Service Manual

ViewSonic VX510-1
Model No. VS10090
15" Color TFT LCD Display
(VX510_SM_833 Rev. 1a May 2004)
ViewSonic 381 Brea Canyon Road, Walnut, California 91789 USA - (800) 888-8583

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VX510-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ViewSonic VX510-1

Summary of Contents for ViewSonic VX510-1

  • Page 1: Service Manual

    Service Manual ViewSonic VX510-1 Model No. VS10090 15” Color TFT LCD Display (VX510_SM_833 Rev. 1a May 2004) ViewSonic 381 Brea Canyon Road, Walnut, California 91789 USA - (800) 888-8583...

  • Page 2: Revision History

    Further, ViewSonic reserves the right to revise this publication and to make changes from time to time in the contents hereof without obligation of ViewSonic to notify any person of such revision or changes.

  • Page 3: Table Of Contents

    4. Circuit Description 5. Adjusting Procedure 6. Trouble Shooting Flow Chart 7. Recommended Spare Parts List 8. Exploded Diagram And Spare Parts List 9. Block Diagram 10. Schematic Diagrams 11. PCB Layout Diagrams Confidential - Do Not Copy ViewSonic Corporation VX510...

  • Page 4: Precautions And Safety Notices

    TFT Module even momentary. At designing the enclosure, it should be taken into consideration that no bending/twisting forces are applied to the TFT Module from outside. Otherwise the TFT Module may be damaged. Confidential - Do Not Copy ViewSonic Corporation VX510...
  • Page 5 Do not touch the surface of the cause “mura”. polarizer. Take out the monitor with cushions. Take out the monitor by grasping the LCD panel. That may cause “mura”. Confidential - Do Not Copy ViewSonic Corporation VX510...
  • Page 6 Place the monitor on a clean and soft foam pad. Placing the monitor on foreign objects. That may scratch the surface of the panel, or cause “mura”. The panel is placed face-down on the lap. That may cause “mura”. Confidential - Do Not Copy ViewSonic Corporation VX510...

  • Page 7: Specification

    80 MHz Primary Preset 1024x768 @ 60Hz Timing Table Timing -- Analog -- Item Resolution 640 x 350 @ 70Hz, 31.5kHz 640 x 400 @ 70Hz, 31.5kHz 640 x 480 @ 60Hz, 31.5kHz Confidential - Do Not Copy ViewSonic Corporation VX510...
  • Page 8 250 cd/m2 (Typ after 30 minute warm up) CT = 6500K, Contrast = Max, 200 cd/m2 (Min after 30 minute warm up) Brightness = Max Brightness Uniformity ¡µL5=Max 1.3 ¡µL5 = Maximum Luminance / Minimum Luminance Confidential - Do Not Copy ViewSonic Corporation VX510...
  • Page 9 Storage Temperature -20°C to +60°C Operating Relative Humidity 10% to 80% RH Non-Condensing Storage Relative Humidity 10% to 90% RH Non-Condensing Operating Altitude 0 to +3,000 meters Storage Altitude 0 to +12,000 meters Confidential - Do Not Copy ViewSonic Corporation VX510...
  • Page 10 Date: Fri Nov 14, 2003 ______________________________________________________________________ ______________________________________________________________________ VIEWSONIC CORPORATION EDID Version # 1, Revision # 3 DDCTest For: ViewSonic VX510 ______________________________________________________________________ ______________________________________________________________________ 128 BYTES OF EDID CODE: ________________________________________ 0 | 00 FF FF FF FF FF FF 00 5A 63...
  • Page 11 1024 X 768 @ 75Hz (VESA) (37) Manufacturer's Reserved Timing: None Specified (38-53) Standard Timing Identification: Not Used Not Used Not Used Not Used Not Used Not Used Not Used Not Used Confidential - Do Not Copy ViewSonic Corporation VX510...
  • Page 12 Max Horiz. Freq - 60 KHz Pixel Clock - 80 MHz Secondary GTF - Not Supported ______________________________________________________________________ (108-125) Detailed Timing / Descriptor Block 4: Monitor Name: VX510 (126) No Extension EDID Block(s) (127) CheckSum OK Confidential - Do Not Copy ViewSonic Corporation VX510...

  • Page 13: Front Panel Function Control Description

    Displays the control screen for the highlighted control. Also toggles between two controls on some screens. Power light Green = ON Orange = Power Saving Power On/Off Confidential - Do Not Copy ViewSonic Corporation VX510...
  • Page 14 • If necessary, make small adjustments using H POSITION and V POSITION until the screen image is completely visible . (The black border around the edge of the screen should barely touch the illuminated “active area” of the LCD display.) Confidential - Do Not Copy ViewSonic Corporation VX510...
  • Page 15 2. The Auto Image Adjust and most Manual Image Adjust functions are not available for DVI input. adjusts the difference between the image background Contrast (black level) and the foreground (white level). adjusts background black level of the screen image. Brightness Confidential - Do Not Copy ViewSonic Corporation VX510...
  • Page 16 To select color (R, G or B) press button [2]. To adjust selected color, press Important: If you select RECALL from the Main Menu when the product is set to a Preset Timing Mode, colors return to the 6500K factory preset. Confidential - Do Not Copy ViewSonic Corporation VX510...
  • Page 17 Horizontal Size sharpens focus by aligning the illuminated text and/ Fine Tune or graphic characters. adjusts the clarity and focus of the screen image. Sharpness Confidential - Do Not Copy ViewSonic Corporation VX510...
  • Page 18 Preset Timing Mode listed in this user guide. Exception: This control does not affect changes made with the User Color control, Language and Power Lock setting. Confidential - Do Not Copy ViewSonic Corporation VX510...

  • Page 19: Circuit Description

    TTL, Reduced Swing Differential Signaling (RSDS) data bus type 1~3.and programmable TCON function. TCON LCD Panel Row/Column R/G/B Driver RTD2011B Flat Panel Display Video TTL Signal Decoder LCD Panel RSDS Signal LCD Panel 24.576MHz Confidential - Do Not Copy ViewSonic Corporation VX510...

  • Page 20: Adjusting Procedure

    18. 1024 x 768@ 75Hz, 60.0kHz 8. 720 x 400@ 70Hz, 31.5kHz 19. 1024 x 768@ 85Hz, 68.67kHz 9. 800 x 600@ 56Hz, 35.1kHz 10. 800 x 600@ 60Hz, 37.9kHz 11. 800 x 600@ 75Hz, 46.9kHz Confidential - Do Not Copy ViewSonic Corporation VX510...
  • Page 21 White Screen & Dark Screen The numbers of dead pixels should Figure7,8 Be compliant with the spec. White Balance White & Black Pattern The screen must have the pure white Figure9 And black pattern, no other color. Confidential - Do Not Copy ViewSonic Corporation VX510...
  • Page 22 Confidential - Do Not Copy ViewSonic Corporation VX510...
  • Page 23 (a) Select and enter “Manual Image Adjuet’’ function on OSD Main Meun. (b) Then, select and enter“Horizontal Size’’or“Horizontal/Vertical Position’’ function to adjust the video boundty to be full scanned and within screen frame. Confidential - Do Not Copy ViewSonic Corporation VX510...
  • Page 24 1.5.13 All Modes Reset After final QC step,we have to erase all saved changes again and restore the factory defaults.You should do“All mode Reset’’again. 1.5.14 Power Off Monitor Turn off the monitor by pressing“Power’’ button. Confidential - Do Not Copy ViewSonic Corporation VX510...
  • Page 25 -Fixture for Firmware upgrade -Power adapter *1 for Fixture -VGA Cable *2 -PC (Personal Computer) -Com port Cable *1 -Firmware Upgrade program -One additional monitor for checking the program execution VX510 Fixture VGA Cable Confidential - Do Not Copy ViewSonic Corporation VX510...
  • Page 26 2.2.3 Connect P2 of fixture with PC VGA output by VAG Cable. 2.2.4 Plug Power Adapter to fixture. 2.2.5 Connect Power Card to VX510 Monitor. 2.2.6 Connect PC to the additional monitor. JP1:to Power Adapter Confidential - Do Not Copy ViewSonic Corporation VX510...
  • Page 27 2.2.7 Run “RTDTOOL”file 2.2.8 Choose ”Winboad 62/65B” and then push “SET” button Confidential - Do Not Copy ViewSonic Corporation VX510...
  • Page 28 2.2.9 Push “File Bin” button and then choose the latest firmware that we want to upgrade Confidential - Do Not Copy ViewSonic Corporation VX510...
  • Page 29 1.1 Press Menu key (keep on) than plug power to VX510 monitor after 2-3 second, and release away Menu key. 1.2 Press “Connect ” then enter the ISP mode.(software will show “Link success¨ if we enter the ISP mode successful) Confidential - Do Not Copy ViewSonic Corporation VX510...
  • Page 30 Step 2 Push “Program” button and start to enter upgrade process Step 3. Upgrade successful Confidential - Do Not Copy ViewSonic Corporation VX510...

  • Page 31: Trouble Shooting Flow Chart

    Electronic Hex Nut M5 mm PC with XGA resolution Main Procedure Start Power-on A. Power Circuit Power LED OK ? Troubleshooting Performance Is Display Troubleshooting Performance OK? Function Is Function Troubleshooting adjustment OK? Confidential - Do Not Copy ViewSonic Corporation VX510...
  • Page 32 Change Is screen Black ? Power Video Board Board Panel Replug or Change Change Is screen White ? Change Video FFC cable Board Panel Change Change Abnormal Color ? Video Board Panel Confidential - Do Not Copy ViewSonic Corporation VX510...
  • Page 33 Change Bad uniformity ? Power Board Lcd Panel Change Change Have line bar or Power Board Video Board noise ? Notice Adjust Notice Change Ghost image ? sharpness or Video auto Board Confidential - Do Not Copy ViewSonic Corporation VX510...
  • Page 34 After this action if ghost image disappears , go to “ yes”; else go to “ no”. 2. Check the compatibility on the computer. If it is compatibility problem, feedback the information to ViewSonic ; else , go to “ no” 2.3 C. Function Troubleshooting...

  • Page 35: Recommended Spare Parts List

    CABLE ASSY D-SUB 15P H/D 9C W/CORE 10 weeks A-PC-0106-0328 21-900212-0000 AC POWER CORD USA 3C BLACK W/VF000 30 days M-MS-0808-9496 K0015020000000 VIEWSONIC QSG W/CD W/PE BAG VX510 3 weeks M-LB-0813-1005 K5310000000001 SMALL LABEL 40*25 VX510 2 weeks M-LB-0813-1006 K5310000000002 ID LABEL 108*48.9 VX510...
  • Page 36 VX510 BOM VX510-1 BOM Item ViewSonic P/N Reference P/N Description Q'ty #N/A K0015001000000 BASIC UNIT VX510 M-SCW-0824-0856 700473300-1000 SCREW TAPPING 3.0*10L P-HEAD P-TITE-ZN/B #N/A K0015012000000 LCD PANEL ASSY VX510 B-CB-0206-0195 40-VF000T-B100 PWA BUTTON BOARD VF000 #N/A 36-020071-0000 TACT SW TC-0102X 160gf DIP...
  • Page 37 21-5D0000-0000 CABLE ASSY D-SUB 15P H/D 9C W/CORE #N/A 21-900214-0000 AC POWER CORD CHINA 3C CCC BLACK W/VF000 M-MS-0808-9496 K0015020000000 VIEWSONIC QSG W/CD W/PE BAG VX510 #N/A K0015020000001 WARRANTY CARD W/STICKER,BAG VSCN(G) CN M-LB-0813-1005 K5310000000001 SMALL LABEL 40*25 VX510 M-LB-0813-1006 K5310000000002 ID LABEL 108*48.9 VX510...
  • Page 39 COVER FOR BASE CABLE (BLACK) VX510 M-LB-0813-1009 K5320000000001 NAME PLATE VIEWSONIC FRONT(E015-016-1)VX M-LB-0813-1010 K5320000000002 LOGO BIRD FRONT(E015 004)AL7.9H VX510 M-LB-0813-1011 K5320000000003 LOGO VIEWSONIC ELLIPTIC BACK E015-017 VX B-CB-0206-0195 40-VF000T-B100 PWA BUTTON BOARD VF000 B-VB-0202-0361 40-VF0009-B200 PWA VIDEO BOARD VF000 B-PS-0204-0072 83-110119-0000 AC POWER SUPPLY&DC-AC INVERTER W/VF000...
  • Page 40 Packing for shipping VX510-1 Packing Part List Item ViewSonic P/N Reference P/N Description Q'ty P-FM-0602-0878 K5550000000001 GIFT BOX VX510 M-MS-0808-9489 K5551000000003 POLY FOAM R 01 VX510 A-VC-0101-0378 21-5D0000-0000 CABLE ASSY D-SUB 15P H/D 9C W/CORE M-MS-0808-9489 K5551000000003 PE BAG W420*H650 VX510...

  • Page 41: Panel Interface

    9. Block Diagram IICSDA IICSCL 24C16 BOTTOM BOARD 5DVCC STANDBY_LED ACTIVE_LED POWER_KEY VRMT MENU_KEY 8051MCU UP_KEY CONNECT SELECT_KEY DDC_SDA DOWN_KEY DDC_SCL 5DVCC UDDC1 24C21 PANEL INTERFACE DARED/GRN/BLU[2..7] ECLK VGA INPUT DBRED/GRN/BLU[2..7] RTD2011B HSIN OCLK VSIN 74LVC14 TCON0--REV TCON1--STH RTD_3DVCC TCON3--LOAD TCON4--OE TCON7--POL TCON8--STV1...
  • Page 42 LM1117MPX-3.3 100UF/EC16V6.3H5.2 MMBT3904 0.1UF_Y5V DGND 2.2K 0.1UF_Y5V DGND 2.2K BKLT-PWM VBRI 1UF_Y5V MMBT3904 ViewSonic Corporation DGND Project Name : Title : LCD MONITOR VX510 Document Number : Size : Rev : 40-VF0009-C000 Monday, May 10, 2004 Date: Sheet : Confidential - Do Not Copy...

  • Page 43: Viewsonic Corporation

    P3.0 8051 Socket 5DVCC 24.000MHz 22PF DGND 10PF 10PF MENU_KEY DGND 1,3,4 DGND ViewSonic Corporation Project Name : Title : LCD MONITOR VX510 Size : Document Number : Rev : 40-VF0009-C000 Monday, May 10, 2004 Date: Sheet : Confidential - Do Not Copy...
  • Page 44 VGA5V DAN202U UDDC1 47PFX4_5% 47PFX4_5% 47PFX4_5% 47PFX4_5% 47PFX4_5% 5.6V_RLZ5.6B 0.1UF_Y5V VGAVS VSYNC DDC_SCL DDC_SDA ViewSonic Corporation 24LC21MB 33PF 33PF Project Name : Title : LCD MONITOR VX510 Document Number : Size : Rev : 40-VF0009-C000 Monday, May 10, 2004 Date:...
  • Page 45 22PF 22PF 22PF 22PF 22PF ACTIVE_LED MMBT3904 5DVCC 1,2,3 680_0805 R101 4.7K STANDBY_LED 2 ViewSonic Corporation MMBT3904 Project Name : Title : LCD MONITOR VX510 Size : Document Number : Rev : 40-VF0009-C000 Monday, May 10, 2004 Date: Sheet :...
  • Page 46 TL431 C016 C003 R017 0.1uF 0.56 2W R040 C028 0.1uF R043 820R R033 ViewSonic Corporation Project Name : Title : LCD MONITOR VX510 Size : Document Number : Rev : 83-110119-0000 Wednesday, May 12, 2004 Date: Sheet : Confidential - Do Not Copy...
  • Page 47 R114 100K 0.01U/16V 0.1U/16V 2.7K ZD104 R151 9.1V R112 100K R115 R113 R154 R102 Q114 100K 3904 ViewSonic Corporation R152 R155 C116 100K 0.1u/25V Project Name : Title : C114 D106 LCD MONITOR VX510 R106 C115 0.1u/16V BAV99 5.1K 1U OPEN...
  • Page 48 UP_KEY AUTO_KEY DOWN_KEY HEADER 8/SM LED/3P AUTO MENU DOWN(-) UP(+) MENU AUTO POWER ViewSonic Corporation Project Name : Title : LCD MONITOR VX510 Size : Document Number : Rev : 40-VF000T-C000 Monday, May 10, 2004 Date: Sheet : Confidential - Do Not Copy...
  • Page 49 11. PCB Layout Diagrams Power Board PCB top view Confidential - Do Not Copy ViewSonic Corporation VX510...
  • Page 50 Power Board PCB bottom view Confidential - Do Not Copy ViewSonic Corporation VX510...
  • Page 51 Button Board PCB top view Confidential - Do Not Copy ViewSonic Corporation VX510...

  • Page 52: Exploded Diagram And Spare Parts List

    Add.: Fax: Tel: E-mail: After completing this form, please return it to ViewSonic Quality Assurance in the USA at facsimile 1-909-839-7943. You may also e-mail any suggestions to the Director, Quality Systems & Processes (marc.maupin@viewsonic.com) Confidential - Do Not Copy...
