- Page 1 Manual 07504513 Model 4513 Model 4513 (8x8) Matrix & 8(4-pole) Star Switches 90900110 Page 1 peration Manual...
- Page 2 Giga-tronics will, at its option, repair or replace products that are proven defective during the warranty period. This warranty DOES NOT cover damage resulting from improper use, nor workmanship other than Giga-tronics service.
- Page 3 San Ramon, California 94583 U.S.A. Type of Equipment: Model Series Number Switching Module 4513 Declaration of Conformity on file. Contact Giga-tronics at the following; Giga-tronics, Incorporated 4650 Norris Canyon Road San Ramon, California 94583 Telephone: 800.726.4442 (only within the United States) 925.328.4650...
- Page 4 Manual 07504513 Model 4513 Record of Changes to This Manual Use the table below to maintain a permanent record of changes to this document. Corrected replacement pages are issued as Technical Publication Change Instructions (TPCI). When you are issued a TPCI, do the following: 1.
- Page 5 Manual 07504513 Model 4513 Revision History Revision Description of Change Chg Order # Approved By Initial Release 10/03 Updated Reformatted 3/12 Page 5 peration Manual...
-
Page 6: Table Of Contents
Manual 07504513 Model 4513 Contents Contents ................................ 6 Chapter 1 Introduction ..........................7 1.1 Safety and Manual Conventions ......................7 1.1.1 Product Reference ........................7 1.1.2 Personal Safety Alert ........................7 1.1.3 Equipment Safety Alert ....................... 7 1.1.4 Notes ............................7 1.1.5 Electrical Safety Precautions ....................... -
Page 7: Chapter 1 Introduction
Manual 07504513 Model 4513 Chapter 1 Introduction 1.1 Safety and Manual Conventions This manual contains conventions regarding safety and equipment usage as described below. 1.1.1 Product Reference Throughout this manual, the term “Common Core Switching Platform, Series 8800” refers to all models of within the series, unless otherwise specified. -
Page 8: Chapter 2 Configuration Table
Manual 07504513 Model 4513 Chapter 2 Configuration Table Module PL90900110 Assy90900110 Assembly/Schematics PL85002750 Assy85002750 SCH85002750 Page 8 peration Manual... -
Page 9: Chapter 3 Functional Description
Model 4513 Chapter 3 Functional Description 3.1 Introduction This manual provides the necessary information for the Model 4513 card assembly. 3.2 General Description This card assembly contains an 8x8 single wire matrix. Connected to the eight input channels of the matrix are eight 4-pole star switches. -
Page 10: Chapter 4 Block Diagram
Manual 07504513 Model 4513 Chapter 4 Block Diagram Analog Groundplane Star Switch 1 of 8 Star Switch 8 of 8 To Front To Analog Panel Backplanes 1 - 8 Page 10 peration Manual... -
Page 11: Chapter 5 Specifications
Manual 07504513 Model 4513 Chapter 5 Specifications Electrical: Switching Voltage (DC/Peak, AC, Resistive): 200 V Switching Current (DC/Peak, AC, Resistive): 0.5 Amps Carry Current (DC/Peak, AC, Resistive): 1.5 Amps Max Switching Power: 10 W Bandwidth 50 MHz Life Expectancy: 1B cycles... -
Page 12: Chapter 6 Register Map
Manual 07504513 Model 4513 Chapter 6 Register Map 6.1 Introduction The Introduction is a VXI register based card assembly designed to be installed within the ASCOR Series 4000 Multi-Slot VXI Module. The Relay Registers on this card assembly are controlled by a high-speed VXIMAX™... - Page 13 Manual 07504513 Model 4513 Register Map A16 Register Offset Value 7Fb5h 7= Register Based, A16/A24 Module FB5=VXI Manufacturer ID, ASCOR 7xxxh 7=A24 space requirement xxx= Model Number for this module (see host module) FFFCh (assigned by Resource Manager) Control Low true output to enable coil driver IC’s...
- Page 14 Manual 07504513 Model 4513 Introduction Memory Map Mode Offset Reg# Bit Numbers 16-bit 8000h 1 32-bit 8000h 1 Relays Controlled K16 K15 K14 K13 K12 K11 K10 K9 16-bit 8002h 2 32-bit 8000h Error ! No text speci fied style...
- Page 15 Manual 07504513 Model 4513 Mode Offset Reg# Bit Numbers 32-bit 8008h Error ! No text speci fied style docu ment Relays Controlled K96 K95 K94 K93 K92 K91 K90 K89 K88 K87 K86 K85 K84 K83 K82 16-bit 800Ch 7...
- Page 16 Manual 07504513 Model 4513 Introduction Relays Page 16 peration Manual...
- Page 17 Manual 07504513 Model 4513 Mode: 16-bit 32-bit Description: Offset: 8004h 8004h Relay # Connection Function Mode: 16-bit 32-bit Description: Offset: 8006h 8004h Relay # Connection Function Page 17 peration Manual...
- Page 18 Manual 07504513 Model 4513 Mode: 16-bit 32-bit Description: Offset: 8008h 8008h Relay # Connection Function Mode: 16-bit 32-bit Description: Offset: 800Ah 8008h Relay # Connection Function Page 18 peration Manual...
- Page 19 Manual 07504513 Model 4513 Mode: 16-bit 32-bit Description: Offset: 800Ch 800Ch Relay # Connection (Signal, Shield) Function Page 19 peration Manual...
-
Page 20: Chapter 7 Front Panel Connectors
Manual 07504513 Model 4513 Chapter 7 Front Panel Connectors DESCRIPTION DESCRIPTION AGND = ANALOG GROUND DESCRIPTION Page 20 peration Manual...
