2011-2013 6.7L Ford Powerstroke - H&S XRT Pro Installation & Operation Manual

2011-2013 6.7l forD PoWersTroke

Power levels
To adjust the Power Level, select change Power level from
the Main Menu and follow the on-screen instructions.
noTe:
The Power Level ratings listed may not be exact for your particular
vehicle. The listed ratings apply to the out-of-the-box tuning that H&S tuning
devices are shipped with. Any custom downloads may result in different rat-
ings and can be found at www.hsperformance.com/update-instructions.
emissions selection
Most 2011-2013 6.7L Powerstrokes are equipped with an
emissions system designed to run Ultra Low Sulfur Diesel (ULSD) Fuel. If you have removed
or modified this emissions system (or plan to immediately after installing this device),
proper tuning must be installed or the vehicle will not operate correctly. Select REMOVED at
this option for a modified emissions system and high sulfur fuel use. Select PRESENT if your
emissions system requires ULSD fuel.
exhaust emissions equipment
When running ULSD tuning, it is required that all sensors located in the exhaust system stay
in place and plugged in, otherwise you may experience a Check Engine Light (CEL) and even
a loss of power (limp mode).
When running High Sulfur tuning, it is recommended that all sensors located in the factory
exhaust system be unplugged from the electrical harnesses. These sensors can also be
removed completely with the factory exhaust if desired. On the 6.7L Powerstroke, there are
usually 3 EGT Sensors, 1 NOX Sensor, 1 UREA Injector, and 1 Pressure Sensor.
noTe:
The vehicle will not run with sensors removed unless High Sulfur tuning is installed.
Urea / scr system
On the 2011 - 2013 6.7L Powerstroke, there is a UREA system that can be unplugged or
removed completely when running High Sulfur tuning. The UREA system may also be left
plugged in with no ill effects.
egr emissions equipment
If you are installing H&S High Sulfur tuning, you must unplug the EGR system on your 2011-
2013 6.7L Powerstroke if not installing an EGR delete. Failing to do so may result in damage
to your EGR parts.
1-888-628-1730 • XRT Pro Installation Manual
HigH sUlfUr caliBraTion
Power LeveLs
Stock
Tow
. . . . . . . . . . . . . . . . . . . .
Street
Performance
0 HP
. . . . . . . . . . . . . . . . . . . .
50 HP
100 HP
. . . . . . . . . . . . . . .
150 HP
. . . .
35
