Contents Of This Service Manual - ENCAD T-200 Service Manual

Environment:
Operating:
41° to 85° F
(5° to 30° C)
20% to 80% RH
non-condensing
Storage:
-5° to 140° F
(-21° to 60° C)
5% to 80% RH
non-condensing

Contents of this Service Manual

Figures are used in this manual to clarify procedures. They are for
illustrative purposes only and may not necessarily be drawn to scale.
Material in this manual may be repeated in various chapters so that
each chapter can "stand alone". This allows information to be located
without having to refer back and forth between chapters.
Figures and tables are easily located and cross-referenced, and are listed
in the front of the manual under List of Illustrations and List of Tables.
This manual is divided into six chapters as:
Weight:
70 lbs(31 kg)
Dimensions:
Chapter 1 GENERAL DESCRIPTION - Contains a general
description of the ENCAD CadJet T-200 printer. This
includes printer specifications, and related materials. Also
included is a description of the use of Warnings, Cautions
and Notes as used in this manual and chapter contents.
Chapter 2 THEORY OF OPERATION - Functional
descriptions of the overall printer and major assemblies are
contained in this chapter.
CadJet T-200 Service Manual
Height 48" (1210 mm)
Width 54" (1370 mm)
Depth 30" (710 mm)
General Description 1-6
