Page 1: Notebook Computer
ORDER NO. CPD0305027A2 Notebook Computer CF-M34 This is the Service Manual for the following areas. G …for Germany Model Number Reference The following models are numbered in accordance with the types of CPU, LCD and HDD etc. featured by product. Model No.
Page 2: How To Replace The Fuse
If you lose the fuse cover the plug must not be used until a replacement cover is obtained. A replacement fuse cover can be purchased from your local Panasonic Dealer. IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE SOCKET OUTLET IN YOUR HOME THEN THE FUSE SHOULD BE REMOVED AND THE PLUG CUT OFF AND DISPOSED OF SAFELY.
Page 4: Exploded View
Exploded View K101 Screw tightening torque K114 A 0.176 ± 0.019N.m (1.8 ± 0.2Kgf.cm) K108 C 0.98 ± 0.1N.m (10 ± 1Kgf.cm) K114 K109 K604 K108 K603 K109 K101 K422 K101 K552 K600 K607 K101 K605 K423 K101 K351 K403 K601 K606 K101...
Page 5 K111 Screw tightening torque E100 K501 A 0.176 ± 0.019N.m (1.8 ± 0.2Kgf.cm) K500 B 0.49 ± 0.049N.m (5 ± 0.5Kgf.cm) K501 D 0.18 ± 0.02N .m (1.8 ± 0.2Kgf .cm) K505 K502 K503 K504 K408 K410 K408 K560 K407 K404 K405 K409...
Page 6: Replacement Parts List
Replacement Parts List Note: Important Safety Notice Components identified by mark have special characteristics important for safety. When replacing any of these components, use only manufacturer's specified parts. CF-M34WD6YNG REF.NO. and AREA PART NO. DESCRIPTION Q'TY Main Block Unit DL3U17077DAA PCB, MAIN DL3U47057GAA PCB, LED...
Page 7 DFMD7594ZA-0 HOLDER, PCMCIA COVER DFMX0635ZB TAPE K 10 DFMX0719XA INSULATION SHEET, LED CARD K 11 DFMX0736YA SPACER, AUDIO JACK K 14 DFMY0218ZA SHEET, CPU HEAT SINK K 15 DFMY5009ZB HEAT PIPE K 16 DFMY5010ZA PLATE, HEAT SINK K 19 DFWV80C0447 CABINET, BOTTOM K 19-1 DFHG1209ZA...
Page 8 K 88 DFHG1272ZB SHIELD SHEET, SERIAL CONNECTOR K 89 DFHG1280YA COVER SHEET, PCMCIA K351 DFHE0490ZA SHIELD SHEET, PCMCIA, BOFROST K353 DFMX0954ZA SHEET, DOC PCB, BOFROST K 403 DFHE0534ZA PCMCIA ASSIST K 404 DFMX0965ZA PCB, INSULATION SHEET T-P K 405 DFHG826ZA ASS'Y, UPPER LCD-TP SHEET K 406 DFHG827ZA...
Page 9 Replacement Parts List Comparison Table Note: Important Safety Notice Components identified by mark have special characteristics important for safety. When replacing any of these components, use only manufacturer's specified parts. CF-M34WD6YNG (03-07-07) REF. NO. PART NO. DESCRIPTION Q'TY and AREA CF-M34JA2BEG CF-M34WD6YNG Main PCB C387...
Page 10 ORDER NO. CPD0204034A2 Notebook Computer CF-M34 This is the Service Manual for the following areas. G …for Germany F …for France T …for Italy Model Number Reference The following models are numbered in accordance with the types of CPU, LCD and HDD etc. featured by product.
Page 11 Replacement Parts List Comparison Table Note: Important Safety Notice Components identified by mark have special characteristics important for safety. When replacing any of these components, use only manufacturer's specified parts. CF-M34WA4YNG/F/T REF. NO. PART NO. DESCRIPTION Q'TY and AREA CF-M34JA2BEG CF-M34WA4YNx Main Block Unit DL3U17077AAA DL3U17077CAA...
Page 12 RN5VD27CA-TR IC60 IC, DETECTOR, (DELETION) 2->1 IC80 DA72012B003D ------------- IC, USB I/O, (DELETION) 1->0 IC81 C0DBZHG00003 ------------- IC, USB I/O, (DELETION) 1->0 IC82 C0DBZHG00004 ------------- IC, USB I/O, (DELETION) 1->0 IC83, 84 DA7W66UT12L0 ------------- IC, USB I/O, (DELETION) 2->0 IC85 DA7W04UT12L0 ------------- IC, INVERTER, (DELETION)
Page 13 Exploded view...
Page 15 ORDER NO. CPD0107003A2 Notebook Computer CF-M34 This is the Service Manual for the following areas. G …for Germany Model Number Reference The following models are numbered in accordance with the types of CPU, LCD and HDD etc. featured by product. Model No.
Page 16 Replacement Parts List Comparison Table Note: Important Safety Notice Components identified by mark have special characteristics important for safety. When replacing any of these components, use only manufacturer's specified parts. CF-M34WA4YEG REF. NO. PART NO. DESCRIPTION Q'TY and AREA CF-M34JA2BEG CF-M34WA4YEG Main Block Unit DL3U17077AAA DL3U17077CAA...
Page 17 R152 ERJ3GEYJ152V RESISTOR, (DELETION) 5->4 R234, ERJ2GEJ104X RESISTOR, (DELETION) 16->13 235, 236 R385, ERJ2GEJ473X RESISTOR, (DELETION R385, 386, 16->14 386, 387, 387, ADDITION R626) ERJ3GEY0R00V R155, 157 RESISTOR, (DELETION) 9->7 R154, ERJ3GEY0R00V RESISTOR, (DELETION R154, 160, 18->20 160, 118, ADDITION R118, 119, 120, 121) 119, 120, RL1220SR12F R624, 625...
Page 18 Exploded View...
Page 20 ORDER NO. CPD0308043A1 Notebook Computer CF-M34 This is the Servic e Manual for the following areas. M …for U.S.A. and Canada Model No. CF-M34VTFZKM...
Page 21 Replacement Parts List Comparison Table Note: Important Safety Notice Components identified by mark have special characteristics important for safety. When replacing any of these components, use only manufacturer's specified parts. CF-M34VTFZKM REF. NO. and PART NO. DESCRIPTION AREA CF-M34UTFZKM CF-M34VTFZKM Main Block Unit DL3U11205CAA DL3U11205EAA...
Page 22 Exploded View K101 Screw tightening torque K565 K114 A 0.176 ± 0.019N.m (1.8 ± 0.2Kgf.cm) K402 C 0.98 ± 0.1N.m (10 ± 1Kgf.cm) K114 K109 K108 K109 K108 K101 K422 K101 K553 K552 K411 K101 K423 K101 K403 K413 K101 K101 K105 K105...
Page 23 K 111 S crew tightening torque K 67 K 70 A 0.176 ± 0.019N.m (1.8 ± 0.2K gf.cm) K 51 B 0.49 ± 0.049N.m (5 ± 0.5K gf.cm) D 0.18 ± 0.02N .m (1.8 ± 0.2K gf.cm) K 505 K 68 E 54 K 408 K 410...
Page 24 ORDER NO. CPD0309022A1 Notebook Computer CF-M34 This is the Service Manual for the following areas. M …for U.S.A. and Canada Model No. CF-M34VHFZ1 2 1: Operation System ® ® D: Microsoft Windows 2000 ® ® K: Microsoft Windows XP Professional 2: Area M: Refer to above area table...
Page 25 Replacement Parts List Comparison Table Note: Important Safety Notice Components identified by mark have special characteristics important for safety. When replacing any of these components, use only manufacturer's specified parts. CF-M34VHFZxM REF. NO. and PART NO. DESCRIPTION AREA CF-M34UHFZxM CF-M34VHFZxM Main Block Unit DL3U11205CAA DL3U11205EAA...
Page 26 Exploded View K101 Screw tightening torque K565 K114 A 0.176 ± 0.019N.m (1.8 ± 0.2Kgf.cm) K402 C 0.98 ± 0.1N.m (10 ± 1Kgf.cm) K114 K109 K108 K109 K108 K101 K422 K101 K553 K552 K411 K101 K423 K101 K403 K413 K101 K101 K105 K105...
Page 27 K 111 S crew tightening torque K 67 K 70 A 0.176 ± 0.019N.m (1.8 ± 0.2K gf.cm) K 51 B 0.49 ± 0.049N.m (5 ± 0.5K gf.cm) D 0.18 ± 0.02N .m (1.8 ± 0.2K gf.cm) K 505 K 68 E 54 K 408 K 410...
Page 28 CF-M34UxFZxx...
Page 63 CF-M34UxFZxx Printed Circuit Board 1. Main PCB<Top View>...
Page 64 2. Main PCB<Bottom View>...
Page 65: Notebook Computer
ORDER NO. CPD0210020A0 Notebook Computer CF-M34 This is the Service Manual for the following areas. M …for U.S.A. and Canada E …for U.K. G …for Germany F …for France S …for Sweden T …for Italy P …for Spain Model Number Reference The following models are numbered in accordance with the types of CPU, LCD and HDD etc.
Page 66: How To Replace The Fuse
If you lose the fuse cover the plug must not be used until a replacement cover is obtained. A replacement fuse cover can be purchased from your local Panasonic Dealer. IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE SOCKET OUTLET IN YOUR HOME THEN THE FUSE SHOULD BE REMOVED AND THE PLUG CUT OFF AND DISPOSED OF SAFELY.
Page 68: Replacement Parts List
Replacement Parts List Note: Important Safety Notice Components identified by mark have special characteristics important for safety. When replacing any of these components, use only manufacturer's specified parts. CF-M34UxFZxx REF.NO. and AREA PART NO. DESCRIPTION Q'TY Main Block Unit DL3U11205CAA PCB, MAIN DL3U27057FAA PCB, MODEM JACK...
Page 69 A 21 DFHR9039ZA-0 STYLUS PEN Note: About the parts which written " * " above, please order to Computer Products Europe (CPE) written below. Matsushita Electric (U.K.) Ltd. Computer Products Europe (CPE) TEL: +44-1222-736060 FAX: +44-1222-735500 Packing Material DFPK1061YA CASE, PACKING DFPE0598ZA CUSHION Mechanical Parts...
Page 70 K 52 DFMC0539ZA WATER RESISTING SHEET K 53 DFMX0762ZB CASE, INVERTER PCB K 54 DFBH1100ZA HINGE K 60 DFHG1299ZA-0 LCD RUBBER K 61 DFHG1300ZA-0 CAP, ANTENNA K 62 DFHG1301ZA-0 CAP, ANTENNA HOLDER K 65 DFWV80C0437 CABINET, LCD REAR K 66 DFHP7069ZA TAPE, TOUCH SCREEN PANEL PCB K 67...
Page 71 K 558 DFMX1031ZA SHEET, PCMCIA K 559 DFMD3096ZA HOLDER, USB CONNECTOR K 560 DFHG1556ZA LCD CUSHION UPPER-2 K 561 DFMC0567ZA SHIELD SHEET B K 562 (E,G,F,T,S,P) DXQN17+A3FZL SCREW K 565 XSB2+4 SCREW K 566 (E,G,F,T,S,P) DFMC0514ZA CONDUCTIVE SHEET K 567 (E,G,F,T,S,P) DFHE0354ZA CONDUCTIVE SHEET K 568 (E,G,F,T,S,P)
Page 72 Replacement Parts List Note: Important Safety Notice Components identified by mark have special characteristics important for safety. When replacing any of these components use only manufacturer's specified parts. CF-M34UxFZxx REF. NO and AREA PART NO. DESCRIPTION Q'TY Main PCB C 2 4 6 8 9 11 12 14 DCUN1C104ZFD CAPACITOR, 16V, 0.1 µF 58 59 60 61 64 65...
Page 73 C44 45 46 47 48 49 50 F1H0J1050013 CAPACITOR, 6.3V, 1 µF 51 52 53 128 130 132 134 154 157 158 196 275 285 290 303 304 317 335 346 352 358 362 364 385 422 424 444 467 468 469 492 493 498 C56 57 305 410 F1G1H471A450...
Page 74 CA 1 2 3 4 5 6 7 8 9 10 EZASCE101M CAPACITOR ARRAY 11 12 13 CN 2 DFJS356ZA004 CONNECTOR CN 3 DFJP050ZA003 CONNECTOR, RTC BATTERY CN 4 K1MN50A00006 CONNECTOR CN 5 DFJP224ZA068 CONNECTOR, PC CARD SLOT CN 6 DFJP214ZA100 CONNECTOR, DOCKING CONNECTOR PCB CN 7...
Page 75 C1DB00000908 IC, ICH3 IC 13 C0DBZHG00004 IC, USB POWER CONTROLLER IC 14 31 DA7S00UT85L0 IC, AND GATE IC 15 45 70 C1DB00000881 IC, VGA CONTROLLER IC 16 DA7ST08U85L0 IC, AND GATE IC 17 18 DAR5C4752T-R IC, PCMCIA CONTROLLER IC 19 DA2562A1BX2V IC, BIPOLAR LOGIC IC 20...
Page 76 Q 18 29 34 40 41 43 DA3LN01STL TRANSISTOR 2SD1819ARTX TRANSISTOR Q 27 DASI6410DQT1 TRANSISTOR Q 28 DETA144EETL TRANSISTOR Q 32 48 55 56 71 DAFDS6690A TRANSISTOR Q 35 45 46 DAFDS6670A TRANSISTOR Q 36 37 DAFDN359AN TRANSISTOR Q 49 50 DAFDS6912A TRANSISTOR Q 51 52 58 60 77...
Page 77 R 32 33 132 139 140 ERJ2GE0R00X RESISTOR, 1/16W, 0Ω 143 156 158 205 208 237 238 239 240 252 296 297 298 299 303 307 308 309 310 312 313 314 315 325 334 336 337 339 341 347 383 395 398 403 422 427 480 485 498 500 R 34 35 37 38 63 64...
Page 78 R 369 370 DBJ14RR068VM RESISTOR, 1/4W, 0.068Ω R 372 491 D0HA333ZA001 RESISTOR, 1/16W, 33kΩ R 373 D0HA123ZA001 RESISTOR, 1/16W, 12kΩ R 384 399 412 416 D0HA103ZA001 RESISTOR, 1/16W, 10kΩ R 385 396 ERJ2RKD5492X RESISTOR, 1/16W, 54.9kΩ R 387 388 389 390 419 D1BDR0330001 RESISTOR, 1/8W, 0.033Ω...
Page 79 SW 513 EVQPLDA15 SW, RIGHT CLICK MODEM JACK PCB C 541 F1L3D102A003 CAPACITOR, 2000V, 1000pF CN 541 DFJS555ZA004 JK, MODEM CN 542 DFJS554ZA008 CN 543 K1KA10B00151 CONNECTOR CN 544 DFJP02C75YAJ CONNECTOR, FOR INTERNAL MODEM PCB R 541 542 ERJ3GEYJ750V RESISTOR, 1/16W, 75Ω DOCKING CONNECTOR PCB CN 551 DFJS553ZA100...
Page 80: Exploded View
Exploded View K101 Screw tightening torque K565 K114 A 0.176 ± 0.019N.m (1.8 ± 0.2Kgf.cm) K402 C 0.98 ± 0.1N.m (10 ± 1Kgf.cm) K114 K109 K108 K109 K108 K101 K422 K101 K553 K552 K411 K101 K423 K101 K403 K413 K101 K101 K105 K105...
Page 81 K111 Screw tightening torque A 0.176 ± 0.019N.m (1.8 ± 0.2Kgf.cm) B 0.49 ± 0.049N.m (5 ± 0.5Kgf.cm) K408 K410 K408 K560 K407 K404 K405 K409 K107 K110 K107 K113 K105 K406 K106 K50-1 K107 K106 K109 K113 K109 K109 K414 K105 K106...
Page 82: Notebook Computer
ORDER NO. CPD0106002A2 Notebook Computer CF-M34 This is the Service Manual for the following areas. 　E　…for U.K. Model Number Reference The following models are numbered in accordance with the types of CPU, LCD and HDD etc. featured by product. Model No. CF-M34 1 2 3 1: CPU type ®...
Page 83 If you lose the fuse cover the plug must not be used until a replacement cover is obtained. A replacement fuse cover can be purchased from your local Panasonic Dealer. IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE SOCKET OUTLET IN YOUR HOME THEN THE FUSE SHOULD BE REMOVED AND THE PLUG CUT OFF AND DISPOSED OF SAFELY.
Page 85 Replacement Parts List Comparison Table Note: Important Safety Notice Components identified by mark have special characteristics important for safety. When replacing any of these components, use only manufacturer's specified parts. CF-M34TA4QDE REF. NO. and PART NO. DESCRIPTION Q'TY AREA CF-M34T42AAE CF-M34TA4QDE Main Block Unit DFJL0033ZA N2EABEC00001...
Page 86 Exploded View K101 Screw tightening torque A 0.176 ± 0.019N⋅m (1.8 ± 0.2Kgf⋅cm) C 0.98 ± 0.1N⋅m (10 ± 1Kgf⋅cm) K114 K109 K108 K109 K108 K101 K101 K101 K304 K101 K302 K300 K102 K105 K301 K307 K105 K101 K105 K105 K315 K315 K306...
Page 87 K111 Screw tightening torque A 0.176 ± 0.019N⋅m (1.8 ± 0.2Kgf⋅cm) B 0.49 ± 0.049N⋅m (5 ± 0.5Kgf⋅cm) K310 K311 K311 K107 K110 K107 K313 K113 K106 K309 K106 K50-1 K107 K106 K109 K113 K109 K109 K106 K106 K314 CF-M34TA4QDE...
Page 123 CF-M34RxFZxx Printed Circuit Board 1. Main PCB<Top View>...
Page 124 2. Main PCB<Bottom View>...
Page 125: Notebook Computer
ORDER NO. CPD0207021A0 Notebook Computer CF-M34 This is the Service Manual for the following areas. M …for U.S.A. and Canada E …for U.K. G …for Germany F …for France S …for Sweden T …for Italy P …for Spain Model Number Reference The following models are numbered in accordance with the types of CPU, LCD and HDD etc.
Page 126: How To Replace The Fuse
If you lose the fuse cover the plug must not be used until a replacement cover is obtained. A replacement fuse cover can be purchased from your local Panasonic Dealer. IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE SOCKET OUTLET IN YOUR HOME THEN THE FUSE SHOULD BE REMOVED AND THE PLUG CUT OFF AND DISPOSED OF SAFELY.
Page 128: Exploded View
Exploded View K101 Screw tightening torque K114 A 0.176 ± 0.019N.m (1.8 ± 0.2Kgf.cm) K402 C 0.98 ± 0.1N.m (10 ± 1Kgf.cm) K114 K109 K108 K109 K108 K101 K422 K101 K553 K552 K411 K101 K423 K101 K403 K413 K101 K101 K105 K105 K558...
Page 129 K111 Screw tightening torque A 0.176 ± 0.019N.m (1.8 ± 0.2Kgf.cm) B 0.49 ± 0.049N.m (5 ± 0.5Kgf.cm) K408 K410 K408 K560 K407 K404 K405 K409 K107 K110 K107 K113 K105 K406 K106 K50-1 K107 K106 K109 K113 K109 K109 K414 K105 K106...
Page 130: Replacement Parts List
Replacement Parts List Note: Important Safety Notice Components identified by mark have special characteristics important for safety. When replacing any of these components, use only manufacturer's specified parts. CF-M34RxFZxx REF.NO.and AREA PART NO. DESCRIPTION Q'TY Main Block Unit DL3U11205AAA PCB, MAIN DL3U27057FAA PCB, MODEM JACK DL3U37057FAA...
Page 131 Note: About the parts which written " * " above, please order to Computer Products Europe (CPE) written below. Matsushita Electric (U.K.) Ltd. Computer Products Europe (CPE) TEL: +44-1222-736060 FAX: +44-1222-735500 Packing Material DFPK1061YA CASE, PACKING DFPE0598ZA CUSHON Mechanical Parts DFMD7583ZB PLATE, DOCKING CONNECTOR PCB DFMD7584ZA...
Page 132 K 53 DFMX0762ZB CASE, INVERTER PCB K 54 DFBH1100ZA HINGE K 60 DFHG1299ZA-0 LCD RUBBER K 61 DFHG1300ZA-0 CAP, ANTENNA K 62 DFHG1301ZA-0 CAP, ANTENNA HOLDER K 65 DFWV80C0437 CABINET, LCD REAR K 66 DFHP7069ZA TAPE, TOUCH SCREEN PANEL PCB K 67 DFKE0496ZA-1 HOLDER, BUCKLE...
Page 133 K 559 DFMD3096ZA HOLDER, USB CONNECTOR K 560 DFHG1556ZA LCD CUSHION UPPER-2 K 561 DFMC0567ZA SHIELD SHEET B K 562 (E, G, F, T, S, P) DXQN17+A3FZL SCREW K 101 XSB2+4FNL SCREW K 103 XYN2+J10FN SCREW K 104 XYN2+J4FN SCREW K 105 XYN2+J6FN SCREW...
Page 134 Replacement Parts List Note: Important Safety Notice Components identified by mark have special characteristics important for safety. When replacing any of these components use only manufacturer's specified parts. CF-M34RxFZxx REF. NO and AREA PART NO. DESCRIPTION Q'TY Main PCB C 2 4 6 8 9 11 12 14 DCUN1C104ZFD CAPACITOR, 16V, 0.1 µF 58 59 60 61 64 65...
Page 135 C 44 45 46 47 48 49 50 F1H0J1050013 CAPACITOR, 6.3V, 1 µF 51 52 53 128 130 132 134 154 157 158 196 275 285 290 303 304 317 335 346 352 358 362 364 385 422 424 444 467 468 469 492 493 498 C56 57 305 410 F1G1H471A450...
Page 136 CA 1 2 3 4 5 6 7 8 9 10 EZASCE101M CAPACITOR ARRAY 11 12 13 CN 2 DFJS356ZA004 CONNECTOR CN 3 DFJP050ZA003 CONNECTOR, FOR RTC BATTERY CN 4 K1MN50A00006 CONNECTOR CN 5 DFJP224ZA068 CONNECTOR, FOR PC CARD SLOT CN 6 DFJP214ZA100 CONNECTOR, FOR DOCKING CONNECTOR PCB...
Page 137 C1DB00000908 IC, ICH3 IC 13 C0DBZHG00004 IC, USB POWER CONTROLLER IC 14 31 DA7S00UT85L0 IC, AND GATE IC 15 45 70 C1DB00000881 IC, VGA CONTROLLER IC 16 DA7ST08U85L0 IC, AND GATE IC 17 18 DAR5C4752T-R IC, PCMCIA CONTROLLER IC 19 DA2562A1BX2V IC, BIPOLAR LOGIC IC 20...
Page 138 Q 18 29 34 40 41 43 DA3LN01STL TRANSISTOR 2SD1819ARTX TRANSISTOR Q 27 DASI6410DQT1 TRANSISTOR Q 28 DETA144EETL TRANSISTOR Q 32 48 55 56 71 DAFDS6690A TRANSISTOR Q 35 45 46 DAFDS6670A TRANSISTOR Q 36 37 DAFDN359AN TRANSISTOR Q 49 50 DAFDS6912A TRANSISTOR Q 51 52 58 60 77...
Page 139 R 32 33 132 139 140 ERJ2GE0R00X RESISTOR, 1/16W, 0Ω 143 156 158 205 208 237 238 239 240 252 296 297 298 299 303 307 308 309 310 312 313 314 315 325 334 336 337 339 341 347 383 395 398 403 422 427 480 485 498 500 R 34 35 37 38 63 64...
Page 140 R 369 370 DBJ14RR068VM RESISTOR, 1/4W, 0.068Ω R 372 491 D0HA333ZA001 RESISTOR, 1/16W, 33kΩ R 373 D0HA123ZA001 RESISTOR, 1/16W, 12kΩ R 384 399 412 416 D0HA103ZA001 RESISTOR, 1/16W, 10kΩ R 385 396 ERJ2RKD5492X RESISTOR, 1/16W, 54.9kΩ R 387 388 389 390 419 D1BDR0330001 RESISTOR, 1/8W, 0.033Ω...
Page 141 SW 513 EVQPLDA15 SW,RIGHT CLICK MODEM JACK PCB C 541 F1L3D102A003 CAPACITOR, 2000V, 1000pF CN 541 DFJS555ZA004 JK, MODEM CN 542 DFJS554ZA008 CN 543 K1KA10B00151 CONNECTOR CN 544 DFJP02C75YAJ CONNECTOR, FOR INTERNAL MODEM PCB R 541 542 ERJ3GEYJ750V RESISTOR, 1/16W, 75Ω DOCKING CONNECTOR PCB CN 551 DFJS553ZA100...
Page 142 Schematic Diagrams 1. Main PIII/GCL(1/2)
Page 143 2. Main PIII/GCL(2/2)
Page 144 3. Main BANISTER(1/3)
Page 145 4. Main CLOCK GENERATOR...
Page 146 5. Main ONBOARD MEMORY...
Page 147 6. Main SO DIMM...
Page 148 7. Main BANISTER(2/3)
Page 149 8. Main BANISTER(3/3)
Page 150 9. Main HDD CONNECTOR...
Page 151 10. Main VGA...
Page 152 11. Main LCD & CRT I/F...
Page 153 12. Main PCMCIA...
Page 154 13. Main PCMCIA I/F...
Page 155 14. Main SUPER I/O(1/2)
Page 156 15. Main SUPER I/O(2/2)
Page 157 16. Main I/O I/F...
Page 158 17. Main KBC...
Page 159 18. Main BIOS ROM...
Page 160 19. Main PMC...
Page 161 20. Main RES./SW/LED...
Page 162 21. Main BT & SI_I/F...
Page 163 22. Main AC97...
Page 164 23. Main AMP/PHONES...
Page 165 24. Main MICROPHONES...
Page 166 25. Main MINI PCI CONN...
Page 167 26. Main RF I/F...
Page 168 27. Main DCIN,BATT,INV...
Page 169 28. Main 5V/3.3V,12V...
Page 170 29. Main VCPUCORE(VC1)
Page 171 30. Main 2.5V,1.5V...
Page 172 31. Main RF DC/DC(5V/4.5V)
Page 173 32. Main CHARGER...
Page 174 33. Main SAFETY CIRCUIT...
Page 175 Printed Circuit Board Main PCB <Top View>...
Page 176 Main PCB <Bottom View>...
Page 177: Notebook Computer
ORDER NO. CPD0201011A0 Notebook Computer CF-M34 This is the Service Manual for the following areas. M …for U.S.A. and Canada E …for U.K. G …for Germany F …for France S …for Sweden T …for Italy P …for Spain Model Number Reference The following models are numbered in accordance with the types of CPU, LCD and HDD etc.
Page 178: How To Replace The Fuse
If you lose the fuse cover the plug must not be used until a replacement cover is obtained. A replacement fuse cover can be purchased from your local Panasonic Dealer. IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE SOCKET OUTLET IN YOUR HOME THEN THE FUSE SHOULD BE REMOVED AND THE PLUG CUT OFF AND DISPOSED OF SAFELY.
Page 180: Exploded View
Exploded View K101 Screw tightening torque K114 A 0.176 ± 0.019N. m (1.8 ± 0.2Kgf .cm) K402 C 0.98 ± 0.1N. m K114 (10 ± 1Kgf .cm) K109 K108 K109 K108 K101 K422 K101 K411 K101 K423 K101 K403 K101 K101 K105 K105...
Page 181 K111 Screw tightening torque A 0.176 ± 0.019N m (1.8 ± 0.2Kgf cm) B 0.49 ± 0.049N m (5 ± 0.5Kgf cm) K408 K410 K408 K407 K404 K405 K409 K107 K110 K107 K113 K105 K406 K106 K50-1 K107 K106 K109 K113 K109 K109...
Page 182 Replacement Parts List Note: Important Safety Notice Components identified by mark have special characteristics important for safety. When replacing any of these components, use only manufacturer's specified parts. CF-M34NPFZxM /M34NEFZxx REF.NO.and AREA PART NO. DESCRIPTION Q'TY Main Block Unit DL3U17119AAA PCB, MAIN DL3U27057FAA PCB, MODEM JACK...
Page 183 Packing Material DFPK1061YA CASE, PACKING DFPE0598ZA CUSHON Mechanical Parts DFMD7584ZA PLATE, DOCKING COVER DFWV84F0080 COVER, KEYBOARD FPC DFWV84F0081 COVER, LCD FPC DFMD7589ZA PLATE, RF FRONT DFMD7592ZA PLATE, AUDIO JACK DFMD7594ZA-0 HOLDER, PCMCIA COVER DFMX0635ZB TAPE K 10 DFMX0719XA INSULATION SHEET, LED CARD K 11 DFMX0736YA SPACER, AUDIO JACK...
Page 184 K 69 DFGB0077ZA-1 TOUGHBOOK LABEL K 70 DFBS0055ZA-1 BUCKLE K 71 DFQT6077YA LABEL, CAUTION, INVERTER K 74 DFMD7581ZA HDD CASE UPPER K 75 DFMD7582ZA HDD CASE LOWER K 76 DFHG1260ZC CUSHION, HDD K 77 DFMD7591ZA-1 COVER, HINGE K 80(M) DFGT0753ZA-0 LABEL, RATING K 80(E,G,F,S,T) DFGT0775ZA...
Page 185 Replacement Parts List Note: Important Safety Notice Components identified by mark have special characteristics important for safety. When replacing any of these components, use only manufacturer's specified parts. CF-M34NPFZxM/M34NEFZxx REF.NO.and AREA PART NO. DESCRIPTION Q'TY Main PCB DCS0ETC221M CAPACITOR, 2.5V, 220µF C 2 3 366 DCS0ETC221M CAPACITOR, 2.5V, 220µF...
Page 186 C 111 114 117 120 191 237 DCSG0JP100RR CAPACITOR, 6.3V, 10µF 287 301 304 C 121 225 360 363 DCUJ1A105ZFL CAPACITOR, 10V, 1µF C 131 183 184 265 410 426 ECST1AX226R CAPACITOR, 10V, 22µF C 185 ICUV1C475ZFX CAPACITOR, 16V, 4.7µF C 188 189 ICUV1H680JCS CAPACITOR, 50V, 68pF...
Page 187 C 679 DCUC1C475KBY CAPACITOR, 16V, 4.7µF C 688 16CV47FH CAPACITOR,16V, 47µF C 701 ICUV1H222KBS CAPACITOR, 50V, 2200pF C 711 F1G1H221A401 CAPACITOR, 50V, 220pF CA 3 4 5 6 7 8 9 10 11 12 13 14 EZASCE101M CAPACITOR ARRAY CN 2 DFJS548ZA004 CONNECTOR, USB PORT CN 3...
Page 188 IC 4 DA9716CTBX3A IC, CLOCK IC 5 7 9 11 DASM716FTL80 IC, SDRAM IC 13 15 30 DA7S04UT85L0 IC, INVERTER IC 14 53 C0DBZHG00003 IC, USB POWER CONTROL SWITCH IC 22 23 DA7ST08U85L0 IC, AND GATE IC 27 48 DA97338VJA2N IC, SUPER I/O IC 29 DA38802M280M...
Page 189 L 27 DEAM60R3T222 FILTER L 28 G1C100KA0002 FERRITE BEAD L 30 31 32 33 34 ILH0070AA TRANSFORMER L 44 DDB5Z024E-L FERRITE BEAD L 45 46 G1C22NJA0007 COIL L 603 604 G1A100ZA0004 COIL L 605 DDAZS1R8MTZE COIL L 606 G1A150ZA0004 COIL L 607 G1A220ZA0004 COIL...
Page 190 R 23 66 67 75 82 272 301 321 ERJ2GEJ102X RESISTOR, 1/16W, 1kΩ 371 382 417 424 425 426 700 R 28 58 76 77 138 139 142 143 ERJ2GEJ103X RESISTOR, 1/16W, 10kΩ 166 329 334 339 342 346 383 415 448 601 634 656 660 674 691 693 699 701 760 R 33 36 47 56 63 71 73 74 86...
Page 191 R 196 197 ERJ3GEYJ682V RESISTOR, 1/16W, 6.8kΩ R 198 ERJ12YJ3R3H RESISTOR, 1/2W,3.3Ω R 235 270 273 274 279 282 ERJ2GEJ104X RESISTOR, 1/16W, 100KΩ 307 310 311 320 322 335 336 338 648 649 736 741 750 758 R 265 286 292 ERJ3GEYJ101V RESISTOR, 1/16W, 100Ω...
Page 192 RA 21 22 23 24 25 26 27 28 29 DEARA8CJ100M RESISTOR ARRAY, 10Ω RA 30 31 32 48 53 56 57 58 73 DEARA8AJ103M RESISTOR ARRAY, 10kΩ RA 33 EXBV8V330JV RESISTOR ARRAY, 33Ω RA 34 35 36 DEARA8CJ330M RESISTOR ARRAY, 33Ω RA 37 38 EXBV8VR000V RESISTOR ARRAY, 0Ω...
Page 193 CN 544 DFJP02C75YAJ CONNECTOR, FOR INTERNAL MODEM PCB R 541 542 ERJ3GEYJ750V RESISTOR, 1/16W, 75Ω DOCKING CONNECTOR PCB CN 551 DFJS553ZA100 CONNECTOR, FOR PORT REPLICATOR CN 552 DFJS226ZA100 CONNECTOR, FOR MAIN PCB HDD FPC CN 1 DFJS502ZA044 CONNECTOR, FOR HDD LCD FPC CN 1 K1KB30A00066...
Page 194 ORDER NO. CPD0109001A2 Notebook Computer CF-M34 Model Number Reference The following models are numbered in accordance with the types of CPU, LCD and HDD etc. featured by product. Model No. CF-M341 2 DW 3 4 1: CPU type ® ® J: for Intel Mobile Pentium III Processor 400 MHz LV...
Page 195 Replacement Parts List Comparison Table Note: Important Safety Notice Components identified by mark have special characteristics important for safety. When replacing any of these components, use only manufacturer's specified parts. CF-M34JADWDL REF. NO. and PART NO. DESCRIPTION Q'TY AREA CF-M34JA2Bxx CF-M34JADWDL Main Block Unit DL3U27057BAA...
Page 196 ORDER NO. CPD0202002A2 Notebook Computer CF-M34 This is the Service Manual for the following areas. T …for Italy Model Number Reference The following models are numbered in accordance with the types of CPU, LCD and HDD etc. featured by product. Model No.
Page 197 If you lose the fuse cover the plug must not be used until a replacement cover is obtained. A replacement fuse cover can be purchased from your local Panasonic Dealer. IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE SOCKET OUTLET IN YOUR HOME THEN THE FUSE SHOULD BE REMOVED AND THE PLUG CUT OFF AND DISPOSED OF SAFELY.
Page 199 Replacement Parts List Comparison Table Note: Important Safety Notice Components identified by mark have special characteristics important for safety. When replacing any of these components, use only manufacturer's specified parts. CF-M34JADUET REF. NO. and PART NO. DESCRIPTION Q'TY AREA CF-M34JA2BxT CF-M34JADUET Main Block Unit DL3U27057BAA ------------...
Page 200: Exploded View
Exploded View K101 Screw tightening torque A 0.176 ± 0.019N.m K114 (1.8 ± 0.2Kgf.cm) C 0.98 ± 0.1N.m (10 ± 1Kgf.cm) K114 K109 K108 K109 K108 K101 K101 K301 K101 K101 K101 K105 K101 K105 K105 K101 K105 K105 K101 K101 K101 K105...
Page 201 ORDER NO. CPD0106003A0 Notebook Computer CF-M34 This is the Service Manual for the following areas. 　E　…for U.K. 　G　…for Germany 　F　…for France 　S　…for Sweden 　T　…for Italy 　P　…for Spain Model Number Reference The following models are numbered in accordance with the types of CPU, LCD and HDD etc. featured by product.
Page 202 If you lose the fuse cover the plug must not be used until a replacement cover is obtained. A replacement fuse cover can be purchased from your local Panasonic Dealer. IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE SOCKET OUTLET IN YOUR HOME THEN THE FUSE SHOULD BE REMOVED AND THE PLUG CUT OFF AND DISPOSED OF SAFELY.
Page 204 Replacement Parts List Comparison Table Note: Important Safety Notice Components identified by mark have special characteristics important for safety. When replacing any of these components, use only manufacturer's specified parts. CF-M34JABBxx REF. NO. and PART NO. DESCRIPTION Q'TY AREA CF-M34JA2Bxx CF-M34JABBxx Main Block Unit DL3U27057BAA ------------...
Page 205 Exploded View K101 Screw tightening torque A 0.176 ± 0.019N.m K114 (1.8 ± 0.2Kgf.cm) C 0.98 ± 0.1N.m (10 ± 1Kgf.cm) K114 K109 K108 K109 K108 K101 K101 K301 K101 K101 K101 K101 K105 K105 K105 K101 K105 K105 K101 K101 K101 K105...
Page 206 Main 1 CPU HOSTBUS...
Page 207 Main 2 CPU POWER...
Page 208 Main 3 855GME DDR,HOSTBUS...
Page 209 Main 4 855GME POWER,VIDEO...
Page 210 Main 5 DDR DUMP R...
Page 211 Main 6 ON BOARD MEMORY BANK 0...
Page 212 Main 7 SO-DIMM BANK 2/3...
Page 213 Main 8 DDR TERM...
Page 214 Main 9 CLOCK GENERATOR...
Page 215 Main 10 ICH4-M...
Page 216 Main 11 ICH4-M POWER...
Page 217 Main 12 HDD,HEATER,USB I/F...
Page 218 Main 13 LCD,BACKLIGHT I/F...
Page 219 Main 14 CARD-BUS CONTROLLER.SLOT...
Page 220 Main 15 FWH...
Page 221 Main 16 SUPER I/O...
Page 222 Main 17 LAN...
Page 223 Main 18 KBC&EC...
Page 224 Main 19 KBD,PAD,LED I/F...
Page 225 Main 20 AC97 CODEC...
Page 226 Main 21 AUDIO AMP,H/P,MIC I/F...
Page 227 Main 22 EXT,I/O I/F...
Page 228 Main 23 MINI PCI RELAY I/F...
Page 229 Main 24 RS-232C,COM1...
Page 230 Main 25 RESETS,POWER SW...
Page 231 Main 26 CONFIG I/F...
Page 232 Main 27 CPU CORE DC/DC...
Page 233 Main 28 VCCP VMCH DC/DC...
Page 234 Main 29 2.5V,1.5V DC/DC...
Page 235 Main 30 1.25V REGULATOR,GMCH ERATTA...
Page 236 Main 31 3.3V,5V DC/DC...
Page 237 Main 32 1.5V,1.8V REGULATOR...
Page 238 Main 33 LOAD SW,OFF SW,OVP...
Page 239 Main 34 DC IN,BATTERY...
Page 240 Main 35 CHARGER...
Page 241 Sub 1 TS-PS2...
Page 242 Sub 2 LVDS...
Page 243 Sub 3 MINI PCI RELAY CARD...
Page 244 Sub 4 DOC STACK...
Page 245 Sub 1 TS-PS2...
Page 246 Sub 2 LVDS...
Page 247 Sub 3 MINI PCI RELAY CARD...
Page 248 Sub 4 DOC STACK...
Page 249 Main Board (Top View)
Page 250 Main Board (Bottom View)
Page 251 Mini PCI Board (Top View) LVDS Board (Top View) Dock Stack Board (Top View) CN103 Mini PCI Board (Bottom View) LVDS Board (Bottom View) Dock Stack Board (Bottom View) CN300...
Page 252: Notebook Computer
ORDER NO. CPD0402022A1 Notebook Computer CF-M34 This is the Service Manual for the following areas. M …for U.S.A. and Canada Model No. CF-M34CGFZ1 2 1: Operation System ® ® D: Microsoft Windows 2000 ® ® K: Microsoft Windows XP Professional 2: Area M: Refer to above area table ©...
Page 253: Replacement Parts List
Replacement Parts List Note: Important Safety Notice Components identified by mark have special characteristics important for safety. When replacing any of these components, use only manufacturer's specified parts. CF-M34CGFZxM REF.NO. and AREA PART NO. DESCRIPTION Q'TY Main Block Unit DL3U11351AAA PCB, MAIN DL3U27057HAA PCB, MODEM JACK...
Page 254: Mechanical Parts
DFPE0598ZA CUSHION Mechanical Parts DFMD7583ZC PLATE, DOCKING CONNECTOR PCB DFMD7584YA PLATE, DOCKING COVER DFWV84F0080 COVER, KEYBOARD FPC DFWV84F0081 COVER, LCD FPC DFMD7589ZB PLATE, RF FRONT DFMD7592ZA PLATE, AUDIO JACK DFMD7594ZA-0 HOLDER, PCMCIA COVER DFMX0635ZB TAPE K 10 DFMX0719XA INSULATION SHEET, LED CARD K 11 DFMX0736YA SPACER, AUDIO JACK...
Page 255 K 68 DFGB0075ZA-0 LOGO BADGE K 69 DFGB0077ZA-1 TOUGHBOOK LABEL K 70 DFBS0055YA-1 BUCKLE K 71 DFQT6077YA LABEL, CAUTION, INVERTER K 74 DFMD7581ZB HDD CASE UPPER K 75 DFMD7582ZA HDD CASE LOWER K 76 DFHG1613ZA CUSHION, HDD K 77 DFMD7591ZA-1 COVER, HINGE K 80 DFGT0753YA-0...
Page 256 K 115 XYN2+J5FZ SCREW K700 DFHE0891ZA INSU SHEET, DOCKING PCB K701 DFMX1119ZA INSU SHEET, RELAY PCB K702 XSB2+4FNL SCREW K703 DFHR3571YA LCD BACK CUSHION S K704 DFHR3800ZA MINI PCI CARD TAPE K705 DFHR3801ZA MDC MODEM TAPE K706 XYN2+J8FZ SCREW K707 DXHM0063ZB SCREW K708...
Page 257 Replacement Parts List Note: Important Safety Notice Components identified by mark have special characteristics important for safety. When replacing any of these components use only manufacturer's specified parts. CF-M34CGFZxM Q'TY REF. NO and AREA PART NO. DESCRIPTION Main PCB C 1 2 286 287 288 EEFUD0D271XR CAPACITOR, 2V, 270µF C 110 181 224 226 248 311 312 318...
Page 258 C 62 63 64 95 116 125 138 139 143 DCUM1A1051BD CAPACITOR, 10V, 1µF 144 188 189 191 194 195 196 199 205 206 215 221 275 283 354 355 384 413 439 444 456 457 469 497 503 517 C 674 F1H1E472A050 CAPACITOR, 25V, 4700pF...
Page 259 B0JCCE000002 DIODE D 51 MAZ80620ML DIODE DEDRB081L20 DIODE D 7 9 631 632 B0JCMD000014 DIODE D 8 14 630 B0JDAE000004 DIODE F 1 2 3 5 K5H202Z00005 FUSE, 2A K5H502Z00003 FUSE, 5A IC 1 C2GBC0000191 IC, CPU IC 10 45 46 DA7W66UT12L0 IC, CMOS IC 12...
Page 260 G1C1R6Z00001 INDUCTOR L 9 10 G1C4R7MA0106 INDUCTOR LA 1 2 J0MAB0000159 INDUCTOR ARRAY PS 3 MINISMDC0752 POLY SW B1HBCFA00006 TRANSISTOR Q 10 20 646 B1DBGD000002 TRANSISTOR Q 13 14 28 31 75 77 650 DAFDS6912A TRANSISTOR Q 18 B1DFGD000026 TRANSISTOR Q 19 21 81 B1DHFD000009 TRANSISTOR...
Page 261 R 2 148 161 172 307 309 314 315 ERJ2GEJ101X RESISTOR, 1/16W, 100Ω 316 317 318 334 335 374 462 470 R 204 ERJ2GEJ302X RESISTOR, 1/16W, 3KΩ R 205 352 484 ERJ2RKF1503X RESISTOR, 1/16W, 150KΩ R 206 733 ERJ2RKF5102X RESISTOR, 1/16W, 51KΩ R 210 272 320 340 377 415 416 417 ERJ2GEJ473X RESISTOR, 1/16W, 47KΩ...
Page 262 R 63 84 87 88 89 90 92 93 94 95 ERJ2GEJ103X RESISTOR, 1/16W, 10KΩ 125 128 129 159 178 182 186 218 223 228 229 278 284 285 333 347 360 362 364 376 378 379 380 381 384 385 387 408 409 410 421 422 424 426 427 430 431 444 446 466 467 469 475 575 580 581 698 719 R 64 286...
Page 263 C 119 DCUN1C104ZFD CAPACITOR, 16V, 0.1µF CN 101 DFJS511ZA124 CONNECTOR CN 102 DFJS226ZA100 CONNECTOR CN 103 K1KB30A00139 CONNECTOR L 101 DDB5Z005-L INDUCTOR R 102 ERJ2GEJ103X RESISTOR, 1/16W, 10KΩ R 110 ERJ2GEJ330X RESISTOR, 1/16W, 33Ω R 111 ERJ2GEJ101X RESISTOR, 1/16W, 100Ω PORT DOCK PCB C 303 304 305 F1G1H220A451...
Page 264: Screw Tightening Torque
Exploded View K101 Screw tightening torque K565 K114 A 0.18 ± 0.02N . m (1.8 ± 0.2Kgf.cm) K402 C 0.98 ± 0.1N.m K717 (10 ± 1Kgf.cm) K721 K114 K109 D 0.2 ± 0.02N.m K108 (2.0 ± 0.2Kgf.cm) K109 K108 K101 K422 K101 K553...
Page 265 Screw tightening torque K111 A 0.18 ± 0.02N. m (1.8 ± 0.2Kgf.cm) B 0.49 ± 0.049N.m (5 ± 0.5Kgf.cm) D 0.2 ± 0.02N.m (2.0 ± 0.2Kgf.cm) E700 K408 K410 K408 E703 K560 K407 K404 K405 K409 K110 K107 K107 K113 K105 K716 K406...
Page 266 ORDER NO. CPD0010004S0 Notebook Computer C.-M34 This is the Service Manual for the following areas. M ...for U.S.A. and Canada E ...for U.K. G ...for Germany ..for .rance S ...for Sweden T ...for Italy Applied Model C.-M34T42AAx Parts Comparison Table PART NO.
