2 • The X-431 Scanner

Components

The main console of the X-431 is composed of three separate pieces: the
Main Unit, the Mini-Printer, and the Smartbox. The following diagram
displays the main console and many of the connectors.
© X - 4 3 1 U S A
1 (877) GET-X431
1 • X-431 Main
Unit
2 • Mini-Printer
3 • CF Card
4 • Diagnostic
Connector
5 • Power
Converting
Cable
6 • Cigarette
Lighter
Cable
7 • Battery
Cable With
Single Clip
8 • Power
Adapter
9 • Main Cable
1 0 • Smartbox
2-1
