STEREO CD TUNER
XC-F10
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model
Type
XC-F10
ZVYXJ
¶ This product is a system(s) component.
This product does not function properly independently ; to avoid malfunctions, be
sure to connect it to the prescribed system component(s), otherwise damage may
result.
¶ Please connect it to the STEREO POWER AMPLIFIER M-F10, for adjustment and
operation inspection.
¶ This product's instructions are contained within the instruction manual of the related
system component(s).
The manual is packed with those component(s).
This product's accessories etc. are packed with its related component(s).
Component
STEREO CD TUNER
STEREO POWER AMPLIFIER
SPEAKER SYSTEM
STEREO CASSETTE DECK
CONTENTS
1. SAFETY INFORMATION ...................................... 2
4. PCB CONNECTION DIAGRAM ......................... 18
5. PCB PARTS LIST ............................................... 25
6. ADJUSTMENT .................................................... 29
PIONEER CORPORATION
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
c
PIONEER CORPORATION 2000
Power Requirement
DC power supplied from other system component
Model
XC-F10
M-F10
S-F10-LRW
CT-F10
4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
Service manual
RRV2319
This manual.
RRV2321
RRV2330
RRV2308
7. GENERAL INFORMATION ................................ 32
7.1 DIAGNOSIS .................................................. 32
7.1.1 DISASSEMBLY ...................................... 32
7.2 PARTS .......................................................... 36
7.2.1 IC ............................................................ 36
7.2.2 DISPLAY ................................................. 40
ORDER NO.
RRV2319
Remarks
Remarks
T - ZZK JUNE 2000 Printed in Japan
