Summary of Contents for Elation DR-512
- Page 1 DR-512 USER INSTRUCTIONS 4-004-1126 Rev 1.0 ) E-mail: support elationlighting.com Internet: www.elationlighting.com Rev. 7/04...
-
Page 2: Table Of Contents
6.5 PROGRAM mode..................8 6.5.1 Recording operation................8 6.5.2 Changing the sequence name ............8 6.6 SETUP mode ....................9 7 External Terminals ..................8 Note Information for usage ................9 Troubleshooting (FAQ) ................. 10 Specifications ....................11 Elation Professional - www.elationlighting.com - Page 2... -
Page 3: General Instruction
1 General Instruction DR-512 is a professional DMX recorder with many useful functions. This unit can translate standard DMX512 signals into recorded data, and send them out at any convenient moment. These signals can be recorded to both the internal memory storage and/or a external CF card. -
Page 4: Safety Warnings
B. Objects have fallen, or liquid has been spilled into the unit. C. The unit has been exposed to rain or water. D. The unit does not appear to operate normally or exhibits a marked change in performance. Elation Professional - www.elationlighting.com - Page 4... -
Page 5: Control And Functions
Used to select one of the possible sequences (I 10. DOWN button: Press this button to select correspondent options or decrease relative values. 11. ENTER button: Press this button to confirm your operation or enter the correspondent menu. Elation Professional - www.elationlighting.com - Page 5... -
Page 6: Rear Panel
3. DMX input (5pin / 3pin): To input relative DMX signals. 4. Terminal connector: Used to connect with external terminals. DC input: Used to plug in an external power supply (DC 9-12V, 500 mA Min). Elation Professional - www.elationlighting.com - Page 6... -
Page 7: Lcd Display
• For internal storage, press the STARTUP button, then the STARTUP sequence will run once, and other sequences will run continuously. • When the SHUTDOWN button is pressed, the SHUTDOWN sequence will run one time, and other the sequences will be stopped. Elation Professional - www.elationlighting.com - Page 7... -
Page 8: Autostart Mode
And the AUTOSTART mode may be available for reference to the operation in MANUAL mode. • Once an effective DMX signal is received, the running sequences will stop automatically. The PLAY, PAUSE and STOP buttons will not function. Elation Professional - www.elationlighting.com - Page 8... -
Page 9: Dmx Trigger Mode
(1) Smpte Trig : enter this submenu to trigger the Smpte signals and to set the trigger time. Press the NEXT button, and then use the UP / DOWN buttons to choose Yes Elation Professional - www.elationlighting.com - Page 9... -
Page 10: External Terminals
02. The PLAY, STOP, RECORD buttons can be used to control the running states. Some information about Prg-mode LED, Record LED and Play LED: In PRG mode, the Prg-mode LED will be “on”. When the internal Record LED is “on”, Elation Professional - www.elationlighting.com - Page 10... -
Page 11: Note Information For Usage
Recovery : press the MODE button to enter the SETUP mode, select submenu 7 choose “N” for unlocking. • Problem : Nothing happens when the PLAY button is pushed. Elation Professional - www.elationlighting.com - Page 11... - Page 12 Cause : Sequences can only be triggered when the unit is receiving a DMX signal. Recovery : Be sure the DMX indicator is “on”. This means that the unit is receiving a DMX signal. Elation Professional - www.elationlighting.com - Page 12...
- Page 13 B. For warranty service, send the product only to the Elation Professional® factory. All shipping charges must be pre-paid. If the requested repairs or service (including parts replacement) are within the terms of this warranty, Elation Professional®...
-
Page 14: Specifications
CF Card Requirement................Exclusive 32 MB LCD Screen ...................2_16 characters Dimensions..................482_120_44mm Weight......................approx. 1.6 kg (Binary coded) switch input........0~5V (no external voltage) /1mA LED output (Prg-mode LED / Record LED / Play-LED)....……….2V / 25mA Elation Professional - www.elationlighting.com - Page 14...
