Page 1 Colorwriter LSR 2000 Printer User Guide Printing Systems InfoCenter http://www.printers.digital.com EK-LCPLE-UG .A01 Digital Equipment Corporation Maynard, Massachusetts This document was created with FrameMaker 4.0.4...
Page 2 Unpublished rights reserved under the copyright laws of the United States. Trademarks The following are trademarks of Digital Equipment Corporation: OpenVMS, VAX, PATHWORKS, Digital, and the DIGITAL logo. The following are trademarks of Electronics for Imaging, Inc.: EFI, the EFI logo, Fiery XJ, Fiery Driven, the Fiery Driven Signature, EFICOLOR, the EFICOLOR logo, and Fiery Print Calibrator.
Page 3 Software which has been included on the Colorwriter LSR 2000 hard disk drive. You may not copy the documentation;...
Page 4 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Page 5 LNC01 (color) LNC01 (b&w) (1 B = 10 dBA) Aktuelle Werte für spezielle Ausrüstungsstufen sind über die Digital Equipment Vertretungen erhältlich. Class 1 Laser Product (100-120V/220-240V models) Laser radiation could be hazardous to the human body. For this reason, laser radiation emitted inside this printer is hermetically sealed within the protective housing and external cover.
Page 6: Table Of Contents
Contents Preface About the Colorwriter LSR 2000 xiii About this guide Related documentation Important safety information Handling the Colorwriter Choosing a location for the Colorwriter Unpacking and setting up the Colorwriter xvii Operating the Colorwriter xvii Protecting the LCD display...
Page 7 viii Contents Chapter 2: Operating the Printer Printer control panel overview Activity lights Buttons Display window Resetting default setup options Status messages Warning, service, and error messages Menu options Using the density control panel Density adjustment Test patterns Using the optional paper feeder unit 2-10 Handling and storing paper 2-11...
Page 8 ix Contents Application notes 3-29 Adobe Illustrator 5.0 and 5.5 3-29 Aldus PageMaker 5.0 3-31 Adobe Persuasion 3.0 3-36 Adobe Photoshop 2.5 and 3.0 3-37 Macromedia FreeHand 5 3-40 Microsoft PowerPoint 4.0 3-42 QuarkXPress 3.2 and 3.3 3-44 Other QuickDraw applications 3-50 Chapter 4: Printing from PC-compatible Computers Printing to the Colorwriter from Windows...
Page 9 x Contents Chapter 5: Printing from UNIX Workstations Printing to the Colorwriter from UNIX Workstations Chapter 6: Printing from OpenVMS Systems Printing from DCPS to the Colorwriter Chapter 7: Administering Print Jobs over the NetWare Print Server Monitoring queued print jobs Printing a PostScript ﬁle Using AppleTalk with Macintosh computers on an IPX (Novell) network...
Page 10 xi Contents Appendix C: Maintenance Identifying the parts of the printer Cleaning and handling the printer Cleaning the cabinet Cleaning the paper pickup area Using the wire cleaner Cleaning the separation corona wire Cleaning the window of the density detection sensor Handling the Colorwriter C-10 Storing and handling toner cartridges...
Page 11 xii Contents Appendix E: Speciﬁcations Colorwriter speciﬁcations Paper requirements Unacceptable paper Effective printing area Appendix F: Ordering Accessories and Supplies Optional paper feeder unit Optional paper cassette Upgrade kits Ordering consumables Toner cartridges Silicone oil Drum cartridge kit Transparency ﬁlm Paper Appendix G: Ordering Related Documentation Technical support...
Page 12: About The Colorwriter Lsr 2000
™ continuous tone color laser technology. Equipped with a Fiery XJe controller, and combined with Digital’s well-known product reliability and support, the Colorwriter LSR 2000 provides top performance and photographic quality for large, complex ﬁles consisting of text, graphics, and images. The Colorwriter not only performs at speeds up to ﬁve times faster than typical desktop models, it does...
Page 13: About This Guide
Speciﬁcations are also included. When referring to the printer, the terms Colorwriter, Colorwriter LSR, and Colorwriter LSR 2000 are used interchangeably in this manual. The audience for this guide is anyone who will be printing to the...
Page 14: Related Documentation
This guide is part of a set of printed documentation (Order Number: EK-LCPLE-DK) that also includes the following: • The Colorwriter LSR 2000 Printer Getting Started describes how to install the Colorwriter and the user software for the Colorwriter, and how to set up ®...
Page 15: Important Safety Information
xvi Important safety information Important safety information This printer is a high-precision electronic device. Therefore be sure to read these safety instructions carefully before you begin. Follow all warnings and instructions marked on the printer and consumables, such as the toner cartridges and silicone oil bottles. Handling the Colorwriter •...
Page 16: Unpacking And Setting Up The Colorwriter
xvii Important safety information Unpacking and setting up the Colorwriter • Before connecting the printer to a power source, check the voltage rating label on the back of the printer to ensure that the printer voltage matches that of the power source.
Page 17 xviii Important safety information • The printer is equipped with a 3-wire grounding type plug, which has a third (grounding) pin. This plug will ﬁt into only a grounding-type power outlet. If you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet.
Page 18: Protecting The Lcd Display
xix Energy Star compliance Protecting the LCD display Do not subject the Colorwriter to strong shocks. The Colorwriter has a liquid crystal display (LCD) that is made of glass and can break. If the display window breaks and the liquid crystal material leaks out, do not inhale, ingest, or touch it. If the material gets on your skin or clothing, wash it off with soap and water immediately.
Page 19: The Properties Of Color
1-1 The properties of color This chapter provides information about: Chapter 1: Introduction • The properties of color to Color • Traditional color printing and Colorwriter printing Printing • Controlling printed color and the Colorwriter The properties of color Color theory is an attempt to systematize the properties of color perception, which by nature is relative and changeable.
Page 20: Cie Color Model
1-2 The properties of color the human eye which can, up to a point, adjust to the different light sources. However, colored objects appear different under tungsten light than they do under sunlight because of the different spectral makeup of the two light sources. The mixture of light wavelengths emitted by a light source is reﬂected selectively by different objects, and the mixture of light reﬂected appears as different colors.
Page 21: Hue, Saturation, And Brightness
A familiar device that uses this color model is the computer monitor (plate 6). Monitors have red, green, and blue phosphors that emit varying amounts of light to display a given color. Scanners create digital representations of colors by measuring their red, green, and blue components through colored ﬁlters.
Page 22 Digital color printers such as the Colorwriter use cyan, magenta, yellow, and black toners. The CMYK colorants used both in offset printing and in digital color printers are to some degree transparent. When one layer of colorant is applied on top of another, you see the effect of both.
Page 23: Printer Gamut
1-5 The properties of color ™ as Adobe Illustrator are geared toward specifying color for offset printing using process and spot colors. Many applications allow you to specify the screening used for each printing plate. Screen frequency settings are generally ignored by the PostScript interpreter when it processes your document for the Colorwriter.
Page 24: Traditional Color Printing And Colorwriter Printing
By streamlining the process of color printing, the Colorwriter makes short print runs economically feasible. In contemporary offset lithographic printing, digital ﬁles from desktop computers are output to an imagesetter, which creates ﬁlm separations. The ﬁlm is then used to make a prepress proof, which is an accurate predictor of the ﬁnal print job, and...
Page 25: Controlling Printed Color
1-7 Controlling printed color Controlling printed color The following factors affect printer consistency, as well as color ﬁdelity and overall output quality: Maintenance and supplies The paper and toner used in a printer affect printed color. For best results, use the paper and toner recommended by the manufacturer of the printer.
Page 26: The Role Of Color Management
1-8 Controlling printed color If you have a densitometer, you can measure your printed output to monitor the range of output densities. Where color accuracy and consistency are crucial, regular calibration of the printer is advisable. In this manual, software or features that are part of the Professional Color Kit (PCK) are indicated with a small PCK icon.
Page 27 PANTONE Color libraries for coated and uncoated paper. CRDs—color management on the Colorwriter LSR 2000 Because the Colorwriter is a PostScript Level 2 printing device, it has the ability to use custom CRDs (color rendering dictionaries). CRDs are used for converting RGB data sent to the printer into CMYK data used by the printer’s print engine,...
Page 28 1-10 Controlling printed color You can choose from four color rendering styles, each of which has a different way of translating color image data to the CMYK color space of your printer. Choosing the appropriate color rendering style will give you the best results within the capabilities of your printer.
Page 29 1-11 Controlling printed color • Saving RGB EPS images from Adobe Photoshop and placing them in other applications If you work with RGB data in Photoshop for Macintosh or Windows, you can load Colorwriter separation tables to perform the same function as the CRDs built into the printer.
Page 30 1-12 Controlling printed color Colorwriter support for the PANTONE color matching system consists of the Macintosh and Windows PANTONE Reference Book for coated and uncoated papers, included with the user software. With the PANTONE Reference Book ﬁles, you can quickly print a book of PANTONE color simulations, accompanied by their CMYK percent values, on your Colorwriter.
Page 31: Chapter 2: Operating The Printer
This chapter contains basic information on operating the Colorwriter. You’ll ﬁnd Chapter 2: instructions on: Operating the Printer • Using the printer control panel • Using the display window • Using the density control panel • Loading paper into the optional paper feeder unit •...
Page 32: Printer Control Panel Overview
2-2 Printer control panel overview Printer control panel overview The printer control panel on the front of the Colorwriter enables you to set options and view information about print jobs, in addition to displaying status information about the Colorwriter. The printer control panel is comprised of the following parts: •...
Page 33: Buttons
2-3 Printer control panel overview Buttons The buttons enable you to control print jobs and choose print options; they have the following meanings: Suspends and resumes printing. Brings the printer offline for setup or for changing language of LCD screens. Cancels the “oldest”...
Page 34: Display Window
2-4 Display window Display window The display window is an LCD panel on the printer control panel that provides information on the status of the Colorwriter, enables you to print special pages, and enables you to view and edit printer setup information. For information about using the Printer Setup menu, see Chapter 4 of Getting Started.
Page 35: Warning, Service, And Error Messages
2-5 Display window Warning, service, and error messages If there is a printing problem, the fault light is lit, and an error message appears on the control panel. You can press the Menu button when an error message is displayed to see the other control panel screens. For information about error messages, see Appendix A.
Page 36: Using The Density Control Panel
2-6 Using the density control panel Using the density control panel This section describes the density control panel located on the back of the Colorwriter. You can use the density control panel to: • Change color density settings • Change test pattern pages The parts of the density control panel are shown in the following illustration: Magenta LED Cyan LED Yellow LED...
Page 37: Density Adjustment
2-7 Using the density control panel ENTER After you select a new density for one of the color selection indicators (M, C, Y, Bk), press this button to save the new density for the selected color indicator. TEST PRINT Prints a built in test pattern (solid color, solid white, gradation, horizontal lines, vertical lines, or grid).
Page 38: Test Patterns
2-8 Using the density control panel Press ENTER to save the new density setting. The density gauge LED stops ﬂashing when the new color density settings have been saved. Turning the printer on and off does not change the color density settings.
Page 39 2-9 Using the density control panel O CHANGE THE TEST PATTERN While holding down COLOR SELECT, press ENTER eight times. All color indicator LEDs will ﬂash to indicate the shift to the test pattern selection mode. TEST COLOR DEFAULT ENTER PRINT SELECT Press + and - to select a test pattern.
Page 40: Using The Optional Paper Feeder Unit
2-10 Using the optional paper feeder unit Using the optional paper feeder unit The optional paper feed unit gives you two distinct advantages: • Increases the paper supply by approximately 250 sheets of 20-pound (80 g/m stock), in addition to the 250-sheet capacity in the main cassette and the 100- sheet multipurpose tray.
Page 41: Handling And Storing Paper
2-11 Handling and storing paper Handling and storing paper Appropriate paper handling and storage keeps the paper in the best condition for printing. Follow the instructions below for handling and storing paper. • Store unused paper in its wrapping to protect the paper against humidity. •...
Page 42: Handling Transparency Film
2-12 Handling and storing paper • Before inserting any color printout between printed pages, make sure the pages are completely dry, otherwise, the ink may cause the toner to melt. • Store color printouts ﬂat. If they are folded or wrinkled, the toner may come off.
Page 43: Loading The Paper Cassette
2-13 Loading the paper cassette Loading the paper cassette The universal paper cassette included in the printer package can hold about 250 sheets of 20-pound (80 g/m stock). The paper sizes supported are Letter, A4, B5, and Legal. The Colorwriter is not designed to print on envelopes or labels. Attempting to print on those materials could damage the printer.
Page 44 2-14 Loading the paper cassette O REMOVE THE PAPER CASSETTE • While pushing up the handle on the underside of the cassette, pull out the paper cassette. To increase the paper supply, you can also add the optional paper feeder unit which comes with a universal paper cassette as well.
Page 45 2-15 Loading the paper cassette While lifting the paper length guide slightly, slide it until the desired paper length is selected (as marked on the tray), then release the guide to lock it. Paper length guide Set the size guide on the front of the cassette to the corresponding paper size. The size guide provides you with a visual indication of the paper size loaded in the cassette.
Page 46 2-16 Loading the paper cassette Check to see that the paper stack does not exceed the paper limit mark, otherwise a paper jam may result. Press down on the paper so that it stays under the two retaining clips, otherwise a paper jam may result.
Page 47 2-17 Loading the paper cassette While pressing the handle upward, slide the cassette all the way into the paper feeder unit until it clicks into place. The cassette is now ready to supply paper. O READ THE PAPER AMOUNT INDICATOR •...
Page 48: Loading Paper Into The Multipurpose Tray
2-18 Loading paper into the multipurpose tray Loading paper into the multipurpose tray The multipurpose tray holds about 100 sheets of paper. Various paper sizes and types are supported, including transparency ﬁlm. See “Paper requirements” on page E-3 for a list of paper types supported. The tray can be closed when not in use.
Page 49 2-19 Loading paper into the multipurpose tray O CLOSE THE MULTIPURPOSE TRAY Lift the end of the extension tray slightly, then push it into the multipurpose tray. Close the multipurpose tray. O LOAD PLAIN PAPER Adjust the paper guides to the desired paper size.
Page 50 2-20 Loading paper into the multipurpose tray Tap a stack of paper on a ﬂat surface to align its edges. Insert the paper stack as far as it can go into the printer, making sure the print side is facing down and the top of the page is going into the printer ﬁrst. Check that the paper stack does not exceed the paper limit mark.
Page 51 2-21 Loading paper into the multipurpose tray Do not load the multipurpose tray with different sized paper at the same time. Do not place anything but paper on the multipurpose tray. Also, avoid pressing or applying excessive force to the multipurpose tray. Do not add paper when there is still paper in the multipurpose tray;...
Page 52 2-22 Loading paper into the multipurpose tray Do not set the paper guides so loose that the paper stack is not evenly aligned. Do not set the paper guides so that there is space between the guides and the paper. Do not place the paper into the multipurpose tray at an angle.
Page 53: Loading Transparency Film
2-23 Loading paper into the multipurpose tray Loading transparency ﬁlm Transparency ﬁlm can be loaded into the multipurpose tray only. About 20 sheets can be loaded at a time. For optimal color print quality, use our letter-size or A4-size transparency ﬁlm. For details, contact an authorized service representative.
Page 54 2-24 Loading paper into the multipurpose tray O LOAD TRANSPARENCY FILM Open the multipurpose tray (see page 2-18 for this procedure). Adjust the paper guides to accept transparency ﬁlm (A4 or Letter size). With the white positioning marker on the upper right, tap a stack of transparency ﬁlm on a ﬂat surface to align its edges.
Page 55 2-25 Loading paper into the multipurpose tray Position each sheet so that the white positing marker is on the upper right as shown, and push it as far as it can go into the printer. White positioning marker When you hold the transparency ﬁlm this way, the print side is facing down on the multipurpose tray.
Page 56: Chapter 3: Printing From Macintosh Computers
3-1 Printing from applications You can print to the Colorwriter from any Macintosh computer with Ethernet Chapter 3: installed. First, select the Colorwriter LSR 2000 as the current printer with the Printing from Chooser desk accessory, then print the ﬁle from within your application. You may...
Page 57 Select the printing options you want in the Page Setup dialog box and click OK. If the LaserWriter Page Setup dialog box lets you select from a list of available printers, select the Colorwriter LSR 2000 The Text Smoothing, Graphics Smoothing, and Faster Bitmap Printing options have no effect on your printed document when you print with the Colorwriter.
Page 58 3-3 Printing from applications Select the options you want and click Print. Print and Print Options dialog boxes vary among printer drivers and applications. If you can select a Paper Source, specify the paper tray to use for the job. For example, you can use this dialog box to specify that the job should be printed on the media in the Multipurpose tray.
Page 59 3-4 Printing from applications Click Save after you change the options to make the new settings your default settings. Don’t click Save if you want to use the Colorwriter defaults for each job. This affects printing from all applications, not just the one you are using. If you select Printer’s Default, the Colorwriter prints with the instructions entered during Setup for Color Mode and Rendering Style.
Page 60 3-5 Printing from applications Color rendering dictionaries are not used when CMYK ﬁles are sent to the Colorwriter, nor are they used when RGB ﬁles are sent from PostScript Level 1 applications when using any printer driver or QuickDraw applications when using the LaserWriter 7.x or other PostScript Level 1 printer drivers.
Page 61: Printing Pages From The Multipurpose Tray
3-6 Printing pages from the multipurpose tray Printing pages from the multipurpose tray You can use the Colorwriter to print manually fed pages if you want to print on special paper, such as letterhead or colored paper, or a transparency. O PRINT PAGES USING THE MULTIPURPOSE TRAY Open the multipurpose tray and insert a sheet of paper or a transparency.
Page 62: Using Colorwriter Lsr Utilities
You can also use standard LaserWriter downloaders, such as the Adobe Font Downloader, with the Colorwriter LSR 2000 . The Colorwriter LSR Downloader was designed speciﬁcally for the Colorwriter LSR 2000 printer. You cannot use it with any other printer.
Page 63 O VIEW STATUS INFORMATION WITH THE OLORWRITER OWNLOADER Double-click the Colorwriter LSR Downloader icon. Select the Colorwriter LSR 2000 in the Chooser window that appears and click Connect. You see the Colorwriter LSR Downloader window, with a File menu, icons, the...
Page 64 The Colorwriter Hard Disk area displays the amount of available disk space on the Colorwriter LSR 2000 You can click the Display Font List button or choose Font List from the File menu to view font information in the window.
Page 65: Printing With The Colorwriter Lsr Downloader
3-10 Using the Colorwriter LSR Downloader Printing with the Colorwriter LSR Downloader Printing PostScript ﬁles with Colorwriter LSR Downloader is fast—generally faster than printing from within applications. If you regularly print large ﬁles, be sure to try printing with the Colorwriter LSR Downloader. LSR D O DOWNLOAD A FILE WITH THE OLORWRITER...
Page 66 3-11 Using the Colorwriter LSR Downloader Select the ﬁle type to display in the Show pop-up menu. You can leave this at the default All known formats, or select All Files. All known formats will list all ﬁles in formats supported by the Colorwriter LSR Downloader;...
Page 67: Downloading And Managing Printer Fonts
Downloading and managing printer fonts Before printing a PostScript or EPS ﬁle that requires fonts that are not resident on the Colorwriter LSR 2000 hard disk, you must download the fonts manually. The Colorwriter comes with PostScript fonts. These include regular, bold, italic,...
Page 68 When you have selected all fonts, click Download. Printer fonts and Macintosh screen fonts Like all PostScript fonts, the fonts included with the Colorwriter LSR 2000 come in two forms: printer fonts and screen fonts. The printer fonts are installed permanently on the Colorwriter LSR 2000 hard disk.
Page 69 3-14 Using the Colorwriter LSR Downloader installed on the Colorwriter LSR 2000 , as long as the printer fonts are installed in your System Folder. These fonts remain in the Colorwriter only until your document has printed. If you print the same document again, your application must download the fonts again.
Page 70 3-15 Using the Colorwriter LSR Downloader O VIEW FONT INFORMATION Choose Font List from the File menu or click the Font List button. The Font List window is displayed with the Update, Print, and Delete buttons in the titlebar.
Page 71 3-16 Using the Colorwriter LSR Downloader The icons in the Font list window are: Update Click this icon to update the information in the font list window. Print Font Click this icon to print the font list. List Delete Select a font and click this icon to delete it from the Colorwriter hard disk.
Page 72: Using The Colorwriter Lsr Spooler
3-17 Using the Colorwriter LSR Spooler Using the Colorwriter LSR Spooler The Colorwriter LSR Spooler lets you monitor and manipulate the print jobs that you send to the Colorwriter. It also lets system administrators track and manage all users’ print jobs. Colorwriter LSR Spooler jobs can be in one of the following queues: Print Print jobs sent to the Colorwriter Print queue appear in the...
Page 73 3-18 Using the Colorwriter LSR Spooler Select the Colorwriter LSR 2000 from the list of devices, and click Connect. The Colorwriter LSR Spooler main window and File, Edit, Window, and Administrator menus appear.
Page 74 3-19 Using the Colorwriter LSR Spooler The job list includes information about the document name, user name, time and date sent, print device, and ﬁle size. The window is split into regions that correspond to the different queues and steps in the printing process.
Page 75 3-20 Using the Colorwriter LSR Spooler Icons also appear above the scroll list. The icons are: Update Click this icon to update the information in the Colorwriter LSR Spooler main window. Duplicate Drag a job onto this icon or select the document and and Print click this icon to move a duplicate of the job to the Print queue.
Page 76 To display information about a different Colorwriter, choose Open Colorwriter LSR from the File menu. The Chooser window appears. Select the Colorwriter LSR 2000 in the Chooser. The Colorwriter LSR Spooler main window appears and displays information about the Colorwriter you selected.
Page 77: Duplicating, Copying, Moving, And Deleting Jobs
3-22 Using the Colorwriter LSR Spooler Duplicating, copying, moving, and deleting jobs Users can always move, delete, and conﬁgure their own print jobs. If a password has been set, users can manipulate only their own print jobs; the Colorwriter system administrator (or anyone with Colorwriter LSR Spooler password access) can move, prioritize, delete, and conﬁgure jobs for all users.
Page 78 3-23 Using the Colorwriter LSR Spooler Click the Duplicate and Print icon, or drag the job to the Duplicate and Print icon. The job appears at the bottom of the Print queue. O COPY A JOB TO ANOTHER QUEUE Select the job that you want to copy by clicking its name. The selected job is highlighted.
Page 79: Changing Print Settings For A Job
3-24 Using the Colorwriter LSR Spooler O MOVE JOBS BETWEEN QUEUES Select the job that you want to move by clicking its name. The selected job is highlighted. If you want to select more than one job, Shift- click to make selections of adjacent jobs in the list; Command-click to select multiple, non-adjacent jobs in the list.
Page 80: Using The Job Log
3-25 Using the Colorwriter LSR Spooler O CHANGE PRINT SETTINGS FOR A JOB Double-click a job or select the job and choose Override Print Settings from the Edit menu. The Override Print Settings dialog box appears. Select the new settings. Select any of the options in the pop-up menus.
Page 81 3-26 Using the Colorwriter LSR Spooler Specify the period for the job log in the dialog box that appears. Click All to view all jobs since the job log was cleared; click Date if you want to specify a period of time for the job log, and enter the dates you want. Click OK.
Page 82 3-27 Using the Colorwriter LSR Spooler The text in the Status column provides information about the job: The job was printed normally. ERROR A PostScript error occurred while a job was processing. You can double-click ERROR to display the error message. A dialog box displays the PostScript error.
Page 83 3-28 Using the Colorwriter LSR Spooler O USE ADMINISTRATOR FUNCTIONS Choose Password from the Administrator menu. This option is only available if a password was created on the Colorwriter. Enter the password in the window that appears. This password is initially set in the Setup on the control panel. Once it is set, only persons with the password can move, override, and delete all users’...
Page 84: Application Notes
3-29 Application notes Application notes This section provides special instructions for optimizing color output with the following Macintosh applications: • Adobe Illustrator 5.0 and 5.5 • Aldus PageMaker 5.0 • Adobe Persuasion 3.0 • Adobe Photoshop 2.5 and 3.0 • Macromedia FreeHand 5 •...
Page 85 3-30 Application notes Working with imported ﬁles You should use EPS ﬁles for all raster artwork that will be placed in Illustrator documents. If the image is RGB, it should be saved from Adobe Photoshop, since Photoshop includes PostScript information in RGB EPS ﬁles that activates the Colorwriter CRDs.
Page 86: Aldus Pagemaker
3-31 Application notes Aldus PageMaker 5.0 In general, you should use the Adobe PostScript Printer Driver, although LaserWriter 8.0 and 7.1 are also supported. O CHANGE THE AGE SETUP DIALOG BOX Choose Page setup from the File menu. Choose options in the Page setup dialog box when you begin creating the PageMaker document.
Page 87 3-32 Application notes does from Photoshop. For details, see “Exporting image ﬁles to other applications” on page 3-39. Note that using a different ﬁle format will compromise the printed output of RGB bitmaps, since no CRD will be activated. If you use a pixel-editing application other than Photoshop, you should separate the image to CMYK before importing it.
Page 88 3-33 Application notes O CHOOSE OPTIONS WHEN PRINTING From the Type pop-up menu in the Print dialog box, choose the printer ﬁle for your Colorwriter. To access more print options, click Paper, Options, or Color. In the Paper dialog box, choose a paper size and a paper tray.
Page 89 3-34 Application notes In the Options dialog box, click Optimized and click Faster (binary). Optimized Faster (binary) In the Color dialog box, click Composite and click Color. Composite Color...
Page 90 3-35 Application notes Using option-print To use the option-print feature, hold down the option key while selecting Print from the File menu. In the Print document dialog that is displayed, the Paper button is replaced by the Setup button, which you use to access printer features. Click Setup to access printer features (a Page...
Page 91: Adobe Persuasion
3-36 Application notes Choose Color/ Grayscale Choose printer features Adobe Persuasion 3.0 Presentations created in Persuasion can be printed to the Colorwriter on plain paper or on transparency ﬁlm for projection. For best results, you should use the Colorwriter’s built-in CRDs. Note that you will need to use a PostScript Level 2 printer driver, such as the Adobe PostScript Printer Driver.
Page 92: Adobe Photoshop 2.5 And
3-37 Application notes Selecting options when printing To use the CRD when printing from Persuasion, choose Calibrated Color/ Grayscale in the Print Options dialog box. In general, you should choose Presentation or Solid Color for Rendering Style. For detailed instructions on setting print options, see “Printing from applications”...
Page 93 3-38 Application notes From the Chooser, select the PSPrinter icon, and then select the name of your Colorwriter. Load the Calibrated RGB monitor settings ﬁle, as described in the next section. Loading Calibrated RGB monitor settings The Calibrated RGB monitor settings ﬁle ensures consistent results when using Colorwriter CRDs.
Page 94 3-39 Application notes Selecting options when printing You must select the “Print in RGB” option in the Print dialog box to use the Colorwriter’s built-in CRDs. You need to make selections in the Print Options dialog box only if: • You previously chose a rendering style other than Photographic for your saved set of print options.
Page 95: Macromedia Freehand
3-40 Application notes Macromedia FreeHand 5 In general, you should use the Adobe PostScript Printer Driver, although LaserWriter 8.0 and 7.1 are also supported. Choosing ﬁll and line colors You can create ﬁll and line colors using the process (CMYK), RGB, or HSL color models, or choose a named color using one of the color matching systems supplied.
Page 96 3-41 Application notes Selecting options when printing Refer to the following illustrations to choose options when printing. Click to set printer- speciﬁc Print Options Click Composite proof Click to set FreeHand Print Options Click to set Output Options Click Use PPD Information Your printer model appears here,...
Page 97: Microsoft Powerpoint
3-42 Application notes Don’t check Split complex paths Click Binary data Leave these ﬁelds blank You need to set printer-speciﬁc Print Options (by clicking Options in the Print dialog box) only if: • The FreeHand document you are printing includes a placed photographic image saved from Photoshop as an RGB EPS ﬁle.
Page 98 3-43 Application notes All RGB ﬁles imported into PowerPoint are affected by your choice of CRD in the Print Options dialog box. Because the CRD that is best suited to the presentation’s other picture elements may not be appropriate for imported photographic images, you may want to have photographs bypass the CRD altogether.
Page 99: Quarkxpress 3.2 And
3-44 Application notes QuarkXPress 3.2 and 3.3 This section gives condensed instructions for using QuarkXPress 3.2 and 3.3 with the EFICOLOR color management system. For further instructions for using QuarkXPress with EFICOLOR, see Using the EFICOLOR XTension with QuarkXPress, included with QuarkXPress. In general, you should use the Adobe PostScript Printer Driver, although LaserWriter 8.0 and 7.1 are also supported.
Page 100 3-45 Application notes Setting QuarkXPress preferences Use the Preferences settings shown in this section to activate EFICOLOR color management. Application Preferences on the Edit menu For accurate display of TIFF images, choose 16 bit or 32 bit Click Display Correction and choose the proﬁle for your monitor...
Page 101 3-46 Application notes EFICOLOR Preferences on the Edit menu Click the checkboxes to activate all of these options Choose Calibrated RGB Choose SWOP-Coated or the Colorwriter proﬁle Default proﬁles selected for EFICOLOR preferences become source proﬁles for vector-based artwork that is either created in QuarkXPress or imported into QuarkXPress.
Page 102 3-47 Application notes Working with imported ﬁles The following ﬁle formats are supported by the EFICOLOR color management system, and are converted to print correctly on your Colorwriter: • TIFF • PICT • Scitex CT • EPS and DCS ﬁles created by Adobe Illustrator 5.5 and earlier, Adobe Photoshop 3.0 and earlier, and Aldus FreeHand 4.5 and earlier QuarkXPress sends only the low-resolution preview of placed DCS ﬁles to composite printers such as the Colorwriter.
Page 103 3-48 Application notes Importing TIFF and PICT ﬁles Assign a source proﬁle and color rendering style to TIFF and PICT image ﬁles in the Get Picture dialog box when you import them. Get Picture on the File menu Choose a source proﬁle for the image Choose a color rendering style for the image...
Page 104 3-49 Application notes Page Setup Refer to the following illustrations to select options in the Page Setup dialog box. Choose the Colorwriter LSR 2000.PDF ﬁle Choose an output paper size Choose Binary Contone printing: Enter 200 for the highest possible quality.
Page 105: Other Quickdraw Applications
3-50 Application notes Setting options when printing It is necessary to make selections in the Print Options dialog box only if you want to choose a printer-speciﬁc feature such as Paper Type. Click to display the Print Options dialog box Make sure Separation is off Choose Color/Grayscale Other QuickDraw applications...
Page 106 3-51 Application notes Be sure to read the application’s User Guide, as well the ReadMe ﬁle if one is included, for additional information about printing. Working with imported ﬁles Although your application may allow you to import a variety of ﬁle formats, we recommend using EPS format ﬁles for all raster images you want to import;...
Page 107 3-52 Application notes Selecting options when printing Refer to this section to select options in the Print and Print Options dialog boxes. To use a CRD when printing from your application, choose Calibrated Color/ Grayscale in Print Options. Click to display the Print Options dialog box IMPORTANT: Choose...
Page 108: Chapter 4: Printing From Pc-Compatible Computers
4-1 Printing from PC-compatible Computers The Colorwriter enables you to print from an IBM PC-compatible computer Chapter 4: connected to the Colorwriter over a network or directly to the parallel port. This Printing from chapter gives some tips on printing from PCs using Windows 3.x, Windows 95 or PC-compatible Windows NT, and includes the following topics: Computers...
Page 109: Printing To The Colorwriter From Windows
4-2 Printing to the Colorwriter from Windows Printing to the Colorwriter from Windows For information on setting up the Windows environment for printing with the Colorwriter, see Chapter 6 of Getting Started, which describes how to set up your network and enable a connection to the parallel port, IPX (Novell) networks, and TCP/IP networks.
Page 110: Conﬁguring Windows Printing Options
4-3 Conﬁguring Windows printing options Conﬁguring Windows printing options Printing options are conﬁgured by using the PostScript printer driver that corresponds to your particular system. The following table refers to the printer driver installation for each type of Windows operating system. Using: PostScript Driver: Installation...
Page 111 In the Main group of the program manager, double-click the Control Panel icon. In the Control Panel window, double-click the Printers icon. In the Printers dialog box, select the Colorwriter LSR 2000 v2015.108 in the Installed Printers box. Then click the Setup button.
Page 112 4-5 Conﬁguring Windows printing options Select the appropriate information for your ﬁle and click OK. Setting Match Color Across Printers activates the color rendering dictionaries. Click the Features tab to display the Features window, select the appropriate settings, and then click OK.
Page 113 4-6 Conﬁguring Windows printing options The options in this window are speciﬁc to the Colorwriter. The settings you select in the PostScript Options, Features, and Print Setup windows override the settings speciﬁed in Printer Setup on the Colorwriter. You can override the Brightness setting in the Colorwriter LSR Spooler Override Print Settings window.
Page 114 4-7 Conﬁguring Windows printing options Color rendering dictionaries are not used when CMYK ﬁles are sent to the Colorwriter, nor are they used when RGB ﬁles are sent using a PostScript Level 1 driver such as PSCRIPT.DRV for Windows 3.1 or the Windows NT PostScript printer driver.
Page 115 4-8 Conﬁguring Windows printing options Use the Print Setup dialog box to specify information about the printer setup such as the paper source, paper size, and paper orientation. Print Setup dialog boxes vary across applications. Click Options in the Print Setup dialog box. Do not use the Encapsulated PostScript File option when you are printing to the Colorwriter.
Page 116 4-9 Conﬁguring Windows printing options Click Advanced to set additional options. The Advanced Options dialog box appears. This dialog box allows you to set advanced printing options. You can use this dialog box to choose how to send TrueType fonts to the Colorwriter.
Page 117: Conﬁguring Printing Options On Windows 95
4-10 Conﬁguring Windows printing options Selecting Mirror prints a mirror image of the original. The Conform to Adobe Document Structuring Convention option should be off. Special effects created with some applications will not print if this option is selected. Click OK. When you have set the printing options, close all the dialog boxes.
Page 118 4-11 Conﬁguring Windows printing options The Colorwriter Properties window contains eight tabs that allow you to conﬁgure printing options. Specify the Paper source and the number of copies that you want printed. You may also use this tab to set orientation and layout options.
Page 119 4-12 Conﬁguring Windows printing options Choose the Device Options tab. The Device Options tab allows you to change the Color Mode, Rendering Style, Brightness, and settings for the Optional Cassette (if installed) of the Colorwriter. To change a setting, select the feature in the Printer features area, and then select one of the options in the “Change settings for”...
Page 120: Conﬁguring Printing Options On Windows Nt
4-13 Printing pages from the multipurpose tray Conﬁguring printing options on Windows NT The Windows NT PostScript printer driver that you install with the Colorwriter PPD does not give your applications access to all the paper and tray selection options and printer features that you get with the PostScript level 2 drivers you can install on Windows 3.1 or Windows 95.
Page 121 4-14 Printing pages from the multipurpose tray These options are available if you are using Windows 95 with the Microsoft PostScript driver (see “Conﬁguring Windows printing options” on page 4-3 or “Conﬁguring printing options on Windows 95” on page 4-10. Some applications provide these options in a different dialog box.
Page 122: Using Colorwriter Utilities
4-15 Using Colorwriter utilities Using Colorwriter utilities The Windows utilities enable you to perform additional functions with your Colorwriter. The following utilities are included on the Colorwriter User Software CD: • Colorwriter LSR Downloader • Colorwriter LSR Spooler • Colorwriter LSR Manager The Windows Colorwriter utilities are supported by the Windows 95 and the Windows NT operating systems, communicating with the printer with TCP/IP or IPX/SPX (Novell) network protocols.
Page 123 4-16 Using the Colorwriter LSR Downloader LSR D O VIEW STATUS INFORMATION WITH THE OLORWRITER OWNLOADER Choose Colorwriter LSR Downloader from the Windows 95 Start button or appropriate Windows NT program group. The Colorwriter LSR utilities function the same way on Windows 95, Windows NT, and Macintosh computers.
Page 124 You can click the Display Font List button or choose Font List from the File menu to view font information in the window. To select a different Colorwriter or Colorwriter connection, choose Open from the File menu, select the Colorwriter LSR 2000 in the chooser dialog that appears, and click OK.
Page 125: Printing With The Colorwriter Lsr Downloader
4-18 Using the Colorwriter LSR Downloader Printing with the Colorwriter LSR Downloader Printing PostScript ﬁles with Colorwriter LSR Downloader is fast—generally faster than printing from within applications. If you regularly print large ﬁles, be sure to try printing with the Colorwriter LSR Downloader. LSR D O DOWNLOAD A FILE OR FONT WITH THE OLORWRITER...
Page 126 4-19 Using the Colorwriter LSR Downloader Select the ﬁle type to display in the Show pop-up menu. You can leave this at the default All known formats, or select All Files. All known formats will list all ﬁles in formats supported by the Colorwriter LSR Downloader;...
Page 127: Downloading And Managing Printer Fonts
4-20 Using the Colorwriter LSR Downloader Some applications, including Adobe Photoshop, provide transfer functions that let you specify density settings for an image. If you saved a Photoshop ﬁle as EPS and included transfer functions, the Colorwriter LSR Downloader Brightness options will have no effect on your printout. For more information on using transfer functions, see the documentation for your application.
Page 128 To do this, follow the instructions from the font manufacturer. Downloading printer fonts to the Colorwriter LSR 2000 If your applications regularly use one or more fonts that are not already installed in the Colorwriter, you can save time by downloading them to the Colorwriter hard disk with the Colorwriter LSR Downloader.
Page 129 4-22 Using the Colorwriter LSR Downloader Colorwriter, the text in these fonts will not print correctly and may not print at all. With some applications, you can include fonts when you create PostScript ﬁles. See your application software for information. O VIEW FONT INFORMATION Choose Font List from the File menu or click the Font List button.
Page 130 4-23 Using the Colorwriter LSR Downloader The icons in the Font list window are: Update Click this icon to update the information in the font list window. Print Click this icon to print the font list. Font List Delete Select a font and click this icon to delete it. Click the Update button to update the information in the list.
Page 131: Using The Colorwriter Lsr Spooler
4-24 Using the Colorwriter LSR Spooler Using the Colorwriter LSR Spooler The Colorwriter LSR Spooler utility lets you monitor and manipulate the print jobs that you send to the Colorwriter. It also lets system administrators track and manage all users’ print jobs. Colorwriter LSR Spooler jobs can be in one of the following queues: Print Normal print jobs sent to the Colorwriter print queue appear...
Page 132 The Colorwriter LSR utilities function the same way on Windows 95, Windows NT, and Macintosh computers. Select the Colorwriter LSR 2000 in the window that appears, and click OK. The Colorwriter LSR Spooler main window and File, Edit, Window, Help, and...
Page 133 4-26 Using the Colorwriter LSR Spooler In the main window, the job list includes information about the document name, user name, time and date sent, print device, and ﬁle size. The job list is split into regions that correspond to the different queues and steps in the printing process.
Page 134 4-27 Using the Colorwriter LSR Spooler Icons also appear above the scroll list. The icons are: Update Click this icon to update the information in the Colorwriter LSR Spooler main window. Duplicate Drag a job onto this icon or select the document and and Print click this icon to move a duplicate of the job to the Print queue.
Page 135 To display information about a different Colorwriter, choose Open from the File menu. A selection window appears. Select the Colorwriter LSR 2000 in the selection window. The Colorwriter LSR Spooler main window appears and displays information about the Colorwriter you selected.
Page 136: Duplicating, Copying, Moving, And Deleting Jobs
4-29 Using the Colorwriter LSR Spooler Duplicating, copying, moving, and deleting jobs Users can always move, delete, and conﬁgure their own print jobs. If a password has been set, users can manipulate only their own print jobs; the Colorwriter system administrator (or anyone with Colorwriter LSR Spooler Password access) can move, delete, prioritize and conﬁgure jobs for all users.
Page 137 4-30 Using the Colorwriter LSR Spooler Click the Duplicate and Print icon, or drag the job to the Duplicate and Print icon. The job appears at the bottom of the Print queue. O COPY A JOB TO ANOTHER QUEUE Select the job that you want to copy by clicking its name. The selected job is highlighted.
Page 138: Changing Print Settings For A Job
4-31 Using the Colorwriter LSR Spooler For example, move a job that is currently in the Hold queue to the Print queue by dragging the job to the Print queue icon. O DELETE A JOB FROM ANY OF THE QUEUES Select the job that you want to delete by clicking its name.
Page 139: Using The Job Log
4-32 Using the Colorwriter LSR Spooler O CHANGE PRINT SETTINGS FOR A JOB Double-click a job or select the job and choose Override Print Settings from the Edit menu. The Override Print Settings window appears. Select the new settings. Select any of the options in the pop-up menus. If you select Default Settings, the job will use the settings in the Print dialog box.
Page 140 4-33 Using the Colorwriter LSR Spooler Specify the period for the job log in the dialog box that appears. Click All to view all jobs since the job log was cleared; click Date if you want to specify a period of time for the job log, and enter the dates you want. Click OK.
Page 141 4-34 Using the Colorwriter LSR Spooler The text in the Status column provides information about the job: The job was printed normally. ERROR A PostScript error occurred while a job was processing. You can double-click ERROR to display the error message. A dialog box displays the PostScript error.
Page 142 4-35 Using the Colorwriter LSR Spooler O USE ADMINISTRATOR FUNCTIONS Choose Password from the Administrator menu. This menu is active only if a password was created on the Colorwriter. Enter the password in the window that appears. This password is set in the Setup on the control panel. Once it is set, only persons with the password can move, override, prioritize and delete all users’...
Page 143: Using The Colorwriter Lsr Manager
4-36 Using the Colorwriter LSR Manager Using the Colorwriter LSR Manager The Colorwriter LSR Manager conﬁgures a special network layer that allows the Colorwriter LSR Spooler and the Colorwriter LSR Downloader to communicate with the printer over IPX or TCP/IP networks. The Colorwriter LSR Manager application runs on Windows 95 and Windows NT systems.
Page 144: Application Notes
4-37 Application notes Application notes This section provides special instructions for optimizing color output with the following applications: • Aldus PageMaker 5.0 for Windows 3.1 • Adobe Photoshop 2.5 and 3.0 for Windows 3.1 • CorelDRAW 5.0 for Windows 3.1 •...
Page 145 4-38 Application notes Page setup Choose options in the Page setup dialog when you begin creating the PageMaker document. Refer to the illustration below for settings applicable to the Colorwriter. Choose the Colorwriter here Choose 600 from the pop-up menu Choosing ﬁll and line colors You can create ﬁll and line colors using the process (CMYK), RGB, or HSB color model, or choose a named color using one of the four color matching systems...
Page 146 4-39 Application notes Selecting options when printing Refer to this section to select options in the Print dialog box. You cannot access Adobe PostScript Printer Driver options from PageMaker 5.0. Settings made for Adobe PostScript Printer Driver options from the Windows Control Panel have no effect. Choose the Colorwriter from both menus Click these buttons...
Page 147: Adobe Photoshop 2.5 And 3.0 For Windows 3.1
4-40 Application notes Click Optimized Click Composite Click Color Adobe Photoshop 2.5 and 3.0 for Windows 3.1 This section explains how to print from Photoshop using the Colorwriter’s built- in CRDs. This way of printing is convenient and fast, and is ideal when the Colorwriter is the ﬁnal printing device.
Page 148 4-41 Application notes color conversions that involve RGB data should start with a EFICOLOR standardized RGB color space. This is provided by the Calibrated RGB ﬁle, which is loaded into Photoshop’s Monitor Setup. Loading Calibrated RGB monitor settings Calibrated RGB monitor settings ensure consistent results. You need to load the settings ﬁle only once.
Page 149 4-42 Application notes Selecting options when printing Consult the following illustrations when selecting options in the Page Setup and Print dialog boxes. Note that you must select Print as RGB in the Print dialog box to use the Colorwriter’s built-in CRDs. If necessary, click Options to access Choose the Colorwriter...
Page 150 4-43 Application notes • You want to choose a feature such as Paper Type. You can access Adobe PostScript Printer Driver options in Photoshop by clicking the Options button in the Page Setup dialog box. Exporting image ﬁles to other applications Photoshop is a PostScript Level 2 application.
Page 151: Coreldraw 5.0 For Windows 3.1
4-44 Application notes CorelDRAW 5.0 for Windows 3.1 The Color Manager The Color Manager is a color management system that is integrated into CorelDRAW and other Corel applications. Because the Color Manager does not include proﬁles for the Colorwriter, this section suggests other ways to get predictable results when printing to the Colorwriter from CorelDRAW.
Page 152: Microsoft Powerpoint 4.0 For Windows 3.1
4-45 Application notes Selecting options when printing Refer to this section to select options in the Print dialog box. To set Adobe PostScript Printer Driver options, choose the Setup button To set CorelDRAW print options, choose the Choose the Colorwriter Options button NOTE: Do not select this option unless you are using...
Page 153 4-46 Application notes If you use one of the templates for color slides, you must change the Slide Setup for printing with the Colorwriter. Choose Slide Setup from the File menu, enter the appropriate page size, and click OK to apply the changes. Working with imported ﬁles In addition to the clip art included with PowerPoint, images from other applications in many formats can be imported.
Page 154 4-47 Application notes Select the Colorwriter It is possible to have multiple instances of the Colorwriter driver installed on your PC. Each driver may have different connections or setup preferences. However, installing the Adobe driver and the Microsoft driver on the same system for the same printer may produce unpredictable results.
Page 155: Chapter 5: Printing From Unix Workstations
5-1 Printing to the Colorwriter from UNIX Workstations This chapter provides information about printing to the Colorwriter directly from Chapter 5: UNIX. Although Colorwriter utilities are not available on UNIX workstations, Printing jobs printed to the Colorwriter are sent to the Print queue and can be from UNIX manipulated from Macintosh and PC computers on the network.
Page 156 5-2 Printing to the Colorwriter from UNIX Workstations For example, if your Colorwriter queue is named colorwriterq , your ﬁle is named Sample , and you want to print two copies, you would type: lpr -P colorwriterq -#2 Sample • On a UNIX system running Solaris 2, use the lp command to send a job to the Colorwriter.
Page 157: Chapter 6: Printing From Openvms Systems
6-1 Printing from DCPS to the Colorwriter This chapter provides information about printing to the Colorwriter from Chapter 6: DECprint Supervisor for OpenVMS (DCPS) on VMS systems. DCPS (version Printing 1.3) is the print client used on OpenVMS systems. from OpenVMS Systems Printing from DCPS to the Colorwriter To print to the Colorwriter from OpenVMS, DCPS must be installed on the...
Page 158 6-2 Printing from DCPS to the Colorwriter Stop/Queue/Next Stop/Queue/Requeue Stop/Queue/Reset Stop/Queues/On_Node Commands to enter and manage print jobs: Delete/Entry Print Set Entry Show Entry Stop/Queue/Entry...
Page 159: Chapter 7: Administering Print Jobs Over The Netware Print Server
7-1 Monitoring queued print jobs The Colorwriter LSR 2000 with the Professional Color Kit (PCK) option Chapter 7: installed supports simultaneous connections to three different Novell NetWare Administering print servers. This chapter contains information on: Print Jobs over • Monitoring queued print jobs...
Page 160: Printing A Postscript File
7-2 Printing a PostScript ﬁle From the list you can: • Delete jobs Use the arrow keys to highlight one or more jobs and Press Del to delete the job from the queue. Queue operators can delete any job; queue users can delete only their own jobs.
Page 161 7-3 Printing a PostScript ﬁle IPX (N O PRINT A CRIPT FILE OVER OVELL NETWORKS Set up the server and the Colorwriter as described in Chapter 5 of Getting Started. On your workstation, at the NetWare MS-DOS prompt, type PCONSOLE. You do not need Supervisor privileges to print a PostScript ﬁle.
Page 162: Using Appletalk With Macintosh Computers On An Ipx (Novell) Network
7-4 Using AppleTalk with Macintosh computers on an IPX (Novell) network Using AppleTalk with Macintosh computers on an IPX (Novell) network Macintosh users on an IPX network can print to the Colorwriter: • Directly, using AppleTalk and bypassing the NetWare server •...
Page 163: Appendix A: Error And Warning Messages
A-1 Printer control panel error messages When an error interferes with printing, you will see a message on the printer Appendix A: control panel. Only two messages are displayed at a time on the printer control Error and panel (one warning message and one error message) even when more than one of Warning each error condition is present.
Page 164 A-2 Printer control panel error messages Message Corrective action/additional information LOAD ___ TRANS. The printer’s multipurpose tray is not loaded with the IN MP TRAY transparency size speciﬁed. The printer will resume printing when the multipurpose tray is loaded with the required transparency.
Page 165: Printer Control Panel Warnings
The printer continues to print while the warnings are displayed. Message Explanation DISK FULL The Colorwriter LSR 2000 hard disk is full. Allow pending jobs to ﬁnish printing before sending any new jobs. If this problem occurs often, consider deleting jobs in the Hold queue and Printed queue, and deleting fonts that were downloaded to the printer.
Page 166: Startup Diagnostic Error Service Calls
A-4 Startup diagnostic error service calls Startup diagnostic error service calls Startup diagnostic tests are performed on the printer controller board every time the Colorwriter LSR 2000 is powered up. Diagnostic test names are displayed brieﬂy, followed by the message DIAGS PASSED .
Page 167 A-5 Printer control panel service calls Message Explanation CALL FOR SERVICE A5 Fixing unit failure (unknown) NOTE #A5 CALL FOR SERVICE A6 Fixing unit failure (heater cut off ) NOTE #A6 CALL FOR SERVICE B1 BD failure NOTE #B1 CALL FOR SERVICE B2 Laser failure NOTE #B2 CALL FOR SERVICE...
Page 168 A-6 Printer control panel service calls Message Explanation CALL FOR SERVICE F3 DC controller failure (thermal/humidity unit) NOTE #F3 CALL FOR SERVICE F4 DC controller failure (abnormal density sensor) NOTE #F4 CALL FOR SERVICE F5 DC controller failure (print engine) NOTE #F5 CALL FOR SERVICE F6 DC controller failure (abnormal IC)
Page 169: Appendix B: Setup Menus
B-1 Setup Menus This appendix reproduces the Help Map, which provides information about Appendix B: Setup menus and options, and also summarizes the status screens and pages you Setup Menus can print from the printer control panel. To print out a full-size version of the Help Map from the printer control panel: •...
Page 170 B-2 Setup Menus H IGH P E R FORM A N C E NE TWOR K COLO R P R I N TE R READY 292MB Colorwriter LSR PRESS MENU TESTING: LOADING READY 292MB FOR SETUP TESTNAME SYSTEM… Colorwriter LSR SELECT FUNCTION RUN SETUP...
Page 171 B-3 Setup Menus H IGH P E R FORM A N C E NE TWOR K COLO R P R I N TE R READY 292MB Colorwriter LSR PRESS MENU TESTING: LOADING READY 292MB FOR SETUP SYSTEM… TESTNAME Colorwriter LSR SELECT FUNCTION RUN SETUP...
Page 172 B-4 Setup Menus NETWORK SETUP SYSTEM SETUP PRINTER SETUP PRINTER NAME ENABLE DIRECT Q ENABLE APPLETALK DATE (MM/DD/YY) ENABLE PRINT Q APPLETALK ZONE SYSTEM TIME ENABLE HOLD Q ENABLE IPX IPX FRAME TYPE PRINT START PAGE ENABLE PRINTED ENABLE TCP/IP IPX SETTINGS PRINT TO PSERROR JOBS TO SAVE...
Page 173: Appendix C: Maintenance
C-1 Identifying the parts of the printer This appendix provides a diagram identifying the parts of the printer and contains Appendix C: maintenance information about: Maintenance • Cleaning and handling the printer • Storing and handling toner cartridges • Replacing a toner cartridge •...
Page 174 C-2 Identifying the parts of the printer 22 Separation corona unit (exposed when top cover is lifted up) Optional paper feeder unit’s right door (open to remove jammed paper) 1 Top cover (open) For access to the transfer drum to remove jammed paper or for replacing the separation corona unit.
Page 175 C-3 Identifying the parts of the printer 4 Release knobs Open the ﬁxing assembly cover and the feeder unit cover for troubleshooting or maintenance. 5 Face-up tray (open) When opened, the face-up tray holds printouts when they come out facing up.
Page 176 C-4 Identifying the parts of the printer 14 Paper width selector Sets the width of the paper loaded. 15 Paper cassette (universal type) for the paper feeder unit (optional) Holds about 250 sheets of Letter-, A4-, Legal-, or B5-size paper at 20 lb (80 g/m 16 Paper size indicator As your reminder, slide the knob to the position corresponding to the paper...
Page 177: Cleaning And Handling The Printer
C-5 Cleaning and handling the printer Cleaning and handling the printer Regular cleaning and careful handling of the printer keep the printer in the best condition and maintain optimal print quality. Cleaning the cabinet Use a soft cloth slightly moistened with water or a mild detergent solution. Avoid using any solvents, such as alcohol, benzine, or any spray, which might damage the ﬁnish.
Page 178: Using The Wire Cleaner
C-6 Cleaning and handling the printer Using the wire cleaner The wire cleaner is oblong, each end is used to clean a different part. Use the padded end to clean the separation corona wire, and use the brush end to clean the window of the density detection sensor.
Page 179 C-7 Cleaning and handling the printer Remove the wire cleaner from inside the printer. Place the padded end of the wire cleaner on the separation corona unit. Clean the separation corona wire by moving the wire cleaner from side to side several times.
Page 180: Cleaning The Window Of The Density Detection Sensor
C-8 Cleaning and handling the printer After cleaning, replace the cleaner in its storage place and close the top cover and the front door. Then, turn on the printer to resume printing. Cleaning the window of the density detection sensor When there is a density detection error or if the window is soiled with toner residue or dust, clean the window with the brush end of the wire cleaner.
Page 181 C-9 Cleaning and handling the printer Place the brush end of the wire cleaner on the window surface as shown. Clean the surface with the brush and remove any dirt. After cleaning, replace the cleaner in its storage place and close the top cover and the front door.
Page 182: Handling The Colorwriter
C-10 Cleaning and handling the printer Handling the Colorwriter Avoid spraying cleaning solution directly onto the printer’s exterior, as the spray could penetrate into the ventilation slots and damage the internal circuits. This printer is a precision machine. Handle it with care. •...
Page 183 C-11 Cleaning and handling the printer • Do not put anything on the printer. The printer weighs 110 lb (about 50 kg). It should always be moved by two or more persons. Do not attempt to move it by yourself. For more information, see page C-34.
Page 184 C-12 Cleaning and handling the printer • Do not cover the printer right after you have ﬁnished using it. Turn off the printer and wait until it cools down. CAUTION! HOT SURFACE. AVOID CONTACT ACHTUNG HEISS ATTENTION! TEMPERATURE ELEVEE PRECAUTION! / ATTENZIONE! ALTA TEMPERATURA Do not close the front door abruptly, or expose the printer to any vibration.
Page 185 C-13 Cleaning and handling the printer Do not attempt to disassemble the printer. To avoid light and dust, do not leave the front door open unnecessarily. Avoid bright sunlight to protect the photosensitive drum from damage. Avoid magnetic ﬁelds.
Page 186 C-14 Cleaning and handling the printer Do not lubricate the printer. Do not tilt the printer.
Page 187: Storing And Handling Toner Cartridges
• Do not attempt to disassemble the cartridges. • Use of only Digital toner cartridges is recommended. (See information on ordering supplies on page F-1.) • The printer uses the rectangular, transparent windows at the top and bottom of a toner cartridge to detect the toner level.
Page 188: Replacing A Toner Cartridge
C-16 Replacing a toner cartridge Replacing a toner cartridge Each toner cartridge prints about 4,000 sheets of Letter- or A4-size paper, when toner coverage of the toner cartridge on the paper is at 4.5% dot ratio. This, however, does not mean all four of the toner cartridges will run out at the same time.
Page 189 C-17 Replacing a toner cartridge While pressing the rotary knob , turn it in the direction of the arrow until the markers for the color indicated by the message on the status panel appear on the rotary. When this is done, the rotary knob pops out and is locked . Make sure the rotary knob is locked and the two color markers are fully visible.
Page 190 C-18 Replacing a toner cartridge While holding the cartridge with one hand, slide it out as shown. Hold the cartridge with one hand from the end with the opening seal, insert it into the protective bag of the new cartridge and dispose of it. We recommend holding the used toner cartridge from the end with the opening seal to avoid getting your hands dirty.
Page 191 C-19 Replacing a toner cartridge Remove the two protective tapes. Place the toner cartridge on a ﬂat surface, then pull the sealing tape completely out in the indicated direction. The tape may break if not pulled out in this direction. Do not pull the sealing tape diagonally, as it may snap.
Page 192 C-20 Replacing a toner cartridge Hold the cartridge with the arrow label facing up, then slide it completely into the rotary until it snaps into place. Avoid touching the windows on the top and bottom of the cartridge. Color markers Insert the toner cartridge all the way into the printer.
Page 193: Tips For Replacing The Toner Cartridge
C-21 Replacing a toner cartridge Tips for replacing the toner cartridge Be sure to observe the following when changing the toner cartridge: • This printer uses four color toner cartridges: cyan, magenta, yellow, and black. Each color cartridge has its own holder in the printer’s rotary. When loading a toner cartridge, make sure its color matches the color markers on the printer.
Page 194: Replacing The Silicone Oil Bottle
C-22 Replacing the silicone oil bottle Replacing the silicone oil bottle Silicone oil is used in the ﬁnal ﬁxing process before the paper comes out of the printer. To prevent toner offset caused by toner on the ﬁxing rollers, the upper roller remains in contact with the cleaning belt saturated with silicone oil supplied from the silicone oil bottle.
Page 195 C-23 Replacing the silicone oil bottle Peel off the seal from the new silicone oil bottle and put it on the old bottle. Do not shake the bottle or the oil may spill out. Insert the new bottle into the compartment with the label facing towards you and the spout on the right and facing down.
Page 196 C-24 Replacing the silicone oil bottle Close the cover completely. Then, close the front door. The oil is very slippery, and may present a skidding or slipping hazard. Following a spill or leak, use absorbent material to contain and collect excess oil for salvage or disposal.
Page 197: Using The Drum Cartridge Kit
C-25 Using the drum cartridge kit Using the drum cartridge kit A message displayed on the printer control panel indicates that the drum cartridge needs replacing. When black vertical streaks or toner spots appear on the printouts after the message appears, replace the drum cartridge immediately, following the procedure below.
Page 198 C-26 Using the drum cartridge kit Push down the release handle to unlock the waste toner bottle and the drum cartridge. Push the handle on the drum cartridge door in the direction of the arrow to open the door fully. Pull out the waste toner bottle.
Page 199 C-27 Using the drum cartridge kit Remove the sealing cap provided and plug it into the opening on the used waste toner bottle to cap it immediately. While pressing the green tab on the right side of the drum, pull out the drum cartridge.
Page 200 C-28 Using the drum cartridge kit Remove the new drum cartridge from its protective bag. Do not open the protective bag or drum cartridge cover until you are ready to install it into the printer. Do not expose the drum cartridge to direct sunlight. Direct the end with the mark towards the printer and insert the drum cartridge cover into the V-shaped opening, as shown.
Page 201 C-29 Using the drum cartridge kit While holding the cover with one hand and the cartridge horizontally, place the drum on the rails of the compartment and gently slide the drum in. When the drum cartridge is completely inside the printer, remove the cover. Save the drum cartridge cover for future use to cover a used photosensitive drum.
Page 202 C-30 Using the drum cartridge kit With the opening facing the printer, attach the new waste toner bottle to the printer. Close the drum cartridge door. Make sure the drum cartridge is fully inserted into the printer before closing the door. Push up the release handle to lock the drum cartridge.
Page 203 C-31 Using the drum cartridge kit O CLEAN THE SEPARATION CORONA WIRE Open the top cover to reveal the separation corona unit and the wire cleaner. Remove the wire cleaner from inside the printer. Place the wire cleaner on the separation corona unit.
Page 204 C-32 Using the drum cartridge kit Clean the separation corona wire by moving the wire cleaner from side to side several times. The separation corona wire is very thin and delicate, so take care not to break it. After cleaning, replace the brush in its original place and close the top cover.
Page 205 C-33 Using the drum cartridge kit Close the front door. This completes the replacement of the drum cartridge and the waste toner bottle, as well as the cleaning of the separation corona wire. Turn on the power again. If you cannot push up the release handle completely, do not continue by force or the printer may be damaged.
Page 206: Moving The Printer
C-34 Moving the printer Moving the printer Before moving the printer, follow these guidelines: • Open the photosensitive drum door and remove the waste toner bottle. • Drop the transfer drum lever and remove the drum cartridge. Store the drum cartridge in the drum cover.
Page 207 C-35 Moving the printer O REMOVE THE SILICONE OIL Make sure the power switch is off, then open the front door. Open the stopper completely and lift out the silicone oil bottle from the holder Be careful as oil may drip from the bottle. Store it on a ﬂat level surface, away from direct sunlight.
Page 208 C-36 Moving the printer Uncap the oil recycle bottle and remove the inner cap. Place the bottle on a ﬂat, level surface, away from direct sunlight. Pump the oil from the holder with the oil pump and transfer it to the recycle bottle.
Page 209 C-37 Moving the printer Then push down the jam release lever about 50 times to guide the silicone oil from the ﬁxing assembly into the holder. About 40 cc of oil may be contained in the ﬁxing assembly. The ﬁxing assembly and the delivery areas may be hot. Be careful when using the lever.
Page 210 C-38 Moving the printer After moving the printer, replace the silicone oil into the printer. To do this, open the front door, then open the stopper completely . Uncap the recycle bottle and slowly pour the oil back into the holder . Finally, replace the silicone oil bottle into the holder , then close the stopper and front door securely.
Page 211: Appendix D: Troubleshooting
The printer contains high-voltage parts which may cause electric shock when touched. Turn off the printer and unplug it from the AC outlet. Then call your authorized warranty service provider or a qualiﬁed Digital Multivendor Customer Services engineer. See Appendix H for more details.
Page 212: Initialization Problems
D-2 Initialization problems Does the printer’s voltage rating match that of the AC outlet? • Check the voltage of the printer as well as the AC outlet. Initialization problems Is the printer level (at less than a 1% angle)? • If the printer is not level the error message REPLACE FIXING UNIT PUMP is displayed.
Page 213: Print Quality And Paper Problems
D-3 Print quality and paper problems Print quality and paper problems Is the correct paper type used? • See “Paper requirements” on page E-3 and check the paper type. Are toner cartridges inserted in the correct order? • See “Replacing a toner cartridge” on page C-16 and make sure the toner cartridges are installed in the correct order.
Page 214: Paper Jams
D-4 Paper jams Paper jams There are three possible paper jam locations: the feeder area, the print and transfer area, and the output area. Output area Print and transfer area Feeder area Optional paper feeder unit If a paper jam occurs, follow the instructions described in the following pages to remove the jammed paper in a way appropriate to the actual jam site on the printer.
Page 215 D-5 Paper jams HECKING THE FEEDER AREA Make sure the multipurpose tray is closed. Push up the release knob to open the feeder door. Remove the jammed paper if you can ﬁnd it.
Page 216 D-6 Paper jams If the jammed paper is not visible or if it is difﬁcult to remove, pull the two green levers and slide out the entire feeder unit. Carefully remove the jammed paper in the likely spots as indicated. Push the levers to slide the feeder unit back into the printer.
Page 217: When Using The Optional Paper Feeder Unit
D-7 Paper jams Close the feeder door. When using the optional paper feeder unit Pull the tab to open the optional cassette feeder door. Carefully remove the jammed paper.
Page 218: Checking The Transfer Drum Area
D-8 Paper jams Close the door and resume printing. Checking the transfer drum area Even if the trailing edge of the jammed paper is visible over the transfer drum, avoid pulling it out from the top cover side. The toner is not ﬁxed onto the paper and falls off to scatter inside the printer.
Page 219 D-9 Paper jams Use the tab identiﬁed in step 1 to raise the top cover. Avoid touching the window of the density detection sensor, which is used to adjust the grayscale. Push down the handle to unlock the transfer drum. Turn the transfer drum knob in the direction of the arrow until the top edge of the paper is visible...
Page 220 D-10 Paper jams Release the top edge of the paper by gently pulling a corner of the paper. Be careful not to stain the density detection sensor with the non-ﬁxed toner. Remove the jammed paper by pulling at a slight angle. Do not touch the print on the paper.
Page 221 D-11 Paper jams Close the front door and resume printing.
Page 222: Checking The Fixing Assembly Area
D-12 Paper jams Checking the ﬁxing assembly area The ﬁxing assembly and delivery areas may be hot. Wait until the printer has completely cooled off. Be careful when accessing the knobs and lever. CAUTION! HOT SURFACE. AVOID CONTACT ACHTUNG HEISS ATTENTION! TEMPERATURE ELEVEE PRECAUTION! / ATTENZIONE! ALTA TEMPERATURA...
Page 223 D-13 Paper jams If the leading edge of the paper is visible, follow the procedure below to remove the jammed paper. Pull the release knobs and open the guide cover. While repeatedly pushing down and releasing the lever, remove the jammed paper completely from the printer.
Page 224 D-14 Paper jams First, open the guide cover , then move the lever up and down until the trailing edge of the jammed paper is visible To pull out the paper, hold and slide the release lever as shown to unlock both ﬁxing rollers .
Page 225 D-15 Paper jams Slowly pull out the jammed paper from the printer while holding the printer with your hand. Before pulling out the trailing edge of the paper, make sure the guide cover has been opened. Finally, set the lever back to its original position, and close the guide cover ( , If you get silicone oil on your hands while removing the jammed paper, wash them with a mild detergent.
Page 226: Correcting Abnormal Printouts
D-16 Correcting abnormal printouts Correcting abnormal printouts If abnormal images similar to the following examples are printed, follow the procedures below to correct them. Example 1 O CORRECT EXAMPLE While pressing the COLOR SELECT button on the density control panel (on the back of the printer), press ENTER three times.
Page 227 D-17 Correcting abnormal printouts Use the +/- buttons to move the level indicator to the position shown, then press the ENTER button to set the separation high voltage ON. COLOR DEFAULT ENTER SELECT Print out the page again and check the results. If the abnormal printout no longer occurs, reset to the default setting.
Page 228 D-18 Correcting abnormal printouts Use the +/- buttons to move the level indicator to the position shown, then press the ENTER button to set the separation high voltage OFF. COLOR DEFAULT ENTER SELECT Print out the page again and check the results. If the abnormal printout no longer occurs, reset to the default setting.
Page 229: Appendix E: Speciﬁcations
E-1 Colorwriter speciﬁcationss This appendix contains speciﬁcations for the Colorwriter LSR 2000 and the Appendix E: kinds of paper you can use in it. Speciﬁcations Colorwriter speciﬁcations Category Speciﬁcation Printer type: Desktop color page printer Printing method: Electrophotographic process via laser beam scanning...
Page 230 E-2 Colorwriter speciﬁcations Category Speciﬁcation Paper feed: Via cassette: Maximum stacking height: 25 mm (approximately 250 sheets of plain paper at 20 lb (80g/m ) or 150 sheets at 24 lb (90 g/m Via MP tray: Maximum stacking height: 10 mm (approximately 100 sheets of plain paper at 20 lb (80 g/m ) or 50 sheets at 24 lb (90 g/m (transparency ﬁlm must use MP tray feed;...
Page 231: Paper Requirements
E-3 Paper requirements Paper requirements Using the correct paper ensures good print quality, prevents paper jams, and extends the printer life. Loading Paper Size Weight/Delivery Capacity Cassette Plain Any size from 216 x 16 to 24 lb (61 to Up to a 25-mm stack 356 mm to 184 x height (about 250 90 g/m...
Page 232: Unacceptable Paper
E-4 Paper requirements Unacceptable paper Avoid using the following types of paper: • Too thick or too thin • Wet paper • Highly textured or rough paper • Curled, creased, or damaged paper • Non-rectangular paper (such as aerograms) • Paper with cutouts or perforations •...
Page 233: Effective Printing Area
E-5 Effective printing area Effective printing area The shaded area in the ﬁgure below indicates the printable area on a sheet of paper. Paper Size Border Width (mm) Letter, A4, Legal, and B5 10.0...
Page 234: Appendix F: Ordering Accessories And Supplies
For high quality and reliability, use genuine Digital accessories and supplies.This Appendix F: appendix lists the accessories and supplies available for the Colorwriter. Contact Ordering your local authorized Digital reseller or Digital sales ofﬁce for more information. Accessories In North America, call 1-800-DIGITAL (1-800-344-4825). and Supplies...
Page 235: Optional Paper Cassette
F-2 Upgrade kits Optional paper cassette You can purchase a universal paper cassette (LNC1X-TB) which can hold any size from 216 x 356 mm to 184 x 267 mm, including Letter, A4, Legal, and B5 paper. You can load only plain paper from 16- to 24-lb (61 to 90 g/m ) into a paper cassette, and the maximum capacity is about 250 sheets at 20 lb (80 g/m Optional cassette...
Page 236: Ordering Consumables
You will want to keep a supply of the following consumables on hand—especially if your site has more than one printer in service. For high quality and reliability, use genuine Digital supplies and accessories. Toner cartridges Use of the genuine toner cartridges designed for this printer is recommended.
Page 237: Silicone Oil
F-4 Ordering consumables Silicone oil Silicone oil is used in the ﬁnal ﬁxing process before the paper comes out of the printer. To prevent toner offset caused by toner on the ﬁxing rollers, the upper roller remains in contact with the cleaning belt impregnated with silicone oil supplied from the silicone oil bottle (LNC1X-AF).
Page 238: Drum Cartridge Kit
F-5 Ordering consumables Drum cartridge kit Each drum cartridge kit (LNC1X-AE) contains a drum cartridge and two waste toner bottles. When you replace the drum cartridge, be sure to always replace the waste toner bottle as well. You will probably need to replace the drum cartridge after about 5,000 to 30,000 pages, based upon the use of color per page.
Page 239: Transparency Film
F-6 Ordering consumables Transparency ﬁlm For optimum printing results, use only the transparency ﬁlm speciﬁcally for the Colorwriter LSR 2000 . Under no circumstances should this type of transparency be used with other laser printers In addition, remember to feed transparency ﬁlm via the multipurpose tray only.
Page 240: Appendix G: Ordering Related Documentation
• Release Notes • Registration Card • Warranty Card The order number for the Colorwriter LSR 2000 Document Package is EK-LCPLE-DK. In addition to the speciﬁc Colorwriter LSR 2000 documentation listed above, the following documents provide general PostScript language information: •...
Page 241: Electronic Orders
800-234-1998, using a modem set to 2400- or 9600-baud. You must be using a VT terminal or terminal emulator set at 8 bits, no parity. If you need assistance using the Electronic Store, call 800-DIGITAL (800-344-4825) and ask for an Electronic Store specialist.
Page 242 G-3 Telephone and direct mail orders For internal orders: Call Write DTN: 264-4446 U.S. Software Supply Business Internal Orders (603) 884-4446 Digital Equipment Corporation (for software 10 Cotton Road documentation) Nashua, NH 03063-1260 Internal Orders DTN: 264-4446 U.S. Software Supply Business...
Page 243: Appendix H: Obtaining Service
• Software driver problem. • Hardware problem, such as print quality. If you cannot correct a problem with the Colorwriter LSR 2000 printer, request servicing from your authorized warranty service provider or a qualiﬁed Digital Multivendor Customer Services engineer. Questions to ask before calling the service center To ensure the best possible service, read the following series of questions and answers before you call the Digital service center.
Page 244 H-2 Questions to ask before calling the service center What does the service center need to know? Write down the serial and model numbers located on the label at the rear of the printer. How should you describe the problem? Summarize the problem.
Page 245: Glossary
Glossary Glossary additive color model calibration A system in which color is produced by The process of ensuring that a device combining primary lights additively. The behaves consistently with respect to a set additive primaries are red, green, and of speciﬁcations. blue.
Page 246 The process whereby EFICOLOR color applied to. management software compresses— composite printer “maps”—the colors in a digital image to Any printer that can print directly in ﬁt the color gamut of a particular device. color without ﬁrst creating color separa- tions.
Page 247 G-3 Glossary moiré Level 2 includes many enhancements to An undesirable pattern in images made older versions of PostScript, including using halftone screens. Moiré can be improved color matching and the ability caused by improper screen angles, to control printer-speciﬁc features from improper alignment of halftone screens, applications.
Page 248 A proﬁle used by EFICOLOR to deter- mine the context for the color values SWOP speciﬁed in a digital image. The abbreviation for Speciﬁcations for Web Offset Publications. A standard of spot color speciﬁcations for separations, proofs, and...
Page 249 Index transfer functions 3-12, 4-20 using CRDs with 1-10 activity lights 2-2 Adobe PostScript Printer Driver 1-9, additive color model 1-3 3-36, 3-50, 4-37, 4-39, 4-42, 4-45 additive primaries 1-3 Windows 4-3 adjusting Adobe PostScript Printer Driver 8.x color density 2-7 to 2-8 Macintosh 3-1 paper guides 2-21 to 2-22 ADOBEPS.DRV 4-3, 4-4...
Page 250 I-2 Index choosing Multipurpose tray option 3-3 backspacing cursor in printer control CIE chromaticity diagram 1-2, 1-3 panel 2-3 CIE color model 1-2 banding, and Solid Color rendering 1-10 cleaning bitmapped images corona wire C-6 to C-8, C-31 to optimizing 3-4 C-33 Black LED, on density control panel 2-6 density detection sensor window C-8...
Page 251 I-3 Index color documents Monitor 1-10 specifying color mode in Print dialog Photographic 1-10 Presentation Graphics 1-10 box 3-4 Color/Grayscale option 3-3 Solid Color 1-10 color image data colors (saturated) translating to CMYK 1-9 to 1-12 optimizing 3-4 color management 1-8 to 1-12 Color Select button, on density control panel 2-6 Color Mode option 3-4, 4-6...
Page 252 I-4 Index conversion densitometer 1-8 RGB image data to CMYK 1-5 density customizing 2-7 to 2-8 copying jobs in Colorwriter LSR Spooler 3-23, 4-30 density control panel CorelDRAW using 2-6 to 2-9 application note (Windows) 4-44 to density detection sensor window 4-45 cleaning C-8 to C-9 choosing ﬁll and line colors 4-44...
Page 253 I-5 Index Enable Direct setup option 1-8, 3-2, fonts 4-15, 4-24, 7-1 downloading from Macintosh 3-13 enabling access by users 1-8, 3-2, enabling/disabling connecting to printer 1-8, 3-2, 4-15, 4-15, 4-24, 7-1 4-24, 7-1 See also screen fonts Encapsulated PostScript File option 4-8 FreeHand.
Page 254 I-6 Index improving line colors print quality C-5 to C-14 in Adobe Illustrator 3-29 liquid crystal display. See LCD incrementing characters on printer control panel 2-3 loading inhalation slot xvii paper 2-15 to 2-17 Initializing, status message on printer transparency ﬁlm 2-12, 2-13 control panel 2-4 location choosing for printer xvi...
Page 255 I-7 Index Menu button 2-3 using 3-6, 3-6, 4-13 to 4-14 menu entry, displaying next/previous 2-3 using for transparency ﬁlm 2-12, 2-13 messages error, displayed on printer control multipurpose tray activity light 2-2 panel 2-5 Multipurpose tray option status, on printer control panel 2-4 choosing 3-3 metamerism 1-2 Microsoft PowerPoint...
Page 256 I-8 Index ordering multipurpose tray activity light 2-2 documentation G-2 optional cassette 2-10 optional paper feeder unit 2-10, F-1 related documentation G-1 to G-3 supplies F-1 to F-6 to F-2 out-of-gamut RGB colors, printing 1-10 printer control panel activity output lights 2-2 matching to color monitors 1-9 to print side 2-15...
Page 257 I-9 Index password, entering in Colorwriter LSR Presentation Graphics rendering Spooler 3-28, 4-35 style 1-10 Presentation rendering style 3-4, 4-6 PCONSOLE 7-1 PDF ﬁle, for QuarkXPress 3-44 presentations Persuasion. See Adobe Persuasion color rendering style appropriate phosphors, in monitors 1-3 for 1-10 photographed images optimizing 3-4...
Page 258 I-10 Index printer queues. See also Hold queue; Print suspend/resume 2-3 queue; Printed queue test patterns 2-8 to 2-9 to disk 4-2 printers available, viewing 3-1 transparency ﬁlm 2-12 Printer’s Default setting 3-4, 4-6 using PostScript Level 1 printer Printers dialog box, Windows 4-7 drivers 3-5 printer setup printing (color)
Page 259 I-11 Index prints queues toner cartridge lifespan C-16 See also Hold queue; Print queue; Printed queue Print Setup dialog box, Windows 4-8 print side of paper 2-15 viewing lpd jobs 5-2 print speed xiii viewing NetWare jobs 7-1 prism 1-1 QuickDraw applications 3-50, 3-52 problems quick reference card xv...
Page 260 I-12 Index resume/suspend printing button 2-3 ‘showpage’ after EPS ﬁles option 3-12, RGB color blends, printing 1-10 4-20 silicone oil F-4 RGB color model conversion of image data to leakage C-34 CMYK 1-5, 1-9 to 1-12 precautions for moving printer xvi RGB ﬁles removing from printer C-35 to C-38 and color rendering dictionaries 3-5...
Page 261 I-13 Index Status T densitometer 1-8 text, deleting in text ﬁelds on printer storing control panel 2-3 three-dimensional color model 1-3 paper 2-11 to 2-12 printouts 2-11 to 2-12 tilting, avoiding C-14 toner cartridges C-15 tilting printer xvi transparency ﬁlm 2-12 toner subtractive color model 1-3, 1-4 distributing in replacement...
Page 262 I-14 Index troubleshooting back side of paper printing vector images 3-46, 3-47 incorrectly 2-13 ventilation xix TrueType fonts 4-9 ventilation slots xvii Tungsten light 1-1 vibration C-10 turret knob C-17 visible spectrum of light 1-1 voltage rating label xix voltage symbol xviii universal cassette 2-10 universal paper cassette blue bar indicator 2-17...

This manual is also suitable for:

Lsr 2000+

Digital Equipment LSR 2000 User Manual

About the Colorwriter LSR 2000

About this Guide

Related Documentation

Important Safety Information

Energy Star Compliance

Chapter 1 :Introduction to Color Printing and the Colorwriter

The Properties of Color

Traditional Color Printing and Colorwriter Printing

Controlling Printed Color

Chapter 2: Operating the Printer

Printer Control Panel Overview

Display Window

Using the Density Control Panel

Using the Optional Paper Feeder Unit

Handling and Storing Paper

Loading the Paper Cassette

Loading Paper into the Multipurpose Tray

Chapter 3: Printing from Macintosh Computers

Printing from Applications

Printing Pages from the Multipurpose Tray

Using Colorwriter LSR Utilities

Using the Colorwriter LSR Downloader

Using the Colorwriter LSR Spooler

Application Notes

Chapter 4: Printing from PC-Compatible Computers

Printing to the Colorwriter from Windows

Conﬁguring Windows Printing Options

Printing Pages from the Multipurpose Tray

Using Colorwriter Utilities

Using the Colorwriter LSR Downloader

Using the Colorwriter LSR Spooler

Using the Colorwriter LSR Manager

Application Notes

Chapter 5: Printing from UNIX Workstations

Chapter 6: Printing from Openvms Systems

Chapter 7: Administering Print Jobs over the Netware Print Server

Appendix A: Error and Warning Messages

Appendix B: Setup Menus

Appendix C: Maintenance

Identifying the Parts of the Printer

Cleaning and Handling the Printer

Storing and Handling Toner Cartridges

Replacing a Toner Cartridge

Replacing the Silicone Oil Bottle

Using the Drum Cartridge Kit

Moving the Printer

Appendix D: Troubleshooting

Power Problems

Initialization Problems

Printing Large Files

Print Quality and Paper Problems

Paper Jams

Correcting Abnormal Printouts

Appendix E: Speciﬁcations

Appendix E:specifications

Colorwriter Speciﬁcations

Paper Requirements

Effective Printing Area

Appendix F: Ordering Accessories and Supplies

Optional Paper Feeder Unit

F-2 Upgrade Kits

Ordering Consumables

Appendix G: Ordering Related Documentation

Technical Support

Electronic Orders

Telephone and Direct Mail Orders

Appendix H: Obtaining Service

Questions to Ask before Calling the Service Center

Glossary

Quick Links

Related Manuals for Digital Equipment LSR 2000

Summary of Contents for Digital Equipment LSR 2000
