ParTs DescriPTion
This section describes each of the parts in the Bill of Materials, the descriptions provide a physical set of
attributes and a purpose for each part. The parts descriptions also list everything that is included in each
assembly.
The XrT Pro Head Unit
The main component is the XRT Pro Head Unit. The Head Unit
is the interface in which you control vehicle performance pa-
rameters. Notice that the head unit has: seven total buttons,
five on the left side and two on the right, a large color screen,
and an electronic plug for docking on the back.
Note: XRT Pro includes a micro SD card inserted
in the side of the Head Unit.
oBD ii adapter Harness
The OBD II Adapter is a communication hub for the XRT Pro. The OBD ll Adaptor plugs directly into the
vehicle OBD ll port and connects to the XRT Pro.
UsB to Micro sD adapter
The USB to Micro SD Adapter is what you will use to update your XRT Pro. You will take the Micro SD card
out of the XRT Pro and insert it into the adapter, then insert the adapter into your personal computer.
