ClientPOS PT6300 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PT6300
User Manual
Version: 2.0
P/N :
1 | 95
Cover page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PT6300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ClientPOS PT6300

Summary of Contents for ClientPOS PT6300

  • Page 1 PT6300 User Manual Version: 2.0 P/N : 1 | 95 Cover page...
  • Page 2 ClientPOS PT6300 User Manual Version: 2.0 Copyright Copyright 2010 Publishing. All Rights Reserved. This manual, software and firmware described in it are copyrighted by their respective owners and protected under the laws of the Universal Copyright Convention. You may not reproduce,...

  • Page 3: Safety Instructions

    ClientPOS PT6300 User Manual Version: 2.0 Safety Instructions Read these instructions carefully. Keep these instructions for future reference. Please disconnect this equipment from AC outlet before cleaning. Don’t use liquid or sprayed detergent for cleaning. Use moisture sheet or cloth for cleaning.

  • Page 4: Table Of Contents

    Table of Contents 1. Packing List………………………………………………. Standard Accessories………………………………………... Optional Accessories………………………………………… 2. System View ……………………………………………… Rear View……………………………………………………… Specification…………………………………………………… Internal Layout………………………………………………… Touch Panel Life test condition………………………………. 3. Pin Definition……………………………………………… 4. Rear I/O Interface………………………………………… 5. System Assembly & Disassembly…………………… HDD……………………………………………………………. CFast Card…………………………………………………….. MSR……………………………………………………………. Cable Cover……………………………………………………...
  • Page 5 ClientPOS PT6300 User Manual Version: 2.0 Save & Exit……………………………………………………. 8. LCD Surface Cleaning…………………………………… 5 | 95...

  • Page 6: Packing List

    Packing List Packing List 1-1 Standard Accessories a. System (with stand) b. Power Adapter c. Power Cord d. Driver Bank e. Screw x2 Cable Cover Optional Accessories a. Single MSR b. 3 IN 1 MSR c. Screw x2 6 | 95...

  • Page 7: System View

    ClientPOS PT6300 User Manual Version: 2.0 System View System View Rear View Item 1. Mic 2. Line-Out 3. RJ11 (Cash Drawer ) 4. RJ45(LAN) 5. USB 2.0 X4 6. COM1 7. VGA 8. COM2 9. RJ45(COM 3 external) 10. PS2(K/B) 11.

  • Page 8: Specification

    ClientPOS PT6300 User Manual Version: 2.0 Specification Intel® Core™ i3-2120 processor (3M Cache, 3.30GHz) Intel® Pentium® G850 processor (3M Cache, 2.90GHz) Processor Intel® Celeron® G540 processor (2M Cache, 2.50GHz) Chipsets: North Bridge/South Bridge One SO-DIMM socket supports DDR3 1333MHZ up to...

  • Page 9: Internal Layout

    ClientPOS PT6300 User Manual Version: 2.0 2-3 Internal Layout 9 | 95...

  • Page 10: Touch Panel Life Test Condition

    ClientPOS PT6300 User Manual Version: 2.0 2-4 Touch Panel Life Test Condition 2-4-1 Pointing life test Hit it thirty five million times with a silicon rubber of R 0.8, Hs 60 and measure it. The measurement must satisfy the under-metioned items. Hitting force shall be 250g and hitting speed 3 times per second.

  • Page 11: Pin Definition

    ClientPOS PT6300 User Manual Version: 2.0 Pin Definition Pin Definition 1. COM 4 for Touch Panel (CN 16) Function Function Function T_UR T_SG T_LR T_UL T_LL 2. Parallel J7 Pin NO. Pin Name Description Pin NO. Pin Name Description STB#...
  • Page 12 ClientPOS PT6300 User Manual Version: 2.0 5. Mic Pin NO. Pin Name Description Ground Ground Mic R Mic right Mic L Mic left Detect Detect 6. Speaker SP1 Pin NO. Pin Name Description Speaker + Speaker - 7. LVDS CN 2 Pin NO.

  • Page 13: Rear I/O Interface

    ClientPOS PT6300 User Manual Version: 2.0 Rear I/O Interface Rear I/O Interface 1. COM1’ COM2’ port Signal Function Signal Function Carrier Detect (IN) Data Set Ready (In) Receive Data (IN) Request To Send (OUT) Transmit Data(OUT) Clear To Send (IN)
  • Page 14 ClientPOS PT6300 User Manual Version: 2.0 4. PS/2 K/B port Signal Name Data from Device Not Connected Ground +5V DC Clock Not Connected 5. LAN port Wire Colour Description White / Orange Transmit Orange Transmit White / Green Receive Blue...

  • Page 15: System Assembly & Disassembly

    ClientPOS PT6300 User Manual Version: 2.0 System Assembly & Disassembly System Assembly & Disassembly 1. Unfasten the HDD cover screw*2 2. Pull out the HDD bracket 3. Fasten the screw*4 4. Place the HDD bracket back to the module 5-2 CFast Card Please notice the unnotched CFast Card .
  • Page 16 ClientPOS PT6300 User Manual Version: 2.0 Before Installing CFast Card. After Installing CFast Card 16 | 95...

  • Page 17: Msr

    ClientPOS PT6300 User Manual Version: 2.0 1. Open the MSR cover 2. Single MSR or 3-in-1 MSR 3. Screw*2 M3x10L 4. Fasten the screw cable cover Assemble the cable cover from bottom and make sure the two latches are on the right position.

  • Page 18: 15" 2 Nd Display

    ClientPOS PT6300 User Manual Version: 2.0 15” 2 Display 1. Remove the plastic pole cover from the stand. 2. Install the pole into the socket in clockwise direction. 18 | 95...
  • Page 19 ClientPOS PT6300 User Manual Version: 2.0 3. Fasten the four screws (M4*8L) to joint the VESA bracket and the rear cover. . 4. Connect the COM port, DC cable as shown in figure (Please refer to page 89 to set the COM port pin9 with 12V DC output.)
  • Page 20 ClientPOS PT6300 User Manual Version: 2.0 8. Route the cables through the opening of stand front cover and cable clip at the bottom and route the cables into the tube of pole. 9. Reeve the cables out of the tube.
  • Page 21 ClientPOS PT6300 User Manual Version: 2.0 11. Connect the DC power cable as shown in figure. 12. Connect the VGA cable as shown in figure. 13. Connect the Audio cable as shown in figure. 14. Put the cable cover on the hinge of VESA bracket.
  • Page 22 ClientPOS PT6300 User Manual Version: 2.0 5-6 Internal VFD ClientPOS electronics Model PT6300 Assembling Figure Inc. Operation VFD MODULE assemblely Item Operation procedure Remark Prepare all components as Fig 1 Assemble HOLDER & HINGE ASSY by TAPPING SCREW P/H 2.6φ*5 x2 pcs(As Fig 2) Torque 2Kgf Fix VFD MODULE on holder assy by TAPPING SCREW P/H 2.6φ*5 x4 pcs as Fig 3...

  • Page 23: Wi-Fi

    ClientPOS PT6300 User Manual Version: 2.0 Wi-Fi Fasten antenna (Part No.: 35D510530-000B) to the left side of VFD cover. Antenna is vertical to the right of the left snap(as the red frame) as shown in the figure below After fastening the Wi-Fi Module to the Rubber (Part No.: 78D200655-000T), fix this on the VFD cover.
  • Page 24 ClientPOS PT6300 User Manual Version: 2.0 Fasten antenna (Part No.: 35D510530-000B) to the right side of VFD cover. Antenna is vertical to the left snap (as the red frame) as shown in the figure below. Fasten antenna cable connector to Wi-Fi module terminal. Then fasten antenna cable to the cover by adhesive tapes Fasten the VFD cover to the rear lid.

  • Page 25: Nd Display

    ClientPOS PT6300 User Manual Version: 2.0 5-8 8” 2 Display Remove the plastic pole cover from the stand. Install the pole into the socket in clockwise direction. 25 | 95...
  • Page 26 ClientPOS PT6300 User Manual Version: 2.0 Connect VGA cable and DC power cable Fasten the four screws (M4*8L) to joint the VESA bracket and the rear cover. Reeve the cables out of the tube. 26 | 95...
  • Page 27 ClientPOS PT6300 User Manual Version: 2.0 Mount the VESA bracket on the pole and route cables out of the tube of VESA bracket. Fasten the thumb screw to fix the VESA bracket. Reeve the cables out from the bottom of pole.
  • Page 28 ClientPOS PT6300 User Manual Version: 2.0 9. Connect the DC power cable as shown in figure. ☆ To setup COM port PIN9 with 12V DC output from BIOS setup, please refer to page 89, Advanced Chipset Features / COM port PIN9 setting.

  • Page 29: 2D/I-Button With Rfid Module

    ClientPOS PT6300 User Manual Version: 2.0 5-9 1D / 2D / i-Button with RFID module 1. Cable installation. a. For i-Button with RFID module; For 2D barcode scanner with RFID module: Connect the cable as shown in figure. b. For 1D barcode scanner with RFID module: Connect the cable as shown in figure.

  • Page 30: Device Driver Installation

    ClientPOS PT6300 User Manual Version: 2.0 Device Driver Installation Device Driver Installation 6-1. Resistive Type Touch Panel and P-CAP 1. Click “Next”. 2. Click “Next”. 30 | 95...
  • Page 31 ClientPOS PT6300 User Manual Version: 2.0 3. Click “Next”. 4 . Select “None”, Click “Next”. 5. Click “OK”. 31 | 95...
  • Page 32 ClientPOS PT6300 User Manual Version: 2.0 6. Select “Support Multi-Monitor System”, Click “Next”. 7. Click “Next”. 32 | 95...
  • Page 33 ClientPOS PT6300 User Manual Version: 2.0 8. Click “Next”. 9. Click “Next”. 33 | 95...
  • Page 34 ClientPOS PT6300 User Manual Version: 2.0 10. Select “Create a eGalaxTouch Utility shortcut on desktop”, Click “Next”. 34 | 95...
  • Page 35 ClientPOS PT6300 User Manual Version: 2.0 12. Would you do 4 point calibration now? Click “Yes”. 13. Do 4 points aligrment to match display. 14. Calibration utility. 35 | 95...

  • Page 36: Magstripe Card Reader Configuration Utility

    ClientPOS PT6300 User Manual Version: 2.0 6-2 MagStripe Card Reader Configuration Utility The MagStripe Card Reader Configuration Utility is used to set up the output format of HID Installation Below steps guide you how to install the Utility program. ...
  • Page 37 ClientPOS PT6300 User Manual Version: 2.0  The utility program will detect the connected reader. If detected, all the input text boxes will be enabled.  If the reader has not been connected to PC yet, please connect the reader and then click Refresh to get connected.
  • Page 38 ClientPOS PT6300 User Manual Version: 2.0 Shown below is the data structure of the output string for MSR. PP PR1  PP: Prefix for package.  PR1: Prefix for track 1.  SS1: Start sentinel for track 1.  TK1: Data for track 1, if error happens, using Error Message instead.
  • Page 39 ClientPOS PT6300 User Manual Version: 2.0 This group defines the start and end sentinel for each track. The sentinel is always used to extract the track data from the whole MSR data string. The data length for each sentinel is fixed to one character.

  • Page 40: Save Settings

    ClientPOS PT6300 User Manual Version: 2.0 There 6 orders allow to be selected. Please select one to fit your application needs. Update Settings Once complete the settings, click Update to update the settings to connected HID MSR reader. Save Settings To save the settings to a file, click Save;...

  • Page 41: Fingerprint Reader

    Fingerprint Reader 1. Check Fingerprint reader be detected by “Device manager “ 2. Select SDK folder. 41 | 95...
  • Page 42 ClientPOS PT6300 User Manual Version: 2.0 3. Run Setup.exe. 4. Click “Next”. 42 | 95...
  • Page 43 ClientPOS PT6300 User Manual Version: 2.0 5. Select “ I accept the terms in the license agreement” and click “Next”. 6. Click “Next”. 43 | 95...
  • Page 44 ClientPOS PT6300 User Manual Version: 2.0 7. Click “Next”. 8. Click “Install”. 44 | 95...
  • Page 45 ClientPOS PT6300 User Manual Version: 2.0 9. Click “Finish”. 10. Restart systems. 45 | 95...
  • Page 46 ClientPOS PT6300 User Manual Version: 2.0 11. Check Fingerprint reader in Device Manager. 12. Launch Fingerprint reader from start menu 46 | 95...
  • Page 47 ClientPOS PT6300 User Manual Version: 2.0 13. Select “COM-ActiveX” 14. Select “Samples” 47 | 95...
  • Page 48 ClientPOS PT6300 User Manual Version: 2.0 15. Select ”VB6’. 16. Select “Enrollment Sample”. 48 | 95...
  • Page 49 ClientPOS PT6300 User Manual Version: 2.0 17. Enroll the fingerprint by the “Enrollment“ 18. Select “Fingerprint Enrollment” 49 | 95...
  • Page 50 ClientPOS PT6300 User Manual Version: 2.0 19. Put your finger on fingerprint reader and follow the direction to enroller your fingerprint, it need scan your fingerprint 4 times 50 | 95...
  • Page 51 ClientPOS PT6300 User Manual Version: 2.0 20. After enroller finish it will popup a dialog box 51 | 95...

  • Page 52: Rfid

    ClientPOS PT6300 User Manual Version: 2.0 6-4 RFID 1. Install (Operating System: Microsoft Windows POSReady 2009) Check the Device Manager to verify the status of RFID reader. Computer Management -> Device Manager -> Other devices (The device will show a question mark if the installation is not done properly.)
  • Page 53 ClientPOS PT6300 User Manual Version: 2.0 1.2.1 After clicking” Next”, A pop up console window appears as below. 1.2.2 Check the Device Manager to verify the status of RFID reader. Computer Management -> Device Manager -> Ports (COM & LPT)
  • Page 54 ClientPOS PT6300 User Manual Version: 2.0 1.3 Install RFID utility MifareDemoSetup_PSW00020.exe 3-1 Path:\MF320\MifareDemoSetup_PSW00020.exe 1.3.1 InstallShield Wizard will be activated. 54 | 95...
  • Page 55 ClientPOS PT6300 User Manual Version: 2.0 1.3.2 Click “Next”. 1.3.3 Click “Next”. 55 | 95...
  • Page 56 ClientPOS PT6300 User Manual Version: 2.0 1.3.4 Click “Giga-TMS” & “Next”. 1.3.5 Click “Next”. 56 | 95...
  • Page 57 ClientPOS PT6300 User Manual Version: 2.0 1.3.6 Click “Finish” 2. Run RFID demo program. Start -> All Programs -> GIGA-TMS -> Mifare Demo 57 | 95...
  • Page 58 ClientPOS PT6300 User Manual Version: 2.0 Run “Auto Scan” Demo AP will detect the RFID reader automatically. Or select the RFID COM port 2-2 After finishing the AutoScan, Request box will be ready for the click and Reader Version will show on the position as marked. (Reader Version: PGM-T1235 V1.0R3 (101230) Place Mifare Card to the RFID reader area.
  • Page 59 ClientPOS PT6300 User Manual Version: 2.0 Place the RFID card on the RFID reader. 2-3 Card type will be recognized when you click “Request”. (Your Mifare card should be placed on the RFID reader area.) 59 | 95...
  • Page 60 ClientPOS PT6300 User Manual Version: 2.0 2-4 Card ID will be recognized when you click “Card ID”. 2-5 SAK will be read when you click “Select”. 60 | 95...
  • Page 61 ClientPOS PT6300 User Manual Version: 2.0 2-6 The result will show when you click “Authenticate”. 61 | 95...

  • Page 62: Internal Vfd

    ClientPOS PT6300 User Manual Version: 2.0 Internal Specification Display Method Vacuum Fluorescent Display(blue-Green) Number of Characters 40 (20 Columns X 2 Lines) Brightness 500 ~ 1000 cd/m2 Character Font 5X7 Doc Matrix Alphanumeric, International Character Type Characters Character Size 6.75(H) X 3.75(W)mm Doc Size (X x Y) 0.55 x 0.75 mm...
  • Page 63 ClientPOS PT6300 User Manual Version: 2.0 63 | 95...
  • Page 64 ClientPOS PT6300 User Manual Version: 2.0 64 | 95...
  • Page 65 ClientPOS PT6300 User Manual Version: 2.0 65 | 95...

  • Page 66: I-Button Reader Configuration Utility

    ClientPOS PT6300 User Manual Version: 2.0 6-6 i-Button Reader Configuration Utility The i-Button Reader Configuration Utility is used to set up the output format of HID MSR Installation Below steps guide you how to install the Utility program.  Insert the setup CD ...
  • Page 67 ClientPOS PT6300 User Manual Version: 2.0  The utility program will detect the connected reader. If detected, all the input text boxes will be enabled.  If the reader has not been connected to PC yet, please connect the reader and then click Refresh to get connected.
  • Page 68 ClientPOS PT6300 User Manual Version: 2.0 Update Settings Once complete the settings, click Update to update the settings to connected HID MSR reader. Save Settings To save the settings to a file, click Save; specify the file name and location to be saved.

  • Page 69: Installation And Testing Of Smart Card Reader

    ClientPOS PT6300 User Manual Version: 2.0 6-7 Installation and Testing of Smart Card Reader Check smart card reader be detected by “Device manager”. 2. Install the SCR driver. 69 | 95...
  • Page 70 ClientPOS PT6300 User Manual Version: 2.0 3. Run Setup.exe. 4. Click “Yes”. 70 | 95...
  • Page 71 ClientPOS PT6300 User Manual Version: 2.0 5. Restart systems. 6. Check SCR reader in Device Manager. 71 | 95...
  • Page 72 ClientPOS PT6300 User Manual Version: 2.0 7. Run the testing program – EZ100test. 8. Conferm that SCR can be detected by the testing program, then run the program - the Start Testing. 72 | 95...
  • Page 73 ClientPOS PT6300 User Manual Version: 2.0 9. Follow dialog boxes displayed to remove and insert card. 10. After finishing the testing, the dialog box will show “oK”. 73 | 95...

  • Page 74: Wi-Fi

    ClientPOS PT6300 User Manual Version: 2.0 6-7 Wi-Fi 1. Install the Wi-Fi driver. 2. Run Setup.exe. 74 | 95...

  • Page 75: Bios/Utility Setup

    ClientPOS PT6300 User Manual Version: 2.0 BIOS/Utility Setup BIOS/Utility setup Press <DEL > / <F2> key to enter BIOS SETUP UTILITY when system boot up. ☆ Please press <DEL > / <F2> key tenderly and slowly. Date and Time The Date and Time items show the current date and time on the computer. If you are running a Windows OS, these items are automatically updated whenever you make changes to the Windows Date and Time Properties utility.

  • Page 76: Advanced

    ClientPOS PT6300 User Manual Version: 2.0 Advanced Use the Advanced menu to configure the CPU and peripheral devices through the following sub-menus: 76 | 95...
  • Page 77 ClientPOS PT6300 User Manual Version: 2.0 7-1-1 ACPI Configuration The ACPI Configuration menu configures the Advanced Configuration and Power Interface (ACPI) options ACPI Sleep State Use the ACPI Sleep State option to specify the sleep state the system enters when it is not being used.
  • Page 78 ClientPOS PT6300 User Manual Version: 2.0 7-1-2 S5 RTC Wake Settings Enable or disable system wake on alarm event. When enabled, system will wake on the hr::min::sec specified. 78 | 95...
  • Page 79 ClientPOS PT6300 User Manual Version: 2.0 7-1-3 CPU Configuration Use the CPU Configuration menu to enter the CPU Information submenu or setup Intel CPU parameter. 79 | 95...

  • Page 80: Sata Configuration

    ClientPOS PT6300 User Manual Version: 2.0 7-1-4 SATA Configuration Use the SATA Configuration menu to change and/or set the configuration of the SATA devices installed in the system. SATA Mode Use the SATA Mode option to configure SATA devices as normal IDE devices.
  • Page 81 ClientPOS PT6300 User Manual Version: 2.0 7-1-5 Intel IGD SWSCI OpRegion Configuration Use the Configuration menu to change and/or set the configuration of the internal graphics devices installed in the system. DVMT Mode Use the DVMT Mode option to configure internal graphics device.
  • Page 82 ClientPOS PT6300 User Manual Version: 2.0 7-1-6 USB Configuration Use the USB Configuration menu to read USB configuration information and configure the USB settings. USB Devices The USB Devices Enabled field lists the USB devices that are enabled on the system...
  • Page 83 ClientPOS PT6300 User Manual Version: 2.0 7-1-7 IT8783F Super IO Configuration Use the Super IO Configuration menu to set or change the configurations for parallel ports and serial ports. 83 | 95...
  • Page 84 ClientPOS PT6300 User Manual Version: 2.0 Serial Port n Configuration Use the Serial Port n Configuration menu to configure the serial port n. Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port. Disabled Disable the serial port...
  • Page 85 ClientPOS PT6300 User Manual Version: 2.0 7-1-8 Parallel Port Configuration Use the Parallel Port Configuration menu to configure the parallel port. 85 | 95...
  • Page 86 ClientPOS PT6300 User Manual Version: 2.0 7-1-9 H/W Monitor The H/W Monitor menu shows the operating temperature and fan speeds. 86 | 95...

  • Page 87: Chipset

    ClientPOS PT6300 User Manual Version: 2.0 Chipset Use the Chipset menu to access the Northbridge and Southbridge configuration menus WARNING! Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction.
  • Page 88 ClientPOS PT6300 User Manual Version: 2.0 7-2-1 Northbridge Configuration Use the Northbridge Chipset Configuration menu to configure the Northbridge chipset. Initiate Graphic Adapter [PEG/IGD] Use the Initiate Graphic Adapter option to select the graphics controller used as the primary boot device. Select either an integrated graphics controller (IGD) or a combination of PCI graphics controller, a PCI express (PEG) controller or an IGD.
  • Page 89 ClientPOS PT6300 User Manual Version: 2.0 7-2-2 Southbridge Configuration Use the Southbridge Configuration menu to configure the Southbridge chipset. Serial Port 1/2 Voltage Select [STD] Select "COM1/2 PIN9 Function" and press <Enter> to setup COM 1/2 PIN9 function. ITEM Option...
  • Page 90 ClientPOS PT6300 User Manual Version: 2.0 7-2-3 ME Subsystem Use the ME Subsystem menu to configure the Intel® Management Engine (ME) configuration options. 90 | 95...

  • Page 91: Boot

    ClientPOS PT6300 User Manual Version: 2.0 Boot Use the Boot menu to configure system boot options. Bootup NumLock State [On] Use the Bootup NumLock State BIOS option to specify if the number lock setting must be modified during boot up.

  • Page 92: Security

    ClientPOS PT6300 User Manual Version: 2.0 Security Use the Security menu to set system and user passwords. Administrator Password Use the Administrator Password to set or change an administrator password. User Password Use the User Password to set or change a user password.
  • Page 93 ClientPOS PT6300 User Manual Version: 2.0 Save & Exit Use the Save & Exit menu to load default BIOS values, optimal failsafe values and to save configuration changes. 93 | 95...
  • Page 94 ClientPOS PT6300 User Manual Version: 2.0 LCD Surface Cleaning CD Surface Cleaning 1. How to clean the LCD surface properly? ☆ Do not spray any liquids on the LCD screen directly, and do not use paper towels, this can cause the LCD screen to become scratched.
  • Page 95 ClientPOS PT6300 User Manual Version: 2.0 CE Notice This device complies with the requirements of the CE directive. FCC Notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
