- Page 1 For the user / for the installer Instructions for Use and Installation time SWITCH 130 24 hour time clock...
- Page 2 4 - 9 Installation instructions page 10 -12 figures page 3, 14 -16 EC declaration of conformity page All Vaillant boilers have a built in frost thermostat. This time clock is not suitable for use with an external frost thermostat.
- Page 3 GB Fig. 1 SWITCH time Fig. 1:...
-
Page 4: Operating Summary
Operating Summary 1 Operating mode switch 4a Slide in the tappets The time is controlled as follows: Tappet in = ”on” = heating on Heating constantly off ”off” Heating constantly on ”on” 4b Slide out the tappets* Automatic heating programme ” ”... -
Page 5: Table Of Contents
Contents Operating summary page 4 Selecting the operating mode page 6 Setting the timer page 7 4 Programming heating periods page 8 5 Special operating conditions page 9 6 Installation instructions page 10 Commissioning page 11 8 Technical data page 12... -
Page 6: Selecting The Operating Mode
GB 2 Selecting of the operating mode 2.1 Selecting the operating mode In position ”off”, the heating is constantly off With the operating mode switch fig. 1 (1), you can change the operating mode In position , the heating operates of your heating system according to automatically depending on the setting your requirements. -
Page 7: Setting The Timer
3 Setting the timer 3.1 Setting the timer 3.1.2 Setting the timer 3.1.1 Reading time of day Turn the minute hand clockwise until the reference triangle coincides with The time of day can be read on the the correct time of day. clock face below the reference triangle. -
Page 8: Programming Heating Periods
GB 4 Programming heating periods 4.1 Setting the tappets 4.2 Setting the heating programme Set the tappets (4a) and (4b) as Set the tappets (3) and (4) according to follows: your heating requirements. For heating on periods stick the tappets (4a) inwards. -
Page 9: Special Operating Conditions
5 Special operating conditions 5.1 Weekend operation 5.3 Operating and mains failure If the heating is to be switched - on The programmer contains no batteries. temporarity, e.g. during the weekend, The timer stops if the mains power turn the operating mode switch (1) fails. -
Page 10: Installation Instructions
6 Installation instructions 6 Installation instructions · Release the time clock blanking plate from the control box. All electrical work shall be undertaken · Locate the five pins on the rear of the by a competent person and shall programmer and gently push the comply with BS 7671 (IEE Regulations). -
Page 11: Commissioning
Low Voltage Directive (73/23/EEC) and, in connec- tion with Vaillant heating appliances, the essential requirements of the Elec- tromagnetic Compatibility Directive (89/336/EEC). We do not accept any liability for damage resulting from non-observance of these instructions. -
Page 12: Technical Data
GB 8 Technical data Appliance type 24 hour time clock Operating voltage 24 V DC Current input 35 mA max Weight approx. 200 g Protection class IP 20 Type of enclosure Permissible storage temperature –25...+70°C... - Page 14 GB Fig. 2 Blanking plate 8 Installation recess 9 24h time clock...
- Page 15 Fig. 2 SWITCH time Fig. 2:...
- Page 16 Fig. 3 10 Pins Fig. 3:...
- Page 17 EC declaration of conformity...
