USER'S MANUAL
DP-619
6 CHANNEL DIGITAL DIMMER PACK
Please read before use
CH. 1
CH. 3
CH. 2
CH. 4
DP-619
6 CHANNEL DIGITAL DIMMER PACK
POWER
CH. 5
DMX
MAP
CH. 6
CHANNELS ON
1
2
3
4
5
6
UP
DOWN
YES
NO

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DP-619 and is the answer not in the manual?

Questions and answers

Summary of Contents for Elation DP-619

  • Page 1 English DP-619 6 CHANNEL DIGITAL DIMMER PACK USER'S MANUAL CHANNELS ON DP-619 6 CHANNEL DIGITAL DIMMER PACK POWER CH. 1 CH. 3 CH. 5 CH. 2 CH. 4 CH. 6 DOWN Please read before use...
  • Page 3: Table Of Contents

    Fan Cooling 22 Over Temperature Solving 22 Master/Slave Link Up 23 Lock the buttons 23 Technical Specifications 24 DP-619 6 CHANNEL DIGITAL DIMMER PACK Improvement and changes to specifications, design and this manual, may be made at any time without prior notice.
  • Page 4: Features

    Features Thank you for your purchasing. This product features include: 6 DMX channels, 24 map in DMX channels 24 programmable scenes 10 shows from 24 programmed scenes 90 built-in chase programs Each channel can be programmed with preheat level(0-20%), maximum output level(30-100%), control curve(linear,square and switch) and fade time(0.0s-999s).
  • Page 5: General Instructions

    General Instructions Please read through this operating instructions before installing or using your new product. After you have finished reading the instructions, put them away in a safe place for future reference. WARNING! This product must be earthed. To prevent fire or shock hazard, do not expose this product under high temperature or moisture area.
  • Page 6: Overview

    Overview Front View...
  • Page 7 Overview Front View 1. Circuit Breaker 16A 2. LCD Display Shows the current activities or adjustments of menus. 3. UP Button Scroll through the menus or increase the values. 4. DOWN Button Scroll through the menus or decrease the values. 5.
  • Page 8: Rear View

    Overview Rear View 1. DMX INPUT This connector accepts DMX input signal. 2. MAP INPUT This connector is used to map in 24 DMX channel to control scene 1-24, show 1-10 or program 1-90. 3. DMX OUTPUT This connector sends DMX signal through to the next DMX device. 4.
  • Page 9 Overview Rear View...
  • Page 10: Set-Up

    Set-up Power Up When power is applied to your dimmer, a self-test is performed, as indicated by its LCD. The LCD reads "DMX ABSENT/ DMX RECEIVED OK/ DMX SIGNAL ERROR" or "OVER TEMPERATURE". After these initial test, a text message begins to scroll through the LCD. By default these messages are "DIGITAL DIM PACK..".
  • Page 11: Set Dmx Address

    Set-up 1. SET DMX ADDRESS? 1. Tap the UP/DOWN button to scroll to "1 SET DMX ADDR?". 1 SET DMX ADDR? 2. Press YES to enter next menu level, Start Address and Patch Address are selectable using UP/DOWN. Start Address I.
  • Page 12: Set Channels

    Set-up 1. SET DMX ADDR? Patch Address IV. T ap UP/DOWN to select desired DMX Address(1~512). V. Press YES to store your setting, the LCD shows 1 SET DMX ADDR? STORED OK VI. Repeat steps II~V until every DMX channel has a separate address. 2.
  • Page 13 Set-up 2. SET CHANNELS? III. Press YES again, the LCD shows 2 SET CHANNELS? 2111 [-0-%] You may select desired value using UP/DOWN, default=0%. IV. Press YES to store your setting, the LCD shows 2 SET CHANNELS? STORED OK SET MAXIMUM OUTPUT I.
  • Page 14 Set-up 2. SET CHANNELS? SET CURVES I. Tap UP/DOWN to scroll to the sub-menu "23 SET CURVES?", the LCD shows 2 SET CHANNELS? 23 SET CURVES? II. Press YES, the LCD shows 2 SET CHANNELS? 231 CHANNEL [A] You may select all or channel 1-6 using UP/DOWN, default=A(all channels).
  • Page 15: Set Scenes

    Set-up 2. SET CHANNELS? SET FADE III. Press YES again, the LCD shows 2 SET CHANNELS? 2411 [0.0S] You may adjust fade time within 0.0s~999s using UP/DOWN, default=0.0s. 2 SET CHANNELS? IV. Press YES to store your setting, the LCD shows STORED OK 3.
  • Page 16 Set-up 3. SET SCENES? RECORD I. Tap UP/DOWN to scroll to the sub-menu "32 RECORD?", the LCD shows 3 SET SCENES? 32 RECORD? II. Press YES, the LCD shows 3 SET SCENES? 321 GET [SCEN 1] You may select Get scenes 1-24/ Clear scenes using UP/DOWN, default=1(scene 1).
  • Page 17 Set-up 3. SET SCENES? DMX FAIL [LAST HELD]: the last signal received is held in the outputs. [ALL OFF]: all channels go to zero output. [SCENE 24]: scene 24 is output. [GO NO DMX]: menu 36 "NO DMX SCN" is recalled. [GO MAP]: map in signal is held in the outputs.
  • Page 18 Set-up 3. SET SCENES? SET FADE TIME I. Tap UP/DOWN to scroll to the sub-menu "35 FADE TIME?", the LCD shows 3 SET SCENES? 35 FADE TIME? II. Press YES, the LCD shows 3 SET SCENES? You may select all or scene 1-24 using 351 SCEN [A] UP/DOWN, default=A(all scenes).
  • Page 19: Test Channels

    Set-up 4. TEST CHANNELS? 1. Tap UP/DOWN to scroll to "4 TEST CHANLS?" 4 TEST CHANNELS? 2. Press YES, the LCD shows 4 TEST CHANNELS? 41 CH [A] You may select all or channel 1-6 using UP/DOWN, default=A(all channels). 3. Press YES once, the appropriate channel(s) will be fully on; press YES twice, the appropriate channel(s) will be half on;...
  • Page 20: Unit Setup

    Set-up 6. UNIT SETUP? 1. Tap UP/DOWN to scroll to "6 UNIT SETUP?" 6 UNIT SETUP? 2. Press YES, the LCD shows 6 UNIT SETUP? 61 [SLAVE] You may select MASTER/ SLAVE using UP/DOWN, default=SLAVE. 3. Press YES to store your setting, the LCD shows 6 UNIT SETUP? STORED OK 7.
  • Page 21: Software Rev

    Set-up 8. SOFTWARE REV? 1. Tap UP/DOWN to scroll to "8 SOFTWARE REV?". 8 SOFTWARE REV? 2. Press YES, the LCD shows the software revision. 8 SOFTWARE REV? REV1.0 05-26-01 9. READ INFO? 1. Tap UP/DOWN to scroll to "9 READ INFO?". 9 READ INFO? 2.
  • Page 22 Set-up 9. READ INFO? TEMPERATURE I. Tap UP/DOWN to scroll to the sub-menu 9 READ INFO? "92 TEMPERATURE", the LCD shows 92 TEMPERATURE II. Press YES, the LCD shows 9 READ INFO? 921 [MAX] You may select MAX/ MIN/ NOW/ temperature or RESET using UP/DOWN.
  • Page 23 Set-up 9. READ INFO? MENU ACCESS I. Tap UP/DOWN to scroll to the sub-menu "94 MENU ACCESS?", the LCD shows 9 READ INFO? 94 MENU ACCESS? II. Press YES, the LCD shows the default setting "UNLOCKED". You may select 9 READ INFO? UNLOCK/LOCK using UP/DOWN.
  • Page 24 Set-up 9. READ INFO? MENU ACCESS VI. Use UP/DOWN to scroll to UNLOCK, SURE press YES, the LCD shows WANT UNLOCK? VII. Press YES, the LCD shows 9 READ INFO? UNLOCK STORED OK If you are not sure, press NO several times until the LCD shows WANT EXIT?
  • Page 25: Additional Information

    Additional Information Fan Cooling The unit's fan is used to improve heat dissipation. If the power is turned on, the cooling fan will automatically run. When the power is turned off, it will stop. Over Temperature Solving A. When the recorded maximum temperature exceeds 70 Celsius and the ambient temperature is below 70 Celsius, the LCD shows "OVER TEMPERATURE"...
  • Page 26: Master/Slave Link Up

    Additional Information Master/Slave Link Up A. You can set up communications between several units using Master/Slave link up, the first unit serves as the Master, and the others are Slaves. (See menu 6 UNIT SETUP.) B. The Master unit transfers the DMX signal and Map input signal to the Slave unit using DMX cables, the Slave transfers the DMX input signal only but not the Map input signal.
  • Page 27: Technical Specifications

    Technical Specifications Power Input ............AC 120V~50-60Hz Channel Output(Single phase)......16A/CH., Total 96A Channel Output(Three phases)......16A/CH., Total 32A DMX Output ..........3 pin female XLR socket DMX Input ............. 3 pin male XLR socket Map Input ............3 pin male XLR socket Dimensions ..............
