JVC DLA-HD100 Instructions Manual

Jvc d-ila projector instructions
Hide thumbs Also See for DLA-HD100:
Table of Contents

Advertisement

Quick Links

D-ILA PROJECTOR
PROJECTEUR D-ILA
PROYECTOR D-ILA
DLA-HD100
For Customer use :
Enter below the serial No. which is
located on the bottom side of the
cabinet. Retain this information for
future reference.
Model No. DLA-HD100
Serial No.
MANUEL D'INSTRUCTIONS
MANUAL DE INSTRUCCIONES
Pour utilisation par le client :
Entrer ci-dessous le N° de série qui
est situé sous le boîtier. Garder
cette information comme référence
pour le futur.
N° de modèle DLA-HD100
N° de série
ENGLISH FRANÇAIS ESPAÑOL
INSTRUCTIONS
Instrucción para el cliente :
Introduzca a continuación el nº de
serie que aparece en la parte
inferior lateral de la caja. Conserve
esta información como referencia
para uso ulterior.
Modelo Nº DLA-HD100
Nº de serie
LCT2342-001A

Advertisement

Table of Contents
loading

Related Manuals for JVC DLA-HD100

Summary of Contents for JVC DLA-HD100

  • Page 1 Conserve pour le futur. esta información como referencia para uso ulterior. N° de modèle DLA-HD100 N° de série ENGLISH FRANÇAIS ESPAÑOL INSTRUCTIONS Modelo Nº DLA-HD100 Nº de serie...

  • Page 2: Getting Started

    FCC rule. If you are unable to insert the plug into the outlet, contact your electrician. FCC INFORMATION (U.S.A. only) CAUTION: Changes or modification not approved by JVC could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for Class B digital devices, pursuant to Part 15 of the FCC Rules.
  • Page 3 Fragments from a broken light-source lamp may cause injuries. - The light-source lamp used in this projector is a high pressure mercury lamp. Be careful when disposing of the lightsource lamp. If anything is unclear, please consult your dealer.

  • Page 4: Power Connection

    Getting Started Safety Precautions (Continued) POWER CONNECTION WARNING: Do not cut off the main plug from this equipment. If the plug fitted is not suitable for the power points in your home or the cable is too short to reach a power point, then obtain an appropriate safety approved extension lead or adapter or consult your dealer.
  • Page 5 ENGLISH...

  • Page 6: Main Features

    Main Features Supports Multiple Digital Devices ..........Comes with a dual HDMI terminal that allows digital transmission of high definition signals.
  • Page 7 Beautiful Images on Big Screen ..............Enjoy smooth and high resolution video images with no visible grid, brought about by full high definition resolution of 1920 c 1080 pixels.

  • Page 8: Table Of Contents

    Connecting via HDMI-DVI Conversion Cable ...16 Connecting via SCART-RCA Cable...17 Connecting via RGB Video Cable ...17 Installing the Projector and Screen...18 Screen Size and Projection Distance...19 Basic Operation ...........

  • Page 9: How To Read This Manual/Accessories/Optional Accessories

    How to Read this Manual/ Accessories/Optional Accessories About this Manual USER USER USER COLOR SHARP GAMMA COLOR SHARP COLOR TEMP CONTRAST BRIGHT INFO HIDE MENU EXIT ENTER TEST LIGHT Buttons to be used are colored in a darker shade. Check the Accessories Remote Control Instruction manual, warranty card and other printed material are also included.

  • Page 10: Controls And Features

    Getting Started Controls and Features Front Side/Left Side Lamp Cover (pP40) To adjust the focus. To adjust the size of the image. Operate using the remote control. (pP20) Do not turn the lens with your hands. This unit comes with buffer material that cushions the lens. Remove the buffer material before use.
  • Page 11 Light on (Red): Standby mode Light on (Green): During projection Blinking (Green): Image is temporarily hidden (pP21) Blinking (Red): Cool Down mode (pP21) To switch input (pP20) To display the menu (pP24) Bottom Surface Light on (Red): WARNING LAMP Light on/Blinking (Orange): STANDBY/ON STANDBY/ON To turn on/off the power...
  • Page 12 CONTRAST BRIGHT INFO (pP34) HIDE MENU (pP24) ENTER TEST LIGHT PROJECTOR To turn on the power To set the screen size (pP22) To set gamma (pP34) To adjust the outline of the image (pP34) To set color temperature (pP34) To adjust brightness...

  • Page 13: How To Use The Remote Control

    How to Use the Remote Control Loading Batteries If the remote control has to be brought closer to the projector to operate, it means that the batteries are wearing out. When this happens, replace the batteries. Insert the batteries according to the +- marks.

  • Page 14: Preparation

    Preparation Selecting Connecting Devices Do not turn on the power until connection is complete. The connection procedures differ according to the device used. For details, refer to the instruction manual of the device to be connected. For audio output, connect the device to an amplifier. The images may not be displayed depending on the devices and cables to be connected.

  • Page 15: Connecting

    Connecting Connecting via Video Cable and S-video Cable This unit To video input terminal RS-232C RS-232C OMPONENT OMPONENT S-VIDEO VIDEO SYNC To S-video input terminal Connecting via Component Video Cable This unit RS-232C RS-232C OMPONENT OMPONENT OMPONENT S-VIDEO S-VIDEO VIDEO VIDEO SYNC SYNC...

  • Page 16: Connecting Via Hdmi Cable

    Preparation Connecting (Continued) Connecting via HDMI Cable This unit HDMI 2 HDMI 1 COMPONENT COMPONENT S-VIDEO S-VIDEO VIDEO VIDEO SYNC SYNC To HDMI 1 or HDMI 2 input terminal Connecting via HDMI-DVI Conversion Cable This unit MDMI 2 MDMI 1 COMPONENT COMPONENT S-VIDEO...

  • Page 17: Connecting Via Scart-Rca Cable

    Connecting via SCART-RCA Cable This unit RS-232C RS-232C OMPONENT OMPONENT OMPONENT S-VIDEO S-VIDEO VIDEO SYNC To RGB video and sync signal input terminals Set “COMP” in the setting menu to “SCART”. (pP28 - Q) Connecting via RGB Video Cable This unit RS-232C RS-232C OMPONENT...

  • Page 18: Installing The Projector And Screen

    Preparation Installing the Projector and Screen Install this unit and the screen. Place this unit and the screen perpendicular to each other. Failing to do so may give rise to trapezoidal distortion of the projected image. Install the projector and screen...

  • Page 19: Screen Size And Projection Distance

    Adjust such that the projected image is in the center of the screen It may be necessary to set “Pixel Adjust” in the setting menu after adjusting the image position. (pP27 - J) Screen Size and Projection Distance Determine the distance from the lens to the screen to achieve your desired screen size. This unit uses a 2.0x power zoom lens for projection.

  • Page 20: Basic Operation

    (pP11) Play back the selected device Adjust the position of the projection screen See “Installing the Projector and Screen” for procedures on adjusting the position. (pP18) Adjust the image size (zoom) and the focus Display the test pattern (crosshatch)

  • Page 21: Adjust The Focus

    Adjust the focus Press for 1 second or more Adjust the image size (zoom) ENTER Switches between “Focus” and “Zoom” whenever the [ENTER] button is pressed. To end EXIT Turn off the power While a confirmation screen is displayed A STANDBY/ON Cool Down mode A STANDBY/ON The power cannot be turned off within approximately 90 seconds after it...

  • Page 22: Convenient Features During Projection

    HIDE MENU EXIT ENTER TEST LIGHT PROJECTOR Setting the Screen Size The projected image can be set to a most appropriate screen size (aspect ratio). ASPECT 16:9 The screen size can also be set from “Aspect” of the setting menu. (pP29 - S) When high definition images are input, the “V-Stretch”...
  • Page 23 Mask the image Display the setting menu MENU Select “Setup” g “Mask” ASELECT ENTER BCONFIRM Set a mask value ASELECT ENTER BCONFIRM Example: When the “Mask” value is changed from “Off” g “5%” To end MENU Image Setup Source Install. Func.

  • Page 24: Settings

    COLOR TEMP BRIGHT CONTRAST INFO HIDE MENU EXIT ENTER TEST LIGHT PROJECTOR Procedures for Menu Operation Example: When changing “Aspect” from “4:3” to “16:9” Display the setting menu MENU Select “Source” g “Aspect” ASELECT ENTER BCONFIRM Set to “16:9” ASELECT...

  • Page 25: Setting Menu

    Setting Menu Item values shown in are factory settings. Items that can be configured differ according to the input signals. Image > Image Adjust Contrast Adjusts the contrast of the projected image. (Black) b50 f 50 (White) Brightness Adjusts the brightness of the projected image. (Darken) b30 f 30 (Brighten) Color Adjusts the color density of the projected image.
  • Page 26 Settings Setting Menu (Continued) Image > Gamma Gamma Sets the gradation characteristics of the projected image. Normal Theater1 Theater2 Dynamic Custom (Gamma Setup) “Normal” is suitable for normal circumstances but other settings can be selected according to your preferences. This setting can also be configured from the remote control. (pP12) *“Gamma Adjust”...
  • Page 27 Image > Offset Offset Adjusts the respective brightness of the red, green and blue colors in dark image areas. (Offset level) (Less red) b60 f 60 (More red) Green (Less green) b60 f 60 (More green) Blue (Less blue) b60 f 60 (More blue) Image >...
  • Page 28 Settings Setting Menu (Continued) Setup > Picture Position Picture Position Adjusts the horizontal/vertical position of the projected image. The display position value varies with the input signal. This adjustment is available for analog input signals, or for COMPONENT and HDMI-1/2 input signals when “V-Stretch” is set to “On”.
  • Page 29 Source > Aspect (When SD video signals are being input) Aspect Configures the screen size (aspect ratio) of the projected image. Sets screen size of the projected image to 4:3. 16:9 Sets screen size of the projected image to 16:9. Zoom Zooms the image.
  • Page 30 Settings Setting Menu (Continued) Source > Color System Color System Configures the color system. Auto NTSC NTSC4.43 PAL-M PAL-N SECAM This setting is available only when projecting the video or S-video input. Source > Black Level Black Level Configures the black level. 7.5 % This setting can only be adjusted when NTSC signals are input to the video or S-video input terminal.
  • Page 31 Install. > Flip H Flip H Select this when the image is projected from the back of the screen or when the projector is hung from the ceiling. Do not flip image to the left or right. Flips image to the left or right.
  • Page 32 Settings Setting Menu (Continued) Func. > Logo Logo Sets whether to display “Logo” during startup. Func. > Lamp Power Lamp Power Configures the output of the light-source lamp. Normal High Changing the lamp power will not change the lamp time (lamp life). The setting cannot be changed within approximately 90 seconds after this unit has been turned on.
  • Page 33 Info. (During video signal input) Input Displays the currently selected video input. Format Displays the types of the current input video signals. H Frequency This item is grayed out with no value display. V Frequency This item is grayed out with no value display. Lamp Time Displays the accumulated hours of usage of the light-source lamp.

  • Page 34: Customizing Projected Images

    BRIGHT INFO HIDE MENU EXIT ENTER TEST LIGHT PROJECTOR Changing the Default Image Profile Values “Contrast”, “Brightness”, “Color”, “Sharpness”, “DNR”, “Color Temp.”, “Gamma” and “Offset” are registered in the image profile. Select the image profile CINEMA NATURAL DYNAMIC Adjust image quality Example: To adjust “Contrast”...

  • Page 35: Registering User-Defined Image Profiles

    Registering User-defined Image Profiles Select the image profile USER USER USER Adjust image quality See “Changing the Default Image Profile Values” for procedures on adjusting the image quality. (pP34) To end MENU Registering User-defined Image Profiles from the Menu Adjust image quality See “Changing the Default Image Profile Values”...

  • Page 36: Troubleshooting

    Troubleshooting Troubleshooting Before sending the unit to your authorized dealer for repair, check the following points. The following situations are not malfunctions. You do not need to worry under the following situations if there is no abnormality on the screen. Part of the top surface or front of the unit is hot.
  • Page 37 Video image is fuzzy Is the focus correctly adjusted? Is the unit placed too near or too far away from the screen? Video images are missing Has setting been performed for screen mask? Is the display out of position? Remote control does not work Are batteries installed correctly? Are batteries exhausted? Is there an obstructive object between the...

  • Page 38: What To Do When These Messages Are Displayed

    Troubleshooting What to Do When These Messages Are Displayed Message COMP No input HDMI-2 Out of range Lamp replacement Lamp replacement Warning No device is connected to the input terminal. The input terminal is connected but there is no signal. gInput the video signals.

  • Page 39: About Warning Indicators

    About Warning Indicators The accumulated lamp time or warning mode of this unit is displayed by the indicators. For information on indicator display during normal operation, see “Controls and Features” (pP10). Indicator LAMP WARNING Light on Blinking Light on Light on Actions to Be Taken for Warning Mode When the unit enters into warning mode (No.

  • Page 40: Replacing The Lamp

    Troubleshooting Replacing the Lamp The lamp is a consumable item. If the image is dark or the lamp is turned off, replace the lamp unit. When the lamp replacement time approaches, a message is displayed on the screen and the condition is indicated by the indicator.
  • Page 41 Install the new lamp unit Tighten the screws of the lamp unit Fasten the screws with a + screwdriver. Attach the lamp cover Insert the top part (with 2 claws) of the lamp cover into the unit. Fasten the screws with a + screwdriver. Use only genuine replacement parts for the lamp unit.

  • Page 42: Resetting Lamp Time

    EXIT ENTER TEST LIGHT WARNING LAMP STANDBY/ON PROJECTOR CAUTION Reset the lamp time only when you have replaced the lamp. Never reset it when the lamp is still in use. Otherwise, the approximate standard for gauging replacement time may be inaccurate and lamp blowout may occur.

  • Page 43: Cleaning And Replacing The Filter

    Cleaning and Replacing the Filter Clean the filter regularly or air intake efficiency may deteriorate and malfunction may occur. Remove the inner filter Lift up while pushing the claw Clean the filter Wash the filter with water and dry it in a shaded area. In extremely soiled cases, use of a neutral detergent is recommended.

  • Page 44: Others

    Others RS-232C Interface Control of this unit via a computer is possible by connecting the computer to this unit with a RS-232C cross cable (D-Sub 9 pin). RS-232C Specifications This unit 1, 4, 6 b 9 PC refers to the controller such as a personal computer. Mode Non-synchronous Character Length...
  • Page 45 Command and data Operating command and data (Binary code) Command Type 0000 Connection check 5057 Power supply 4950 Input 4754 Gamma table 4750 Gamma coefficient 4752 Gamma data (R) 4747 Gamma data (G) 4742 Gamma data (B) 5453 Test pattern 5243 Remote Control Data description...
  • Page 46 Others RS-232C Interface (Continued) Reference command and data (Binary code) Command 5057 4950 4754 4750 4752 4747 4742 5453 This code indicates the end of communication. The binary code is fixed at “0A”. Type During standby or power on 30 : Standby mode Power supply 31 : Power-on mode 32 : During Cool Down mode...
  • Page 47 Remote control code Binary code is sent during communication. Remote control button Binary code name 37 33 30 31 37 33 30 32 EXIT 37 33 30 33 OPERATE ON 37 33 30 35 OPERATE OFF 37 33 30 36 HIDE 37 33 31 44 MENU...

  • Page 48: Rs-232C Communication Examples

    Others RS-232C Communication Examples This section shows the communication examples of RS-232C. Operating command Type This unit: 21 89 01 00 00 0A Connection check This unit This unit: 21 89 01 50 57 31 0A Power (On) This unit This unit: 21 89 01 50 57 30 0A Power (Off) This unit...
  • Page 49 Reference command Type This unit: 3F 89 01 50 57 0A Power (On) This unit PC: 06 89 01 50 57 0A This unit PC: 40 89 01 50 57 31 0A This unit: 3F 89 01 49 50 0A Input (S-VIDEO) This unit PC: 06 89 01 49 50 0A...

  • Page 50: Copyright And Caution

    Others Copyright and Caution About Trademarks and Copyright HDMI, HDMI logo and high definition multimedia interface are trademarks or registered trademarks of HDMI Licensing LCC. Caution D-ILA Device Characteristics ..........Do not project still pictures or pictures that have still segments for a long period of time.

  • Page 51: Mounting This Unit

    Bottom Surface 4 locations Air inlets Regardless whether the unit is still under guarantee, JVC is not liable for any product damage caused by mounting the unit with non-JVC ceiling fittings or when the environment is not suitable for ceiling-mount.

  • Page 52: Specifications

    Please note that some of the pictures and illustrations may have been abridged, enlarged or contextualized in order to aid comprehension. Images may differ from the actual product. D-ILA Projector DLA-HD100 D-ILA device 1 2 / 0.7" (1920 pixels c1080 pixels) c 3 (Total no. of pixels: Approx. 6.22 million) 2.0x power zoom lens (1.4: 1 f 2.8: 1) (Zoom/Focus: Power)

  • Page 53: Dimensions

    PC compatible signals Resolution [kHz] [kHz] 640 c 480 31.500 60.000 640 c 480 31.469 59.940 800 c 600 37.879 60.317 1024 c 768 48.363 60.004 1280 c 1024 63.981 60.020 Images may not be displayed if the above timings are not met. Dimensions Top Surface Front...
  • Page 54 Others Memo...
  • Page 55 FOR SERVICING (Only in U.S.A.) © 2007 Victor Company of Japan, Limited 1007TTH-SW-VP...
