3.3. Playback Range

Operate the playback range accordingly to play back the video images of a specific time that you want to
view.
The [Playback Range (10 min / 1 Hour / 1 Day)] buttons are used to select the range of the seek bar.
For example, when 1 hour is selected, the time range from the left to the right end of the seek bar
represents a duration of 1 hour.
The [Skip Range (Previous/Next)] buttons are used to slide to the previous or next seek bar range.
For example, when the seek bar range is at "9:00 – 10:00", clicking the [Skip Range (Next)] button shifts
the seek bar to the "10:00 – 11:00" range.
Sliding the seek bar changes the playback time. Playback will start from the time where you stopped
sliding.
Playback Range (1 Hour) Button
Playback Range (10 min) Button
Playback Range (1 Day) Button
Skip
Range (Next) Button
Skip
Range (Previous) Button
Time Display
Time Display
on Right End of Seek Bar
on Left End of Seek Bar
Playback Time Display
Seek Bar
Playback Range Specification Area
11
