  • Page 1 OWNER'S HANDBOOK - SUPPLEMENT...
  • Page 2 Welcome This document describes the special features relating to the presentation and use of your DS3 CABRIO. Refer to the DS3 owner's handbook for all other descriptions and specifications, and also to maintenance and warranty guide for servicing information for your vehicle.

  • Page 3: Table Of Contents

    Contents Contents ACCESS PRACTICAL INFORMATION safety warning Soft top Changing a bulb additional information Boot Changing a fuse Recommendations on care contributes to the protection of the environment FITTINGS TECHNICAL DATA refer to the page indicated Rear shelf Petrol engines Petrol weights Diesel engine Diesel weights...

  • Page 4: Access

    Access Soft top Your vehicle is fitted with an electric soft top roof. Electric opening and closing The roof is opened and closed by pressing the control at the interior lamp, in the opening direction 1 and in the closing direction 2 .
  • Page 5 Access Operating zones Roof positions Operation of the roof is possible: engine running, or ignition on. In order to maintain the state of charge of the battery, it is recommended that the roof be operated with the engine running . There are two operating zones: Position 0 : Roof completely closed.

  • Page 6: Manual Mode

    Access Opening Manual mode In zone A , press and hold the control The roof stops as soon as you release the without passing the point of resistance to control. open the roof. Opening of the roof in zone B can only be done in automatic mode.

  • Page 7: Automatic Mode

    Access Automatic mode In zone A , press the control beyond the Release the control: opening of the roof In zone B , a press on the control opens the point of resistance to begin opening the continues up to the maximum horizontal roof completely (position 3 ).
  • Page 8 Access Closing Manual mode In zone A , press and hold the control The roof stops as soon as you release the without passing the point of resistance to control. close the roof. To close the roof completely, press and hold the control until the the roof is heard to lock.
  • Page 9 Access Automatic mode In position 3 , press the control to begin Release the control: closing of the roof Between positions 2 and 1 , pressing the closing the roof. continues up to position 2 . control beyond the point of resistance allows automatic closing of the roof to When the roof is completely open, the position 1 .
  • Page 10 Access Aero-acoustic deflector Operating the roof when driving An aero-acoustic deflector is available to With the roof open, this deflector can be The roof opening and closing control improve the acoustic comfort of occupants of folded away manually and secured at its operates up to about 70 mph (120 km/h).

  • Page 11: Precautions For Use

    Access Precautions for use Do not place objects on the roof, whether open or closed. an opening operation in progress in zone B is continued through to completion, To avoid damaging the roof, do not open it under snowy or frosty conditions. Do not use sharp tools to remove ice or accumulations of snow on the roof.
  • Page 12 Access Downgraded operation Reinitialisation Operating fault If the automatic roof operation mode is lost, the In the event of an electrical fault, system must be reinitialised. contact a CITROËN dealer or a With the engine running , press and hold qualified workshop.
  • Page 13 Access Boot Opening Closing If the boot is not closed correctly: when the engine is running , this warning lamp comes on, accompanied by a message on the multifunction screen for a few seconds, when the vehicle is moving (speed above 6 mph (10 km/h)), this warning lamp comes on, accompanied by an audible signal and a message in the multifunction screen for a...
  • Page 14 Access Conditions for opening the boot with the roof in zone B To avoid interference between the boot and the roof in zone B, opening the boot depends on the position of the roof. If the roof is carrying out an opening operation in zone B , an action on the boot opening control causes the roof to close.

  • Page 15: Emergency Release

    Access Emergency release System for mechanical unlocking of the boot in the event of a battery or central locking malfunction. Unlocking Fold back the rear seat to gain access to Insert a small screwdriver into hole A of the two latches, from inside the boot. each lateral latch to unlock the boot.

  • Page 16: Fittings

    Fittings Rear shelf The rear shelf is fixed . Before opening the roof completely, When the roof is fully open, the rear check that no object has been left on screen rests on the shelf. Do not place the shelf. any object on the screen.

  • Page 17: Practical Information

    Practical information Changing a bulb 3D rear lamps 3D LED sidelamps (LEDs). Access to the bulbs Changing direction indicator (4) 2. LED brake lamps / sidelamps (LEDs). and foglamp or reversing Open the boot. 3. LED lateral sidelamps (LEDs). lamp (5) bulbs Remove the access flap from the 4.

  • Page 18: Changing A Fuse

    Practical information Changing a fuse There are three fuses for the soft top roof. Fuses under the rear shelf Fuse under the bonnet (maxi-fuse) Fuse N° Rating Functions MF08 40 A Soft top roof The maxi-fuses provide additional protection for the electrical systems. All work on the maxi-fuses must be carried out by a CITROËN dealer or a qualified workshop.

  • Page 19: Recommendations On Care

    Practical information Recommendations on care of your vehicle The general recommendations on the care of your vehicle are given in the maintenance and warranty guide. Soft top Before washing the soft top, first To remove marks, sponge them (but Never use chemical products, remove as much dirt as possible from never rub them) using soapy water, detergents, stain removers, solvents,...
  • Page 20 Technical data MODELS: ENGINES AND GEARBOXES Model codes: 5FV8 HMZ0 5FS0 5FS9 SB... 5FN8 * THP 155 PETROL ENGINES VTi 82 VTi 120 THP 150 * Cubic capacity (cc) 1 199 1 598 1 598 Bore x stroke (mm) 75 x 90.5 77 x 85.8 77 x 85.8 Max power: EU standard (kW)

  • Page 21: Technical Data

    Technical data WEIGHTS AND TOWED LOADS (in kg) THP 155 Petrol engines VTi 82 VTi 120 THP 150 * Gearboxes Manual Manual Auto matic Manual Model codes: 5FV8 HMZ0 5FS0 5FS9 SB... 5FN8 * Unladen weight 1 032 1 088 1 133 1 156 Kerb weight...

  • Page 22: Diesel Engine

    Technical data MODELS: ENGINES AND GEARBOXES Model codes: 9HP0/S 9HP8/PS SB... DIESEL ENGINES e- HDi 90 PEF Cubic capacity (cc) 1 560 Bore x stroke (mm) 75 x 88.3 Max power: EU standard (kW) Max power engine speed (rpm) 4 000 Max torque: EU standard (Nm) Max torque engine speed (rpm) 1 750...
  • Page 23 Technical data WEIGHTS AND TOWED LOADS (in kg) Diesel engines e-HDi 90 PEF Manual Electronic gearbox system Gearbox (5-speed) (6-speed) Model codes: 9HP0/S 9HP8/PS SB... Unladen weight 1 085 1 090 Kerb weight 1 160 1 165 Gross vehicle weight (GVW) 1 625 1 639 Gross train weight (GTW)

  • Page 24: Dimensions

    Technical data Dimensions (in mm)
  • Page 27 This handbook describes all of the equipment Automobiles CITROËN declares, by application of available in the whole range. the provisions of the European regulation (Directive 2000/53) relating to End of Life Vehicles, that it Your vehicle will be fi tted with some of this achieves the objectives set by this regulation and equipment described in this document, depending that recycled materials are used in the manufacture...
  • Page 28 13DS3C.040 Anglais...
