Page 1 Film-Tech The information contained in this Adobe Acrobat pdf file is provided at your own risk and good judgment. These manuals are designed to facilitate the exchange of information related to cinema projection and film handling, with no warranties nor obligations from the authors, for qualified field service engineers.
Page 2: Xd10 Cinema Media Player
XD10 Cinema Media Player Installation and Operating Guide Version 1.0 Effective Date: June, 2003 Document # 9301E692001.0 Digital Theater Systems, Inc. Cinema Products Division 5171 Clareton Drive Agoura Hills, CA 91301...
Page 3: Table Of Contents
XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 Table Of Contents XD10 Cinema Media Player .......................... i Introduction..............................vii DTS Customer Service ..........................viii Returning Units for Service ......................... ix Installation Checklist ............................ x OPERATIONAL OVERVIEW .....................1-1 1.1. Loading Discs ..........................1-1 1.1.1.
Page 4 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 1.8.4. CSP Setup ........................1-21 1.8.4.1. Image Size .........................1-21 1.8.4.2. Vertical Offset ......................1-21 1.8.4.3. Test Patterns ......................1-21 1.8.4.4. Options ........................1-22 1.8.5. Automation Setup ......................1-23 1.8.5.1. Format Assignment ....................1-23 Operating Modes .......................1-26 1.8.5.2.
Page 5 XD10 MAINTENANCE AND TROUBLESHOOTING ............5-1 5.1. Routine Maintenance ........................5-1 5.2. XD10 Troubleshooting Tips ......................5-1 5.2.1. I have a DTS print but I don’t have discs................5-1 5.2.2. Film not in sync or doesn’t sound right ................5-2 5.2.3. Volume too loud.........................5-2 5.2.4.
Page 6 E732 (XD10-CP200) E733 (XD10-CP200SRD) E734 (XD10-CP55 MONO) E735 (XD10-CP55 STEREO) E742 (XD10-CP200) B.2. Brackets for the DTS Timecode Reader Head, 35mm and 70mm..........B-2 B.3. Timecode Reader Head Aux Roller Installation ................. B-11 B.4. Timecode Reader Head Drawings ....................B-12 B.5.
Page 7 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 G.7.1. Reset the Lamp Hour Counter on the Projector .............. G-20 G.8. DTS-EMA Maintenance ......................G-21 G.9. Troubleshooting the DTS-CSS Option ..................G-22 G.10. Troubleshooting Rear Window (Captions) Option ..............G-24 G.11.
Page 8: Introduction
The DTS XD10 provides the standard 5.1 channel outputs: Left, Center, Right, Left Surround, Right Surround, and Subwoofer (L, C, R, LS, RS, SW). In addition, the XD10 can provide Left Center, Right Center, Back Surround, and Auxiliary outputs for select releases. A Mono Surround output, derived from mixing the LS and RS outputs, is also available.
Page 9: Dts Customer Service
We also publish the Tech Talk newsletter with tips and updates for our users. Tech Talk is published quarterly – and posted on our web site. If you would like to be added to our mailing list, contact DTS Customer Service.
Page 10: Returning Units For Service
Before sending any item back to DTS for warranty, repair, exchange or replacement parts, please call DTS at (818) 706-3525 or USA toll free (800) 959-4109 to provide the serial number of the equipment to be returned and to obtain a Return Authorization number. No replacement units will be sent and no shipments will be accepted without a Return Authorization number.
Page 11: Installation Checklist
Use these checklists to ensure important settings are completed before showing film to an audience. The first one is for the XD10. The second list is for the CSS Option. The third one is for the Video option. Table 0-1. XD10 Installation and Setup...
Page 12: Version
XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 If Cinema Subtitling System (CSS) option is to be installed, complete the following steps. Table 0-2. CSS Installation and Setup Completed Task Refer to: Install EMA and subtitling projector Appendix G Cinema Subtitling System (option) Installation and Troubleshooting, p.
Page 13: Operational Overview
“DTS Cinema Video” disc. This disc has special formatting that enables the material to become part of the XD10 “Video Playlist”. It must be part of the Video Playlist in order for the material to be available for playback at the appropriate time.
Page 14: About Dts Trailer Discs
1. Power on the unit (if it is not already ON). The Main power switch is on the rear of the unit (and should always be ON). The Standby / On switch is on the front of the XD10 – turn it 2.
Page 15: Loading A 2-Disc Movie
6. Remove the disc from the tray and place it in its case. Put the case and disc back into the film carrier for return to the depot with the print. DTS trailer discs may be stored. They do not need to be returned. When a new trailer is loaded (replacing the previous one), you may discard the old trailer disc(s).
Page 16: Cd-Rom Read Error
1.2.6. Splice in the DTS Logo Trailer Film Add the DTS trailer (logo) film to the head of the DTS encoded movie. Splice it in at about six frames after fade-out (where it should still have timecode) and add it directly to the first frame of the movie with timecode.
Page 17: Routine Maintenance
Maintenance and Troubleshooting. 1.4. After the Show Feature discs After the feature has been loaded into the XD10, replace the discs into their cases and place back into the correct film cans. Trailer discs These are sent out by DTS and do not have to be returned after use.
Page 18: Controls And Indicators
1.5.2. LCD Playscreen In addition to the front panel status LEDs, the XD10 liquid crystal display (LCD) screen shows useful information during playback. This information includes identifying data for the program material being played, as well as running timecode. It can also display additional information as described below.
Page 19: Menus
1.6. Menus The XD10 menus are divided into two major areas of control, one for System Setup, the other for Playback functions. Status displays showing System Version and other information are also available from the Main Menu. The diagram on the next page shows how to use navigation buttons with the menu structure to perform a typical adjustment.
Page 20 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 Using the Menus If no program material is running, the display will simply show Ready to indicate that it is on. Ready Press the Enter button. MAIN MENU ▼ Press once and then ⇒...
Page 21: Playback
XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 MAIN MENU INFO SETUP PLAYBACK VERSION MAC ADDRESS OPTIONAL PASSWORD PROTECTION SOUNDTRACK CSP LANGUAGE SYSTEM OPTIONS TC RDR CSP SETUP Soundtrack Language: Automation OFFSET Automation CSP Off Image Size:50-100% COM2 Config...
Page 22 Version 1.0 1.7. Playback The XD10 Playback menu contains all of the controls and status reporting which might be needed during system operation. Many XD-10 functions are automated and programmed during system installation. The Playback Menu is intended for the projectionist/operator and is not password protected.
Page 23: Play Menu
• Playlist Zone – the zone code of the current Playlist • Player Zone – the zone code for this XD10 player, as set in Set Player Zone, page 1-19 • Audio Type – in this example, DTS Operational Overview 1-11 Document #: 9301E692001.0...
Page 24: Control Menu
1.7.2.4. Video Logging If Video Logging is enabled, the XD10 will track up to a month of video play data and allow you to send reports to a PC to satisfy a variety of reporting requirements. You can select to compile logs based on content, playlist, or both, and choose reporting periods that range from daily activity reports to reviews as far back as a month.
Page 25: Csp Language
ENTER to activate. ( )Yes (Delete) 1.7.3. CSP Language If your XD10 is equipped with the CSS Option, this menu will allow you to select MAIN MENU any of the issued subtitle languages for projection, to have the language specified by Automation controls, or to specify that no subtitling be shown.
Page 26: Csp Lamp Status
1.7.5. CSP Lamp Status MAIN MENU If the XD10 is equipped with the CSS Option, this menu displays the number of hours the DTS-CSP (cinema subtitle projector) lamp has been used (when the projector is powered up). The DTS-CSP lamp must be replaced after 1400 hours of PLAYBACK use.
Page 27: System Setup
Version 1.0 1.8. System Setup The XD10 Setup menu contains all of the controls needed to configure the unit for installation, operation, automation, and test. This section of the menu also provides controls for setup and configuration of the CSS and Video Options.
Page 28: Audio Setup
Playback menu. SYSTEM SETUP 1.8.2.1. Level Adjustment OPTIONAL PASSWORD PROTECTION The XD10 is set for 300mV reference tone output. This is what most cinema processors suggest for input. However, if changes are AUDIO SETUP needed, follow these instructions.
Page 29: Audio Tests
XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 1.8.2.3. Audio Tests This menu allows selection of Audio Tests, which are used for listening tests. System calibration is performed using the Level Adjustment menu (on the preceding page). Use ▲ and ▼ to move the cursor,...
Page 30: Video Setup
XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 1.8.3. Video Setup MAIN MENU The Video Setup controls are present only if your unit is equipped with the Video Option. If this option is not installed, the controls SYSTEM SETUP in this menu section will be inactive.
Page 31: Set Player Zone
Press ◄ to exit this screen. 1.8.3.3. Set AutoStop This menu allows you to determine the Stop behavior of video material when the XD10 is under Automation control. Select Stop Immediately to have Video shut off on receipt of an automated Stop command.
Page 32: Set Test/Normal
XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 1.8.3.5. Set Test/Normal VIDEO SETUP This menu is provided to allow the play of test images used in system troubleshooting. For normal operation, it should be left at the default setting,...
Page 33: Csp Setup
Flat Mask reflect your choice. You can select from the different subtitle sizes Scope mask supplied on the DTS-CSS subtitle disc. If you select a size that is View Area not available, the system will use the closest available size.
Page 34: Options
XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 1.8.4.4. Options This menu gives you the option of specifying a black background for displayed subtitles, and lets you adjust the light intensity of subtitle projection, if necessary for optimal viewing.
Page 35: Automation Setup
Soundtrack and Video. Note that the menus for Video Fallback will only be active if the XD10 Video Option is installed.
Page 36 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 Predefined Formats automatically configure the pins correctly for the most commonly used cinema processors: Use ▲ and ▼ to move the cursor, Automation Preset ( )DTS-6D Emulation then press ENTER to Save the ( )DTS-6AD/ECP setting.
Page 37 • DTS (Sustained) • DTS-ES If Automatic is selected as a fallback format, audio errors will cause the XD10 to switch to the optical format (Mono, A or SR) specified in the soundtrack audio header. Operational Overview 1-25 Document #: 9301E692001.0...
Page 38: Operating Modes
2 minutes from the end of the file – as determined by file size.) AutoSwitch (Optical Formats) In this mode, the XD10 switches to DTS format only if it is currently in one of the optical formats (Mono, A or SR). This allows the possibility of an alternate external format to be used without being overridden by the XD10.
Page 39: I/O Control
DTS format to activate XD10 automation. When DTS is selected by the automation system, the XD10 will remain in a predetermined fallback optical format, switching to DTS when a soundtrack begins, and automatically switching back to the fallback format if the soundtrack decoder stops before the end of the show.
Page 40 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 Use ▲ and ▼ to move the cursor, Change Out 1 then press ENTER to select. ( )Unassigned ( )Video Stop Select one of the following assignments: Unassigned Video Stop...
Page 41: Automation Test
XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 The Language Setup screens for Soundtrack and Subtitle offer similar choices. Use ▲ and ▼ to move the cursor, Language #1 ( )Arabic then press ENTER to select. ( )Basque Scroll down to EXIT or press ◄...
Page 42: System Options
1.8.6.2. Set Password Once your system is configured and installed, you can limit access to all of the XD10 Setup menus by assigning a 3-digit password. Once a password is assigned, selecting System Setup from the Main menu will trigger display of a Password Request window.
Page 43: Network
The System Clock menus allow you to view or set the Date, Time and Time Zone for your unit. Setting the time zone will allow the XD10 to automatically accommodate Daylight Savings Time. (The date, time, and time zone settings are only needed for video logging.) Use ▲...
Page 44: Display Language
The Mac Address is the unique address for this particular XD10 player that was assigned at the DTS factory. It is used as a network identifier, and for implementing option upgrades and other future applications.
Page 45: Language Management For The Xd10
A theater may also desire to change versions throughout the day. In the XD10, multiple versions of a film may be copied onto the hard drive. Since all of the versions are assigned the same serial number, there needs to be additional information given to the XD10 to select which version should be played.
Page 46: Using Automated Language Setups
XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 If you installed the same show with three different languages, then only the last one loaded will play under “Last Installed”. (The same is true if Language Versions is disabled.) •...
Page 47 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 2. Assign default audio language (no closure) under Language Setups. MAIN MENU I/O Control SETUP Pin Definitions Language Setups OPTIONAL PASSWORD PROTECTION Exit LANGUAGE SETUP MENU AUTOMATION SET UP Default...
Page 48: Check Procedures
When loading a disc that does not contain the Language ID value, and when Language Versions is enabled, the program will ask the user to identify the language. If Language Versions is disabled, the XD10 program does NOT prompt you to identify the language. (See Language Versions Enable, page 1-33.)
Page 49: Installation
Version 1.0 2. Installation This chapter includes unpacking and inspection advice, a list of XD10 components and options, XD10 installation procedure, including Timecode Reader head instructions and XD10 mounting and connection instructions. In addition, connector pinouts and information about XD10 interactivity with other cinema processors is provided.
Page 50: System Components
2.2. System Components The following is a list of the standard components for an XD10 shipment. Refer to the actual packing slip from your order to verify the contents of your shipment. Contact DTS immediately if items listed on your packing slip are missing.
Page 51: Xd10 Interconnection To Cinema Processors
XD10 Digital Playback System, Installation and Operating Guide Version 1.0 2.3. XD10 Interconnection to Cinema Processors This table identifies cables and breakout boards necessary when connecting the XD10 to specific cinema processors. Table 2-1. XD10 Interconnection to Cinema Processors Drawing Number...
Page 52: Dts Xd10 Interaction With Other Cinema Processors
2.3.1.2. Dolby CP45, CP55, CP65, CP500, CP650, UltraStereo JS Series, and SMART Operation The DTS XD10 will automatically pulse the audio processor to the digital format when it starts to play a digital sound track. Whenever the XD10 drops out of digital, a pulse will be sent to switch the audio processor back to optical format.
Page 53: Installation Procedures
All interconnects are standalone, and most systems require no cuts or jumpers. The XD10 requires 3U of standard rack space (5 1/4 x 15 x 19 inches) for proper mounting. Select a space in the sound rack within three feet of the cinema processor to which you are connecting.
Page 54: Rack Mount Considerations
XD10 Digital Playback System, Installation and Operating Guide Version 1.0 Caution: Because the XD10, like any other computer-based system, can be damaged by power line surges, we recommend using a computer-grade surge/spike suppresser. 4. Connect the analog and logic cables/cards to your cinema sound processor. (See Appendix B for installation diagrams –...
Page 55: Xd10 Connectors
XD10 Digital Playback System, Installation and Operating Guide Version 1.0 2.5. XD10 Connectors Refer to installation drawings in Appendix B. The back panel of the XD10 provides connectors for these functions: • receiving signals from the timecode reader • output of main audio, digital audio, and descriptive Narration audio •...
Page 56 XD10 Digital Playback System, Installation and Operating Guide Version 1.0 AUTOMATION – DB25F Description FORMAT 0 FORMAT 1 FORMAT 2 FORMAT 3 FORMAT 4 FORMAT 5 FORMAT 6 FORMAT 7 USER GND USER SUPPLY +5V to +15V @ 40mA (required for status feedback) TIMECODE –...
Page 57 XD10 Digital Playback System, Installation and Operating Guide Version 1.0 EMA CONTROL – DB15F Description EMA FAN SENSE COM 2 RX COM 2 TX COM 2 GND EMA DOUSER CONTROL +12V +12V +12V +12V COM 1 – DB9M Description DCD IN...
Page 58: Options List
DTS Digital Audio Output Card – to output digital audio • DTS Video Card – to output standard definition digital video for alternative media 2.7. Options Setup and Testing For instructions to install and configure these options, see the appropriate reference: •...
Page 59: Calibration And Setup
Consult the manual for your CP to determine the input buss level, or contact the manufacturer. Use the procedure below to verify that the XD10 is set to the correct output level or to make any necessary changes.
Page 60: Verifying Audio Levels
Version 1.0 3.2.1. Verifying Audio Levels The pink noise tests that are built into the XD10 are used only to make A-B comparisons to an alternate sound source such as magnetic sound track or analog sound. Be aware that some external pink noise generator cards used on some cinema processors (such as CP65 and CP55, that do not have internal pink noise generators) may have a level discrepancy of as much as 1.5dB.
Page 61: A Note About Dts Subwoofer Output
The mono surround output is a mix of the left and right surround signals. This “mono” signal is available ONLY on the mono surround output pin (pin 21) on the XD10's ANALOG OUT (CH 1-10) connector. 1. In theaters with only mono surrounds, select the left surround pink noise and adjust for 76 dBC SPL in the theater.
Page 62: Verifying Operation
5. While still in the booth, verify the XD10 DTS Playback LED (blue) is lighted and that the LCD screen displays the film title, Serial number, Reel number, and running timecode.
Page 63: Check Automatic Fail-Safe (Default) Operation
Verify that after 4 to 5 seconds of not seeing timecode, the DTS-XD10 switches to the SR optical sound format. There should not be a dramatic sound level difference when the cinema processor switches from digital to analog during dialogue scenes.
Page 64 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 Calibration and Setup Document #: 9301E692001.0...
Page 65: Specifications
SMPTE (25, 29.97, 30 ndf) Note: Theater uses 30fnd referenced to video (29.97) and D-Cinema uses 24 frame referenced to video (23.976) Timecode signal (DTS and SMPTE formats), “standard DTS timecode signal captive range 1.X-5V” Automation Connector: Rear Panel DB25F 8 “format”...
Page 66: Other Connectors
XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 Analog (Narr and Aux) Designed to support Descriptive Narrative (only available with CSS option?) Connectors: two Rear panel RCA Output Impedance: 10 K ohms Output Level: 300 mV +/- 10 mV Dynamic Range: 90dB, 20 –...
Page 67: Dvd Rom Drives
The added board scales the video output to the projector resolution (up to 1024 x 768) Coherent Acoustics and PCM48/24 If subtitling and pre-show video are both set up in an XD10, the video’s resolution will be that of the signal going to the CSP projector. However, only one of the two outputs (subtitling and pre-show) can be operating at a given time.
Page 68: User Interface
XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 4.6. User Interface 4.6.1. Status LEDS (Front Panel) LCD (Front Panel) A 4 line X 20 character, backlit LCD Backlight not adjustable. Viewing angle adjustment via trim pot through front panel.
Page 69: Regulatory - Safety, Emissions, And Susceptibility Specifications
XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 4.7. Regulatory – Safety, Emissions, and Susceptibility Specifications Table 4-3. Regulatory, Safety, EMI/EMC Safety UL950 (USA) (NOTE: THX requires U813) CSA 22.2 NO.950.95 3 edition (USA) c-UL (Canada) TUV (Europe): EN60950: 1992+A1+A2; 1993+ A3; 1995+A4; 1997...
Page 70: Xd10 Block Diagrams
Version 1.0 4.8. XD10 Block Diagrams The basic system provides 10 audio channels, 2 auxiliary channels, two DVD/CD drives and an internal hard drive. Downloadable CSS software allows the XD10 to be used with subtitling. BASIC SYSTEM INDICATOR DTS PLAYBACK...
Page 71 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 XD10 with VIDEO OPTION INDICATOR DTS PLAYBACK TIMECODE LIGHTS SOLID OUTLINE INDICATES VIDEO STANDARD COMPONENT NARRATION SERIAL CSP TEXT DOTTED OUTLINE INDICATES OPTION CSP LAMP FAULT DB25M AES/EBU OUT DB25F CINEMA...
Page 72 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 Specifications Document #: 9301E692001.0...
Page 73: Xd10 Maintenance And Troubleshooting
To adjust the overall sound level in the theater, adjust the main fader on the cinema processor. Be sure the soundtrack was loaded for the film you are playing. Feel free to contact DTS Post Production for help.
Page 74: Film Not In Sync Or Doesn't Sound Right
As a last resort, force the unit to play in optical mode. Turn off the DTS XD10 and verify that the cinema processor switches to optical. If it does not, adjust manually. Contact your DTS Theater Technician.
Page 75: Guide For A Seamless Change-Over
This is due to the fact that as soon as the first frame of action reaches the picture aperture on the incoming projector, the DTS digital sound will change over to that reel.
Page 76: Inside The Dts Xd10
Version 1.0 5.4. Inside the DTS XD10 Refer to Figures 5-1 and 5-2 (pages 5-5 and 5-6) for location of components within the XD10 chassis. 5.4.1. Timecode Board The Timecode board (E622) contains the timecode head offset information and these connectors: •...
Page 77 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 Figure 5-1. XD10 Top View Maintenance and Troubleshooting Document #: 9301E692001.0...
Page 78 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 Figure 5-2. XD10 Cutaway View Maintenance and Troubleshooting Document #: 9301E692001.0...
Page 79: Dts Xd10 System Parts List
8 inch DTS Panel Marquee Cables and Breakout Boards (for connecting to cinema processor) 2503 0014-00 Cable Assy, 25-pin “D” M/F, 6 ft long for DTS-6AD, DTS-ECP, CP65, UltraStereo JS series, Panastereo CSP1200 2503 0017-00 Cable Assy, 25-pin “D” M/M 6 ft long for DTS-6AD or DTS-ECP 9022 E173-00 Cable Assy, fem”D”...
Page 80: Replacement Parts
Wall Mounting Plate (fasteners not included – obtain locally) 1007 M601 00 Thumb screw (on wall mounting plate) Audio Output Testing 9030E31300A DTS tester board, for testing outputs at the XD10 Analog Output connector A.2. Replacement Parts Part Number Description Subtitles projector...
Page 81: Installation Diagrams
Version 1.0 B. Installation Diagrams Appendix The diagrams on the following pages cover most installations of XD10, Timecode Reader heads and EMAs. Contact DTS if the system you are installing requires additional information. B.1. Interconnect Diagrams: XD10 to Cinema Processor...
Page 82 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 Installation Diagrams Document #: 9301E692001.0...
Page 83: Brackets For The Dts Timecode Reader Head, 35Mm And 70Mm
10 x 24 x ½ in. long screw • D617 - DP75 Bracket (35mm only) Used to mount the DTS timecode reader head to the side of the projector. Comes with same hardware as the D614. See also D628 - “L” adapter panel, below. •...
Page 84 D628 - “L” adapter panel (35mm / 70mm) – used with D617 and breakaway plates Used to mount the DTS timecode reader head to the side of the projector. Comes with same hardware as the D614. D628 is used to adapt the D617 for use with the breakaway plates (D628 attaches to D617).
Page 85 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 DTS Reader Standard Mounting Brackets (next 3 pages) Installation Diagrams Document #: 9301E692001.0...
Page 86 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 Installation Diagrams Document #: 9301E692001.0...
Page 87 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 Installation Diagrams Document #: 9301E692001.0...
Page 88 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 Mounting adapters used when switching between 35mm & 70mm readers (next 3 pages) Installation Diagrams Document #: 9301E692001.0...
Page 89 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 Installation Diagrams Document #: 9301E692001.0...
Page 90 XD10 Cinema Media Player, Installation and Operating Guide XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 Version 1.0 Installation Diagrams Installation Diagrams B-10 B-10 Document #: 9301E692001.0 Document #: 9301E692001.0...
Page 91 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 Installing DTS Timecode Reader with spacer plates on a projector with a “mag” (magnetic) head. Installation Diagrams B-11 Document #: 9301E692001.0...
Page 92: Timecode Reader Head Aux Roller Installation
XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 B.3. Timecode Reader Head Aux Roller Installation Aux Roller Installation Procedure Installation Diagrams B-12 Document #: 9301E692001.0...
Page 93: Timecode Reader Head Drawings
XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 B.4. Timecode Reader Head Drawings These drawings are to be used to help installers determine Timecode offset (delay) only. Installation Diagrams B-13 Document #: 9301E692001.0...
Page 94: Dts 35Mm And 70Mm Readers, Switchable, Using The Same Bracket
XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 B.5. DTS 35mm and 70mm Readers, Switchable, Using the Same Bracket If both 35mm and 70mm reader heads are to be used on the same bracket, add spacer breakaway plates to the readers.
Page 95 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 Mounting adapters when switching between 35mm and 70mm Readers Installation Diagrams B-15 Document #: 9301E692001.0...
Page 96 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 Installation Diagrams B-16 Document #: 9301E692001.0...
Page 97: Xd10 Menu Structure
XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 C. XD10 Menu Structure Appendix MAIN MENU PLAYBACK MENU • Soundtrack Soundtrack Language • ( )Automation • ( )Last Installed ( )English (etc.) • Exit Menus • Video • Play Menu VIDEO PLAY MENU •...
Page 98 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 • Video Logging VIDEO LOG MAIN MENU • Log Report Menu • Select Report Type Report Type • ( )Content • ( )Playlist • ( )Both • Exit Menus •...
Page 99 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 • Contents CONTENTS MENU • Features Contents: Features • Films and Trailer names are shown • Trailers Contents: Trailers • thxbrdwy, etc. • Delete Contents DELETE CONTENTS MENU • Delete All Delete All Contents? •...
Page 100 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 • Setup SYSTEM SETUP MENU • TC Reader Offset Set Timecode Reader Offset: [ n.nn] Frames • Audio Setup AUDIO SETUP MENU • Level Adjustment Select Audio • Play 300mV Tone •...
Page 101 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 • Video Setup INSTALLATION MENU • Set Image SET IMAGE MENU • Resolution RESOLUTION MENU • ( ) 1024 x 768 • ( ) 1280 x 1024 • Exit Menus •...
Page 102 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 • CSP Setup CSP SETUP • Image Size Image Size Menu • ( )100% • ( )90% • ( )80% • ( )70% • ( )60% • ( )50% •...
Page 103 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 • Options • Douser Type ( ) Electronic ( ) Mechanical • Background Color ( )Normal ( )Black • Light Intensity ( )Low ( )High • Exit Menus • Exit Menus •...
Page 104 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 • Fallback Format Fallback Formats • Soundtrack Soundtrack Fallback ( )Automatic ( )Mono ( )A ( )etc. ( )Exit Menus • Video Video Fallback ( )Mono ( )A ( )SR (1) ( )etc.
Page 105 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 Language #1 ( )English ( )Fr. Canadian (…)Exit Menus • Subtitle Subtitle #1 ( )CSP Off ( )Undefined ( )Arabic (…)Exit Menus • Setup Input 2 Language Setup 2 (Same as above) •...
Page 106 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 • System Clock SYSTEM CLOCK MENU • Set Time Zone Select Time Zone Location: [Americas] Select Country: [United States] Select Time Zone and hit ‘Enter’ [America/Los Angeles] • Set System Date Set Date: [MM”DD”YYYY]...
Page 107: Language Management
XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 D. Language Management Appendix D.1. Soundtrack Dubbed Languages Area Language Code Code ext (Note 1) NORTH AMERICA English Fr. Canadian SOUTH AMERICA Braz.Portuguese Latin Spanish EUROPE Basque Bulgarian Castilian Spanish...
Page 108: File Header (Header.exe
D.2.1. XD10 Operation The XD10 can store multiple languages of any given movie. The operator selects which language version they wish to play. The language code must match the selected language. If more than one file is loaded with the same language code, then the code extension is used to determine which of those will play.
Page 109: Subtitle Languages
XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 D.3. Subtitle Languages Subtitle languages do not differentiate the following: • German or Swiss German • Castilian Spanish or Latin Spanish • Portuguese or Brazilian Portuguese • French or French Canadian...
Page 110 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 Area Language Code Code ext Mandarin Tamil Telugu Thai Urdu Vietnamese AFRICA/ MIDDLE EAST Arabic Zulu Note: The code extension selects between two files with the same code. If two files with the same code are loaded, then the extension is used to determine which file to use.
Page 111: Dts Track Specifications
XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 E. DTS Track Specifications Appendix 35mm DTS Track Specifications Document #: 9301E692001.0...
Page 112 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 70mm DTS Track Specifications Document #: 9301E692001.0...
Page 113: Video Option Installation
4. Audio cable – short RCA Male to RCA Male provided with video card 5. Video cable to projector At the XD10 end this must be 15 pin male cable; the projector end can be either 15 pin (typically male), 3 BNC (RGB) or 5 BNC (RGBHV).
Page 114 6. Depending on whether you are using the CSS option: a. If NOT using CSS, connect the “Projector Video” socket on the back of the XD10 to the 15 pin end of the “overlay cable”. b. If using CSS, connect the “Projector Video” on the XD10 to “video in” on the splitter using the extra video cable (item 8.b under Required Components, previous page).
Page 115: Enable / Test Procedure
1280x1024) gives the best results. In this case the projector should be set to “native” (or similar term to indicate no scaling). On the XD10, go to System Setup | Video Setup | Set Video | Resolution. After a change, some projectors need to be restarted in order to re-sync.
Page 116: Restore Factory Defaults
XD10 Cinema Media Player, Installation and Operating Guide Version X1.0 5. Set Player Zone from System Setup | Video Setup | Set Video | Set Player Zone menu, if needed. This may be left at the default of Zone 00 to display all content.
Page 117: Cinema Subtitling System (Css) Option
For most theaters, it will be in the projection booth. It is used to project subtitles that are supplied by the XD10 software. The subtitle video is downloaded into the XD10 from a “show disc.” Then the operator chooses the language desired for the subtitles, from the Playback | CSP Language menu, or chooses Automation to automate the subtitles selection process.
Page 118 *Wall Mounting Plate Fasteners requirement: Quantity: Four (4). Size: Larger than ¼ inch (6mm) to maximum 5/16 inch (8mm). Type depends on wall composition. Wall fasteners NOT supplied by DTS. Replacement Parts: DTS-EMA, External Masking Apparatus – see Appendix A. Cinema Subtitling (CSS) Option Document #: 9301E692001.0...
Page 119: Dts-Ema Assembly
XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 G.3. DTS-EMA Assembly Light shutter assembly, Part # 9020E65600 Fan assembly, wire assembly included, Part # 9022E65500 Replacement mask trims are available. Please specify size and part numbers. Each DTS-EMA comes with a set...
Page 120 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 Bracket (shown attached to arm). Part # 9120E57301D. Arm, three different lengths available. Choose the one appropriate for installation. See “DTS-EMA Vertical Drop Mounting Guide” (next page) for Wall mounting plate, Part # 9120E61000B.
Page 121: Dts-Ema Vertical Drop Mounting Guide
XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 G.4. DTS-EMA Vertical Drop Mounting Guide EMA VERTICAL DROP MOUNTING GUIDE - 6" ARM (DTS P/N 5006000300) If the distance from the bottom of the wall mounting plate to the bottom of the obstruction in the port window is no more than 4.3 inches (10.9 cm), then you can use...
Page 122 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 EMA VERTICAL DROP MOUNTING GUIDE - 12" ARM (DTS P/N 5006000400) If the distance from the bottom of the wall mounting plate to the bottom of the obstruction in the port window is no more than 10.3 inches (26.2 cm), then you can...
Page 123 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 EMA VERTICAL DROP MOUNTING GUIDE - 18" ARM (DTS P/N 5006000500) If the distance from the bottom of the wall mounting plate to the bottom of the obstruction in the port window is no more than 16.3 inches (41.4 cm), then you can...
Page 124: Subtitle Projector Installation
The installer shall be responsible for any injury or damage resulting from installer’s failure to follow procedure set forth in the manual, and DTS shall have no responsibility what-so-ever for any injury or damage resulting from installer’s failure to follow procedure set forth in this manual.
Page 125 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 Figure 1. Arm must pivot upward, when mounting foot is attached to EMA. b. Secure mounting foot to EMA chassis using the 3 metric (M6) screws (Figure 2). Figure 2. Secure mounting foot to EMA chassis c.
Page 126 Figure 4. (Before/After) Connect the arm to the support bracket. (EMA shown not attached.) 3. Connect the projector to the DTS-EMA assembly. Secure using the three captive Phillips screws (see arrows, Figure 5). The projector must be installed upside down.
Page 127 With four (4) proper fasteners, secure mounting plate to wall. (See figure 8.) Fastener size should be larger than ¼ inch (6 mm) to maximum 5/16 inch (8 mm). Since the type of fastener depends on the material used in the wall, DTS does not provide these fasteners.
Page 128 Separate the power cable from the data cables. Do not route them bundled together. Ensure data cables are not routed next to power sources or fluorescent lights. The EMA cable goes to EMA Control connector on the XD10. The Projector cable goes to Projector Video connector on the XD10.
Page 129: Programming The Dts-Csp Subtitle Projector
Figure 10. Connect cables. As a safety precaution, the addition of a safety cable to secure the DTS-EMA is highly recommended. In case of earthquake or mounting plate failure, the projector assembly will be prevented from falling to the floor.
Page 130 5. Check the Light Output of the projector. a. From the XD10 MAIN menu, press the ▼ button and scroll to SETUP. Press the ► button. b. Once in SETUP, press the ▼ button and scroll to CSP SETUP. Press the ► button.
Page 131: Vertical Subtitles
7. Aim the DTS-CSP Subtitle Projector (with screen masking removed). a. From the XD10 MAIN menu, press the ▼ button and scroll to SETUP. Press the ► button. b. Press the ▼ button and scroll to CSP SETUP. Press the ► button.
Page 132 (See step 6 on the previous page.) The magnetic trims are used to block out any extraneous light at the DTS-EMA. You will receive one large, one medium, and two small trims. Position them as needed so that only the intended “subtitle area” is lit by the test pattern.
Page 133: Regular Maintenance Of The Dts-Csp System
1400 of in-use hours may result in damage to the projector and is not covered by warranty. The XD10 CSS Lamp Fault red LED will flash, when 1400 in-use hours has been reached. The same indicator will light continuously to indicate that the lamp has failed.
Page 134: Replacing The Lamp Module
The lamp hour counter in the CSP Lamp Status menu displays the number of hours the lamp has been in use. Change the lamp when the brightness is no longer acceptable or after 1400 hours. The XD10 front panel features a CSP Lamp Fault indicator that will flash (red) when the lamp needs replacing. The indicator will light continuously (not flashing) in case of lamp failure.
Page 135 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 4. Loosen the two captive screws on the outside of the module, as shown in the figure below. 5. Lift and grasp the metal bail wire and lift the module out, as shown in the figure below.
Page 136: Reset The Lamp Hour Counter On The Projector
XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 9. Replace the lamp door by inserting the hooks on the lamp door into the slots on the projector and pressing the lamp door into place. The arrow on the lamp door should point to the lock icon on the bottom of the projector.
Page 137: Dts-Ema Maintenance
XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 G.8. DTS-EMA Maintenance The DTS-EMA comes with a special light shutter that requires periodic cleaning. Wipe it clean of dust and dirt using non-abrasive camera lens cleaner on a soft, dry cloth. Clean the shutter DTS EMA...
Page 138: Troubleshooting The Dts-Css Option
NO – then fix or replace the cables. 7. Go into the CSP Lamp Status menu (on the XD10) and verify the number of lamp hours has not exceeded 1400. The projector lamp must be replaced after 1400 hours of use.
Page 139 Subtitle text is dim on-screen 1. Verify the DTS-EMA fan is rotating. If fan stops, the projector light will dim. If fan stops rotating, replace it. Note: The projector light intensity is always set to “high” unless the EMA fan stops running, in which case the projector automatically switches to “low”.
Page 140: Troubleshooting Rear Window (Captions) Option
1. The DTS-EMA douser is probably open. Be sure “Douser/Fan Control” cable is plugged in and DTS-EMA fan is turning. Check cable for broken wires 2. Verify the XD10 menu SETUP | CSP SETUP | Test Patterns menu has been correctly exited. All test patterns should be turned off.
Page 141: Testing Subtitles
The narration is NOT playing in sync with the sound track or action on-screen Go to the XD10’s Setup | Timecode Reader menu to verify the offset value has been correctly set. If necessary, see Timecode Reader Sync Adjustment (chapter 3).
Page 142: Testing Rear Window Captions
2. Run the audio test “Alignment Tones”. This is accessible from the System Setup | Audio Setup | Audio Tests Menu. The XD10 should output a 1kHz reference tone on the narration output. 3. Use a voltmeter to verify 300 mV RMS ± 10 mV at the NARR connector on the rear of the XD10.
Page 143 XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 H. Technical Notes Appendix This appendix contains DTS Technical Notes related to the XD10 and its options. The table below lists the TNs, which follow this page in the order they are listed. Tech Note Designator Title...
Page 144: Technical Notes
XD10 Cinema Media Player, Installation and Operating Guide Version 1.0 Technical Notes Document #: 9301E692001.0...
Page 145 First, set the meter to DC volts. Connect leads to TP1 (“+” ) and TP2 ( ) on the D424 board. signal ground Then, connect the reader to a powered DTS player. The reader gets its power from the DTS player.
Page 146 LED may be damaged or aged. Older version D424 boards may not have a trim pot. In that case, if the voltage is not between 3.5 and 4.5 volts DC, then you must do a repair-exchange on the reader. Contact your local DTS dealer. Adjust trim pot until...
Page 147 K. Hultgren 8/7/02 B. Plunkett DTS, 5171 Clareton Dr., Agoura Hills, CA 91301 Contact Document Control for the latest revision. After adjustments are complete, reattach the back cover using the saved hex screws. Tighten all set- screws on the reader and check that all rollers rotate freely and do not wobble. Check that the reader’s mounting bracket is tightly fastened to the projector and that the reader is securely attached to the bracket.
Page 148 Contact Document Control for the latest revision Maintenance to Prevent Premature DTS-CSP Lamp Failure In dirty or dusty environments, the lamp module dust filter screen in the DTS-CSP projector can become plugged, causing excessively high temperatures inside the lamp module. Excessively high temperatures can cause premature lamp failure.
Page 149 K. Hultgren 7/02/2002 B. Plunkett DTS, 5171 Clareton Dr., Agoura Hills, CA 91301 Contact Document Control for the latest revision 2. After removing the lamp module, examine the condition of the dust filter screen. The screen is in the front part of the lamp module. Dirt and dust accumulation on the screen must be removed.
Page 150 K. Hultgren 7/02/2002 B. Plunkett DTS, 5171 Clareton Dr., Agoura Hills, CA 91301 Contact Document Control for the latest revision 4. Before replacing the cleaned lamp module, use canned air to clean out the projector lamp house cavity. Then, replace the lamp and lamp door.
Page 151 Version 1.0 DTS MARQUEE SIGN ORDER FORM For every DTS unit installed in a theater, we will provide one-sheet posters, 4-inch mini- marquee, 8-, 10-, or 12-inch marquee signs at no charge. Simply complete and submit the following information. Marquees and posters can be sent directly to the theater or dealer for distribution.
Page 152 Are the Left Extra and Right Extra being used for Subwoofer? Yes Return complete form via Fax to: +1 (818) 879-2476; Att: Customer Service, Or via mail to: DTS Customer Service – 5171 Clareton Drive – Agoura Hills, CA 91301 – USA. DTS Warranty Information...
