- Page 2 ABOUT THE DIAMOND AUDIO EXPERIENCE Congratulations, you have purchased the finest audio product on the market. At Diamond Audio, our mobile audio products represent the latest advances in acoustic technology. Diamond Audio products are designed and engineered using innovative components and materials resulting in exceptional sound reproduction.
- Page 3 Guide the tweeter wires so that they lay in the groove of the inside of the rubber boot as it replaced. Attach wires to the proper terminals. MID-BASS SPEAKER MOUNTING ©2012 Diamond Audio Technologies. All rights reserved.
- Page 4 Route speaker wires through tweeter cup, connect tweeter to wires, and snap tweeter into cup by aligning the notches. Mounting Hole size: 1.73” (44mm) Dia. ©2012 Diamond Audio Technologies. All rights reserved.
- Page 5 Acoustic Fill. This output can be used to power an additional speaker off the same channel without affecting the impedance load on the source unit. This output provides 15-20% of the total power to the extra speaker and is unfiltered or full range. INPUT WOOFER TWEETER ©2012 Diamond Audio Technologies. All rights reserved.
-
Page 6: Physical Dimensions
Mounting Diameter 5.53 5.53 140.6 140.6 Screw Hole Dia. 6.14 6.14 156.0 156.0 Mounting Depth 2.32 2.32 59.0 59.0 Magnet Diameter 3.40 3.40 86.4 86.4 Max Power Watt Sensitivity Freq. Response 55-20k 55-20k ©2012 Diamond Audio Technologies. All rights reserved. - Page 7 LIMITED SPEAKER WARRANTY STATEMENT Diamond Audio Technologies, LLC (DAT) warrants this product to be free from defects in material and workmanship for a period of one (1) year from the original date of purchase provided it was purchased from an authorized DAT retailer within the United States.
- Page 8 ® www.DiamondAudio.com 012512...
