Installation and Operation Instructions
These instructions are to be stored next to the boiler for reference purposes.
FOR YOUR SAFETY: This product must be installed and serviced by a professional service technician,
qualified in hydronic boiler installation and maintenance. Improper installation and/or operation could
create carbon monoxide gas in flue gases which could cause serious injury, property damage, or death.
Improper installation and/or operation will void the warranty.
If the information in this manual is not followed exactly, a fire or explosion may result
causing property damage, personal injury or loss of life.
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance.
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a nearby phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency, or gas
supplier.
Installation and
Operation
Instructions for
Mini-Therm JVi
WARNING
WHAT TO DO IF YOU SMELL GAS
Induced Draft
Residential
Gas-Fired
Hydronic Boilers
Models JVH, JVP
Document 1080C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mini-Therm JVi JVH and is the answer not in the manual?

Questions and answers

Related Manuals for Laars Mini-Therm JVi JVH

Summary of Contents for Laars Mini-Therm JVi JVH

  • Page 1: Installation And Operation

    Installation and Operation Instructions Document 1080C Installation and Operation Instructions for Mini-Therm JVi Induced Draft Residential Gas-Fired Hydronic Boilers Models JVH, JVP These instructions are to be stored next to the boiler for reference purposes. FOR YOUR SAFETY: This product must be installed and serviced by a professional service technician, qualified in hydronic boiler installation and maintenance.
