Appendix I: Technical Maintenance
This appendix provides instructions on how to change the battery on the motherboard and how to install
or change the auxiliary roller for the Timecode Reader Head. The information on installing the auxiliary
roller applies to Timecode Reader Heads that do not have an RoHS sticker.
This appendix also has reference material for the technician servicing the product. This includes:
Description of the components inside the unit
Drawings of the inside of the unit
Drawing of the back panel
Appendix I. Technical Maintenance
DTS XD10 Cinema Media Player Installation and Operating Guide
1
I-
V 2.1
Document #: 9301E69200V2.1
Advertisement
Table of Contents
Related Manuals for DTS XD10
Summary of Contents for DTS XD10
- Page 1 DTS XD10 Cinema Media Player Installation and Operating Guide V 2.1 Appendix I: Technical Maintenance This appendix provides instructions on how to change the battery on the motherboard and how to install or change the auxiliary roller for the Timecode Reader Head. The information on installing the auxiliary roller applies to Timecode Reader Heads that do not have an RoHS sticker.
- Page 2 A coin-cell battery (CR2032) powers the real-time clock and CMOS memory when the XD10 is disconnected from AC power. The battery has an estimated life of three years. When the XD10 is connected to AC power, the standby current from the power supply extends the life of the battery.
- Page 3 7. Reconnect the IDE cable E540. It was removed in Step 3. 8. Reinstall the top cover of the XD10. 9. If you removed the XD10 from the rack, replace it into the rack and reconnect all cabling. 10. Connect the power cord to the AC source.
- Page 4 DTS XD10 Cinema Media Player Installation and Operating Guide V 2.1 Installing or Changing Auxiliary Roller for Timecode Reader Head The Auxiliary Roller is designed to mount at either end of the reader’s small secondary rollers. The following instructions and diagrams provide step-by-step instructions for installing or changing an auxiliary roller.
-
Page 5: Inside The Dts Xd
A circuit breaker protects the power going to the DTS Timecode Reader Head (through the 9-pin connector) against short circuits. The breaker is self-resetting so replacement is unnecessary. The 9-pin connector (accessed on the DTS XD10 rear panel) is used to connect the timecode cable to the Timecode Reader on the projector. - Page 6 DTS XD10 Cinema Media Player Installation and Operating Guide V 2.1 Figure 3. Top View of the XD10 Appendix I. Technical Maintenance Document #: 9301E69200V2.1...
- Page 7 DTS XD10 Cinema Media Player Installation and Operating Guide V 2.1 Figure 4. XD10 Cutaway View Appendix I. Technical Maintenance Document #: 9301E69200V2.1...
- Page 8 DTS XD10 Cinema Media Player Installation and Operating Guide V 2.1 Back Panel Diagram Figure 5. XD10 Back Panel Diagram Appendix I. Technical Maintenance Document #: 9301E69200V2.1...
