GCS-2000
GB Subject to change
2000W Electric Chain Saw
USER'S MANUAL
WARNING • PLEASE READ
For your own safety please read this manual before
attempting to operate your new unit. Failure to follow
instructions can result in serious personal injury. Spend
a few moments to familiarize yourself with your trimmer
before each use.
Art. no. KZM6003 • 09/06
www.servotool.nl
GB-0604-18
Advertisement
Table of Contents
Related Manuals for Gardenline GCS-2000
Summary of Contents for Gardenline GCS-2000
- Page 1 GCS-2000 GB Subject to change 2000W Electric Chain Saw USER’S MANUAL WARNING • PLEASE READ For your own safety please read this manual before attempting to operate your new unit. Failure to follow instructions can result in serious personal injury. Spend a few moments to familiarize yourself with your trimmer before each use.
- Page 2 Exploded view Spare parts list GCS-2000 Gardenline nr. Description Position nr. 501532 Sprocket wheel 1 till 4 501533 Chain adjustment (set) 10, 11, 12, 14, 17 KZA1004 Chain Guide Bar 40 cm KZA1005 Saw Chain 40 cm 501534 Insert plate...
- Page 3 5.77 m/s Vibration rear handle 4.89 m/s Lpa (sound pressure) 91 dB (A) Lwa (sound power) 105 dB (A) General Information Page 2 Rear handle Oil tank cap Trigger start Sprocket cover Chain cover control knob Chain tension ring Gardenline Gardenline...
- Page 4 2. SAFETY RULES Meaning of symbols marked on the product The following pictograms are used in these instructions for use: Read the user manual before using the machine In accordance with essential applicable safety standards of European directives Gardenline Gardenline...
- Page 5 Do not expose the chain saw to rain. Do not use the chain saw in damp or wet locations. Do not use the chain saw in the presence of flammable liquids or gases. Gardenline Gardenline...
- Page 6 17. Stay alert. Watch what you are doing. Use common sense. Do not operate the chain saw when you are tired. Keep all parts of your body away from the saw chain when the motor is operating. Before you start the saw, make sure the saw chain is not contacting anything. Gardenline Gardenline...
- Page 7 Warning! Never have more than 3 links removed from a loop of chain this could 25. Do not operate a chain saw with one hand! Serious injury to the operator, helpers, or cause damage to the sprocket. bystanders may result from one-handed operation. A chain saw is intended for two- handed use. Gardenline Gardenline...
- Page 8 30 mA. • The first time user should have practical instruction in the use of the chainsaw and the protective equipment from an experienced operator. The initial practice should be cutting logs on a saw horse or cradle. Gardenline Gardenline...
- Page 9 Low-kickback saw chain does not Fig. 2A completely eliminate kickback. A low-kickback or “safety chain”, should never be A = Kickback path regarded as total protection against injury. B = Kickback reaction zone Gardenline Gardenline...
-
