Page 1: User Guide
User Guide For Windows 8.1 Tablet-laptop TL10IE2... -
Page 2: Regulatory Compliance
Regulatory Compliance Information FCC Declaration of Conformity This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 3 conducted using standard operating positions accepted by the FCC with the device transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the device while operating can be well below the maximum value.
- Page 4 susceptible d’en compromettre le fonctionnement. CE mark. Declaring compliance to all the applicable European Union (EU) directives. For CE mark related questions: Elitegroup Computer Systems Co., Ltd No.239, Sec. 2, Ti Ding Blvd., Taipei, Taiwan 11493 886-2162-1177 French SAR/DAS Votre ordinateur tablette a un DAS. Pour plus d'informations, voir le portail radiofréquences-sante-environnement: www.radiofrequences.gouv.fr In the European Union, this symbol indicates that...
- Page 5 This product is an educational tool designed for school children, ages 6 and up. There must be supervision by an adult on school children under 10 when using this Intel Classmate PC - Convertible. It is a must to have a thorough explanation to students on safe and proper handling of the Intel Classmate PC - Convertible, power supply, battery pack, and power cord.
-
Page 6: Safety Precautions
Safety Precautions The following are lists of precautionary measure the students must understand before using this computer inside the classroom or home environment: Do not place near the fire or other sources of heat. Do not expose to magnetic fields. Do not expose to direct sunlight. -
Page 8: Table Of Contents
Contents 1. Getting to know your computer ........1 Package contents ................. 1 Separating your tablet-laptop ..............1 Layout ....................2 Tablet Views ................. 2 Front ..................2 Back ..................3 Left (I/O cabinet) ..............4 Bottom ................. 4 Keyboard Duck Views ..............5 Connectors and indicators ........... - Page 9 3. Setup and Connection ............. 19 Windows Activation ................19 Configuring your Microsoft Account ............ 20 Setup your Start screen ..............20 Adding an App ................20 Removing an App ............... 21 Wireless LAN ..................21 Enabling wireless connection ............. 21 Connecting to a wireless LAN ............
-
Page 10: Getting To Know Your Computer
1. Getting to know your computer This chapter provides an overview of the tablet, including the locations of the connectors and controls, tablet features, and accessories. Package contents Carefully unpack your box and take out the items listed as below. If any of the items is missing or damaged, contact your dealer immediately: •... -
Page 11: Layout
Layout Tablet Views Front Name Function Mainly for sound and speech recording. Microphone It detects the brightness of the environment. Light sensor Often for taking self-portraits as well as for video Front facing conferencing. camera This is where you can rest and charge the Digital pen attached digital pen (optional). -
Page 12: Back
Back Name Function Push here to power on/off or lock on/off your Power lock tablet. Push here to active or cancel the screen rotating Screen function. rotation lock The camera is mainly used when you are taking Rear facing photos or recording videos. -
Page 13: Left (I/O Cabinet)
Left (I/O cabinet) Name Function This is where you can connect your HDMI HDMI port external screen. This is where you can insert a Micro SD memory Micro SD card card. slot Headphone Here you can plug in a standard headphone. connector This is for establishing a USB 3.0 connection. -
Page 14: Keyboard Duck Views
Keyboard Duck Views Connectors and indicators Name Function Docking A connector where you docking your tablet. Connector A jack to connect the AC adapter that supplies DC Jack power to the computer. You can connect a USB 2.0 device here. USB 2.0 port Battery It lights up in amber when the battery is being... -
Page 15: Shortcut Keys
Shortcut keys You can access certain system settings quickly by pressing the appropriate function keys. Press both the Fn key and One of the following shortcut key at the same time to perform your desired function. Enable/disable the Increases the volume Airplane mode to turn level. -
Page 16: Using Your Computer
2. Using your computer Powering ON/OFF Powering on your computer 1. If this is the first time you turn this computer on, connect the AC adapter and fully charge the battery. 2. Press the power button. 3. A logo will appear when the system is powered on. -
Page 17: Putting Your Tablet Into Sleep Mode
B. Using the power button Press and hold the power button for at least four seconds, and you will see an instruction appears in the middle of the screen, which is as shown below. Slide your finger on the screen downward, and the system will power off itself. -
Page 18: Waking Up Your Computer
Waking up your computer Note: It is recommended that you put your computer to sleep before you move it. Moving your computer while the hard disk is spinning can sometimes damage the hard disk, causing loss of data. Do one of the following: •... - Page 19 Gesture name Explanation Touch once on an item to start an app, open a link, or perform an optional function. This is similar to a left-click with a mouse. Double-tap Slightly press twice with your finger to select an item. Press and hold Press and leave your finger on an item.
-
Page 20: Digital Pen Operations
Rotate Place two or more fingers on an item and then turn your hand. This enables you to turn an object. (Note: Not all items can be rotated, depending upon the app.) Slide Drag your finger across the screen. This can scroll through lists and pages, and can also move an object or be used to draw or write, depending upon your apps. - Page 21 With the digital pen, you can perform not only one-finger gestures, but also more advanced actions with the buttons on it (if supported by apps). The digital pen has a battery built in. To charge your digital pen, you need to rest it in the digital pen slot, which you can find on the front right of your tablet.
-
Page 22: Windows Interface
3. Windows Interface Start Screen When you turn on the computer, the Start screen is displayed, which allows you to access many features and installed applications (also referred to as apps) at one glance. These bricks are the shortcuts for respective Apps applications. -
Page 23: Desktop
Desktop In Windows 8.1, the Desktop is treated as an app. You can find and activate it from your Start screen and All Apps screen. Taskbar Allows you to add toolbars that hold extra buttons and menus. Notification Shows you the current system status and area notifications Program area... -
Page 24: Customizing Your Taskbar
Customizing your taskbar Right-click (or press and hold using your finger) on a blank part of the taskbar, a pop-up menu leaps out. In the menu, select Toolbars and offer and you can see following five toolbar options: Address By choosing this, part of your taskbar becomes a place for typing website addresses where you want to visit. -
Page 25: The Charms Menu
The Charms menu This menu consists of five options that are called charms and provide quick access to various aspects of Windows 8.1. To display the Charms, do one of the following: Move the pointer to the upper-right or lower-right corner; ... -
Page 26: All Apps
Device This enables you to operate directly a desired device. You can import pictures from a digital camera, stream a video to your TV, or transfer files to a device listed on the screen. Settings This charm enables you to perform basic tasks such as adjusting the volume, turning off the PC, etc. - Page 27 Move the mouse cursor to the lower-left corner, and click the Windows icon. Press the Windows key on your keyboard or tap the Windows button on your tablet. Click the Windows icon in the Charms bar.
-
Page 28: Setup And Connection
3. Setup and Connection Windows Activation When you turn the computer on for the first time, the Windows activation screen may appear. Follow the instructions on the screen to register and active your computer. If you fail to activate your windows and want to retry again, do the following: 1. -
Page 29: Configuring Your Microsoft Account
Configuring your Microsoft Account To share files or settings with other devices running Windows 8, you need to setup a Microsoft Account. Furthermore, if you want to download or purchase apps from the Microsoft Store, such Microsoft Account is required. To setup a Microsoft account 1. -
Page 30: Removing An App
appears at the bottom of the screen. 3. Touch the icon named Customize in the menu. 4. Touch the app that you want to add to your Start screen. The available options will appear in the right side of the option menu. 5. -
Page 31: Connecting To A Wireless Lan
To confirm that Airplane mode is disabled, go to the desktop and check the notification area. If you see an airplane icon displayed on the lower right, then Airplane mode is on. Otherwise, wireless function is enabled. Connecting to a wireless LAN Once the wireless has been enabled, the computer automatically scans for available wireless networks and displays them in the wireless LAN network list. -
Page 32: To Remove Your Memory Card
the screen, and choose to open and view files. 3. A Windows Explorer runs and shows all the folders and files in the micro SD cards, and you can save, move and delete data as you are handling a storage device. To remove your memory card 1. -
Page 33: Connecting An External Device
Connecting an External Device Connecting to the USB port Your computer comes with two USB ports compatible with USB devices. The one on the tablet is the latest USB 3.0 port. You can easily identify the USB 3.0 port by its blue color. Once you plug a USB device into a USB port on your computer, Windows automatically loads a driver for that device. -
Page 34: Connecting To The Hdmi Port
Connecting to the HDMI port You can connect an external display device such as a monitor, TV, projector, etc., only if such device has a HDMI port. By doing so, you have a wider view when you give a presentation or watch a video or movie. -
Page 35: Battery
4. Battery Charging your battery You can charge your tablet directly by connecting the adapter to the DC jack on your tablet and to a wall socket. If you dock the tablet into the keyboard dock, the dock will start to charge the tablet. -
Page 36: By Inspecting The Taskbar
In the lower-left corner is the battery status icon. By inspecting the taskbar In Desktop, move the cursor to the battery icon in the taskbar. A pop-up dialog box appears and shows you the remaining battery percentage, as shown below. Approximate status of your battery The battery icon reveals the approximate status of your battery, which describes as below. - Page 37 Battery is starting to drain Battery is about to completely drain, and you should stop using your tablet and charge it at once. Battery is being charged. A battery is an expendable supply, so when using it over a long time, the capacity/battery life is shortened.
-
Page 38: Windows Help And Troubleshooting
5. Windows Help and Troubleshooting To know how to use Windows 8 properly, it is better to learn how to use Windows by utilizing Windows Help. Windows Help Move the pointer on the screen to the top or bottom right edge of the screen to view the Charm menu. - Page 39 the problem occurred. Provide detailed information to your service provider for quicker problem resolution. For about any problem, follow these steps: 1. Restart your tablet. 2. Check your Wi-Fi connection. 3. Reset your Wi-Fi connection. 4. Plug your tablet to a wall socket to charge it for at least one hour.
- Page 40 Sleep problems • The battery power is getting low. The critical low-battery error message appears, and the Connect the AC adapter to the computer. computer turns off • Make sure that the battery is charged. The computer enters sleep mode immediately after - The operating temperature may be too Power-on.
- Page 41 • Make sure that: The screen is unreadable or distorted. - The screen resolution and color quality are correctly set. - The monitor type is correct. • Are the operating system or programs Incorrect characters appear on the screen. installed correctly? If they are installed and configured correctly, have the computer serviced.
- Page 42 • Do not connect or disconnect any The connected external device does not work. external device cables other than USB while the computer power is on. Otherwise, you might damage your computer. • When using a high power consumption external device such as an external USB optical disk drive, use an external device power adapter.
-
Page 43: Specification
6. Specification Intel Bay Trail-T 2.4 GHz Quad Core Processor 2GB Memory DDR3L two channel, 1333MT/s (max.) 32GB NAND flash Storage eMMC Version 4.51 interface 282.0 x 180.0 x 11.4 mm Dimension 750 g Weight ... - Page 44 Tablet Input/Output 1 x DC-in jack 1 x A-type USB 3.0 port 1 x Mic/head phone jack combo 1 x Micro HDMI port 1 x Micro SD card slot 1 x 3G SIM slot Keyboard Dock ...
- Page 45 Portuguese Russian Simplified Chinese Spanish Thai Traditional Chinese Turkish DC Output: 12V/24W AC-Adapter Input Voltage: 100–240VAC Nominal Input Frequency: 50–60Hz. Model No. Asian WA-24R12Fy (y=U,G,K,B,A) CE /FCC/CCC Certification ...
