Page 1 ® XD10 Cinema Media Player Installation and Operations Guide Version 2.1 Effective Date: June 2007 Document # 9301E692002.1 DTS, Inc. Cinema Division 5171 Clareton Drive Agoura Hills, CA 91301...
Page 2 The content of this publication is subject to change without notice and does not represent a commitment on the part of DTS, Inc., to notify you of any changes or updates. While DTS, Inc, believes this publication is accurate, due to ongoing improvements and revisions, DTS, Inc. cannot guarantee the accuracy of printed material, nor can it accept responsibility for errors or omissions.
Page 3: Table Of Contents
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 Table of Contents INTRODUCTION ..............................VIII DTS TECHNICAL SERVICE ..........................X INSTALLATION CHECKLIST..........................XI PART 1: OPERATOR ..............................1 OPERATING THE XD10 CINEMA MEDIA PLAYER ................1 1.1. XD10 C .............................1 OMPONENTS 1.1.1.
Page 4 Film Is Not in Sync or Does Not Sound Right...................46 4.3.3. Volume Is Too Loud ..........................46 4.3.4. XD10 Does Not Play Soundtrack Audio to Film ................47 4.3.4.1. Timecode LED Is Blinking ........................... 47 4.3.4.2. Timecode LED is Solid, but Playback LED is Not Lit ................. 47 4.3.4.3.
Page 5 XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 ® 5.3.3. Sony SDDS ............................56 5.3.4. Panastereo CSP1200 and SMART ....................56 ® 5.3.5. Dolby CP200 Operation........................57 5.3.6. XD10P Operation..........................57 5.4. XD10 C ........................57 ALIBRATION AND ETUP 5.4.1. Equipment Requirements........................57 5.4.2.
Page 6 XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 7.5.2.2. Custom Formats ............................91 7.5.3. Fallback Format for Soundtrack.......................93 7.5.4. Automation Operating Mode......................94 7.5.4.1. DTS-6D Emulation ............................94 7.5.4.2. AutoSwitch (Optical Formats) ........................95 7.5.4.3. Preselect Mode (SRD compatible)........................ 95 7.6.
Page 7 XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 Appendices A. Connector Pinouts B. Cinema Processor Interface Wiring Diagrams C. HD Video and DTS-CSS Option Wiring Diagrams D. Cable Assemblies and Breakout Cards E. DTS Timecode Reader Head Mounting Brackets F.
Page 8: Introduction
® This manual explains the DTS XD10 Cinema Media Player setup and operation. It contains full instructions for installing hardware and software, setting up audio playback, configuring the system, performing maintenance and troubleshooting, and setting up and operating optional functions: high definition video, DTS-CSS (subtitling, narration and captions), and digital audio out.
Page 9 The XD10 contains two DVD drives and a large-capacity internal hard drive, which can store approximately 30 full-length feature soundtracks. To get the most out of the XD10 system, we suggest that you review this manual and keep it available during system installation and initial operation.
Page 10: Dts Technical Service
Please also provide a description of the problem or complaint. If DTS determines that the unit should be replaced or returned, we will ask you to contact your dealer and provide the same information. When your dealer sends us a purchase order (PO), a Return Authorization (RA) number will be issued for the returning item(s).
Page 11: Installation Checklist
Version 2.1 Installation Checklist Use these checklists to make sure that important settings are completed before playing content to an audience. There are separate checklists for installing the XD10, CSS Option and Video Option. Table 1. XD10 Installation and Setup Completed...
Page 12 Power Cord to the XD10 back panel: The power cord is the main disconnect device. It should be plugged into an easily accessible outlet. The power cord is to be used in a minimum type SVT 18/3 rated 250 Volts ac, 10 Amps with a maximum length of 4.5 M, with one end terminated in an IEC 320...
Page 13: Part 1: Operator
Power Switch: Switch turns the unit on and off. (The main power switch is located on the back of the XD10.) • USB Port: A USB memory device can be used to save and restore XD10 configuration settings. Document #: 9301E692002.1...
Page 14: Powering On The Xd10
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 1.1.2. Powering on the XD10 Start by verifying that the rear panel power switch is in the ON position. Then, turn on the front panel power switch. It typically takes the system 45 seconds to initialize. It may take an additional minute if the system is performing one of its period self diagnostics.
Page 15: Led Indicators
• Menu mode. In menu mode, the screen displays menus that can be used to view and adjust playback settings. The XD10 front panel keypad may be used to switch the display between the status mode and menu mode. 1.1.4.2.
Page 16: Configurable Information Line
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 1.1.4.3. Configurable Information Line Table 5 lists the options for Line 4. In the screen above, Line 4 displays End of Reel time. Table 5. Configurable Information Options Option Example Indication Blank.
Page 17: Navigating Through The Menus
1.1.4.4. Navigating through the Menus Use the five buttons on the XD10 front panel to navigate through the XD10 menus. When the status display reads "Ready", as shown below, press the Enter button, shown on the front panel in Figure 1, to access the menus.
Page 18 XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 This page intentionally left blank. Document #: 9301E692002.1...
Page 19: Loading And Playing Content
In order to use the CSS system, your XD10 must have a license for the CSS Option. Three types of program content may be provided to a theater equipped with an XD10 that has the CSS option installed.
Page 20: Content Delivery
4. DTS Access™ discs are issued by the film studios' distribution companies and must be returned with the prints. Access discs may include any or all of the following and will only play when the XD10 has the CSS option: •...
Page 21: Loading Content
XD10 video content disc will automatically load when inserted in the XD10 drive. The content will be copied onto the XD10 hard disc for playback at a later time. The XD10 will store several soundtracks and/or DTS Access™ discs for multiple features and trailers.
Page 22: Loading Soundtrack Discs
Disc A into the top drive and Disc B in the bottom drive. 3. Close the tray by pressing the “open/close” button, and the XD10 will check the contents of the disc before loading. If it detects an error, it will display one of the following messages.
Page 23: Compatibility With Legacy Soundtrack Discs
Compatibility with Legacy Soundtrack Discs Old DTS soundtrack discs did not contain a language ID. If you load an older disc that does NOT contain a Language ID, and if Language Versions is enabled, the XD10 will prompt you to identify the playback language desired.
Page 24: Handling A Cd-Rom Read Error
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 2.3.3. Handling a CD-ROM Read Error The following message may appear on the screen if an error occurs while the XD10 is loading the soundtrack disc: Warning: CD ROM Error Some Audio Missing [Left] –...
Page 25: Loading Dts Xd10 Video Content Discs
2. Open the DVD drive. Place the disc in the tray with the printed side up. 3. Close the tray. The XD10 will check the contents of the disc before loading to ensure that it does not reload load video content already on the XD10.
Page 26: Loading A Dts Access™ Disc
1. Start when "Ready" is displayed on the LCD screen on the XD 10's front panel. Ready 2. Open the drive, place the disc in the tray with the printed side up, and close the tray. The XD10 will display information about the content being copied. For example:...
Page 27: Playing Content With Film
The XD10 will automatically track any length of edit. A 30-millisecond cross fade will make the edit transparent. In the unfortunate event of a film break, DTS can be started from that point after the film repair is made. Before starting again, verify that the cinema processor is in DTS digital format.
Page 28: Playing Video Playlists
There are two ways to start and stop video playlists: using menu commands or using automation. 2.6.2.1. Start and Stop Video with Menu Commands The XD10 menus may be used to start or stop a video playlist. See Chapter 3, Playback Menus, for details. 2.6.2.2.
Page 29: Playlist Schedules
Preshow playlist when the playlist starts at night than when it starts during the day. In order for the scheduling to be correct, the date and time for the XD10 clock must be set correctly. If the XD10 is connected through the network and has a network time server configured, then the clock is automatically set by the program.
Page 30: Video Inhibit
See the information on Pin Definitions in Chapter 7, System Setup Menus, to define these pins. The XD10 will not start video playback as long as the video inhibit signal is active. The XD10 will also stop video playback immediately if this signal becomes active during the video playback.
Page 31: Xd10 Indicators And Display For Video
Version 2.1 The XD10 may be programmed to send an end pulse near the end of the playlist. The end pulse timing may be programmed to occur from between 60 seconds before to 60 seconds after the end of the playlist (negative end pulse).
Page 32: Display When Playing Playlist
Fmt: (Format) Identifies the XD10 format pin selected by the XD10 or external automation system. The following display text appears during the video playback when the XD10 is switching audio decoder formats (inside the XD10): (Playlist Name) Audio Switching Please wait...
Page 33: Video Projector Support
Then you can use "Get Settings" menu command to save the video projector settings. Video projectors not listed can be used, but the XD10 will not have the functions listed above and will require an external automation controller to turn their lamps on and off.
Page 34: Video Projector Settings
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 2.8.1. Video Projector Settings The following table lists the video projector settings that are saved by the menu command and restored for each playlist. Some settings are forced to a certain value on the projector.
Page 35: Xd10 Playback And Info Menus
This chapter describes the Playback and Info menus, submenus and their functions. 3.1. Main Menu The Main menu is the top level menu in the XD10 menu structure. To access it, start at the LCD screen on the front panel of the XD10 when it is displaying the following message. Ready Press the Enter button and the Main menu, shown below, will display on the screen.
Page 36: Playback Menu
Use this menu to change playback parameters relating to feature film and trailer soundtrack and CSS playback. External S/PDIF Use this menu to allow the XD10 to route audio from the external S/PDIF input on the rear panel out to the cinema processor.
Page 37: Video Playlist Functions
Note: You cannot gain access to this menu unless your XD10 has the Video Option installed. An XD10 unit must have a license for the HD Video Option in order to play video. If it doesn't, the following message will appear when you try to access the Video Playlist.
Page 38: Stop Playlist
The playlist will not start while the XD10 is receiving timecode or the Video Inhibit signal is active. Provided that the start command has been given through automation, the XD10 will automatically start after timecode has stopped for 10 seconds as long as the timecode ends within one minute of the command being given.
Page 39: Play Acv (Alternate Content Video)
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 3.2.1.3. Play ACV (Alternate Content Video) Content Files Main menu → Playback → Video → Play ACV Playing the alternate content video is similar to the playback of a video playlist.
Page 40 XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 3.2.1.4.2. Seek This menu allows you to seek to a specific point in the currently playing clip. It displays the seek position in terms of hours, minutes, and seconds. Use the keys to change the position and then start the playback at that position.
Page 41: Video Contents
• Start Times • Schedules • Playlists • Exit Menus Main menu → Playback → Video → Contents These menus display information about the playlists that are currently installed on the XD10. 3.2.2. Film Playback FILM PLAYBACK • TC Reader Offset •...
Page 42: Soundtrack Language
Language Versions option is enabled during the XD10 setup. If Language Versions is not enabled, then the XD10 will only load and play one version of the soundtrack for the feature or trailer. Loading a second language for a soundtrack will overwrite the first language.
Page 43: Css Playback
To access this menu, select CSS Playback from the Film menu. The following menu will appear on the screen. Note: You cannot gain access to this menu unless your XD10 has the CSS Option installed. CSS Playback •...
Page 44 XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 • • One Show Only • 3. When you reach the desired mode, simply release the Enter button and the Right arrow button. This selection has the same effect as entering a selection in the CSS mode menu.
Page 45 The system is not connected to a DTS cinema subtitling projector. 3.2.2.3.5. CSS Not Enabled If an XD10 is not equipped with the CSS Option, the CSS Playback menu will be locked. An attempt to access it will generate the following message on the screen.
Page 46: Contents Menu
Lists any feature films titles that have soundtrack or CSS content on the XD10. Trailers List any that have soundtrack or CSS content on the XD10. Delete Contents Delete selected contents from the XD10 hard drive. This includes the following contents available through DTS Access™: subtitling, captions, and narrations.
Page 47 Main menu → Playback → Film → Contents → Features Feature films will be listed in the order of the last played or loaded onto the XD10. Scroll up and down the menu to view the entire list. Put the cursor on the feature name and press Enter to view content loaded for that feature, as shown below.
Page 48 Main menu → Playback → Film → Contents → Features→ (Feature Name) 3.2.2.5. 3.2.2.5.1. Trailer Contents From the Contents menu, select Trailers and the XD10 displays a list of trailers for which soundtrack or CSS content is loaded on the XD10. Contents: Trailers •...
Page 49 3.2.2.5.1.1. Trailer File The display below shows an example of the contents for a trailer file. The abbreviated name of the trailer is shown, followed by the DTS serial number .for that trailer, the type of content file, and the language.
Page 50 3.2.2.5.2.1. Deleting All Contents From the Delete Contents menu, select All to delete all feature and trailer contents loaded on the XD10. The menu shown below will appear to confirm that all of the content is to be deleted. Delete All Contents/ ►...
Page 51 XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 3.2.2.5.2.2. Delete Features The Delete Features menu allows you to delete all soundtrack and CSS content associated with a selected feature. From the Delete Contents menu, select Features to display the menu below.
Page 52: External S/Pdif Mode
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 3.2.2.5.2.3. Delete Trailers The Delete Trailers menu allows you to delete all soundtrack and CSS content associated with a selected trailer. From the Delete Contents menu, select Trailers to display the menu below.
Page 53 Accepts 2-channel PCM audio from the S/PDIF input and uses NEO:6 decoding to route it to all 6 channel outputs. When a selection is made, it will take a few seconds until the XD10 is ready for use. The following message will appear during that time.
Page 54: Load From Usb
Main Menu → Playback→ Load from USB This option allows content that is stored on a USB storage device to be uploaded to the XD10. The USB device, which may be a drive or a memory device, must contain either FAT32 or EXT2 file format.
Page 55: Info Menu
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 3.3. Info Menu The Info Menu contains information about the XD10 software, licenses and MAC address. The MAC address is used to uniquely identify an XD10 unit. INFO MENU • Version •...
Page 56: Mac Address
3.3.2. Licenses Menu This menu displays which licenses are installed in the XD10. You must use the Up and Down arrow buttons to scroll to view all license options. An asterisk in the brackets indicates that the license type described on the line has been installed.
Page 57: Maintenance And Troubleshooting
After three months service – and every six months afterwards: If your DTS Timecode Reader Head does not have an RoHS sticker on it, check and recalibrate the DTS Timecode Reader Head’s voltage using TN-E550. (You can see TN-E550 on the free DTS Online TechCenter located on the DTS website at www.dts.com/cinema.) DTS Timecode Reader Heads with stickers...
Page 58: Frequently Asked Questions
XD10 hard drive. 2. If the soundtrack is not listed in the XD10 contents, find the feature’s soundtrack disc and load it into the XD10. If you cannot find the soundtrack disc, contact the film distributor and request the disc.
Page 59: Xd10 Does Not Play Soundtrack Audio To Film
4.3.4.1. Timecode LED Is Blinking If the XD10 is not playing digital audio, first check to see if the timecode LED on the front panel is illuminated. If it is illuminated, but is blinking, then check the following: 1. If the reader’s LED is dark, check to make sure that the film is threaded correctly through the DTS Timecode Reader and that the film has a timecode strip (located between picture and analog sound tracks).
Page 60: Playback Led Is Flashing At Regular Intervals
XD10. 5. As a last resort, force the unit to play in optical mode. Turn off the XD10 and verify that the cinema processor switches to optical. If it does not, press the desired format button on the cinema processor.
Page 61: Display Error Messages
If this occurs when playing digital format, the XD10 will switch the cinema processor to the predefined fallback format (usually SR). The error may disappear or the XD10 may reset itself after power is cycled (power off, then on again). However, if the problem persists, contact DTS Technical Service for assistance at 1 (800) 959.4109 from within the USA or 1(818) 401.4253 from outside the USA.
Page 62: Guide For A Seamless Change-Over
Guide For a Seamless Change-Over When you are running a DTS movie with dual projectors, the picture and sound may not change at the same time during a change-over. The reason is that as soon as the first frame of action reaches the ®...
Page 63: Hardware Installation
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 Part 2: Installation and Setup The remaining chapters in this manual describe the information the technician needs to install and configure the XD10 cinema media player. The chapters are: • Hardware Installation •...
Page 64: Unpacking System Components
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 5.1. Unpacking System Components The following is a list of the standard components for an XD10 shipment. The exact contents will vary, depending on the options you have ordered. • XD10 Cinema Media Player and power cord •...
Page 65: Installation Procedures
All interconnects are standalone and most systems require no cuts or jumpers. The XD10 requires 3U of standard rack space (5 1/4 x 15 x 19 inches) for proper mounting. Select a space in the sound rack within three feet of the cinema processor to which you are connecting.
Page 66: Rack Mount Recommendations
Version 2.1 5.2.1.2. Rack Mount Recommendations Follow these recommendations if the XD10 is installed in a closed or multi-unit rack assembly. • Determine the maximum and ambient temperatures within the rack, since they may be greater than the maximum and ambient temperatures in the room. The maximum temperature for the equipment in a closed or multi-rack assembly is 50°C (122F°)
Page 67: Power Supply
Two Projector (Change-over) Theaters Use a DTS timecode “Y” cable that will connect two readers to one XD10. Be sure to place each reader at the same location on each projector. This is to ensure the soundtrack plays in sync. The timecode offset values (distance from DTS reader to the projector’s picture gate) must be the same for...
Page 68: Connection To Cinema Processors
Panastereo and SMART Operation The XD10 will automatically send one pulse to the cinema processor, changing the format to DTS. Whenever the XD10 drops out, a pulse will be sent to switch the cinema processor back to an analog (usually SR) format.
Page 69: Dolby ® Cp200 Operation
Channel setup tests and tones are pre-recorded onto the XD10 hard drive. The audio playback level of the XD10’s built-in 1 kHz test tone has been fixed at 300mV RMS. This level should match the audio buss level on the cinema processor that the XD10 is connected to. Verify the buss level by consulting the manufacturer of your cinema processor.
Page 70: Adjusting Levels
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 5.4.2.1. Adjusting Levels The XD10 contains several built-in audio tests described in Section 7.2.2. They can be accessed through → → the following menu path: Setup Audio Audio Tests. Level adjustment audio tests for SPL calibration are described in Section 7.2.1, which can be accessed through the following menu path: Setup...
Page 71: A Note About Dts Subwoofer Output
5.4.3. A Note about DTS Subwoofer Output The XD10 subwoofer output level ranges from 20 Hz to 80 Hz and 20 Hz to 120 Hz (Coherent Acoustics format), up to 27 dB above reference (85 dB). Check your subwoofer’s specifications to avoid damage to the speaker.
Page 72: Timecode Reader Sync Adjustment
Important: Make the same size film loops inside the projector when measuring offset as when running a movie. Failure to do so will result in improper sync when the movie runs in DTS Digital mode. For two-projector houses, the reader at each projector must have the same OFFSET value.
Page 73: Dts Special Venue Timecode Offset
Verify Sound Performance 1. Thread the DTS Demo reel (Buzz and Bill) through the projector and DTS reader. Be sure the XD10 is fully booted and ready to play. The soundtrack for Buzz and Bill is factory-loaded on the hard drive.
Page 74: Check Automatic Fail-Safe (Default) Operation
To block the timecode reader, insert a business card between the film and the lens of the DTS Timecode Reader Head and keep it there for at least six seconds. 2. Verify that after 4 to 5 seconds of not seeing timecode, the DTS XD10 switches to the SR optical sound format.
Page 75: Installing Licenses And Upgrading Software
• • CineCast License The following text describes these options. • DTS HD Video Option: A card is added, which provides high definition digital video playback. • DTS-CSS Option: provides subtitling and access options that include: • Projecting subtitles or captions directly onto the screen via a video projector.
Page 76: Installation Of License Discs
6.3. Installation of License Discs 1. Check that the XD10 serial number on the license disc matches the serial number on the back of the XD10. The option contained on the disc (CSS, Video and CineCast) is indicated by the disc label.
Page 77: Xd10 Software Updates
XD10. The update will not affect any of the XD10 configuration or contents and there is no special action required after the install takes place. The only noticeable affect will be the extra time required after loading the soundtrack or trailer disc.
Page 78 XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 This page intentionally left blank Document #: 9301E692002.1...
Page 79: Setup Menus
Version 2.1 7. Setup Menus The Setup menu contains all configurable settings for the XD10 that should be set by the technician and are not expected to change during day-to-day operations. The setup menu can be password protected to assure that the configuration does not change after the technician leaves.
Page 80 4) Set system network parameters, 5) Set XD10 time and date, 6) Revert to an earlier XD10 software version. Display Language Enters menu to change the language used on the XD10 LCD to one of the following: English, French, German, Italian, or Spanish.
Page 81: Tc (Timecode) Reader Offset
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 7.1. TC (timecode) Reader Offset This menu allows you to enter the offset required for your particular timecode reader location. See Chapter 5, Section 5.5, Timecode Reader Sync Adjustment, for information on calculating the correct settings.
Page 82: Smpte: Serial Number
7.1.2.1. SMPTE: Serial Number This menu assigns a DTS serial number to the incoming SMPTE timecode. If the value is set to zero, then the serial number value comes from the user bits on the SMPTE timecode. The DTS serial number is used to determine which film soundtrack will be used for playback.
Page 83: Smpte: Offset
SMPTE: Reel Number This menu assigns a DTS reel number to the incoming SMPTE timecode. If the value is set to zero, then the hours value from the incoming SMPTE timecode will be used for the reel number. The reel number must be set to 1 in order to play long audio files (greater than one hour in length).
Page 84: Audio Setup Menu
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 7.2. Audio Setup Menu This menu allows you to set up and test the XD10 audio. It also allows you to enable or disable the Language Versions function. AUDIO SETUP MENU ► Level Adjustment •...
Page 85 XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 Adjust level for Ch 1 (Left) [ +00.0dB] Tone on all channels Main menu → Setup → Audio → Reference Tone or Pink Noise Commands: Increase the volume for the current channel. Maximum is +6.4 dB.
Page 86: Audio Tests
Sonic Landscape DTS trailer Sparks Plays Sparks DTS trailer Bill and Buzz Plays introduction track, but not movie clips, from DTS Demo reel Buzz and Bill. Contains soundtrack, narration, and captions/subtitles, which will play only with the CSS option. Document #: 9301E692002.1...
Page 87: Language Versions
This menu is used to either enable or disable the Language Versions function. Language Versions allows the XD10 to play different soundtrack languages for the same film. The XD10 may load several language versions of a feature or trailer soundtrack, and play the selected language. The playback language maybe entered by the projectionist or selected by automation.
Page 88: Video Setup
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 7.3. Video Setup The Video Setup menu is used to set the video configuration, audio parameters specifically for the video playlists, and video projector settings. VIDEO SETUP • Output • Video Audio •...
Page 89: Video Interface
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 7.3.1.1. Video Interface The Video Interface menu is used to select the appropriate cable for the video projector or monitor being used. Video Interface Type •(*)DVI •( )VGA • Exit Menus Main menu →...
Page 90: Video Resolution
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 7.3.1.4. Video Resolution This menu is used to set the video output resolution. In most cases this should be set to the native resolution of the video projector. Changing the video output resolution requires that both a resolution and a frame rate be selected.
Page 91 XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 Table 9, below, lists all frame rates available for each resolution. Table 9. Available Frame Rates for Each Resolution Resolution Available Frame Rates 640 x 480 700x600 1024x768 1280x720 1280x768...
Page 92: Video Audio
It can be set to a value between 0db and -15db. Video Audio Trim 0] dB Main Menu → Setup → Video → Video Audio → Audio Trim Note: Change takes affect only after rebooting the XD10. Document #: 9301E692002.1...
Page 93: Video Projector
Create a copy of the projector settings on the XD10. The settings are restored to the projector upon the start of any video playlist. Note: In order for the XD10 to control the projector through the serial interface you also need to set the serial port for Video Projector (not Rear Window).
Page 94: Lamp On/Off Control
NOTE 1: The video projector may take one to two minutes to respond to the Lamp On command when the lamp is still warm from use. NOTE 2: Only available for projectors supported by XD10 serial control. 7.3.3.3. Save Video Projector Settings The Save Settings menu is used to save or delete projector settings.
Page 95: Video Test Contents
The image remains until the stop command is used. Motion Image Plays a motion video clip with DTS audio. The video projector lamp should go on immediately after executing this command, The clip repeats until the stop command is used.
Page 96: Cinema Subtitling System (Css) Setup
Set color options. If your XD10 is not equipped with the CSS Option, you will be locked out of the CSS option on the Setup menu. When you try to access it, the following message will appear on the screen.
Page 97: Image Size
This menu allows you to make fine adjustments to the vertical placement (in pixels) of CSS subtitles. When you enter this menu, the XD10 projects a subtitle area pattern to use to reference the position. When installing the projector, set the projector vertical offset to 0 and physically position the projector to project in the subtitle area.
Page 98: Test Patterns
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 7.4.3. Test Patterns This menu allows you to select from an array of test patterns used for optimizing subtitle/caption display. The EMA dowser opens when this menu is entered. Test Pattern Menu •...
Page 99: Options
Exit Menus Main menu → Setup → CSS → Options → Background Options: Normal This results in a blue background color that must be used with the DTS cinema subtitling projector. It is used to correctly position the video image. Black Color that must be used when using a non-DTS projector Normal must be selected when using a DTS CSP (InFocus) cinema subtitling projector.
Page 100: Css Text Color
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 7.4.4.3. CSS Text Color This menu lets you select the color of the text in subtitles and projected captions. CSS Text Color • (*)White • ( )Yellow • Exit Menus Main menu →...
Page 101: Automation
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 7.5. Automation / Control This is the top level menu in the menu structure for setting format automation and I/O Control functions. AUTOMATION / CONTROL ► Format • I/O Control •...
Page 102: Pin Definitions
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 7.5.2. Pin Definitions The Format Pin Defs menu is used to select settings for eight user-assignable pins in the XD10 25-pin Automation connector. FORMAT PIN DEFS ► Predefined Formats • Custom •...
Page 103: Custom Formats
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 7.5.2.2. Custom Formats The Format Pins menu is used to view or change the setting for any of the eight user-assignable format pins. Format Pins ► Pin 1: Mono • Pin 2: A •...
Page 104 Sustain XD10 input. Use this definition to switch the CP to the XD10 input and process as extended surround (ES). This should not be used to replace the DTS pulse signal, but as an alternate format used when the XD10 detects DTS ES that the soundtrack is encoded for extended surround.
Page 105: Fallback Format For Soundtrack
If the fallback format is set to SR (1) and that pin is not defined as one of the format pins, then the XD10 will pulse the A format pin. If there is not an A format pin, then it will pulse the MONO format pin.
Page 106: Automation Operating Mode
DTS-6D Emulation. The operating mode defines the conditions that need to be met for the XD10 to switch the CP to the DTS format. The operating mode applies only to format switching for film soundtrack playback. It does not affect format switching for the video playlists soundtrack.
Page 107: Autoswitch (Optical Formats)
DTS or any of the optical formats—Mono, A, SR (1) or SR (2). If any other format has been selected by the automation system, then the XD10 will not switch the cinema processor when audio starts.
Page 108: I/O Control
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 7.6. I/O Control The I/O CONTROL menu is used to configure the automated control input and output signals on the I/O connector. (This is NOT the same as cinema processor automation control.) It is also used to configure the automated soundtrack and subtitle language setups.
Page 109: Input Control Pins
( ) ACV ( ) 70mm TCR · Exit Menus Options: Unassigned A pulse on this pin is ignored by the XD10. Start Preshow Starts the video Preshow. Stop Video Stops the video playlist. Lang Setup Activates a specified soundtrack language and subtitle language.
Page 110 XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 S/PDIF On Enables the S/PDIF input to process DTS 5.1 audio or stereo PCM audio to the front left and front right speakers. S/PDIF Off Disables the S/PDIF input. Intermission Starts the intermission video playlist.
Page 111: Output Control Pins
Used for the end pulse during the video playlist automation sequence. DTS Output Output will be low whenever the XD10 is playing audio (or the Blue DTS Playback light is on). ES Output Output will be low whenever the XD10 is playing audio for extended surround (soundtrack audio only).
Page 112: Language Setups
5. The selected soundtrack language or subtitle language plays only if the content for that language has been loaded on the XD10. Each feature soundtrack dub is normally a separate set of discs. Also, each CSS subtitle language for a feature may be on separate discs. Check the disc label for the contents language.
Page 113: Soundtrack Language Setups
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 The menu shown below appears when one of the selections is made. The setup title describes which selection is being modified. LANGUAGE [Setup Title] ► Soundtrack · Subtitle · Exit Menus Main →...
Page 114: Subtitle Language Setups
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 7.6.3.2. Subtitle Language Setups When Subtitle is selected from the language setup (Default of Language setup 1-3), the list of 48 available languages appears on the screen. Select the subtitle language that is desired for the language setup.
Page 115: Assigned Subtitle Language
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 7.6.3.3. Assigned Subtitle Language When a Setup Input pin number is selected from the Language Setup menu, this menu may be used to access a specific pin in order to assign a subtitle language to it.
Page 116: Playlist
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 7.6.4. Playlist The playlist setup is a series of menus used to set the delays and options for the video playlist. To access the Playlist menu, select Playlist from the Automation /Control menu, as shown below: AUTOMATION / CONTROL •...
Page 117: Video Start Delay
7.6.4.1. Video Start Delay The Video Start delay is the amount of time the XD10 waits after receiving the “start” command (to start playing videos from the playlist). This is used to allow the video projector lamp time to warm up.
Page 118: End Pulse Enable
End Pulse Enable This menu allows the end pulse to be enabled or disabled for the selected playlist type. The End Pulse must also be defined as one of the XD10 Control Output Pins. See Section 7.6.2, Output Control Pins. <Playlist> Setup...
Page 119: Silent Video Format
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 7.6.4.7. Silent Video Format This menu selects what sound format will be selected during the playback of a silent video clip. <Playlist> Setup Select format for silent video clips: [Format Options] Main menu →...
Page 120: Automation Test
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 7.6.5. Automation Test This menu is used to confirm the assignments already made to automation pins 1-8, I/O Control pins 1-3, and pin 4, and the signal from the Cinema Subtitling Projector fan.
Page 121: Usb Memory
MAC address. When loading the Configuration through the USB, the XD10 will load only the configuration from the folder named with that XD10’s MAC address. If you want to save settings from one XD10 and load them into a different XD10, see “Master Settings” after this section.
Page 122: Save On Usb
On USB memory [Enter]-OK Insert the USB memory device into the USB port on the XD10 and press Enter to start. If there is no USB memory device connected to the XD10, the following message appears and asks you to insert one.
Page 123: Load From Usb
USB memory [Enter]-OK Insert the USB memory device that contains the settings for your XD10 into the USB port and press Enter to copy the settings onto the XD10's hard drive. If there is no USB memory device, the following message appears, asking you to insert one.
Page 124: Master Settings
Master settings On USB [Enter]-OK Insert the USB memory device into the XD10 and press Enter to start the process. If there is no USB memory device, the following message appears, asking you to insert one. Please insert USB memory device…...
Page 125: Load From Usb
USB memory [Enter]-OK Insert the USB memory device that contains the Master settings into the XD10 and press Enter to start the process. If there is no USB memory device, the following message appears, asking you to insert one.
Page 126: Copy
Each XD10 configuration is identified by the MAC address. You must identify the XD10 unit to copy the configuration from by its MAC address. This function may be used if an XD10 is being replaced, and the new unit requires the configuration of the one being replaced.
Page 127: Log Files
7.7.1.8. Log Files This menu allows you to copy XD10 log files onto a USB memory device. You may use this if the XD10 is having playback problems and a DTS representative asks you copy the log files and send them to DTS for analysis in order to determine the cause of the problem.
Page 128: Com1 Configuration
To confirm the password, select OK. The following message will appear. Press Enter to return to the set password form. Password is changed. [Enter]-Continue If you forget your password, contact DTS Technical Service to receive help regaining access to the XD10. Document #: 9301E692002.1...
Page 129: Disable Password
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 7.7.1.11. Disable Password The Password menu also allows you to provide full access to the setup menus by setting the password to the default setting: 000. Password: [ 0 0 0 ] Main Menu →...
Page 130: Network
Network The network is used for connection to either the DTS Cinema Media Network™ or the DTS MediaLink XD. This menu is used to set the network parameters to allow remote access to the XD10. NETWORK MENU • Network Mode •...
Page 131: Static Ip Address
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 7.8.2. Static IP Address This menu allows you to select a Static IP Address, along with other network addressing parameters. STATIC IP ADDRESS • IP Address • Subnet Mask • Default Gateway •...
Page 132: Set Subnet Mask
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 7.8.2.2. Set Subnet Mask This menu allows you to select and enter a static Subnet Mask IP Address. Set Subnet Mask: 000.000.000.000 Main Menu → Setup → System → Network → Set Static IP → Subnet Mask The cursor (‘*’) is below one of the four three-digit fields.
Page 133: Set Default Gateway
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 7.8.2.3. Set Default Gateway This menu allows you to select and enter a static Default Gateway IP Address. Set Default Gateway: 000.000.000.000 Main Menu → Setup → System → Network → Set Static IP → Default Gateway The cursor (‘*’) is below one of the four three-digit fields.
Page 134: Set Secondary Dns
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 7.8.2.5. Set Secondary DNS This menu allows you to enter a static Secondary DNS IP Address. Set Secondary DNS 000.000.000.000 Main Menu → Setup → System → Network → Set Static IP → Secondary DNS The cursor (‘*’) is below one of the four three-digit fields.
Page 135: Set Defaults
7.8.3. View Network IP Address This menu allows you to see your XD10 Network IP Address. If your XD10 is not connected to a network, the following message will appear on the screen. Press Enter to exit. Network IP Address: (not connected) Main Menu →...
Page 136: Server Type
Press Enter to return to the Server Type menu. The Custom option shows as selected, but the server interface will not operate until the license is installed. 7.8.5. Notify Server This command sends a notification message to the server to identify the XD10 on the network. Notification message Has been sent to...
Page 137: System Clock
7.9. System Clock The System Clock menus allow you to set and view the date, time and Time Zone for your XD10. These settings are needed for logging information and for playing video playlists with auto-start times. Setting the Time Zone also allows the XD10 to automatically accommodate Daylight Savings Time.
Page 138: Set System Date
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 If you select Americas and press Enter, the following menu will appear. Select Country [United States] Use the ▲ and ▼ buttons to cycle through the list of 58 countries.
Page 139: Set System Time
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 7.9.1.2. Set System Time → → Start by accessing the System Clock menu. From the Main Menu, select Setup System System Clock. Scroll to Set System Date and press Enter, as shown below.
Page 140: 7.10. Software Revert
The Revert operation allows the XD10 you are using to revert back to the previous version of XD10 software. It will only allow one step back (It will not revert back further than the previous version). Note: It the XD10 has been updated using a full install disc, it will not revert to a previous version. →...
Page 141: 7.11. Display Language
XD10 Cinema Media Player, Installation and Operating Guide Version 2.1 7.11. Display Language This menu allows you to select the language displayed on the XD10's front panel LCD screen. English is the default. DISPLAY LANGUAGE • (*) English • ( ) French •...
