4.7.1 Control logic sequencing
Figure 4-10 shows the sequencing of the signals which must be accomplished with this
logic.
Figure 4-10 Control logic and sequencing
AC SUPPLY
SELECT
AC SUPPLY
CONTACTOR
LOW VOLTAGE
DC SUPPLY
CONTACTOR
DISCHARGE
RESISTOR
DRIVE ENABLE
SIGNAL
Unidrive SP Low Voltage DC Installation Guide
Issue Number: 1
t1
Both delays t1 & t2 should have a minimum value of 1s.
www.controltechniques.com
AC SUPPLY SELECTED
DC SUPPLY SELECTED
CONTACTOR CLOSED
CONTACTOR OPEN
CONTACTOR CLOSED
CONTACTOR OPEN
t2
CONTACTOR CLOSED
CONTACTOR OPEN
DRIVE ENABLE PROVIDED
DRIVE ENABLE REMOVED
