Marantz SR5400 Service Manual

Av surround receiver
Hide thumbs Also See for SR5400:
Table of Contents

Advertisement

Quick Links

See also: User Manual
Service
Manual
REMARK :
1. Refer to service manual (part no. 27AW855020) for the parts list of model SR5400/L1G.
2. Refer to service manual (part no. 28AW855010) for the parts list of model SR6400/K1G/K1S/U1B.
SECTION
1. TECHNICAL SPECIFICATIONS ............................................................................ 1
2. TECHNICAL DESCRIPTION ................................................................................. 3
3. WIRING DIAGRAM................................................................................................ 5
4. BLOCK DIAGRAM................................................................................................. 7
5. SCHEMATIC DIAGRAM ........................................................................................ 9
6. PARTS LOCATION .............................................................................................. 31
7. IC DATA................................................................................................................ 43
8. EXPLODED VIEW AND PARTS LIST ................................................................. 55
9. POWER AMPLIFIER ADJUSTMENT .................................................................. 59
10. SERVICE PROCEDURE ..................................................................................... 60
11. SYSTEM ERROR ................................................................................................ 60
12. ELECTRICAL PARTS LIST ................................................................................. 62
Please use this service manual with referring to the user guide ( D.F.U. ) without fail.
SR5400 / SR6400 / PS5400
AV SURROUND RECEIVER SR6400
SELECTOR
DISP
AUTO
SLEEP
AUTO
SURR
DIRECT
CLEAR
MEMORY
SPEAKERS A/B
6.1CH INPUT
SELECT
ENTER
TV
DVD
VCR1
STANDBY
POWER ON/OFF
PHONES

TABLE OF CONTENTS

AV Surround Receiver
AV Surround Amplifi er
SURROUND
TUNED
ST
V – OFF
NIGHT
PEAK
ATT
ANALOG
DIGITAL
DIGITAL
DISC 6.1
MTX 6.1
SPKR AB
EQ
L
C
R
PCM
LFE
SL
S
SR
DOWN
TUNING
F/P
MODE
A/D
S-DIRECT
DISPLAY
MUTE
DSS/VCR2
AUX
CD-R
TAPE
CD
TUNER
S-VIDEO
SR5400 /
K1G/N1B/U1B
/K1S/N1S/L1G
SR6400 /
K1G/K1S/U1B
PS5400 /
VOLUME
UP
ATT
AUX INPUT
VIDEO
L
AUDIO
R
PAGE
Part no. 27AW855010
First Issue 2003.06
F1N
ecm
