- Page 1 Quick Guide of Network Box Camera Network Box Camera Quick Guide V3.0.0 Hangzhou Hikvision Digital Technology Co., Ltd. http://www.hikvision.com 2010-04...
-
Page 2: Camera Description
Quick Guide of Network Box Camera 1.Camera Description 1.1 Side Panel Description Serial NO. Description Lens mount Bracket mounting holes, used to fix the camera to the bracket Auto iris interface... -
Page 3: Rear Panel Description
Quick Guide of Network Box Camera 1.2 Rear Panel Description Rear Panel of DS-2CD886BF-E and DS-2CD876BF: Serial NO. Description F1+ F1-, F2+ F2- , F3+ F3-: Alarm output interface T1, T2, T3, T4, GND: Alarm input interface D+,D-: RS-485 interface... - Page 4 Quick Guide of Network Box Camera Rear Panel of DS-2CD886MF-E and DS-2CD876MF: Serial NO. Description ALARM OUT, GND: Alarm output interface ALARM IN, GND: Alarm input interface D+, D-: RS-485 interface TXD , RXD,GND: RS-232 interface HDMI interface RESET: Reset all parameters to factory default settings 10M / 100M self-adaptive Ethernet interface Power supply Power LED indicator, which turns red when power is applied to the unit...
-
Page 5: Installation
Quick Guide of Network Box Camera 2.Installation Box camera can be fixed in both wall and ceiling, the following section introduces the ceiling mounting, and the wall mounting follows the same way: Step 1: Fix the camera mounting bracket to the ceiling. Fig 2.1 Fix camera mounting bracket NOTE: If it is wall, you need to fix the expand bolt (note: the mounting hole of the expand bolt should align... - Page 6 Quick Guide of Network Box Camera Fig 2.2 Fix the Camera Step 3: Mount the camera lens: connect the VIDEO OUT interface of the camera to the debugging monitor, and adjust lens focus until you have obtained the clearest video images on the monitor, and then lock the lens.
-
Page 7: Search And Modify Ip
Quick Guide of Network Box Camera 3.Search and Modify IP SADP (Search Active Devices Protocol) software can automatically search the IP address of network cameras’ on the same network with connection diagram as follows: The operation of searching and modifying IP address is described as following: 1. - Page 8 Quick Guide of Network Box Camera 1. Click [modify] 2. Input new IP address and the password ( Default: 12345) of the camera, then click [save] 3. Modify successfully...
- Page 9 Quick Guide of Network Box Camera 4.Preview via IE browser Note: The default IP of network cameras’ is ‘192.0.0.64’ with ‘admin’ as the administrator, ‘12345’ as the password, and ‘8000’ as the default port. For monitoring camera images, a comptuer running the Microsoft Windows Operating System and Internet Explorer (Version 6.0 or later) are required.
- Page 10 Quick Guide of Network Box Camera 2. Type the IP address of the camera and press [Enter], and then click the mention box that pop up. 3. Click [Run] to install the ActiveX control.
- Page 11 Quick Guide of Network Box Camera 4. Input “Username” (Default: admin), “Password” (Default: 12345) and “Port” (Default: 8000) of the camera, then click [Login]...
- Page 12 Quick Guide of Network Box Camera 5. View the image For detailed instructions of further configuration, please refer to the user manual of network camera.
- Page 13 Quick Guide of Network Box Camera First Choice for Security Professionals...
