2010-2012 6.7L Dodge Cummins - H&S XRT Pro Installation & Operation Manual

2010-2012 6.7l DoDge cUMMins

Power levels
To adjust the Power Level, select
change Power level from the
Main Menu and follow the on-
screen instructions.
noTe:
The Power Level ratings listed
may not be exact for your particular
vehicle. The listed ratings apply to the
out-of-the-box tuning that H&S tuning
devices are shipped with. Any custom
downloads may result in different ratings and can be found at www.hsperformance.com/update-instructions.
emissions selection
Most 2010-2012 6.7L Cummins are equipped with an emissions system designed to run Ultra
Low Sulfur Diesel (ULSD) Fuel. If you have removed or modified this emissions system (or plan
to immediately after installing this device), proper tuning must be installed or the vehicle will
not operate correctly. Select REMOVED at this option for a modified emissions system and high
sulfur fuel use. Select PRESENT if your emissions system requires ULSD fuel.
exhaust emissions equipment
When running ULSD tuning, it is required that all sensors located in the exhaust system stay
in place and plugged in, otherwise you may experience a Check Engine Light (CEL) and even
a loss of power (limp mode).
When running High Sulfur tuning, it is recommended that all sensors located in the factory
exhaust system be unplugged from the electrical harnesses. These sensors can also be
removed completely with the factory exhaust if desired. On the 2010 - 2011 Pickup, there
are usually 3 EGT Sensors, 2 O2 Sensors, and 1 Pressure Sensor.
2011 cab & chassis Urea system
On the 2011 Cab & Chassis, there is usually an additional NOX sensor as well as a UREA sys-
tem that needs to be unplugged when running High Sulfur tuning. The UREA system must
at least be unplugged but can be completely removed from the vehicle if desired. Failure to
unplug the UREA system may result in a check engine light and/or dash messages. Follow
these instructions to unplug the UREA system:
2010-2012 PiCkuP
Power LeveLs
Stock
. . . . . . . . . . . . . . . . . . . .
Tow
. . . . . . . . . . . . . . . . . . . .
Street
. . . . . . . . . . . . . . .
Performance
1-888-628-1730 • XRT Pro Installation Manual
HigH sUlfUr caliBraTion
Power LeveLs
0 HP Stock
60 HP Tow
120 HP Street
175 HP Performance
. . . .
2011 Cab & Chassis
0 HP
. . . . . . . . . . . . . . . . . . . .
25 HP
. . . . . . . . . . . . . . . . . . . .
50 HP
. . . . . . . . . . . . . . . . .
75 HP
. . . . . .
31
