  • Page 1 PT8000 User Manual Version: 1.0 P/N :...
  • Page 2 ClientPOS PT8000 User Manual Version: 1.0 Copyright Copyright 2012 Publishing. All Rights Reserved. This manual, software and firmware described in it are copyrighted by their respective owners and protected under the laws of the Universal Copyright Convention. You may not reproduce,...

  • Page 3: Safety Instructions

    ClientPOS PT8000 User Manual Version: 1.0 Safety Instructions Read these instructions carefully. Keep these instructions for future reference. Please disconnect this equipment from AC outlet before cleaning. Don’t use liquid or sprayed detergent for cleaning. Use moisture sheet or cloth for cleaning.

  • Page 4: Fcc Notice

    ClientPOS PT8000 User Manual Version: 1.0 CE Notice This device complies with the requirements of the CE directive. FCC Notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 5: Table Of Contents

    ClientPOS PT8000 User Manual Version: 1.0 Table of Contents Copyright……………………………………………………. Safety Instructions………………………………………… CE /FCC/WEEE Notice…………………………………….. 1. Packing List……………………………………………… Standard Accessories……………………………………….. Optional Accessories………………………………………... 2. System View ……………………………...………. …… Rear View…………………………………………………….. Specification………………………………………………….. Internal Layout……………………………………………….. 3. Pin Definition……………………………………………... 4. Rear I/O Interface…………………..…………………… 5. System Assembly & Disassembly……………………...
  • Page 6 ClientPOS PT8000 User Manual Version: 1.0 Installation and Testing of Smart Card Reader…………… 7. BIOS/Utility Setup……………………………………….. Advanced…………………………………………………….. 7-1-1 ACPI Configuration………………………………… 7-1-2 S5 RTC Wake Settings……………………………. 7-1-3 CPU Configuration…………………………………. 7-1-4 IDE Configuration…………………………………... 7-1-5 IT8783F Super IO Configuration…………………. 7-1-6 Parallel Port Configuration…………………………...

  • Page 7: Packing List

    ClientPOS PT8000 User Manual Version: 1.0 Packing List Standard Accessories System (with stand) Power Adapter Power Cord Driver Bank M3 Screw x2 Optional Accessories 1. Single MSR 2. 3 IN 1 MSR 3. Screw x2 1| 72...
  • Page 8 ClientPOS PT8000 User Manual Version: 1.0 System View 2-1 Rear View 9 10 Item Power Switch 19V DC-in lock connector USB x4 RJ45(LAN) RJ11 for cash drawer PS/2 RJ45(COM3 for External VFD) Mic-in 10. Line-out 11. LPT(Option) 12. PS/2 MSR Switch Gear(Option) 13.

  • Page 9: System View

    • Intel™ Cedarview CPU does not support 64-bit OS, therefore 64-bit Microsoft Windows® Embedded POSReady 7 and 64-bit Microsoft Windows® 7 are not supported on PT8000. • Current Intel™ XP Pro / POSReady 2009 graphics driver for Cedarview platform does not support dual display.

  • Page 10: Internal Layout

    ClientPOS PT8000 User Manual Version: 1.0 System View Internal Layout Front Side Backside 4 | 72...

  • Page 11: Pin Definition

    ClientPOS PT8000 User Manual Version: 1.0 Pin Definition 1. Power Switch (CN1) Power switch (CN1) Signal PWRBTN_N 2. Internal connector fo USB6 ☆ USB 6 is connected to one hub, and it Signal is for iButton, RFID and barcode scanner.
  • Page 12 ClientPOS PT8000 User Manual Version: 1.0 Pin Definition Jumper setting JP2 Signal Signal Signal K/B Data MSR K/B Data K/B Clock MSR K/B Clock 6. CFast connector Signal Signal Signal Signal V3.3 V3.3 7. 22Pin SATA connector Signal Signal Signal Signal V3.3...
  • Page 13 ClientPOS PT8000 User Manual Version: 1.0 Pin Definition 9. Mini PCI-E Signal Signal Wake# Signal Signal +3.3V RSVD RSVD RSVD REFCLK- USB D- RSVD RSVD RSVD RSVD REFCLK+ W_Disable# USB D+ 1.5V RSVD RSVD CLKREQ# PERST# RSVD RSVD PER_ND RSVD +3.3V_AUX...
  • Page 14 ClientPOS PT8000 User Manual Version: 1.0 Pin Definition 12. Line Out & Mic In (Audio CN8) Signal Signal Line_Out L MIC_Th_L AMP-L MIC_Th_R AMP-R Line_Out R 13. Speaker (CN5) Signal 14. LCD Panel (LVDS) LVDS connector Back light(Inverter) Signal Signal...

  • Page 15: Rear I/O Interface

    ClientPOS PT8000 User Manual Version: 1.0 Rear I/O Interface 1. COM Port Signal Signal Signal Ground 5V/12V/Ring **COM1 and COM2 Pin9 function selection by BIOS Item 2. Cash Drawer(COM 6) Signal Signal Signal Example DOS COMMAND for Cash Drawer: 1. Create the file: TEST.TXT Open/close detection 2.
  • Page 16 ClientPOS PT8000 User Manual Version: 1.0 Rear I/O Interface 7. Giga LAN Signal Signal Signal MDI2+ LED1(Green +, Orange -) MDI0+ MDI2- LED1(Green -, Orange +) MDI0- MDI3+ LED2(Yellow +) MDI1+ MDI3- LED2(Yellow -) MDI1- ** LED1 : Link signal ** LED2 : Action signal 8.

  • Page 17: System Assembly & Disassembly

    ClientPOS PT8000 User Manual Version: 1.0 System Assembly & Disassembly 1. Put the HDD on the HDD bracket HDD bracket 67D200418-000B (67D200418-000B) 2. Fasten the 4 M3 screws (64D030044-100B) 3. Unscrew 2 M3 screws (64D030060-200T) 4. Unscrew the HDD cover 5.

  • Page 18: Ram

    ClientPOS PT8000 User Manual Version: 1.0 System Assembly & Disassembly 1. Unscrew 2 M3 screws (64DA30104-100B) and remove MSR 2. Unscrew 4 M4 screws (64D040081-100B) and remove the stand. 3. Unscrew 6 M4 screws (64D030060-200T) and remove the panel back 4.

  • Page 19: Cfast

    ClientPOS PT8000 User Manual Version: 1.0 System Assembly & Disassembly CFAST 1. Unscrew 2 M3 screws (64D030060-200T) and remove the HDD cover 2. Insert CFAST card 3. Reinstall the HDD cover and secure it with screws 1. Unscrew 2 M3 screws (64D030060-200T) 2.
  • Page 20 ClientPOS PT8000 User Manual Version: 1.0 System Assembly & Disassembly 1. Remove VFD door(68D640000-000B) 2. Plug M/B side of VFD cable (35D510528-000B) into the motherboard 3. Plug the VFD cable (35D510528-000B) into the VFD device 4. Install VFD with screws.
  • Page 21 ClientPOS PT8000 User Manual Version: 1.0 System Assembly & Disassembly WLAN 1. Unscrew 2 M3 screws (64DA30104-100B) and remove MSR 2. unscrew 2 M3 screws (64D030060-200T) and remove the VFD cable from the VFD module 3. Unscrew 4 M4 screws (64D040081-100B) and remove the stand.
  • Page 22 ClientPOS PT8000 User Manual Version: 1.0 System Assembly & Disassembly 9. Disconnect the 2 cable 10. Adhere 2 pcs of aerials (35D510576-000B) through the red window 11. Adhere the cable clip 12. Arrange wires and adhere them on the cable clip 13.

  • Page 23: Device Driver Installation

    ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation Resistive Type Touch Panel 1. Click “Next”. 2. Click “Next”. 17 | 72...
  • Page 24 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation 3. Click “Next”. 4. Select “None”, Click “Next”. 5 Click “OK”. 18 | 72...
  • Page 25 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation 6. Select “Support Multi-Monitor System”, Click “Next”. 7. Click “Next”. 19 | 72...
  • Page 26 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation 8. Click “Next”. 9. Click “Next”. 20 | 72...
  • Page 27 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation 10. Select “Create a eGalaxTouch Utility shortcut on desktop”, Click “Next”. 21 | 72...
  • Page 28 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation 11. Would you do 4 point calibration now? Click “Yes”. 12. Do 4 points aligrment to match display. 13. Calibration utility. 22 | 72...

  • Page 29: Magstripe Card Reader Configuration Utility

    ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation MagStripe Card Reader Configuration Utility The MagStripe Card Reader Configuration Utility is used to set up the output format of HID Installation Below steps guide you how to install the Utility program ...
  • Page 30 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation  The utility program will detect the connected reader. If detected, all the input text boxes will be enabled.  If the reader has not been connected to PC yet, please connect the reader and then click Refresh to get connected.
  • Page 31 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation  ISO: Define start and end sentinel character.  Decode Mode: Determines the way of outputting the three tracks data. Shown below is the data structure of the output string for MSR.
  • Page 32 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation package can be up to 127.  TK1: For the prefix string, it is appended in the front of the start sentinel of track 2. For the suffix, it is appended in the end of the end sentinel of track 2. The max data length of the prefix and suffix for the TK1 can be up to 127.
  • Page 33 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation Track Data Filtering Shown below is the filter setting for track 1. This provides a fool-proofing method in case of receiving unwanted or uncompleted track data. These three filter settings are: ...
  • Page 34 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation There 6 orders allow to be selected. Please select one to fit your application needs. Update Settings Once complete the settings, click Update to update the settings to connected HID MSR reader.

  • Page 35: Fingerprint Reader

    ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation Fingerprint Reader 1. Check Fingerprint reader be detected by “Device manager “ 2. Select SDK folder. 3. Run Setup.exe. 29 | 72...
  • Page 36 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation 4.Click “Next”. 5. Select “ I accept the terms in the license agreement” and click “Next”. 30 | 72...
  • Page 37 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation 6. Click “Next”. 7. Click “Next”. 31 | 72...
  • Page 38 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation 8. Click “Install”. 9. Click “Finish”. 32 | 72...
  • Page 39 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation 10. Restart systems. 11. Check Fingerprint reader in Device Manager. 33 | 72...
  • Page 40 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation 12. Launch Fingerprint reader from start menu 13. Select “COM-ActiveX” 34 | 72...
  • Page 41 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation 14. Select “Sample” 15. Select ”VB6’. 35 | 72...
  • Page 42 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation 16. Select “Enrollment Sample”. 17. Enroll the fingerprint by the “Enrollment“ 18. Select “Fingerprint Enrollment” 36 | 72...
  • Page 43 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation 19. Put your finger on fingerprint reader and follow the direction to enroller your fingerprint, it need scan your fingerprint 4 times 20. After enroller finish it will popup a dialog box...

  • Page 44: Rfid

    ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation RFID 1. Install (Operating System: Microsoft Windows POSReady 2009) Check the Device Manager to verify the status of RFID reader. Computer Management -> Device Manager -> Other devices (The device will show a question mark if the installation is not done properly.)
  • Page 45 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation 1.2.1 After clicking Next, A pop up console window appears as below. 1.2.2 Check the Device Manager to verify the status of RFID reader. Computer Management -> Device Manager -> Ports (COM & LPT)
  • Page 46 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation 1.3 install RFID utility MifareDemoSetup_PSW00020.exe 3-1 Path:\MF320\MifareDemoSetup_PSW00020.exe 1.3.1 InstallShield Wizard will be activated. 40 | 72...
  • Page 47 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation 1.3.2 Click “Next”. 1.3.3 Click “Next”. 41 | 72...
  • Page 48 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation 1.3.4 Click “Giga-TMS” & “Next”. 1.3.5 Click “Next”. 42 | 72...
  • Page 49 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation 1.3.6 Click “Finish” 2. Run RFID demo program. Start -> All Programs -> GIGA-TMS -> Mifare Demo 43 | 72...
  • Page 50 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation 2.1 Run “Auto Scan” Demo AP will detect the RFID reader automatically. Or select the RFID COM port 2.2 After finishing the AutoScan, Request box will be ready for the click and Reader Version will show on the position as marked.
  • Page 51 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation Place the RFID card on the RFID reader. 2.3 Card type will be recognized when you click “Request”. (Your Mifare card should be placed on the RFID reader area.) Card ID will be recognized when you click “Card ID”.
  • Page 52 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation 2.5 SAK will be read when you click “Select”. 2.6 The result will show when you click “Authenticate”. 46 | 72...

  • Page 53: Internal Vfd

    ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation Internal VFD Specification Display Method Vacuum Fluorescent Display(blue-Green) Number of Characters 40 (20 Columns X 2 Lines) Brightness 500 ~ 1000 cd/m2 Character Font 5X7 Doc Matrix General Character Type 95 Alphanumeric, 32 International Characters Character Size 6.75(H) X 3.75(W)mm...
  • Page 54 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation 48 | 72...
  • Page 55 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation 49 | 72...
  • Page 56 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation 50 | 72...

  • Page 57: I-Button Reader Configuration Utility

    ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation i-Button Reader Configuration Utility The i-Button Reader Configuration Utility is used to set up the output format of HID MSR Installation Below steps guide you how to install the Utility program.
  • Page 58 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation  The utility program will detect the connected reader. If detected, all the input text boxes will be enabled.  If the reader has not been connected to PC yet, please connect the reader and then click Refresh to get connected.
  • Page 59 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation Update Settings Once complete the settings, click Update to update the settings to connected HID MSR reader. Save Settings To save the settings to a file, click Save; specify the file name and location to be saved.

  • Page 60: Version: 1.0

    ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation Installation and Testing of Smart Card Reader Check smart card reader be detected by “Device manager”. 2. Install the SCR driver. 54 | 72...
  • Page 61 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation 3. Run Setup.exe. 4. Click “Yes”. 5. Restart systems. 55 | 72...
  • Page 62 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation 6. Check SCR reader in Device Manager. 7. Run the testing program – EZ100test. 56 | 72...
  • Page 63 ClientPOS PT8000 User Manual Version: 1.0 Device Driver Installation 8. Conferm that SCR can be detected by the testing program, then run the program - the Start Testing. 9. Follow dialog boxes displayed to remove and insert card. 10. After finishing the testing, the dialog box will show “oK”.

  • Page 64: Bios/Utility Setup

    ClientPOS PT8000 User Manual Version: 1.0 BIOS/Utility setup Press <DEL > / <F2> key to enter BIOS SETUP UTILITY when system boot up. ☆ Please press <DEL > / <F2> key tenderly and slowly. Date and Time The Date and Time items show the current date and time on the computer. If you are running a Windows OS, these items are automatically updated whenever you make changes to the Windows Date and Time Properties utility.

  • Page 65: Advanced

    ClientPOS PT8000 User Manual Version: 1.0 BIOS/Utility setup Advanced Use the Advanced menu to configure the CPU and peripheral devices through the following sub-menus: Launch PXE OPROM: Enable or Disable PXE Function 59 | 72...

  • Page 66: Acpi Configuration

    ClientPOS PT8000 User Manual Version: 1.0 BIOS/Utility setup 7-1-1 ACPI Configuration The ACPI Configuration menu configures the Advanced Configuration and Power Interface (ACPI) options ACPI Sleep State Use the ACPI Sleep State option to specify the sleep state the system enters when it is not being used.

  • Page 67: S5 Rtc Wake Settings

    ClientPOS PT8000 User Manual Version: 1.0 BIOS/Utility setup 7-1-2 S5 RTC Wake Settings Enable or disable system wake on alarm event. When enabled, system will wake on the hr::min::sec specified. 61 | 72...

  • Page 68: Cpu Configuration

    ClientPOS PT8000 User Manual Version: 1.0 BIOS/Utility setup 7-1-3 CPU Configuration Use the CPU Configuration menu to enter the CPU Information submenu or setup Intel CPU parameter. 62 | 72...

  • Page 69: Ide Configuration

    ClientPOS PT8000 User Manual Version: 1.0 BIOS/Utility setup 7-1-4 IDE Configuration Use the SATA Configuration menu to change and/or set the configuration of the SATA devices installed in the system. SATA Mode Use the SATA Mode option to configure SATA devices as normal IDE devices.

  • Page 70: It8783F Super Io Configuration

    ClientPOS PT8000 User Manual Version: 1.0 BIOS/Utility setup 7-1-5 IT8783F Super IO Configuration Use the Super IO Configuration menu to set or change the configurations for parallel ports and serial ports. 64 | 72...
  • Page 71 ClientPOS PT8000 User Manual Version: 1.0 BIOS/Utility setup Serial Port n Configuration Use the Serial Port n Configuration menu to configure the serial port n. Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port.

  • Page 72: Parallel Port Configuration

    ClientPOS PT8000 User Manual Version: 1.0 BIOS/Utility setup 7-1-6 Parallel Port Configuration Use the Parallel Port Configuration menu to configure the parallel port. 66 | 72...

  • Page 73: Chipset

    ClientPOS PT8000 User Manual Version: 1.0 BIOS/Utility setup Chipset Use the Chipset menu to access the Southbridge configuration menus WARNING! Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction.

  • Page 74: Southbridge Configuration

    ClientPOS PT8000 User Manual Version: 1.0 BIOS/Utility setup 7-2-1 Southbridge Configuration Use the Southbridge Configuration menu to configure the Southbridge chipset. 68 | 72...

  • Page 75: Boot

    ClientPOS PT8000 User Manual Version: 1.0 BIOS/Utility setup Boot Use the Boot menu to configure system boot options. Bootup NumLock State [On] Use the Bootup NumLock State BIOS option to specify if the number lock setting must be modified during boot up.

  • Page 76: Security

    ClientPOS PT8000 User Manual Version: 1.0 BIOS/Utility setup Security Use the Security menu to set system and user passwords. Administrator Password Use the Administrator Password to set or change an administrator password. User Password Use the User Password to set or change a user password.

  • Page 77: Save & Exit

    ClientPOS PT8000 User Manual Version: 1.0 BIOS/Utility setup Save & Exit Use the Save & Exit menu to load default BIOS values, optimal failsafe values and to save configuration changes. 71 | 72...

  • Page 78: Lcd Surface Cleaning

    ClientPOS PT8000 User Manual Version: 1.0 LCD Surface Cleaning 1. How to clean the LCD surface properly? ☆ Do not spray any liquids on the LCD screen directly, and do not use paper towels, this can cause the LCD screen to become scratched.
