(58) MODEL 604 FILTER PUMP ENGLISH 7.5" X 10.3" PANTONE 295U 06/08/2009
Krystal Clear™
Model 604 Filter Pump
220 - 240 V~, 50 Hz, 45 W
Hmax 1.0 m, H min 0.19 m, IPX5/IPX7
Max. Water Temperature 35 °C
For illustrative purposes only.
Don't forget to try these other fine Intex products: pools, pool accessories,
inflatable pools and in-home toys, airbeds and boats available at fine
retailers or visit our website.
Rechte vorbehalten. Printed in China/Imprimé en Chine/Impreso en China/Gedruckt in China.
®™ Trademarks used in some countries of the world under license from/®™ Marques utilisées dans certains pays sous
licence de/Marcas registradas utilizadas en algunos países del mundo bajo licencia de/Warenzeichen verwendet in einigen
Ländern der Welt in Lizenz von/Intex Marketing Ltd. to/à/a/an Intex Trading Ltd., Intex Development Co. Ltd., G.P.O
Box 28829, Hong Kong & Intex Recreation Corp., P.O. Box 1440, Long Beach, CA 90801 • Distributed in the European
Union by/Distribué dans l'Union Européenne par/Distribuido en la unión Europea por/Vertrieb in der Europäischen Union
durch/Intex Trading B.V., P.O. Box nr. 1075 – 4700 BB Roosendaal – The Netherlands
IMPORTANT
SAFETY RULES
Read, understand, and follow all
instructions carefully before
installing and using this product.
©2009 Intex Marketing Ltd. - Intex Development Co. Ltd. - Intex Trading Ltd.
- Intex Recreation Corp.
All rights reserved/Tous droits réservés/Todos los derechos reservados/Alle
English
58
058**-A0-1006

Advertisement

Table of Contents
loading

Related Manuals for Intex Krystal Clear 604

Summary of Contents for Intex Krystal Clear 604

  • Page 1 Ländern der Welt in Lizenz von/Intex Marketing Ltd. to/à/a/an Intex Trading Ltd., Intex Development Co. Ltd., G.P.O Box 28829, Hong Kong & Intex Recreation Corp., P.O. Box 1440, Long Beach, CA 90801 • Distributed in the European Union by/Distribué dans l’Union Européenne par/Distribuido en la unión Europea por/Vertrieb in der Europäischen Union durch/Intex Trading B.V., P.O.

  • Page 2: Table Of Contents

    Parts List & Reference............ 4-5 Setup Instructions............6-8 Maintenance..............9-10 Pool Care and Chemicals..........9 Long Term Storage............10 Troubleshooting Guide........... 11 Common Pool Problems..........12 General Aquatic Safety........... 13 Limited Warranty............. 14 Intex Service Center Locations........15 SAVE THESE INSTRUCTIONS Page 2...

  • Page 3: Warnings

    (58) MODEL 604 FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2009 English IMPORTANT SAFETY RULES Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product. READ AND FOLLOW ALL INSTRUCTIONS WARNING • To reduce the risk of injury, do not permit children to use this product. Always supervise children and those with disabilities.

  • Page 4: Parts List & Reference

    (58) MODEL 604 FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2009 English PARTS LIST NOTE: Drawings for illustration purpose only. May not reflect actual product. Not to scale. SAVE THESE INSTRUCTIONS Page 4...

  • Page 5: Parts Reference

    (58) MODEL 604 FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2009 English PARTS REFERENCE Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. NOTE: Drawings for illustration purpose only. May not reflect actual product. Not to scale.

  • Page 6: Setup Instructions

    (58) MODEL 604 FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2009 English SETUP INSTRUCTIONS Be sure you have access to water to fill the pool and chemicals for the water. A small coin can be used to tighten the hose clamps (7). IMPORTANT: This filter pump is shipped with the air release valve (1) open (open the air release valve if necessary).
  • Page 7 (58) MODEL 604 FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2009 English SETUP INSTRUCTIONS (continued) WARNING Position this product away from the pool, so as to prevent children from climbing on it and accessing the pool. To inspect and change the filter cartridge, disconnect line cord, unscrew the pool inlet nozzle (10) and strainer grid (11) from the strainer connectors and insert the hat-like plugs into the strainer connectors before servicing the filter.

  • Page 8: Filter Pump Stationary Mounting Option

    (58) MODEL 604 FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2009 English FILTER PUMP STATIONARY MOUNTING OPTION There are three mounting holes located at the bottom of the filter pump base. These holes are provided because various country’s regulations, especially in the European community, require the filter pump to be secured to the ground or to a base in a permanent upright position.

  • Page 9: Maintenance

    (58) MODEL 604 FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2009 English POOL CARE AND CHEMICALS • All pools require care to keep the water clear and hygienically clean. With proper chemical control, your filter will help attain this objective. Consult your pool supply dealer for instructions regarding the proper use of chlorine, algaecide and other chemical agents required for sparkling clear water.

  • Page 10: Long Term Storage

    (58) MODEL 604 FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2009 English CLEANING OR REPLACING FILTER CARTRIDGES It is recommended that the filter cartridge be replaced at least every 2 weeks. 1. Make sure filter pump is not operating. Disconnect line cord. 2.

  • Page 11: Troubleshooting Guide

    (58) MODEL 604 FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2009 English TROUBLESHOOTING GUIDE TROUBLE CAUSE SOLUTION FILTER MOTOR • The motor is not plugged in. • Filter cord must be plugged into a 3 FAILS TO START • The fuse box needs checking. wire outlet that is protected by a Class •...

  • Page 12: Common Pool Problems

    • Finger tighten all caps. LEVEL • The drain valves are loose. SEDIMENT • Dirt or sand on • Heavy use, getting in • Use Intex pool vacuum to ON POOL pool floor. and out of pool. clean bottom of pool. BOTTOM SURFACE •...

  • Page 13: General Aquatic Safety

    (58) MODEL 604 FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2009 English GENERAL AQUATIC SAFETY Water recreation is both fun and therapeutic. However, it involves inherent risks of injury and death. To reduce your risk of injury, read and follow all product, package and package insert warnings and instructions.

  • Page 14: Limited Warranty

    This Limited Warranty applies only to those parts and components sold by Intex. The Limited Warranty does not cover unauthorized alterations, repairs or disassembly by anyone other than Intex Service Center personnel.

  • Page 15: Intex Service Center Locations

    AREAS LOCATION • ARGENTINA JARSE INDUSTRIAL Y COMERCIAL S.A • ASIA INTEX DEVELOPMENT CO. LTD. MANUEL GARCIA Nº124, PARQUE PATRICO, 8TH FLOOR, BUENOS AIRES, ARGENTINA DAH SING FINANCIAL CENTRE, TEL: 4942-2238 (interno 106); 108 GLOUCESTER ROAD, TEL: 4942-2238( interno 145) WANCHAI, HONG KONG E-mail: Martín Cosoleto: mcosoleto@jarse.com.ar...
  • Page 16 WEEE IO ELECTRIC PRODUCT 7.5” X 10.3”...
