Operating Summary - Vaillant time SWITCH 130 Instructions For Use And Installation

1

Operating Summary

GB
1 Operating mode switch
The time is controlled as follows:
Heating constantly off
Heating constantly on
Automatic heating programme "
*
2 Minute hand
For showing and setting the time
3 Reference triangle
Indicates the time of day
e.g. Fig. 1 "15.00"
4
"off"
"on"
"
*
4a Slide in the tappets
Tappet in = "on" = heating on
4b Slide out the tappets*
Tappet out = "off" = heating off
5 Time of day
The time of day can be read opposite
the reference triangle (3). Please
note that the time of day is given
using a 24 hour clock.
