- Page 1 DS90 DS90 ™ DOOR/WINDOW SENSOR USER MANUAL 20540/20120530 • DS90 ALL RIGHTS RESERVED MARMITEK©...
- Page 2 © MARMITEK...
- Page 3 • In case of improper usage or if you have altered and repaired the product yourself, all guarantees expire. Marmitek does not accept responsibility in the case of improper usage of the product or when the product is used for purposes other than specified. Marmitek does not accept responsibility for additional damage other than covered by the legal product responsibility.
- Page 4 DOOR/WINDOW SENSOR DS90 Transmitter part. Magnet contact. Control Indicator - Lights up when a signal is transmitted. Screw for opening the sensor. Switch for entry delays. Connection for extra wired contact. Battery compartment. Screw holes for mounting the sensor. Tamper contact.
- Page 5 REGISTER THE DS90 DOOR/WINDOW SENSOR You need to register the DS90 door/window sensor with your TotalGuard/SafeGuard/Protector system. Your system’s user guide will show you how to do this. If you do not have a user guide at hand, you can download one from www.marmitek.com (customer service ->...
- Page 6 These sensors need to be of type NC (normally closed contacts). There should not be any power on this contact (potential-free). 1. Open the transmitter part of the DS90 by removing the screw. 2. Remove the wire bridge from the connection for the wired sensor (6).
-
Page 7: Declaration Of Conformity
DECLARATION OF CONFORMITY Hereby, Marmitek BV, declares that this DS90 is in compliance with the essential requirements and other relevant provisions of the following Directives: Directive 1999/5/EC of the European Parliament and of the Council of 9 March 1999 on...
