Product Manual
Model 9113-0-0
Ethernet Bridge
for Ultra 3000 Servo
Quartech Corporation
15923 Angelo Drive
Macomb Township, Michigan 48042-4050
Phone: (586) 781-0373 FAX: (586) 781-0378
www.QuartechCorp.com
PM9113-0-0 Revision 2
The product described in this document can have a variety of uses, the user and those responsible for applying this
equipment must satisfy themselves as to the acceptability of each application and the use of the unit. Under no
circumstances will QUARTECH CORPORATION be responsible or liable for any damage, including indirect or
consequential losses resulting from the use, misuse, or application of the unit.
The text, illustrations, charts, and examples included in this document are intended solely to help explain applications
of the product. Due to the many variables associated with specific uses or applications, QUARTECH CORPORATION
cannot assume responsibility or liability for actual use based upon the data provided in this document.
No patent liability is assumed by QUARTECH CORPORATION with respect to the use of circuits, information,
equipment, or software described in this document.
This document is subject to change without notice.
PM9113-0-0 Revision 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9113-0-0 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Quartech 9113-0-0

Summary of Contents for Quartech 9113-0-0

  • Page 1 The text, illustrations, charts, and examples included in this document are intended solely to help explain applications of the product. Due to the many variables associated with specific uses or applications, QUARTECH CORPORATION cannot assume responsibility or liability for actual use based upon the data provided in this document.
  • Page 2 Page 1 Model 9113-0-0 Product Manual The Model 9113 Ethernet Bridge allows an Allen-Bradley PLC such as the MicroLogix 1100 to monitor and control an Ultra 3000 Servo Drive over an ethernet connection. The 9113 connects to the Ultra 3000 CN3...

  • Page 3: Theory Of Operation

    Page 2 Model 9113-0-0 Product Manual Theory of Operation The 9113 allows a PLC to read and write parameters within the Ultra 3000 drive using the Message Instruction. The parameters in the Ultra 3000 are mapped to File/Element numbers so the PLC accesses the Ultra parameters as though they were File/Elements in a peer SLC500 PLC For the PLC to read or write File/Elements it must first establish a TCP connection to the 9113.
  • Page 4 Page 3 Model 9113-0-0 Product Manual Multiple Axis: The 9113 provides a bridge to a single drive When an application requires multiple drives to be controlled then each drive will have an associated 9113 with a unique IP address. An ethernet hub or switch will be required to connect the devices.

  • Page 5: Ethernet Cables

    Page 4 Model 9113-0-0 Product Manual Ethernet Cables: The 9113 operates with standard ethernet cables available from many sources. The examples below are consistent with the TIA/EIA 568-B color code standard. Straight Through Cable Crossover Cable Device to Hub / Switch...
  • Page 6 Page 5 Model 9113-0-0 Product Manual 2180 Cable - 9113 to Ultra 3000 (Supplied with 9113) 9 Pin Male D-Type Ultra 3000 Communication Parameters: 38400 Baud, 8 Data Bits, No Parity, One Stop Bit 2181 Cable - 9113 to Personal Computer...
  • Page 7 Page 6 Model 9113-0-0 Product Manual 9113 Hardware Dip Switch: Four switches are accessible through an opening at the side of the 9113 as shown in the image above. A switch is OFF when the lever is pushed toward the front of the 9113. Currently switches one and two are not assigned. The operation of the 9113 is controlled by switch three and four.

  • Page 8: Led Indicators

    Page 7 Model 9113-0-0 Product Manual LED Indicators: The five LEDs indicate the ongoing status of the 9113 during both Run and Utility mode. During power-up a checksum verification is made on the 9113 firmware. If the verification fails then the three LEDs on the front will light red and the micro controller will halt execution.
  • Page 9 Page 8 Model 9113-0-0 Product Manual Physical Size and Mounting: Dimensions in inches The 9113 is enclosed in a rugged steel case and provides a spring loaded DIN rail mounting clip that allows mounting and dismounting without any tools. To mount the 9113 tilt it forward and hook the clip to the bottom of the DIN rail.
