FP2500-T42-24V / FP2600-T42-24V
• Prior to connecting the FP2500-T42-24V/FP2600-T42-24V (hereafter referred to as
the "FP" or "FP unit") unit's power cord terminals to the Terminal Block, be sure to
check that the FP unit's power supply is completely turned OFF, via a breaker, or
similar unit.
• Whenever changing the backlight be sure to unplug the FP unit's power cord and
wear protective gloves to prevent electric shocks and burns.
• Do not open or remodel the FP unit. Doing so may lead to a fire or electric shock.
• Do not use voltage levels that exceed the FP unit's specified voltage range. Doing so
may cause a fire or an electric shock.
• Do not use the FP in an environment where flammable gases are present, since
operating the FP may cause an explosion.
• Do not use the FP as a warning device for critical alarms that can cause serious
operator injury, machine damage or production stoppage. Critical alarm indicators
and their control/activator units must be designed using stand-alone hardware and/
or mechanical interlocks.
• Do not use FP unit touch panel switches in human-safety-related or important disas-
ter prevention situations. For safety-related switches, such as an emergency stop
switch, be sure to use a separately installed mechanical switch.
• After the FP unit's backlight burns out, unlike "Standby Mode", the unit's touch panel
is still active. If the operator fails to notice that the backlight is burned out and
touches the panel, a potentially dangerous machine operation error can occur.
Therefore, do not use FP unit touch-screen switches for the control of equipment
safety mechanisms, such as Emergency Stop switches, etc. that protect humans
from injury and equipment from damage.
If your FP unit's backlight suddenly turns OFF, use the following steps to determine
if the backlight is actually burned out.
1) If your currently running FP application is not set to turn the backlight OFF, and
the screen has gone blank, your backlight is burned out.
2) If your current FP application is set to turn the backlight OFF, if touching a corner of
the screen does not cause the display to reappear, your backlight is burned out.
• To prevent operator injury or machine damage, be sure to design your machine
operation system so that the machine will not malfunction due to a communication
fault between the FP unit and its host controller.
• Do not use the FP with aircraft control devices, aerospace equipment, central trunk
data transmission (communication) devices, nuclear power control devices, or medical
life support equipment, due to these devices' inherent requirements of extremely
high levels of safety and reliability.
• When using the FP with transportation vehicles (trains, cars and ships), disaster
and crime prevention devices, various types of safety equipment, non-life support
related medical devices and others, be sure to use redundant and/or failsafe system
designs to ensure the appropriate degree of system reliability and safety.
Installation Guide
WARNINGS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FP2500-T42-24V and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Pro-face FP2500-T42-24V

  • Page 1 Installation Guide WARNINGS • Prior to connecting the FP2500-T42-24V/FP2600-T42-24V (hereafter referred to as the "FP" or "FP unit") unit's power cord terminals to the Terminal Block, be sure to check that the FP unit's power supply is completely turned OFF, via a breaker, or similar unit.
  • Page 2 To prevent this unit from malfunctioning: • Do not strike the FP unit's touch panel with a hard or heavy object, or press on the touch panel with too much force, since it may damage the display. • Do not install the FP where the temperature will exceed the specified range. •...
  • Page 3: Ul/C-Ul/Csa Application Notes

    UL/c-UL/CSA Application Notes The FP2500-T42-24V/FP2600-T42-24V units are UL/c-UL listed products (UL File No. E182139). These units conform as components to the following standards: UL508 Industrial Control Equipment UL1604 Electrical Equipment for use in Class 1 & 2 - Division 2, or Class III Hazardous (classified) locations.
  • Page 4: Package Contents

    The following items are included in the FP unit's package. Before using the FP, please confirm that all items listed here are present. FP unit CD-ROM (1) (FP2500-T42-24V/FP2600-T42-24V) (FP-2500/FP-2600 Series User Manual ® Touch Panel Programs for MS-DOS Installation Gasket (1)
  • Page 5: About The Manual

    About The Manual The FP-2500/FP-2600 Series unit's PDF manual file (fp2000e.pdf) is contained in the CD-ROM's [Manual Eng] folder. ® Reading a PDF file requires installation of the Adobe Corporation's Acrobat Reader. ® Acrobat Reader Installation: ® To install the Acrobat Reader software, follow the steps given below.
  • Page 6 Dimensions FP2500-T42-24V Unit:mm [in] 301 [11.85] Top View 58 [2.28] 317 [12.48] 8 [0.31] Side View Front View FP2600-T42-24V Unit:mm [in] 301 [11.85] Top View 58 [2.28] 317 [12.48] 8 [0.31] Front View Side View...
  • Page 7: Dip Switches

    Dip Switches The FP unit's dip switches are located behind the Dip Switch Cover. Dip switch setting are effective only when starting up the FP unit. After changing any dip switch settings, be sure to restart your FP unit. Bottom View Factory Function Description...
  • Page 8: Analog Rgb Interface

    BLACK LEVEL H-POS OSD Settings V-POS (On Screen Display) H-SIZE PHASE BACKLIGHT DEFAULT (ALL CLEAR) The FP unit's available screen resolutions are as follows: (Unit: dot/pixel) FP2500-T42-24V Screen Resolution H Sync. V Sync. Dot Clock Expansion Display Size (kHz) (Hz)
  • Page 9 FP2600-T42-24V Screen Resolution H Sync. V Sync. Dot Clock Expansion Display Size (kHz) (Hz) (MHz) (H: Horizontal) Resolution (V: Vertical) 31.469 70.000 25.175 800 × 525 640×350 × 1.25 (H) 640×400 31.469 70.000 25.175 800 × 600 × 1.5 (V) 640×400 24.827 56.420...
  • Page 10: Dvi-D Interface

    Input signal type DVI-D H-POS Setting by OSD V-POS (On Screen Display) BACKLIGHT DEFAULT (ALL CLEAR) The FP unit's available screen resolutions are as follows: (Unit: dot/pixel) FP2500-T42-24V Screen Resolution H Sync. V Sync. Dot Clock Expansion Display Size (kHz)
  • Page 11 DVI-D Pin Assignments and Signal Names Signal Name Signal Name Pin Location TMDS DATA2- TMDS DATA2+ TMDS DATA2/4 SHIELD GND (+5V) Hot Plug Detect TMDS DATA0- DDC Clock TMDS DATA0+ DDC Data TMDS DATA0/5 SHIELD TMDS DATA1- TMDS DATA1+ TMDS CLOCK SHIELD TMDS DATA1/3 SHIELD TMDS CLOCK+ TMDS CLOCK-...
  • Page 12 RS-232C Interface Baud rate: 9600 bps Data length: 8 bits RS-232C Interface Parity: none Stop bit: 1 RS-232C (Serial) Interface Pin Assignments and Signal Names Signal Condition Pin Location Name Carrier Detect *1 → Receive Data (FP Host) ← Send Data (FP Host) Data Terminal Ready *1 Ground Data Set Ready *1...
  • Page 13: Usb Interface

    USB Interface Pin Assignments and Signal Names for USB Interface Signal Condition Pin Location Name 1 USB1-5V +5V IN 2 USBD1 (-) USB data (-) 3 USBD1 (+) USB data (+) 4 GND Ground Communication : Low speed Device Connector : B type connector USB Cable : FP-US00...
  • Page 14 Create a Panel Cut and insert the FP into the panel from the front Unit: mm [in] Panel Panel +0.04 301.5 [11.87 Panel thickness 1.6mm[0.06in] to 10.0mm[0.39in] Attach the Installation Fasteners from Inside the Panel The following figures show the four (4) fastener insertion slot locations. Insert each fastener's hook into the slot.
  • Page 15 OFF, via a breaker, or similar unit. • FP2500-T42-24V/FP2600-T42-24V units are designed to use only DC24V input. Any other power level can damage both the FP and the power supply.
  • Page 16: Power Supply Cautions

    Power Supply Cautions Power Supply Cautions Please pay special attention to the following instructions when connecting the power cord terminals to the FP unit. • If the power supply voltage exceeds the FP unit's specified range, connect a voltage transformer. •...
  • Page 17: Screen Display Adjustment

    Screen Display Adjustment OSD Features Use the FP unit's touch panel and the OSD (On Screen Display) menu to set the FP screen settings, and fine-tune your screen's display. You can enter these settings even while the FP si operating. The following table explains each OSD setting item and its function.
  • Page 18 • The OSD is not displayed when SW1-2 is set to ON. Using the OSD Icons on the screen are used to operate the OSD. When you start up the OSD, the main menu appears. Touching the icon of the item you want to adjust displays its submenu or setting change screen.
  • Page 19 V-POS Adjustment buttons Applies the setting and then returns to the main menu. Cancels the setting and then returns to the main menu. H-SIZE Adjustment buttons Applies the setting and then returns to the main menu. Cancels the setting and then returns to the main menu. PHASE Adjustment buttons Applies the setting and then returns to the main menu.
  • Page 20: Replacing The Backlight

    For an explanation of how to replace the FP unit's backlight, please refer to the FP- 2500/FP-2600 Series User Manual or the backlight's Installation Guide. Corresponding Replacement Backlight Model Numbers FP Model No. Backlight Model No. FP2500-T42-24V GP577RT-BL00-MS FP2600-T42-24V PS600-BU00 Use of a different model backlight may cause a FP malfunction or breakdown.
