Summary of Contents for Diamond Audio D580
- Page 2 INTRODUCTION Thank you for purchasing a Diamond Audio product for your vehicle audio system. You have chosen Diamond Audio because you deserve the best! Diamond Audio products are designed and engineered to the highest quality standards in the industry to create the ultimate listening experience.
- Page 3 OPERATION/INSTALLATION OVERVIEW Control Panel Display Connection Ports Mounting Hole Speaker Reset Button Micro SD Card Slot...
- Page 4 INSTALLATION Please install according to the specific motorcycle environment and connect the power cable. The installation diagram is show as below: A. Main Unit B. Front and Rear Cameras C. Power Harness (Red: Swith Power, Yellow: Battery +, Black: Ground or Battery) D.
-
Page 5: System Setting
INSTRUCTIONS Video mode • During recording, press the button on the remote control to lock the current recording file. Press the button again to unlock the locked video in the current recording. Press to take a photo. Press button to start recording, and the upper left side of LCD would show a recording mark the red mark would flashes during recording. -
Page 6: General Settings
OPERATION Movie Mode Connect to a Computer Video mode: 1920x1080 FHD 30fps Film cutting time: 3 minutes, 5 minutes, 10 minutes. Voice recording: on/off Explanatory note: record the sound simultaneously when the video is recorded. When the voice recording is closed, it can ensure the video shot is silent. General Settings Key tone: on/off Auto off: Never, 1 minute and 5 minutes... -
Page 7: Long Press
Please use your mobile phone to connect the camera’s WIFI （1） Long press down key for 3 seconds to turn on the WIFI; Camera’s WIFI name: DA-D580-XXXX ; Password: 1234567890 （2） After connecting the camera’s WIFI, users could set the camera’s setting on APP---CAR_DVR （3）... - Page 8 GPS Location and Application Technical Specifications Plug the GPS, the display would show the red GPS mark , when the GPS locates successfully,the mark would turn to green and the time would Lens 120 degrees A + level high resolution be synchronized automatically.
-
Page 9: Technical Specifications
SPECIFICATIONS Technical Specifications 2.7” (16:9) TFT LCD Front cam 1080P-AHD English (Default) Language Spanish Russian Chinese Video 1080P 30fps Video Format Mic/Speaker Built-in Light Source 50Hz/60Hz Frequency External Power Supply 5V 2A Rearcam 1080P-AHD Battery Built-in Super capacitor. Notes: the design and specification of the product are subject to the change without notice. - Page 10 NOTES...
-
Page 11: Service/Tech Support
WARRANTY Diamond Audio Technologies (DAT), a division of CV & DA Holdings Incorporated, warrants this product to be free from defects in material and workmanship for a period of one (1) year from the original date of purchase, provided it was purchased from an authorized DAT retailer within the United States. - Page 12 3761 S. Hill Street Los Angeles, CA 90007...
