GreenTech Pure Wash Owner's Manual

Eco-friendly laundry system

Hide thumbs

Warnings & Important Info

Installation Requirements

Frequently Asked Questions

www.GreenTechEnv.com

Owner's Manual

Table of Contents

Need help?

Do you have a question about the Pure Wash and is the answer not in the manual?

Questions and answers

Summary of Contents for GreenTech Pure Wash

Page 1: Table Of Contents
Owner’s Manual Introduction Specifications Warnings & Important Info Diagrams Installation Requirements Installation Indicators & Alarms Using your pureWash Frequently Asked Questions Troubleshooting Internal Diagram Replacement Parts Warranty Information www.GreenTechEnv.com...
Page 2: Introduction
Weight: ............. 5 lbs Records: Purchase Date: ___________________________________________________________ Model Number: __________________________________________________________ Serial Number: ___________________________________________________________ Distributor Name: ________________________________________________________ Distributor Phone: ________________________________________________________ Copyright © 2010 GreenTech Environmental: All Right Reserved...
Page 3 Warning & Important Info: Disconnect power before servicing. Do not mount your pureWash vertically or at any angle. See installation instructions. (unit is designed to operate horizontally ONLY). Do not operate the unit with the cover removed. pureWash is designed for residential use only and is not intended for use in a commercial or industrial setting.
Page 4: Diagrams
Front Diagram: Water Water Outlet Intlet Rear Diagram: Mounting Mounting Hole Hole LEFT Side Diagram: Cover Release D/C Adapter Plug-in Copyright © 2010 GreenTech Environmental: All Right Reserved...
Page 5: Installation Requirements
Installation Requirements: Electrical Requirements: • pureWash requires 120 Volt 60 Hz power on a 15 amp fuse or circuit breaker. • Never use an extension cord or a power adapter other than the one provided with pureWash. Water Requirements: • Water pressure of 40 to 75 psi is required for pureWash to operate correctly and safely.
Page 6: Installation
NOT overtighten. Again, use a wrench to hold the hose bib secure on the pureWash while tightening. 6. Replace the cover on your pureWash by placing it one inch over the tabs and sliding it down until it locks. Copyright © 2010 GreenTech Environmental: All Right Reserved...
Page 7: Indicators & Alarms
Installation Cont: 7. Plug the power adapter into the DC adapter plug-in on the left side of your pureWash and then plug the adapter into a wall outlet. 8. Ensure all hoses are properly installed and tightened, and that the power supply has been properly installed.
Page 8: Using Your Purewash
Efficiency pureWash, but standard-efficiency top-loading washers should use Standard pureWash. If the Standard pureWash is used on a high-efficiency washer, there will be no bubbles and you will not experience the benefits of using pureWash. Copyright © 2010 GreenTech Environmental: All Right Reserved...
Page 9: Frequently Asked Questions
Frequently Asked Questions: Do tough stains have to be pretreated? We recommend that you continue to treat stains in the same manner as you did before. However, for normally soiled laundry, using pureWash will allow you to use less detergent or no detergent at all.
Page 10: Troubleshooting
GreenTech Environmental. 3. Flashing red light. Oxidizing Module has failed. Contact your distributor or GreenTech Environmental for replacement. 4. No ozone smell in laundry. Check the viewing glass for bubbles as it may be producing ozone but not injecting it into the water correctly.
Page 11 GreenTech Environmental. 7. Clothes are being bleached. Incorrect pureWash model or Venturi part. Contact your distributor or GreenTech Environmental for replacement. 8. Suds in the basin after first uses. Detergent or residue is being cleaned out. Run multiple washes without clothing until the problem is resolved. If problem persists contact your distributor or GreenTech Environmental.
Page 12: Internal Diagram
The following table shows available replacement parts and their part numbers. Use this table as a guide when ordering replacement parts for your pureWash unit. Part Name Part No. Ozone Generator PUREWASH OxMod Control Board PUREWASH CntrMod PCO Cell PUREWASH PCO Copyright © 2010 GreenTech Environmental: All Right Reserved...
Page 13: Warranty Information
Genuine GreenTech Environmental parts are not covered. GreenTech Environmental, LLC. will, at its option, repair or replace a defective pureWash Laundry System or part(s) for the pureWash Laundry System that is covered by this warranty. As a matter of warranty policy, GreenTech Environmental, LLC.
Page 15 Notes...
