- Page 1 LUCREZIA IDRO LCD USER MANUAL ENGLISH/INGLESE...
-
Page 3: Table Of Contents
We thank you for having chosen our company; our product is a great heating solution developed from the most advanced technology with top quality machining and modern design, aimed at making you enjoy the fantastic sensation that the heat of a flame gives, in complete safety. Extraflame S. p. A. Warnings ....................................5 safety ......................................5 HydraULiC systeM .................................. - Page 4 MenU strUCtUre ...................................22 set power ..............................................23 set temperature ............................................23 set adjustments ..........................................23 enaBle chrono............................................23 pellet regulatIon ..........................................23 user menu ..............................................24 chrono ................................................24 programmIng example ........................................25 adjustIng language ..........................................26 dIsplay .................................................26 reset ................................................26 otHer fUnCtions ..................................26 aIr dIscharge ............................................26 CLeaning Under User's responsibiLity.........................27 roUtine MaintenanCe ...............................28 dispLays ....................................30 aLarMs ....................................31...
-
Page 5: Warnings
Extraflame s.p.a. cannot be held responsible for the failure to comply with such precautions. After removing the packaging, ensure that the content is intact and complete. Otherwise, contact the dealer where the appliance was purchased from. -
Page 6: Hydraulic System
Standards in force, national, regional and municipal, as well as these instructions. For Italy, installation must be carried out by professionally authorised staff (Ministerial Decree dated 22.01.08 n°37). Extraflame s.p.a. declines all responsibility for damage to objects and/or persons caused by the system. safEty DEvicEs for cLosED vEssEL systEM... -
Page 7: Type Of System
| EngLisH coMponEnt DistancE Temperature safety sensors On the machine or not exceeding 30 cm Missing devices because not as per standard Not exceeding one metre, on the flow pipe The domestic heating appliances with automatic feeding must: be supplied with a fuel block thermostat or be supplied with a cooling circuit set-up by the appliance manufacturer. -
Page 8: Closed Expansion Vessel
Valves on the market have different calibrations. Extraflame advises use of 55°C model with 1" hydraulic connections. Once the valve calibration temperature is reached, route 2 is opened and the boiler water goes to the system via the flow. -
Page 9: Hydraulic System Basic Layout
| EngLisH HyDrauLic systEM basic Layout nota bEnE: the drawing in the figure is an example. STBY VMTA Primary air inlet Ø 60mm Smoke exhaust outlet Ø 120mm Pump (in the models envisioned) 1/2 " 3 bar safety drain 1/2 " Boiler flow/output 1"... -
Page 10: Instant Domestic Hot Water Production Kit
| EngLisH instant DoMEstic Hot WatEr proDuction kit Warnings: if the instant hot water production kit is to be used, contact the company technical after-sales service. stovE positioning For correct product functioning, it is recommended to position it in a way that it is perfectly level, with the aid of a spirit level. rEarM The figures below show the rearm positions of the tank (85°C) and h2O (100°C). -
Page 11: Safety Devices
| engliSH Safety deviceS glOSSaRy Safety deviceS clOSed HeaRtH aPPliance Key: * = present, - = not present Heat generator which opening is only allowed through the loading of the fuel during use. circuit board: intervenes directly by sending the product BiOMaSS into alarm conditions until complete cooling, in the case Biological material, excluding the material incorporated in... -
Page 12: Installations Allowed
| engliSH RadiatiOn aRea for expelling combustion products, the instructions below Area immediately near the hearth in which the heat caused by must be followed: combustion is diffused, where no combustion materials must Insulating be present. product ReflUX aRea Area where leaking of the combustion products is verified, from the appliance towards the installation room. -
Page 13: Chimney Or Individual Flue
| engliSH cHiMney OR individUal flUe the chimney or individual flue must respond to the following requisites: Š seal the combustion products, be waterproof and adequately insulated in line with the use conditions; Š be realised with materials which resist the normal mechanical stress, heat, action of the combustion products and any condensate;... -
Page 14: Chimney Cap
| engliSH < 3 m external pipe that is isolated 45° Inspection 45° Inspection Appliance connection to the flue and combustion products evacuation the flue must receive the discharge from only one heat generator. Direct discharge towards closed spaces is forbidden, even with clear sky. the direct discharge of the combustion products must be at roof and the smoke pipe must have the features provided in the "Chimney or individual flue"... -
Page 15: Connection To External Air Inlets
Š Ö-norm M 7135 Š DIn plus 51731 Š UnI Cen/ts 14961 extraflame recommends the use of pellets with use pellet having a 6 mm diameter. open the tank lid and load the pellets using a scoop. tHe USe Of Bad QUality PelletS OR any OtHeR MateRial can daMage yOUR StOve and will MaKe tHe... -
Page 16: Control Board
| EnGlISH Control Board ON/OFF Display OF variOUs TO aCCess BUTTON TexT messages THe meNU OperaTiON pOWer TemperaTUre aDJUsTmeNT seTTiNg dISplay IConS kEy indicates the receipt of the radio signal indicates the stove modulation On = during radio communication On = the stove is working at the set power Off = no radio communication Flashing = the power at which the stove is working is different to Flashing = excluded serial port... -
Page 17: General Menu
| EnGlISH GEnEral mEnu Go BaCk - ExIt BrowSE paramEtErS: nExt (2); prEvIouS (3) modIfy SEttInG data: InCrEaSE (4); dECrEaSE (5) ConfIrm - aCCESS mEnu SEt powEr SEt tEmpEraturE SEt H2o SEt adjuStmEntS EnaBlE CHrono SET BOILER mAx StatuS StovE StatuS pEllEtS SET BOILER mIn BOILER STATUS... -
Page 18: The Remote Control
| EnGlISH tHE rEmotE Control all that can normally be implemented through the lCD can be adjusted can be adjusted using the remote control. The table below provides a detailed description of the various functions: on / off pressing the key for three seconds, the stove will switch-on or off powEr InCrEaSE pressing the key will increase the operating power powEr dECrEaSE... -
Page 19: Commissioning Settings
| EnGlISH CommISSIonInG SEttInGS Once the power cable at the back of the stove has been connected, move the switch, also located on the back, to (i). The switch at the back of the stove powers the stove board. The stove remains off and a first screen appears on the panel reading OFF. -
Page 20: Operation And Logic
| EnGlISH opEratIon and loGIC IGnItIon Once the points listed previously have been checked, press key 1 for three seconds to ignite the stove. 15 minutes are available for the ignition phase. after ignition and having reached the control temperature, the stove interrupts the ignition phase and passes to sTarTiNg. -
Page 21: Additional Thermostat
| EnGlISH addItIonal tHErmoStat n.B. : Installation must be performed by an authorised technician it is possible to thermostat a room adjacent to the room where the stove is positioned: just connect a thermostat following the procedure described in the next point (it is recommended to position the optional mechanical thermostat at a height of 1.50m from the ground). -
Page 22: Menu Structure
| EnGlISH mEnu StruCturE Go BaCk - ExIt BrowSE paramEtErS: nExt (2); prEvIouS (3) modIfy SEttInG data: InCrEaSE (4); dECrEaSE (5) ConfIrm - aCCESS mEnu mEnu tExt valuE funCtIon SEt powEr powEr 01 - 05 selecting the power SEt tEmpEraturE SEt H2o 65 - 80°C selection of the boiler temperature set-point... -
Page 23: Set Power
| EnGlISH SEt powEr The following menu allows the power to be set. minimum power 1, maximum power 5. CONTrOls prOCeDUre Š press key 6 and SEt powEr will appear Š press key 6 to access and key 2 to proceed Š... -
Page 24: User Menu
| EnGlISH NO FUel: Š the stove can never develop a suitable flame, tending to remain very low even at high powers. Š at minimum power the stove tends to almost switch-off taking the stove into “ ” alarm condition. no pEllEtS Š... -
Page 25: Programming Example
| EnGlISH proGrammInG ExamplE let's suppose that the weekly programmer function is to be used and 4 time periods are to be used in the following way: 1st time period: from 08:00 to 12:00 every day of the week excluding Saturday and Sunday 2nd time period: from 15:00 to 22:00 only Saturday and Sunday with both times having a water temperature set of 75°C 1sT Time periOD sWiTCH-OFF CONTrOls prOCeDUre:... -
Page 26: Adjusting Language
| EnGlISH adjuStInG lanGuaGE • see chapter: first ignition settings dISplay This menu allows to regulate the brightness of the display. The possible settings range from OFF - 10 to 31. activating OFF, the back light of the display will go off after a preset delay. The back light will go on as soon as a key is pressed or if an alarm should be triggered in the machine. -
Page 27: Cleaning Under User's Responsibility
| ENGLISH CLEaNING uNdEr uSEr'S rESpoNSIbILIty Some images could be offset from the original model. daILy burn pot: remove the burn pot from the relevant compartment and free the holes using the appropriate fire irons supplied, remove the ash from the burn pot using a suction device. Suck the ash deposited in the brazier compartment. UPPEr DIVIDEr BUrN POT KEEP THE COrrECT POSITION AS INDICATED IN THE FIGUrE... -
Page 28: Routine Maintenance
| ENGLISH CLEaNING uNdEr uSEr'S rESpoNSIbILIty Some images could be offset from the original model. MoNtHLy Cleaning the deflector: The smoke deflector located under the cleaning springs of the heat exchanger must be removed every month. Move it as follows: remove part A of the door upper deflector fixed with 3 screws, remove part B of the door upper deflector fixed with 2 screws and remove the smoke central deflector as if it were a drawer. - Page 29 | ENGLISH routINE MaINtENaNCE Some images could be offset from the original model. Fumes motor (disassembly and cleaning and fumes pipe and "T"), new silicone in the provided points Inspections of gaskets, ash drawer and door (replace them and apply silicone where envisioned) ...
-
Page 30: Displays
| enGlisH Displays Display Reason Stove off sTaRT The start phase is in progress pelleT feeDinG The continuous feeding of the pellets during the ignition phase is in progress iGniTion The ignition phase is in progress sTaRT-up The start-up phase is in progress BuRn poT The automatic burn pot cleaning is in progress cleaninG... -
Page 31: Alarms
| enGlisH alaRMs Display eXplanaTion soluTion On: indicates the presence of an alarm Flashing: indicates the deactivation of the depression sensor. Indicates the presence of an alarm. The alarm can be reset by pressing key 1 for 3 seconds only if the fumes motor has stopped and if 15 minutes have passed from when the alarm was displayed. -
Page 32: Warranty Conditions
Š EXTRAFLAME S.p.A. is not liable for any damage that can, directly or indirectly, affect persons, objects and pets as a consequence of failure to comply with the prescriptions indicated in this manual/book... - Page 33 Š Masonry work Š The system particulars for the production of domestic hot water not supplied by EXTRAFLAME S.p.A. (water products only). Š The heat exchanger is excluded from the warranty unless an adequate anti-condensate circuit is realised, which guarantees a minimum return temperature of the appliance of at least 55°C (only water products).
- Page 35 | ENGLISH...
- Page 36 Extraflame si riserva di variare le caratteristiche e i dati riportate nel presente fascicolo in qualunque Extraflame reserves the right to vary the features and data shown in this booklet at any momento e senza preavviso, al fine di migliorare i propri prodotti.
