UK Subject to change
www.servoltool.nl
UK
USERS MANUAL
Art.nr. KZM6002
42cc Petrol Chain Saw
GPCS-42cc
This product has been tested at a computed kickback angle (CKA) of no greater than 16.3 degrees.
Beware of kickback. Hold chain saw firmly with both hands when using. For your own safety, please read and
follow the safety precautions in this manual before attempting to operate your chain saw. Improper use can
cause serious injury.
0511-17
WARNING • PLEASE READ
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Gardenline GPCS-42cc
Summary of Contents for Gardenline GPCS-42cc
- Page 1 USERS MANUAL Art.nr. KZM6002 42cc Petrol Chain Saw GPCS-42cc This product has been tested at a computed kickback angle (CKA) of no greater than 16.3 degrees. WARNING • PLEASE READ Beware of kickback. Hold chain saw firmly with both hands when using. For your own safety, please read and follow the safety precautions in this manual before attempting to operate your chain saw.
- Page 2 GENERAL SAFETY RULES Meaning of symbols marked on the product Read the user manual before using the machine Warning! Danger Beware of kickback! Hold chain saw firmly with both Whenever the machine is in use, safety goggles must be CKA 16.3˚ hands when using.
- Page 3 BAR SHEATH, 18" B = Kickback reaction HANDLE, RIGHT, 348C GREEN MUFFLER ASS'Y C = Push Your Gardenline Chain Saw is provided with a safety zone SWITCH SCREW label located on the chain brake lever/hand guard. This label, along with the safety instructions on these pages,...
- Page 4 GENERAL INFORMATION BAR WEAR - Turn guide bar frequently at regular inter- operations is essential to minimize friction with the guide vals (for example, after 5 hours of use), to ensure even WARNING: Never have more than 3 links wear on top and bottom of bar. removed from a loop of chain.
- Page 5 Lubrication of the sprocket tip is recommended after 10 Sharpen the chain using protective gloves and a round SPECIFICATIONS hours of use or once a week, which ever occurs first. file of ø5/32” (4mm). Always thoroughly clean guide bar sprocket tip before Model No.
- Page 6 After making adjustment, and while still holding nose Fill tank with fresh fuel / oil mixture. See Section • STORING A CHAIN SAW of bar in the uppermost position, tighten the bar FUEL AND LUBRICATION. Install fuel cap. Storing a chain saw for longer than 30 days requires stor- retaining nut securely.
- Page 7 3. Be certain the chain brake is disengaged (C) before start- WARNING: If 2-cycle lubricant other than ing unit (Fig. 8). Gardenline Custom Lubricant is to be used, it must be a premium grade oil for 2-cycle air • TO START ENGINE cooled engines mixed at a 40:1 ratio.
- Page 8 WARNING: If chain does not stop, turn engine Use wooden or plastic wedges (A) to prevent binding off and take your unit to the nearest Gardenline Authorized Service Center for service. the bar or chain (B) in the cut. Wedges also control felling (Fig.
