2. Specification

1. CRT : 46CM(19") 90 Deflection, Shadow mask ,29mm Neck, flat high contrast CRT, 0.21mm(H) / 0.25mm
(D) dot pitch, Non-Glare Screen
2. Viewable image Size: 45.7CM (18") diagonal
3. Display Color: Unlimited Colors
4. External Controls:
Power On/Off, OSD key, Function knob: Contrast, Brightness, Degauss, H-Size, H-Center, V-Center, V-Size, ZOOM,
Pincushion, Trapezoid, Pin-Balance, Parallelogram, Rotation, Color Temperature, H-Moire Reduce, V-Morie,
Memory Recall, Language, ViewMeter,OSD position select
5. Input Video Signal
Timing Timing116
Resolution 640*480
H(KHz) 31.347
V(Hz)
Timing Timing140
Resolution 1024*768
H(KHz) 69 000
V(Hz) 85 000
6. Display Size
Default:
Full scan
7. Scanning Frequencies
Horizontal:
Vertical:
8. Factory Preset Timings: 9
User Timings: 10
9. Misconvergence
A Zone:
B Zone:
ViewSonic Corporation
Timing119
640*480
43.269
60 85.008
Timing 148
1280*1024
79.976
75.025
352 mm(H) ×264 mm(V)
352 mm(H) ×264 mm(V)
30KHz ~ 86KHz
50 Hz ~ 160 Hz
0.25 mm Max.
0.35 mm Max.
Timing 127 Timing 129
800*600 800*600
46.875 53 000
75.000
85 000
Timing 156 Timing179
1600*1200 640*480
75 000 31.469
60 000 70.086
3
Confidential - Do Not Copy
Timing 139
1024*768
60.023
75.029
E90fB -4
