Truma Compact Crystal 2; Shurflo Water Pump - Swift 2004 Owner's Handbook Manual

TRUMA COMPACT CRYSTAL 2

Raise the lid, clean both the water socket
and the plug of the pump assembly.
pump connection
Plug the pump connector into the socket.
Turn the top security clip anti-clockwise and
the bottom security clip clockwise to lock
the plug into place.
dust cover
Place the pump into the water container,
ensuring that it is fully submerged before
operating the system. A dust cover is
available to stop contaminates falling into
the water container.
To remove the pump assembly from the
Crystal Compact Housing, release the
security clips and pull the hose adaptor by
using the finger grips provided.
Do not remove by pulling the hose or
electric cable.
Services
When using the Winter Kit the blanking plug
provided will be fitted to the housing not
being used.
Clean the water system at the start and
end of the season with sterilising fluid
(see notes under sterilising).
If the pump fails to deliver water the most
likely cause will be air in the system. Switch
off the pump and shake the pump assembly
in the water. Then switch on again.
STERILISING
1. When cleaning the water system at the
start or the end of the season it is
advisable to use a sterilising fluid e.g.
Chempo SDP or similar.
2. Flush the system thoroughly to remove
the effective fluid traces.
3. After sterilising the system at the start of
the season it is recommended that a new
filter cartridge (if fitted) should be fitted.
(Not standard).

SHURFLO WATER PUMP

(MODEL SPECIFIC)
Fresh water is supplied to the caravan on
some models by a Shurflo pump. This pump
is a completely sealed unit designed for
intermittent use and is self priming.
25
