V_X5R_06 22u_6.3V_X5R_08 10u_4V_X6S_06 10K_04 PEX_DVDD PEX_CLKREQ# AD25 PEX_CLKREQ PEX_DVDD NV FOOTPRINT...

  • Page 62: Vga Frame Buffer Interface

    Schematic Diagrams VGA Frame Buffer Interface Term Description The total trace length measured from GPU ball to capacitor is Under GPU Frame Buffer Interface no more than 150 mil The total trace length measured U169D from GPU ball to capacitor is no Near GPU more than 850 mil INS31420079...

  • Page 63: Vga Frame Buffer A

    Schematic Diagrams VGA Frame Buffer A U151B U151C INS1220714 INS1221418 BGA170 BGA170 COMMON 11,13 FBA_CMD[31:0] COMMON FBA_CMD12 Normal 0307 Change 0ohm FBA_CMD15 FBA_SOE0 FBA_CMD5 MF_VSS/SOE* FBA_CLK0 FBVDDQ FBA_CMD0 add 1k to VSS FBA_CLK0# FBA_D[31:0] FBA_CMD8 0_04 U151D U151A FBA_CMD10 A0_A10 INS1221112 INS1220380 FBA_CMD11...
  • Page 64 Schematic Diagrams VGA Frame Buffer A U152B U152C 0307 Change 0ohm INS1224528 INS1224754 BGA170_MIRR BGA170_MIRR 0_04 COMMON COMMON 11,12 FBA_CMD[31:0] FBVDDQ Mirrored FBA_CMD28 FBA_CLK1 FBA_CMD31 FBA_SOE3 FBA_CLK1# SOE*/MF_VDD FBA_CMD21 add 1k to VDD FBA_CMD16 FBA_D[63:32] FBVDDQ FBA_CMD24 U152D U152A INS1225672 INS1226066 FBA_CMD26 A0_A10...

  • Page 65: Vga I/O

    Schematic Diagrams VGA I/0 U169J U169I U169N INS31420402 INS31416542 NVVDD INS31415217 U169F COMMON COMMON INS31416294 COMMON NVVDDS 0218 4/14 IFPAB 3/14 JTAG 5/14 NC COMMON 7/14 VDDS DVI HDMI GM108 SL/DL AA14 JTAG_TCK PEX_PLLVD D JTAG_TDI AA15 VDDS PEX_PLLVD D IFPA_L3 JTAG_TDO VDDS...
  • Page 66 Schematic Diagrams VGA NVVDD Coupling Gary_from RS1 to PJ74 NVVDD under U169C U169H U169G INS31413859 NVVDD INS31421525 INS31422839 C143 C137 COMMON COMMON COMMON 1u_6.3V_X6S_04 1u_6.3V_X6S_04 1u_6.3V_X6S_04 1u_6.3V_X6S_04 11/14 NVVDD 6/14 XVDD NVVDD NVVDD 13/14 GND NV FOOTPRINT NV FOOTPRINT NV FOOTPRINT NV FOOTPRINT XVDD XVDD...
  • Page 67 Schematic Diagrams Panel, Inverter PANEL POWER PANEL CONNECTOR For common design change net name SHORT PJ47 VLED OPEN_2A 3.3VS Q38A *MTS3572G6 Fro common design LED PANEL (EDP Channel). BAV99N3 C162 C163 D02A PLVDD C529 eDPHPD R491 1K_04 J_LCD1 EDP_HPD 3.3V R484 R492 C585...
  • Page 68 Schematic Diagrams For common design change J_CRT1 5VS_CRT 6-19-31001-003 DS15146BAC067 RB751S-40H DAC_RED FCM1005MF-600T01 FRED DAC_GREEN FCM1005MF-600T01 FGRN 6-06-75140-068 R388 DAC_BLUE FCM1005MF-600T01 FBLUE 2.2K_04 2.2K_04 C102 C101 C100 VGA_SDA 6-13-36R01-28C VGA_HSYNC VGA_HS_R R376 36_1%_04 For common design change net name VGA_VSYNC VGA_VS_R 36_1%_04 POWER...
  • Page 69 Schematic Diagrams HDMI Differential pair mismatch < 5 mil R4.4 CPU to Level Shift total trace length < 5.5” ,via count 2 ,referenc e t o ground . Level Shift to HDMI connector total trace length < 1” ,via count 2 ,referenc e t o ground .
  • Page 70 Schematic Diagrams PCH 1/9 BOOT HALT JTAG ODT ENABLE:LOW DISABLE:LOW (INTERNAL WEAK PD) (INTERNAL WEAK PU) SPT-H_PCH U45A SPI_SI_R SPI_SO_R LAN_W UP# BD17 BB27 R478 *0_04 30,34,38 LAN_W AKEUP# PLT_RST# 14,24 GPP_A11/PME# GPP_B13/PLTRST# AG15 RSVD R446 R470 AG14 T125 RSVD GPP_G16/GSXCLK AF17 *4.7K_04...
  • Page 71 Schematic Diagrams PCH 2/9 SPT-H_PCH U45B DMI_MT_IR_0_DN DMI_RXN0 USB2N_1 USB_PN1 1- USB3 Port 1 Charger DMI_MT_IR_0_DP DMI_RXP0 USB2P_1 USB_PP1 USB_PN2 DMI_IT_MR_0_DN DMI_TXN0 USB2N_2 2- CCD USB_PP2 DMI_IT_MR_0_DP DMI_TXP0 USB2P_2 DMI_MT_IR_1_DN USB_PN3 DMI_RXN1 USB2N_3 AG10 3- BT DMI_MT_IR_1_DP USB_PP3 DMI_RXP1 USB2P_3 DMI_IT_MR_1_DN DMI_TXN1 USB2N_4...
  • Page 72 Schematic Diagrams PCH 3/9 BIOS RECOVERY ENABLE :LOW PCH_RSVD MFG_MODE 3.3VS 3.3VS 3.3VS SATAGP3 3.3VS SATAGP2 10K_8P4R_04 SATAGP1 SATAGP0 R160 R161 R531 SCI#_R R543 10K_04 *10K_04 *10K_04 *10K_04 SATA_LED# R530 10K_04 BIOS_REC PCH_RSVD MFG_MODE SW I#_R R541 10K_04 SPT-H_PCH 3.3VA U45C T116 CL_CLK...
  • Page 73 Schematic Diagrams PCH 4/9 R521 1.5K_1%_04 R522 45.3K_1%_04 VDD3 SPT-H_PCH U45D ISH_GP_6_R RTC3.2V BB17 HDA_BITCLK HDA_BCLK GPP_A12/BMBUSY#/ISH_GP6/SX_EXIT_HOLDOFF# PM_CLKRUN# AW22 HDA_RST# HDA_RST# GPP_A8/CLKRUN# 6-06-00054-06F HDA_SDIN0 HDA_SDI0 AR15 LAN_DISABLE_N HDA_SDI1 GPD11/LANPHYPC VCC_RTC HDA_SDOUT PCH_SLP_W LAN# AV13 23,37 HDA_SDOUT HDA_SDO GPD9/SLP_WLAN# PCH_SLP_W LAN# HDA_SYNC HDA_SYNC BC14...
  • Page 74 Schematic Diagrams PCH 5/9 3.3VS R124 R125 U45E 100K_04 100K_04 SPT-H_PCH HDMI_CTRLCLK GPP_I7/DDPC_CTRLCLK HDMI_CTRLCLK VGA_HPD HDMI_CTRLDATA VGA OUT(B) VGA_HPD GPP_I0/DDPB_HPD0 GPP_I8/DDPC_CTRLDATA HDMI_CTRLDATA VGA_CLK HDMI OUT(C) HDMI_HPD DDPB_HPD GPP_I1/DDPC_HPD1 GPP_I5/DDPB_CTRLCLK VGA_DATA GPP_I2/DDPD_HPD2 GPP_I6/DDPB_CTRLDATA GPP_I3/DDPE_HPD3 GPP_I9/DDPD_CTRLCLK GPP_I10/DDPD_CTRLDATA H_SKTOCC_N GPP_F14 DGPU_PW R_EN DGPU_PW R_EN 14,38,50 GPP_F23 DGPU_RST#_PCH...

  • Page 75: Pch 6/8

    Schematic Diagrams PCH 6/9 C625 15p_50V_NPO_04 6-07-18034-1A0 R556 FSX3M_24MHZ 1M_1%_04 R557 SPEC: 20PPM *10mil_short C626 15p_50V_NPO_04 SPT-H_PCH U45G AR17 GPP_A16/CLKOUT_48 PCH_XDP_CLK_DN 24 MHz CLKOUT_ITPXDP PCH_XDP_CLK_DP 2015.9.11 CPU_24MHZ_R_DP CLKOUT_CPUNSSC_P CLKOUT_ITPXDP_P 100 MHz CPU_24MHZ_R_DN XTAL R O R CLKOUT_CPUNSSC R482 100 MHz 32.768KHz PC H V I A...
  • Page 76 Schematic Diagrams PCH 7/9 VDD1.0 VDD1.0 SPT-H_PCH U45H VDD3 eSPI:1.8V 2.899A AA23 R113 *20mil_04 LPC:3.3V 3.3VA VCCPRIM_1P0 AA26 VCCPRIM_1P0 AA28 AL22 0.0908A R115 *20mil_04 VCCPRIM_1P0 VCCPRIM_1P0 3.3VA AC23 VCCPRIM_1P0 AC26 BA24 0.403A C273 R137 *20mil_04 3.3VA VCCPRIM_1P0 VCCDSW_3P3 AC28 BA31 V3.3A_V1.8A_VCCPGPPA 0.1u_10V_X7R_04 R159...
  • Page 77 Schematic Diagrams PCH 8/9 U45I SPT-H_PCH SPT-H_PCH AC18 U45L AB11 AN10 M-MARK M-MARK M-MARK M-MARK BE14 AB14 BE18 AE29 AB31 BE23 AB32 BE28 AE42 AB38 BE32 AF18 BE37 AF20 BE40 AF21 AF23 AC20 AF25 AC21 AF26 AC25 AF28 AC29 AF29 AC45 M-MARK M-MARK...
  • Page 78 AL44 R510 10K_04 PCH 9/9 3.3VS GPP_B21/GSPI1_MISO GPP_D9 AV29 AL36 BOARD_ID2 R513 1K_04 R138 GPP_B20/GSPI1_CLK GPP_D10 BOARD_ID3 BC27 AL35 N850HL 1K_04 GPP_B19/GSPI1_CS# GPP_D11 TPM_DET AJ39 R134 *10K_04 GPP_D12 3.3VS W /O TPM LPSS_GSPI0_MOSI BD28 R136 1K_04 GPP_B18/GSPI0_MOSI BD27 AJ43 GPP_B17/GSPI0_MISO...
  • Page 79 Schematic Diagrams M.2 3G Card 3G_EN 3G CARD 6-34-P750S-010(BOT) GPS_DISABLE# CURRENT2A ,DON'T DROP BELOW 3.135V 3G_PW R_EN 3G_3.3V 3G_3.3V 80 mils H6_5D3_7 J_3G1 C720 220u_6.3V_6.3*6.3*4.2 C702 0.1u_16V_Y5V_04 CONFIG_2 3.3V4 GND10 3.3V3 C712 0.1u_16V_Y5V_04 GND9 3.3V2 CONFIG_1 SUSCLK(32Khz)(O) DETECT_SW Reset#(O)1.8V SIM Detect(O) ANTCTL3(I)1.8V COEX1(I/O)1.8V Gary_RF Modify...
  • Page 80 Schematic Diagrams M.2 WLAN+BT, SSD J_W LAN1 For common design WLAN+BT 40 mil W LAN_3.3V GND10 3.3V3 Reserved/REFCLKN1 3.3V2 C352 C391 C351 Reserved/REFCLKP1 UIM_Power_In/Gpio1/PEWake1# GND9 UIM_Power_Out/CLKREQ1# 22u_6.3V_X5R_08 22u_6.3V_X5R_08 0.1u_16V_Y5V_04 Reserved/PERn1 UIM_SWP/PERST1# Reserved/PERp1 Reserved1 GND8 ALERT#(I) R229 10K_04 0310 del Reserved/PETn1 I2C CLK(O) W LAN_3.3V VDD3...
  • Page 81 Schematic Diagrams ASM 1142 & 2142 PCIE_TXP1_ASM FSX3M 20.0000000M16FAO PCIE_TXN1_ASM PCIE_RXP1_ASM 0.22u_10V_X5R_04 C344 USB3.1 0.22u_10V_X5R_04 C345 USB3.1 PCIE_RXN1_ASM USB3.1 12p_50V_NPO_04 C342 USB3.1 VDDP_12P R222 0_04USB3.1 ASM_1.2VS_1.05VS <0.5" , Diff : 95 ohm C633 4.7u_6.3V_X5R_06 USB3.1 USB3.1 ASM1142_REXT R573 12.1K_1%_04 PCIE_RXP2_ASM 0.22u_10V_X5R_04 C346 USB3.1...
  • Page 82 Schematic Diagrams ASM Power For ASM2142 Layout trace 2A after jumper ASM_1.2V_1.05V_P ASM_1.2V_1.05V PR126 10_06 PC69 PC56 USB3.1 USB3.1 *HCB1608KF-121T30 HCB1608KF-121T30 USB3.1 PC60 VDDQ USB3.1 USB3.1 MP2315GJ-Z USB3.1 0.1u_10V_X7R_04 *HCB1608KF-121T30 1.24V or 1.05V VDD1.0 USB3.1 ASM_1.2VA_1.05VA PC59 PR131 USB3.1 USB3.1 *0_04 BCIHP0420TB-2R2M PJ26...

  • Page 83: Usb 3.0

    Schematic Diagrams USB, Charger USB3.0 PORT(PORT3) USB3.1 USB3.0/3.1 PORT(PORT1) Add TYPE-C Function 5V_MUX 6-02-75495-9C0 5V_MUX ASM1543_VCONN_EN ASM_3.3V CC_RDY# ASM1543_PWR_EN MC_RDY# VDD5 USBVCC_CH pin1 ASM1543_MODE_SEL HC_RDY# 80 mil C601 C597 HCB1608KF-121T30 80 mil USB3.1 USB3.1 pin33 ASM1142+ASM1543 VOUT 1u_6.3V_X5R_04 10u_6.3V_X5R_06 C637 USB3.1 pin#12 pin#12...
  • Page 84 Schematic Diagrams Card Reader / LAN RTL8411B LAN (RTL8411B) Crystal HSX32 1 S(3. 2X 2. 5X 0. 6 5 ) 6 IN 1 SOCKET - MMC / RSMMC meet realtek Freq tolerance 50ppm - SD / mini SD / SDHC / SDXC J_CARD-REV1 RSET R265...
  • Page 85 Schematic Diagrams HDD, Click TP, Audio, Hall Con. FOR SUPPORT OPTANE project, SATA HDD POWER GATEING HDD CONNECT1 (MASTER) SATA_5VS PJ56 *OPEN-3mm SATA_5VS 6-20-43790-122 2.5A 2.5A J_HDD1 Gen3 VOUT C653 C652 C644 C643 JHDD_SATA_TXP2 C701 0.01u_16V_X7R_04 SATA_TXP2 VOUT JHDD_SATA_TXN2 C700 0.01u_16V_X7R_04 SATA_TXN2 VOUT...
  • Page 86 Schematic Diagrams LED, CCD, TPM, Power SW Con. NGFF B & M KEY TPM 2.0 (SLB9665TT) WLAN LED P C I E S S D L E D S A T A L E D WLAN ON P I N 2 4 S S D L E D B I O S...

  • Page 87: Audio Codec, Alc269Vc2

    Schematic Diagrams Audio Codec ALC269 VC2 Footprint ALC26 9 VC2-QFN48-6 X 6 M AUDIO CODEC ALC269 VB7 EMI Require Layout note: PVDD1_2 HCB1005KF-121T20 GND and AUDG space is *HCB1005KF-121T20 60mils ~ 100mils AUDG DVDD_IO For 3.3V HDA Link. R332 *20mil short-p C468 C469 R331...
  • Page 88 VGA_FAN DAC4/GPJ4 KSO15 N85HL KB-SO15 N87_WHITE N850HN 4.42K DAC5/GPJ5 6-20-94K40-106 6-20-94AF0-124 N87HL FLASH Gary_D02 for ALC269-VB7 co-lay BAT_DET AUTO_LOAD_PWR R289 10K_04 For N850HL N870HL 1.78K 0.5V 38,47 BAT_DET ADC0/GPI0 FLFRAME#/GPG2 VDD3 BAT_VOLT HSPI_CE# BAT_VOLT ADC1/GPI1 FLAD0/SCE# HSPI_MSI HSPI_CE# N850HL 8.25K 1.5V...

  • Page 89: 5V, 5Vs, 3.3V, 3.3Vs, 3.3Va

    Schematic Diagrams 5V, 5VS, 3.3V, 3.3VS, 3.3VA DD_ON# VDD3 VDD3 SUSB PR144 PR136 VIN1 10K_04 10K_04 DD_ON# SUSB DD_ON# 33,42 SUSB 19,32,35 C454 C455 C453 PQ12 PQ11 PC71 0.1u_50V_Y5V_06 0.1u_50V_Y5V_06 0.1u_50V_Y5V_06 2SK3018S3 PC74 2SK3018S3 2,33,38,41,50 DD_ON 17,21,32,33,39,40,42 SUSB# *0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 PR143 PR135 Clost to P2808B0...
  • Page 90 Schematic Diagrams VDD1.0, VCCIO For CV test VDD1_EN TON_P1U1 R334 100K_04 PR138 820K_1%_06 VDD3 PJ35 *CV-1mm PC216 PC218 PC217 R333 *0_04 DD_ON_EN PR134 PC73 SHORT VREG5 0_06 0.1u_10V_X7R_04 PQ35 23,38,45 SLP_SUS# VDD1.0 QM3004M3 EN_PSV PJ36 PR142 0_06 DH_PU1 V1.0A PL15 SHORT VDD1.0 VTT_SELECT...

  • Page 91: Vdd3, Vdd5

    Schematic Diagrams VDD3, VDD5 VREF PR289 *10mil_short PC205 1u_10V_Y5V_06 PR287 PR290 EN_5V PC203 62K_1%_04 62K_1%_04 PC206 1000p_50V_X7R_04 1000p_50V_X7R_04 D01A PU15 2.5A VREG3 PC78 PC76 PC77 PC188 PC164 PC81 PC80 PC79 VDD3 PC204 1u_6.3V_X5R_04 LDO3 PQ32 PQ36 QM3004M3 PC211 QM3004M3 12 A VDD5 BOOT2 BOOT1...
  • Page 92 Schematic Diagrams DDR 1.2V/0.6VS, 2.5V DDR4 PD14 PQ30 1.2V/0.6VS MDU1516 PU14 ULTRASO-8 PC191 PC189 PC190 RB0540S2 G5616BRZ1U VDDQ_R VTT_MEM(0.6V) PC194 1.2V PC195 0.1u_10V_X7R_04 VLDOIN VBST SHORT EMR3 10u_6.3V_X5R_06 VDDQ_R SHORT VTT_MEM DRVH PL14 2.2_1%_06 PJ58 BCIHP0730-1R0M PJ55 PC196 VDDQ VTTGND PR283 PCB Footprint = BCIHP0735A EMR4...
  • Page 93 Schematic Diagrams VCore, VCCGT Output Stage VCORE & VCCGT OUTPUT STAGE PC128 PC127 PC183 PC31 PC129 PC33 PR230 PC144 VCORE_R change to 2.2_06 0.1u_25V_X7R_06 VCORE 2Phase VCORE Gary_D02 for BUG solution Gary_D02 Change PC172 footprint INS19909547 MLP08 Gary_D02 PC157 non-stuff COMMON PR231 1_1%_06...
  • Page 94 Schematic Diagrams VCC_Core, VCCGT Intel SKYLAKE IMVP8 POWER CKT - 2+1 PHASE VCORE IMON GT IMON VREF_VCORE Gary_D02 for BUG solution VREF_VCORE PR11 PR198 0_04 0_04 H-line 42 PR197 33.2K_1%_04 PR10 56K_1%_04 10k ntc 100k_1%_04_NTC EWTF02-103F3I-N 1.0V_VCCST PC42 3.3VS 0_04 1.0V_VCCST 1u_6.3V_X5R_04 PR33...
  • Page 95 Schematic Diagrams 1.0DX_VCCSTG/VCCSFR_OC, 3.3VA NOTE: SHORT 1.0DX_VCCSTG PJ12 *1mm 1.0DX_VCCSTG Ton need <65us VCCSFR_OC VCCSFR_OC 1.0DX_VCCSTG M5938 TURON-ON TIME=60us VCCSFR_OC PJ13 SHORT VDD1.0 Gary_Reserved PJ73 VDDQ PJ21 VCCIO VOUT1_U140 VOUT2_U141 VOUT VOUT C202 C393 C397 C165 C164 *10u_6.3V_X5R_06 C369 *10u_6.3V_X5R_06 VDD3 R242 *10u_6.3V_X5R_06...
  • Page 96 Schematic Diagrams VCCSA VCCSA For CV test PR80 820K_1%_06 PQ23 QM3004M3 PR69 100K_04 VDD3 PC30 PC165 PC166 Modify,3/20 Ken PJ11 *CV-1mm 0.1u_50V_Y5V_06 4.7u_25V_X5R_08 *4.7u_25V_X5R_08 PC34 PR79 10K_04 *1mm PR70 0_06 VCCIO_EN EN_PSV 0.1u_10V_X7R_04 PJ10 0_06 21,40 VCCIO_PW RGD SHORT BCIHP0730-1R0M VCCSA PR72 VOUT...
  • Page 97 Schematic Diagrams AC_In, Charger SMART CHARGER V_BAT PD11 PD10 MDL914S2 MDL914S2 VDD3 PR51 287K_1%_04 PR50 *HCB2012KF-800T80 PQ21 PQ22 QM3006M3 QM3006M3 ILIM J_DC_JACK1 PRS4 75K_1%_04 2DC3003-002211 HCB2012KF-800T80 0.01_1%_32 Battery Voltage: PC109 PC110 C497 PC124 PC121 PC118 PC117 PC107 PC106 PC119 PC120 12V~16.8V PR24 PR299...
  • Page 98 Schematic Diagrams NVVDD NVVDD PHASE 1 ~2 NVVDD FOR N17_VGA 1.8V PJ44 *CV-40mil PR224 10K_04 3.3V PR185 PR263 0_04 NV_NVVDD_EN 14,48 *0_04 VDD_MAIN_EN PR222 12K_04 NVVDD_DGPU_ON VDD_MAIN_EN 14,50 PR177 0_04 GPU_PWR_VID PC115 PR223 4.7K_1%_04 PR178 RB751V-40(lision) 0.1u_10V_X7R_04 *10K_04 0314 del PR210 10K_04 VDD_AON...
  • Page 99 Schematic Diagrams FBVDDQ FBVDDQ FOR N17 VGA 3.3VS 3.3VS 3.3VS R364 R363 *100K_04 *100K_04 PR117 DGPU_PWRGD 10K_04 BAT54AS3 14,48,49 NVVDD_PWRGD Q35A Q35B DGPU_PWRGD 10,24 FB_PWRGD *MTDK3S6R 49,50 PEXVDD_PWRGD *MTDK3S6R FB_PWRGD R200 0_04 FBVDDQ PR118 820K_1%_06 Sheet 48 of 55 PJ20 *CV-1mm PR110 0_04...
  • Page 100 Schematic Diagrams PEX_VDD/3V3 PEX_VDD PC148 PC136 PR239 N16-->1.05V 22u_6.3V_X5R_08 0.1u_10V_X7R_04 10_06 INS29939716 N17-->1V G5671RE1U PEX_VDD PR242 10K_04 DFN10 3.3VS G5671RE1U PEX_VDD PEXVDD_PWRGD PGOOD SHORT OpenVReg VDD_MAIN_EN_R PR241 39K_1%_04 PS6_SW_PEXVDD BCIHP0420TB-2R2M PR252 PR248 PS6_VCC_PEXVDD PJ46 RB751V-40(lision) PC153 PC154 10_06 *10_06 PC138 PR225 10K_04 PJ45...
  • Page 101 Schematic Diagrams Audio Board *0_04 *0_04 6-71-N8508-D03 USB PORT(PORT9) USB2.0 CON *0_04 *0_04 AC12 *22u_6.3V_X5R_08 AGND *0_04 *0_04 A_5V 60 mil A_USBVCC2 0.1u_10V_X7R_04 A_USBVCC2 AGND 60 mil 60 mil AUDIO BOARD Connector VOUT AC10 22u_6.3V_X5R_08 AGND AC18 AC20 CLOSE TO CONNECTOR 10u_6.3V_X5R_06 AJ_USB2 AD37...

  • Page 102: Power Switch Board

    Schematic Diagrams Power Switch Board *0_04 *0_04 6-71-N850S-D03 *0_04 *0_04 POWER SW BOARD *0_04 *0_04 Sheet 51 of 55 Power Switch BH_3.3VS POWER BH_3.3VS POWER POWER Board BUTTON BUTTON BOTTOM 6-53-31500-B41 820_06 820_06 For N850 BSW 1 Gary_change for ME T4BJB10BQR 6-13-82001-2AB 6-13-82001-2AB...
  • Page 103 Schematic Diagrams Hall Sensor Board HALL Sensor Board *0_04 *0_04 *0_04 *0_04 *0_04 *0_04 H_VDD3 6-02-09249-LC0 OLD Value MH248-ALFA-ESO Sheet 52 of 55 6-02-00248-LC2 100K_04 HJ_HALL1 Hall Sensor Board H_VDD3 H_LIDSW# H_LID_SW# H_GND H_LID_SW# *10mil_short AH9249NTR-G1 FP226H-004S10M *100p_50V_NPO_04 *V15AVLC0402 H_GND H_GND H_GND H_GND...

  • Page 104: Click Board

    Schematic Diagrams Click Board *0_04 *0_04 6-71-N8502-D04A *0_04 *0_04 *0_04 *0_04 CTP_VCC N87RC_RN 6-20-94K30-108 FP225H-008S11M C_TP_CLK C_TP_DATA C_CTPBUTTON_L C_CTPBUTTON_R Sheet 53 of 55 C_SMB_CLK C_SMB_DATA CJ_TP3 Click Board C_GND CTP_VCC 0.1u_10V_X7R_04 *10u_6.3V_X5R_06 CJ_TP2 N87RC_RN C_GND C_GND C_TP_DATA C_TP_CLK C_SMB_DATA C_SMB_CLK FPC0502-6AW -S-HF 6-20-94K10-006 N87RC_RN...

  • Page 105: Led Board

    Schematic Diagrams LED Board *0_04 *0_04 6-71-N8704-D04 *0_04 *0_04 *0_04 *0_04 6-52-55001-021 GREEN YELLOW HDD LED WLAN LED L_LED_HDD# 220_04 L_3.3VS RY-SP190YG34-5M WLAN ON GREEN YELLOW Windows 7 Airplane mode L_AIRPLAN_LED# 220_04 WLAN OFF L_3.3VS RY-SP190YG34-5M Airplane ON 6-52-55001-021 Windows 8 Airplane OFF WLAN/BLUETOOTH GREEN/YELLOW...

  • Page 106: Power Sequence

    Schematic Diagrams Power Sequence POWER ON SEQUENCE VDD3 3.372v DD_ON 595.47us 3.367V 3.3V 1.398ms 5.19V VDD5 1.963ms 5.18V 30.459ms 3.348V SLP_SUS# 31.018ms 3.371V 3.3VA 31.333ms 1.054V VDD1.0 81.21963ms 3.368V RSMRST 182.725ms 3.369V PWR_BTN 178.754ms 3.372V SUSC# 33.405us 3.372V SUSB# 98.177 1.214V VDDQ 255.43us...

  • Page 107: Updating The Flash Rom Bios

    BIOS Update Appendix C:Updating the FLASH ROM BIOS  BIOS Version To update the FLASH ROM BIOS, you must: Make sure you down- • Download the BIOS update from the web site. load the latest correct version of the BIOS ap- •...

  • Page 108: Use The Flash Tools To Update The Bios

    BIOS Update Use the flash tools to update the BIOS 1. Make sure you are not loading any memory management programs such as HIMEM by holding the F8 key as you see the message “EFI Shell”. You will then be prompted to give “Y” or “N” responses to the programs being loaded by EFI Shell.
