- Page 1 AIMS POWER INVERTER 2500 WATT / 5000 WATT PEAK INPUT VOLTAGE 24 VOLTS DC PWRINV2.5K24V ASSEMBLY AND OPERATING INSTRUCTIONS TO PREVENT SERIOUS INJURY, READ AND UNDERSTAND ALL WARNINGS AND INSTRUCTIONS BEFORE USE.
-
Page 2: Specifications
Specifications 2500 Watts 5000 Watts Input Voltage 24 Volts DC (34V over voltage protection) s t l 30 Amps, 10 Qty. " " " 11 Ibs n, Volt and Amp LED bar graph c t i ° c i t ;... - Page 3 Observe work area conditions. Do not use machines or power tools in damp or wet locations. Don’t expose to rain. Keep work area well lit. Do not use electrically powered tools in the presence of flammable gases or liquids. Keep children away. Children must never be allowed in the work area. Do not let them handle machines, tools, or extension cords.
- Page 4 Unpacking When unpacking, check to make sure that the Inverter is in good condition. If any parts are missing or broken, please call AIMS Power,Inc. at the number found on the warranty card.
- Page 5 BACK Ground Negative Positive Connection For the power inverter to work properly, your power source must provide 24 volts DC, and the power source must provide enough current (i.e., 46 amps to operate the load of 560 Watts or under). Caution: This inverter must only be connected to batteries with a nominal output voltage of 24 volts.
-
Page 6: Operation
FRONT Power Switch Indicator Remote Outlets Display (covered) Operation Warning: NEVER operate this inverter unless it is properly grounded. Open the rubber cover on the receptacle(s) and plug the 115 VAC device(s) you wish to power into the 3-prong AC Receptacles. See FRONT above. The appliance(s) must not use more than 2500 (total) watts during continuous operation, otherwise it may overload the Inverter. -
Page 7: Remote On/Off Switch
Now you are ready to open the fuse cover and replace or check the fuses. This device does not contain any other user replaceable parts.If it needs service,contact your retailer or AIMS Power(see warranty page for details). Fuses can be replacement by user. -
Page 8: Troubleshooting Tips
Troubleshooting Tips If the low battery alarm sounds, this means that the input voltage is below the necessary 21 V. The battery needs recharging. You should stop using the appliance and then recharge the battery. If this is not done, the Inverter will shut off automatically at around 20 V. - Page 9 RA# prepaid to AIMS. You have a full 1 year from date of purchase warranty. This warranty is valid world wide with the exception that freight and duth charges incurred outside the contiguous 48 United States will be prepaid by customer.
