CITROEN DS3 Ready To Set Off

FOLDING THE BACKREST
AUDIO AND TELEMATICS
SOS
EMERGENCY CALL
ASSISTANCE CALL
2
3 5
4 6
1
1. On/Off and volume adjustment.
2. CD eject.
3. Selection of the display on the screen from the following modes:
Audio (AUDIO), Trip Computer (TRIP) and Telephone (TEL)
functions.
4. Selection of source:
radio, audio CD/MP3 CD, USB, Jack connection, Streaming.
5. Selection of FM1, FM2, FMast and AM wavebands.
6. Setting audio options: front/rear fader, left/right balance,
loudness, sound ambience.
FUEL TANK
DIESEL
1. Opening the fuel fi ller fl ap.
2. Opening and hooking the fuel fi ller cap.
Tank capacity:
- approximately 50 litres (petrol),
- approximately 48 litres (Diesel).
Fiche_loueur_DS3_an_01-2010.indd1 1 Fiche_loueur_DS3_an_01-2010.indd1 1
ACCESS TO THE REAR SEATS
Pull the control upwards to fold the seat back and move the
seat forward.
When put back in place, the seat returns to its initial position.
1 7
3 4 5 6
2
1. Engine not running
- Short press: on/off.
- Long press: CD pause, mute for the radio.
Engine running
- Short press: CD pause, mute for the radio.
- Long press: reinitialisation of the system.
2. Volume adjustment (each source is independent, including also
navigation messages and alerts).
3. Access to the "Radio" Menu. Display the list of stations.
4. Access to the "Music" Menu. Display the tracks.
5. Access to the "SETUP" menu.
Long press: access to the GPS coverage and the demonstration
mode.
6. Access to the "Phone" Menu. Display the call list.
7. . CD eject.
BONNET
A. Interior release lever.
B. Exterior safety catch.
C. Bonnet stay.
READY TO SET OFF
STEERING WHEEL ADJUSTMENT
1. Unlock the adjustment mechanism.
2. Adjust for height and reach.
3. Lock the adjustment mechanism.
PARKING BRAKE
Applying
Pull the parking brake lever fully up to immobilise your vehicle
Releasing
Pull the parking brake lever gently, press the release button
then lower the lever fully.
GEAR SHIFT INDICATOR
System which reduces fuel consumption by advising the driver to
change up on vehicles fi tted with a manual gearbox.
CITROËN DS3
REMOTE CONTROL KEY
A. Unfolding/Folding the key.
B. Unlocking the vehicle.
C. Normal locking of the vehicle.
Vehicle location.
6-SPEED MANUAL GEARBOX
Engaging reverse gear
Raise the ring under the knob and push the gear lever to the
left then forwards .
STOP & START
Going into engine STOP mode
The "ECO" warning lamp comes on in the instrument
panel and the engine goes into standby :
- with a manual gearbox: at speeds below 12 mph (20 km/h),
put the gear lever in neutral, then release the clutch pedal.
Going into engine START mode
The "ECO" warning lamp goes off and the engine
restarts:
- with a manual gearbox: depress the clutch pedal.
09/07/2010 12:41:32 09/07/2010 12:41:32
